ENVIRONMENTAL GEOMECHANICS CE-641 Lecture No. 9 Prof. D N Singh Department of Civil Engineering 04.9.2019 Lecture No. 9 Lecture Name: Waste: A Man-made Resource Sub-topics Waste generation

slide-1
SLIDE 1

ENVIRONMENTAL GEOMECHANICS

CE-641 Lecture No. 9

  • Prof. D N Singh

Department of Civil Engineering

slide-2
SLIDE 2

Sub-topics

  • Waste generation
  • Forms
  • Hazardous wastes
  • Non-hazardous wastes
  • Examples and Differences
  • Need for Characterization

(important for its utilization, reuse, recycling and recovery of precious materials)

04.9.2019 Lecture No. 9 Lecture Name: Waste: A Man-made Resource

slide-3
SLIDE 3

Waste Generation

  • Depends on the source of generation
  • May degrade into harmless products
  • May be: non-degradable & hazardous (and may have

cumulative detrimental effects)

  • Solid
  • Liquid
  • Sludges
  • Gases
  • Combination of all these forms
slide-4
SLIDE 4

Definitions

“wastes other than radioactive wastes, which by

reason of their chemical reactivity or toxic, explosive, corrosive or other characteristics causing danger or likely to cause danger to health or the environment, whether alone or coming into contact with other wastes, are legally defined hazardous in the state in which they are generated or in which they are disposed of or through which they are transported”.

Several definitions and Interpretations United Nations Environment Programme (UNEP)

slide-5
SLIDE 5

Materials which are:

  • inherently dangerous to the human body or to animals,

including, but not limited to, materials that are toxic/poisonous

  • Irritants
  • strong sensitizers
  • Flammable
  • explosive (i.e., generate power through decomposition, heat or
  • ther means)
  • infectious (i.e., represent a potential source for transmission of

disease to humans, domestic animals or wildlife)

  • radioactive (i.e., containing sufficient radioactivity)
  • pesticides
slide-6
SLIDE 6

waste is any substance for which the owner/generator has no further use and which is discarded. Hazardous wastes are those wastes which due to their nature and quantity are potentially hazardous to human health and/or the environment, and require special disposal techniques to eliminate or reduce the hazard.

  • ne that may cause or significantly contribute to serious illness
  • r death or that poses a substantial threat to human health or

the environment when improperly managed wastes from commercial or trade companies, which, due to their nature, composition or quantities, are especially hazardous to human health, air or water, or are explosive, flammable or may cause diseases”.

slide-7
SLIDE 7

Types of the WASTE

NON-HAZARDOUS WASTE HAZARDOUS WASTE

slide-8
SLIDE 8

Types of the WASTE

Municipal Industrial Non-hazardous Industrial NON-HAZARDOUS WASTE HAZARDOUS WASTE Resource Conservation & Recovery Act (RCRA)

slide-9
SLIDE 9

Municipal Waste

Compost Scrap tires Used oil Sewage sludge Water treatment sludge

slide-10
SLIDE 10

Industrial Non-Hazardous Waste

Coal ash (fly ash /Bottom ash) Ferrous & non-ferrous slags Reclaimed paving materials Construction & Demolition debris Cement & lime kiln dusts Sulphates Foundary, Cermaic, Silica fumes Dredged material (too much volume, disposal problems) Minerals waste rocks mill tailings coal refuse washery rejects phosphogypsum Agricultural Animal manure Crop wood Organic & Liquid wastes Solid waste combustion residues Reclaimed plastic Waste glass

slide-11
SLIDE 11

Disposal of Industrial Non-Hazardous Waste

Land disposal Ocean disposal Incineration (reduces the wt. of the waste, ash production) Sewer disposal Septic tanks Lagoons/surface impoundments Construction applications Resource recovery

slide-12
SLIDE 12

HAZARDOUS WASTE (source USEPA)

