Dynamic Programming for Linear Time Incremental Parsing

Kenji Sagae

Institute for Creative Technologies University of Southern California

Liang Huang

Information Sciences Institute University of Southern California

ACL 2010, Uppsala, Sweden, July 2010 (slightly expanded)

DP for Incremental Parsing (Huang and Sagae)

Ambiguities in Parsing

I feed cats nearby in the garden ...

• let’s focus on dependency structures for simplicity
• ambiguous attachments of nearby and in
• ambiguity explodes exponentially with sentence length
• must design efficient (polynomial) search algorithm
• typically using dynamic programming (DP); e.g. CKY

2

DP for Incremental Parsing (Huang and Sagae)

Ambiguities in Parsing

I feed cats nearby in the garden ...

• let’s focus on dependency structures for simplicity
• ambiguous attachments of nearby and in
• ambiguity explodes exponentially with sentence length
• must design efficient (polynomial) search algorithm
• typically using dynamic programming (DP); e.g. CKY

2

DP for Incremental Parsing (Huang and Sagae)

Ambiguities in Parsing

I feed cats nearby in the garden ...

• let’s focus on dependency structures for simplicity
• ambiguous attachments of nearby and in
• ambiguity explodes exponentially with sentence length
• must design efficient (polynomial) search algorithm
• typically using dynamic programming (DP); e.g. CKY

2

DP for Incremental Parsing (Huang and Sagae)

Ambiguities in Parsing

I feed cats nearby in the garden ...

• let’s focus on dependency structures for simplicity
• ambiguous attachments of nearby and in
• ambiguity explodes exponentially with sentence length
• must design efficient (polynomial) search algorithm
• typically using dynamic programming (DP); e.g. CKY

2

DP for Incremental Parsing (Huang and Sagae)

But full DP is too slow...

3

I feed cats nearby in the garden ...

• full DP (like CKY) is too slow (cubic-time)
• while human parsing is fast & incremental (linear-time)

DP for Incremental Parsing (Huang and Sagae)

But full DP is too slow...

3

I feed cats nearby in the garden ...

• full DP (like CKY) is too slow (cubic-time)
• while human parsing is fast & incremental (linear-time)
• how about incremental parsing then?
• yes, but only with greedy search (accuracy suffers)
• explores tiny fraction of trees (even w/ beam search)

DP for Incremental Parsing (Huang and Sagae)

But full DP is too slow...

3

I feed cats nearby in the garden ...

• full DP (like CKY) is too slow (cubic-time)
• while human parsing is fast & incremental (linear-time)
• how about incremental parsing then?
• yes, but only with greedy search (accuracy suffers)
• explores tiny fraction of trees (even w/ beam search)
• can we combine the merits of both approaches?
• a fast, incremental parser with dynamic programming?
• explores exponentially many trees in linear-time?

DP for Incremental Parsing (Huang and Sagae)

Linear-Time Incremental DP

4

greedy search principled search

incremental parsing

(e.g. shift-reduce)

(Nivre 04; Collins/Roark 04; ...)

this work:

fast shift-reduce parsing

with dynamic programming

full DP

(e.g. CKY)

(Eisner 96; Collins 99; ...)

fast (linear-time) slow (cubic-time)

☹

☺ ☺

☹

DP for Incremental Parsing (Huang and Sagae)

Preview of the Results

• very fast linear-time dynamic programming parser
• best reported dependency accuracy on PTB/CTB
• explores exponentially many trees (and outputs forest)

5

0.2 0.4 0.6 0.8 1 1.2 1.4 0 10 20 30 40 50 60 70 parsing time (secs) sentence length

DP for Incremental Parsing (Huang and Sagae)

Preview of the Results

• very fast linear-time dynamic programming parser
• best reported dependency accuracy on PTB/CTB
• explores exponentially many trees (and outputs forest)

5

C h a r n i a k B e r k e l e y MST this work

0.2 0.4 0.6 0.8 1 1.2 1.4 0 10 20 30 40 50 60 70 parsing time (secs) sentence length

DP for Incremental Parsing (Huang and Sagae)

Preview of the Results

• very fast linear-time dynamic programming parser
• best reported dependency accuracy on PTB/CTB
• explores exponentially many trees (and outputs forest)

