Efficient Detection of Empty-Result Queries Gang Luo IBM Watson - - PowerPoint PPT Presentation

Damon Sotoudeh

Efficient Detection of Empty-Result Queries

Gang Luo IBM Watson Research Centre

Agenda

 Introduction  The detection method  Related work  Future work  Conclusion

Empty-Result Queries

 Queries that return nothing

 Do not provide much information  May take much time to produce  Frequently encountered:

○ CRM (at IBM): 18% ○ Biomedical domain: up to 40% ○ In interactive systems

Empty-Result Queries

 In interactive systems

 Users keep refining queries  Few parameters are changed  Much of query parts are common

○ In IBM CRM application, only 38% of queries

are distinct

Intuition

 Remember query parts that previously

led to empty result sets

 If a new query matches those parts, it

will generate empty results No query execution required

Detection Method

Numbers are set cardinalities

Detection Method

Identify lowest set with cardinality zero, and the sub-tree rooted at that point

Detection Method

 Easy to see that the set cardinalities

above this point are all zero

Detection Method

 If a new query has this query part, it is an

empty-result query

 Only if all the operators above it are empty-result

propagating

○ Selection ○ Projection ○ Join ○ And most of SQL operators

Simplifying query plans

 Abstractly

 Certain operators have no influence on the

emptiness of output

○ Projection ○ Hash ○ Sort, ...

 Any join operator is simply a join

○ Hash join ○ Sort-merge join ○ Nested-loops join

Simplifying query plans

Simplifying query plans

 Previous figure corresponds to the

following query:

Further simplification

 Convert selection conditions to DNF

 Disjunctive normal form  For example: =  Interval selection does not need to be

changed

Further simplification

 After rewriting selections in DNF, combine

the individual selection terms in each relation

Further simplification

 Great news:

 The output of the four simplified query parts is

also empty!

○ Proof by intuition!

 They are called atomic query parts

○ Cannot be further simplified

 But generating them is exponential

○ Poor performance for complex queries

Detection

 How to detect an empty-result query Q?

 Break Q into its atomic parts  Is there any atomic part in container that covers

Q?

○ If yes, then it is an empty-result query

Coverage

 A selection condition X covers selection

condition Y, if and only if when Y is true, then X is true.

 In other words, if X is false, then so is Y.

Coverage

 Notion of coverage expands the detection

possibilities

 But deciding coverage is exponential  Paper uses a restricted coverage detection  Trade off between efficiency and coverage detection

 If an empty result atomic query part covers an

atomic part of query Q, then Q definitely generates empty results

 But we may not necessarily find such match

Atomic query container

 Is fully stored in memory

 For fast access

 Is of fixed size M, but M can be fairly

large

 Trade off between efficiency and coverage  Once the container is full, maintain the most

frequently used atomic parts only

○ E.g. Least recently used (LRU) algorithm

Atomic query container

 To avoid scanning the whole container

 Index the container based on involved

relations

Experiments

 Based on two queries

 Q1: Find the information about certain parts that were

sold on certain days

 Q2: Find the information about certain parts that were

sold to certain customers on certain days

Experiments

 The overhead is trivial compared to query

execution overhead

0.001 0.01 0.1 1 10 100 1000 1 2 3 database size (GB) execution time or overhead (second) execute Q1 check Q1 execute Q2 check Q2

Experiments

 The overhead of our method increases with both query complexity

and the number of atomic query parts stored in C



When check fails, the overhead of our method is higher than that when check succeeds

Related Work

 Two general approaches

1.

Find what leads to empty results

○

Time consuming

○

A lot of possibilities

2.

Automatically generalize the query to obtain some answers

○

Domain specific

○

Restricted forms of queries  No best approach

Open issues

 How to include updates?  Extension beyond empty result propagating

• perators

 A method that takes into account

advantages of all current solutions

 Not restrictive  Efficient

Conclusion

 An efficient detection method of empty result

sets

 High detection rate once the container is

highly filled

 Low overhead compared to actual execution

• f query

 Small storage requirements  Perfect for interactions

 Existence of hotspots is reflected

Thanks for listening! Questions?