Major source is Industrial activity Poses significant threat to the environment/health In combination with other materials or alone Four types (EPA, 1980) Type 1 Aqueous-Inorganic Type 2 Aqueous-Organic Type 3 Organic Type 4 Hazardous sludges, slurries & solids www.epa.gov ( U.S. Environmental Protection Agency)

slide-13
SLIDE 13

HAZARDOUS WASTE

Major source is Industrial activity Poses significant threat to the environment/health In combination with other materials or alone Hazard associated with the waste is not only due to its presence but also due to its concentration Hazardous material in a very dilute form may be harmless, even though in its concentrated form it may be very toxic. As such, detection of a “Hazardous material” in the ground does not necessarily indicate a significant problem

slide-14
SLIDE 14

Sources of Hazardous Waste Nuclear Power Plants Municipal Solid Waste (MSW) Landfills Chemical and Primary Metal Industries Paint and Dye Manufacturing Industries Mining Industries Paper and Pulp Industries Battery, Fuel cell industry Leather industry Electroplating Textile industries Hospitals and pharmaceutical companies

slide-15
SLIDE 15

Examples

Heavy Metal Non-biodegradable Synthetic Organics (Chlorinated Hydrocarbons) Lead Dioxin (A chemical which causes cancer,

especially breast cancer, the combination of fat, high heat, and plastics releases dioxin)

Mercury DDT Arsenic Kepone Cadmium Mirex Tin PCB's Zinc Carbon Tetrachloride Chromium Benzene Copper Chloroform Beryllium Strontium Polyvinyl Chlorides