5

C h a r n i a k B e r k e l e y MST this work

0.2 0.4 0.6 0.8 1 1.2 1.4 0 10 20 30 40 50 60 70 parsing time (secs) sentence length 100 102 104 106 108 1010 0 10 20 30 40 50 60 70 sentence length

DP: exponential

non-DP beam search

DP for Incremental Parsing (Huang and Sagae)

Outline

• Motivation
• Incremental (Shift-Reduce) Parsing
• Dynamic Programming for Incremental Parsing
• Experiments

6

DP for Incremental Parsing (Huang and Sagae)

I feed cats ... feed cats nearby ... cats nearby in ... cats nearby in ... nearby in the ... nearby in the ... in the garden ...

Shift-Reduce Parsing

7

action stack queue

I feed cats nearby in the garden.

DP for Incremental Parsing (Huang and Sagae)

I feed cats ... feed cats nearby ... cats nearby in ... cats nearby in ... nearby in the ... nearby in the ... in the garden ...

Shift-Reduce Parsing

8

action stack queue

I feed cats nearby in the garden.

I

• 1

shift

DP for Incremental Parsing (Huang and Sagae)

I feed cats ... feed cats nearby ... cats nearby in ... cats nearby in ... nearby in the ... nearby in the ... in the garden ...

Shift-Reduce Parsing

9

action stack queue

I feed cats nearby in the garden.

I feed I

• 1

shift 2 shift

DP for Incremental Parsing (Huang and Sagae)

I feed cats ... feed cats nearby ... cats nearby in ... cats nearby in ... nearby in the ... nearby in the ... in the garden ...

Shift-Reduce Parsing

10

action stack queue

I feed cats nearby in the garden.

I feed I feed

I

• 1

shift 2 shift 3 l-reduce

DP for Incremental Parsing (Huang and Sagae)

I feed cats ... feed cats nearby ... cats nearby in ... cats nearby in ... nearby in the ... nearby in the ... in the garden ...

Shift-Reduce Parsing

11

action stack queue

I feed cats nearby in the garden.

I feed I feed

I

feed cats

I

• 1

shift 2 shift 3 l-reduce 4 shift

DP for Incremental Parsing (Huang and Sagae)

Shift-Reduce Parsing

12

action stack queue

I feed cats nearby in the garden.

I feed cats ... feed cats nearby ... cats nearby in ... cats nearby in ... nearby in the ... nearby in the ... in the garden ...

I feed I feed

I

feed cats

I

feed

I

cats

• 1

shift 2 shift 3 l-reduce 4 shift 5a r-reduce

DP for Incremental Parsing (Huang and Sagae)

Shift-Reduce Parsing

13

action stack queue

I feed cats ... feed cats nearby ... cats nearby in ... cats nearby in ... nearby in the ... nearby in the ... in the garden ...

I feed cats nearby in the garden.

I feed I feed

I

feed cats

I

feed

I

cats

feed cats nearby

I

• 1

shift 2 shift 3 l-reduce 4 shift 5a r-reduce 5b shift

DP for Incremental Parsing (Huang and Sagae)

Shift-Reduce Parsing

14

action stack queue

shift-reduce conflict

I feed cats nearby in the garden.

I feed cats ... feed cats nearby ... cats nearby in ... cats nearby in ... nearby in the ... nearby in the ... in the garden ...

I feed I feed

I

feed cats

I

feed

I

cats

feed cats nearby

I

• 1

shift 2 shift 3 l-reduce 4 shift 5a r-reduce 5b shift

DP for Incremental Parsing (Huang and Sagae)

Choosing Parser Actions

• score each action using features f and weights w
• features are drawn from a local window
• abstraction (or signature) of a state -- this inspires DP!
• weights trained by structured perceptron (Collins 02)

15

... s2 s1 s0 q0 q1 ...

← stack queue → ← stack queue →

features: (s0.w, s0.rc, q0, ...) = (cats, nearby, in, ...)

... feed cats

I nearby

in the garden ...

DP for Incremental Parsing (Huang and Sagae)

Greedy Search

16

• each state => three new states (shift, l-reduce, r-reduce)
• search space should be exponential
• greedy search: always pick the best next state

DP for Incremental Parsing (Huang and Sagae)

Greedy Search

17

• each state => three new states (shift, l-reduce, r-reduce)
• search space should be exponential
• greedy search: always pick the best next state

DP for Incremental Parsing (Huang and Sagae)

Beam Search

18

• each state => three new states (shift, l-reduce, r-reduce)
• search space should be exponential
• beam search: always keep top-b states

DP for Incremental Parsing (Huang and Sagae)

Dynamic Programming

• each state => three new states (shift, l-reduce, r-reduce)
• key idea of DP: share common subproblems
• merge equivalent states => polynomial space

19

DP for Incremental Parsing (Huang and Sagae)

Dynamic Programming

• each state => three new states (shift, l-reduce, r-reduce)
• key idea of DP: share common subproblems
• merge equivalent states => polynomial space

20

“graph-structured stack” (Tomita, 1988)

DP for Incremental Parsing (Huang and Sagae)

Dynamic Programming

• each state => three new states (shift, l-reduce, r-reduce)
• key idea of DP: share common subproblems
• merge equivalent states => polynomial space

21

“graph-structured stack” (Tomita, 1988)

DP for Incremental Parsing (Huang and Sagae)

Dynamic Programming

• each state => three new states (shift, l-reduce, r-reduce)
• key idea of DP: share common subproblems
• merge equivalent states => polynomial space

21

“graph-structured stack” (Tomita, 1988)

each DP state corresponds to exponentially many non-DP states

DP for Incremental Parsing (Huang and Sagae)

Dynamic Programming

• each state => three new states (shift, l-reduce, r-reduce)
• key idea of DP: share common subproblems
• merge equivalent states => polynomial space

22

“graph-structured stack” (Tomita, 1988)

100 102 104 106 108 1010 0 10 20 30 40 50 60 70 sentence length

DP: exponential

non-DP beam search

each DP state corresponds to exponentially many non-DP states

DP for Incremental Parsing (Huang and Sagae)

Merging Equivalent States

• two states are equivalent if they agree on features
• because same features guarantee same cost
• shift-reduce conflict:
• feed cats nearby in the garden

I

• feed cats nearby in the garden

I

23

... s2 s1 s0 q0 q1 ...

← stack queue → ... cats

re feed

... feed I

sh sh

DP for Incremental Parsing (Huang and Sagae)

Merging Equivalent States

• two states are equivalent if they agree on features
• because same features guarantee same cost
• shift-reduce conflict:
• feed cats nearby in the garden

I

• feed cats nearby in the garden

I

23

... s2 s1 s0 q0 q1 ...

← stack queue → ... cats

re feed

... feed I

sh sh

assume features only look at root of s0

DP for Incremental Parsing (Huang and Sagae)

Merging Equivalent States

• two states are equivalent if they agree on features
• because same features guarantee same cost
• shift-reduce conflict:
• feed cats nearby in the garden

I

• feed cats nearby in the garden

I

23

... s2 s1 s0 q0 q1 ...

← stack queue → ... cats

re feed

... feed I

sh sh

assume features only look at root of s0 two states are equivalent if they agree on root of s0

DP for Incremental Parsing (Huang and Sagae)

Merging Equivalent States

• two states are equivalent if they agree on features
• because same features guarantee same cost
• shift-reduce conflict:
• feed cats nearby in the garden

I

• feed cats nearby in the garden

I

23

... s2 s1 s0 q0 q1 ...

← stack queue → ... cats

re feed

... feed I

sh sh

assume features only look at root of s0 two states are equivalent if they agree on root of s0

DP for Incremental Parsing (Huang and Sagae)

Merging Equivalent States

• two states are equivalent if they agree on features
• because same features guarantee same cost
• shift-reduce conflict:
• feed cats nearby in the garden

I

• feed cats nearby in the garden

I cats

24

... s2 s1 s0 q0 q1 ...

← stack queue →

sh re

... cats ... nearby ... feed ...

DP for Incremental Parsing (Huang and Sagae)

Merging Equivalent States

• two states are equivalent if they agree on features
• because same features guarantee same cost
• shift-reduce conflict:
• feed cats nearby in the garden

I

• feed cats nearby in the garden

I cats

24

... s2 s1 s0 q0 q1 ...

← stack queue →

sh re

... cats ... nearby ... feed ...