slide-16
SLIDE 16

Coal Washery Residues NTPC @ Korba

slide-17
SLIDE 17

Coal Washery Residues NTPC @ Korba

slide-18
SLIDE 18

Coal Washery Residues NTPC @ Korba

slide-19
SLIDE 19

Coal Washery Residues NTPC @ Korba

slide-20
SLIDE 20

Coal Washery Residues NTPC @ Korba

slide-21
SLIDE 21

Coal Washery Residues NTPC @ Korba

slide-22
SLIDE 22

Coal Washery Residues NTPC @ Korba

slide-23
SLIDE 23

Coal Washery Residues NTPC @ Korba

slide-24
SLIDE 24

Coal Washery Residues NTPC @ Korba

slide-25
SLIDE 25

Coal Washery Residues NTPC @ Korba

slide-26
SLIDE 26

Coal Washery Residues NTPC @ Korba

slide-27
SLIDE 27

Coal Washery Residues NTPC @ Korba

slide-28
SLIDE 28

Coal Washery Residues NTPC @ Korba

slide-29
SLIDE 29

Coal Washery Residues NTPC @ Korba

slide-30
SLIDE 30

Coal Washery Residues NTPC @ Korba

slide-31
SLIDE 31

Coal Washery Residues NTPC @ Korba

slide-32
SLIDE 32

Coal Washery Residues NTPC @ Korba

slide-33
SLIDE 33

Coal Washery Residues NTPC @ Korba

slide-34
SLIDE 34

Coal Washery Residues NTPC @ Korba

slide-35
SLIDE 35

Coal Washery Residues NTPC @ Korba

slide-36
SLIDE 36

Coal Washery Residues NTPC @ Korba

slide-37
SLIDE 37

Coal Washery Residues NTPC @ Korba

slide-38
SLIDE 38

Coal Washery Residues NTPC @ Korba

slide-39
SLIDE 39

Coal Washery Residues NTPC @ Korba

slide-40
SLIDE 40

Coal Washery Residues NTPC @ Korba

slide-41
SLIDE 41

Coal Washery Residues NTPC @ Korba

slide-42
SLIDE 42

Coal Washery Residues NTPC @ Korba

slide-43
SLIDE 43

Coal Washery Residues NTPC @ Korba

slide-44
SLIDE 44

Coal Washery Residues NTPC @ Korba

slide-45
SLIDE 45

Coal Washery Residues NTPC @ Korba

slide-46
SLIDE 46

Coal Washery Residues NTPC @ Korba

slide-47
SLIDE 47

Coal Washery Residues NTPC @ Korba

slide-48
SLIDE 48

Coal Washery Residues NTPC @ Korba

slide-49
SLIDE 49

Coal Washery Residues NTPC @ Korba

slide-50
SLIDE 50

Coal Washery Residues NTPC @ Korba

slide-51
SLIDE 51

Coal Washery Residues NTPC @ Korba

slide-52
SLIDE 52

IIT Bombay Environmental Geomechanics Lecture No. 5 D N Singh 52

slide-53
SLIDE 53

IIT Bombay Environmental Geomechanics Lecture No. 5 D N Singh 53

slide-54
SLIDE 54

IIT Bombay Environmental Geomechanics Lecture No. 5 D N Singh 54

slide-55
SLIDE 55

IIT Bombay Environmental Geomechanics Lecture No. 5 D N Singh 55

slide-56
SLIDE 56

IIT Bombay Environmental Geomechanics Lecture No. 5 D N Singh 56

slide-57
SLIDE 57

IIT Bombay Environmental Geomechanics Lecture No. 5 D N Singh 57

slide-58
SLIDE 58

IIT Bombay Environmental Geomechanics Lecture No. 5 D N Singh 58

slide-59
SLIDE 59

IIT Bombay Environmental Geomechanics Lecture No. 5 D N Singh 59

slide-60
SLIDE 60

IIT Bombay Environmental Geomechanics Lecture No. 5 D N Singh 60

slide-61
SLIDE 61

IIT Bombay Environmental Geomechanics Lecture No. 5 D N Singh 61

slide-62
SLIDE 62

IIT Bombay Environmental Geomechanics Lecture No. 5 D N Singh 62

slide-63
SLIDE 63

IIT Bombay Environmental Geomechanics Lecture No. 5 D N Singh 63

slide-64
SLIDE 64

IIT Bombay Environmental Geomechanics Lecture No. 5 D N Singh 64

slide-65
SLIDE 65

IIT Bombay Environmental Geomechanics Lecture No. 5 D N Singh 65

slide-66
SLIDE 66

IIT Bombay Environmental Geomechanics Lecture No. 5 D N Singh 66

slide-67
SLIDE 67

IIT Bombay Environmental Geomechanics Lecture No. 5 D N Singh 67

slide-68
SLIDE 68

IIT Bombay Environmental Geomechanics Lecture No. 5 D N Singh 68

slide-69
SLIDE 69

IIT Bombay Environmental Geomechanics Lecture No. 5 D N Singh 69

slide-70
SLIDE 70

IIT Bombay Environmental Geomechanics Lecture No. 5 D N Singh 70

slide-71
SLIDE 71

IIT Bombay Environmental Geomechanics Lecture No. 5 D N Singh 71

slide-72
SLIDE 72

14800 15000 15200 15400 15600 15800 16000 16200 16400 305 310 315 320 325 330 335 340

Ground level Fomation level

RL (m) Chainage (m)

14800 15000 15200 15400 15600 15800 16000 16200 16400 4 6 8 10 12 14 16

H (m) Chainage (m)

. Topography of the site.

Height of the filling required

Use of Coal washery residues for Construction of Railway Embankment and Sidings at BSES-Korba (6 to 10 million tons consumed )

slide-73
SLIDE 73

4 8 12 16 20 24 4 8 12 16 20 Stone pitching

G.L.

2.5:1 2:1

Native soil CR

C/L

Height (m) X (m)

slide-74
SLIDE 74

4 8 12 16 20 24 28 32 36 40 4 8 12 16 20 24 28 Stone pitching 2:1 3 m berm

G.L.

2.5:1 2:1

Native soil CR

C/L

Height (m) X (m)

slide-75
SLIDE 75

5 10 15 20 25 30 35 40 45 50 55 5 10 15 20 25 30 35 40

Native soil

Stone pitching 2:1 2:1 3 m berm 3 m berm

G.L.

2.5:1 2:1

CR

C/L

Height (m) X (m)