DP for Incremental Parsing (Huang and Sagae)

Merging Equivalent States

• two states are equivalent if they agree on features
• because same features guarantee same cost
• shift-reduce conflict:
• feed cats nearby in the garden

I nearby

• feed cats nearby in the garden

I cats

25

... s2 s1 s0 q0 q1 ...

← stack queue →

sh re

... cats ... nearby ... feed

re ... cats sh ... nearby

...

DP for Incremental Parsing (Huang and Sagae)

Merging Equivalent States

• two states are equivalent if they agree on features
• because same features guarantee same cost
• shift-reduce conflict:
• feed in the garden

I cats nearby

• feed in the garden

I cats nearby

26

... s2 s1 s0 q0 q1 ...

← stack queue →

sh re

... cats ... nearby ... feed

re ... cats

... feed

re

... feed

re sh ... nearby

...

DP for Incremental Parsing (Huang and Sagae)

Merging Equivalent States

• two states are equivalent if they agree on features
• because same features guarantee same cost
• shift-reduce conflict:
• feed in the garden

I cats nearby

• feed in the garden

I cats nearby

26

... s2 s1 s0 q0 q1 ...

← stack queue →

sh re

... cats ... nearby ... feed

re ... cats

... feed

re

... feed

re sh ... nearby

...

DP for Incremental Parsing (Huang and Sagae)

Merging Equivalent States

• two states are equivalent if they agree on features
• because same features guarantee same cost
• shift-reduce conflict:
• feed in the garden

I cats nearby

• feed in the garden

I cats nearby

27

... s2 s1 s0 q0 q1 ...

← stack queue →

sh re

... cats ... nearby ... feed

re ... cats re

... feed

re sh ... nearby

...

DP for Incremental Parsing (Huang and Sagae)

Merging Equivalent States

• two states are equivalent if they agree on features
• because same features guarantee same cost
• shift-reduce conflict:
• feed in the garden

I cats nearby

• feed in the garden

I cats nearby

27

... s2 s1 s0 q0 q1 ...

← stack queue →

sh re

... cats ... nearby ... feed

re ... cats re

... feed

re sh ... nearby

...

(local) ambiguity-packing!

DP for Incremental Parsing (Huang and Sagae)

Merging Equivalent States

• two states are equivalent if they agree on features
• because same features guarantee same cost
• shift-reduce conflict:
• feed in the garden

I cats nearby

• feed in the garden

I cats nearby

28

... s2 s1 s0 q0 q1 ...

← stack queue →

sh re

... cats ... nearby ... feed

re ... cats re

... feed

re sh ... nearby

... in

sh

...

DP for Incremental Parsing (Huang and Sagae)

Merging Equivalent States

• two states are equivalent if they agree on features
• because same features guarantee same cost
• shift-reduce conflict:
• feed in the garden

I cats nearby

• feed in the garden

I cats nearby

28

... s2 s1 s0 q0 q1 ...

← stack queue →

sh re

... cats ... nearby ... feed

re ... cats re

... feed

re sh ... nearby

... in

sh

...

graph-structured stack

DP for Incremental Parsing (Huang and Sagae)

Theory: Polynomial-Time DP

• this DP is exact and polynomial-time if features are:
• a) bounded -- for polynomial time
• features can only look at a local window
• b) monotonic -- for correctness (optimal substructure)
• features should draw no more info from trees farther

away from stack top than from trees closer to top

• both are intuitive: a) always true; b) almost always true

29

... s2 s1 s0 q0 q1 ...

← stack queue →

DP for Incremental Parsing (Huang and Sagae)

Theory: Monotonic History

• related: grammar refinement by annotation (Johnson, 1998)
• annotate vertical context history (e.g., parent)
• monotonicity: can’t annotate grand-parent without

annotating the parent (otherwise DP would fail)

• our features: left-context history instead of vertical-context
• similarly, can’t annotate s2 without annotating s1
• but we can always design “minimum monotonic superset”

30

parent grand-parent s1 s2 s0

stack

DP for Incremental Parsing (Huang and Sagae)

Related Work

• Graph-Structured Stack (Tomita 88): Generalized LR
• GSS is just a chart viewed from left to right (e.g. Earley 70)
• this line of work started w/ Lang (1974); stuck since 1990
• b/c explicit LR table is impossible with modern grammars
• general idea: compile CFG parse chart to FSAs (e.g. our beam)

31

DP for Incremental Parsing (Huang and Sagae)

Related Work

• Graph-Structured Stack (Tomita 88): Generalized LR
• GSS is just a chart viewed from left to right (e.g. Earley 70)
• this line of work started w/ Lang (1974); stuck since 1990
• b/c explicit LR table is impossible with modern grammars
• general idea: compile CFG parse chart to FSAs (e.g. our beam)
• We revived and advanced this line of work in two aspects
• theoretical: implicit LR table based on features
• merge and split on-the-fly; no pre-compilation needed
• monotonic feature functions guarantee correctness (new)
• practical: achieved linear-time performance with pruning

31

Experiments

DP for Incremental Parsing (Huang and Sagae)

Speed Comparison

33

• 5 times faster with the same parsing accuracy

time (hours)

n

• n
• D

P DP

DP for Incremental Parsing (Huang and Sagae)

Correlation of Search and Parsing

34

92.2 92.3 92.4 92.5 92.6 92.7 92.8 92.9 93 93.1 2365 2370 2375 2380 2385 2390 2395 dependency accuracy average model score DP non-DP

• better search quality <=> better parsing accuracy

DP for Incremental Parsing (Huang and Sagae)

Search Space: Exponential

35

100 102 104 106 108 1010 0 10 20 30 40 50 60 70 sentence length

DP: exponential

non-DP: fixed (beam-width)

number of trees explored

DP for Incremental Parsing (Huang and Sagae)

N-Best / Forest Oracles

36

DP forest oracle (98.15) DP k-best in forest n

• n
• D

P k

• b

e s t i n b e a m

DP for Incremental Parsing (Huang and Sagae)

Better Search => Better Learning

37

• DP leads to faster and better learning w/ perceptron

DP for Incremental Parsing (Huang and Sagae)

Learning Details: Early Updates

• greedy search: update at first error (Collins/Roark 04)
• beam search: update when gold is pruned (Zhang/Clark 08)
• DP search: also update when gold is “merged” (new!)
• b/c we know gold can’t make to the top again

38

DP for Incremental Parsing (Huang and Sagae)

Parsing Time vs. Sentence Length

39

• parsing speed (scatter plot) compared to other parsers

0.2 0.4 0.6 0.8 1 1.2 1.4 0 10 20 30 40 50 60 70 parsing time (secs) sentence length

DP for Incremental Parsing (Huang and Sagae)

Parsing Time vs. Sentence Length

39

• parsing speed (scatter plot) compared to other parsers

C h a r n i a k B e r k e l e y MST t h i s w

• r

k

0.2 0.4 0.6 0.8 1 1.2 1.4 0 10 20 30 40 50 60 70 parsing time (secs) sentence length

DP for Incremental Parsing (Huang and Sagae)

Parsing Time vs. Sentence Length

39

• parsing speed (scatter plot) compared to other parsers

C h a r n i a k B e r k e l e y MST t h i s w

• r

k

0.2 0.4 0.6 0.8 1 1.2 1.4 0 10 20 30 40 50 60 70 parsing time (secs) sentence length

O(n2) O(n) O(n2.4) O(n2.5)

DP for Incremental Parsing (Huang and Sagae)

Final Results

• much faster than major parsers (even with Python!)
• first linear-time incremental dynamic programming parser
• best reported dependency accuracy on Penn Treebank

time

complexity trees searched

0.12

O(n2)

exponential

• O(n4)

exponential 0.11

O(n)

constant 0.04

O(n)

exponential 0.49

O(n2.5)

exponential 0.21

O(n2.4)

exponential

McDonald et al 05 - MST Koo et al 08 baseline* Zhang & Clark 08 single this work Charniak 00 Petrov & Klein 07 89 91 93 92.4 92.5 92.1 91.4 92.0 90.2

DP for Incremental Parsing (Huang and Sagae)

Final Results

• much faster than major parsers (even with Python!)
• first linear-time incremental dynamic programming parser
• best reported dependency accuracy on Penn Treebank

time

complexity trees searched

0.12

O(n2)

exponential

• O(n4)

exponential 0.11

O(n)

constant 0.04

O(n)

exponential 0.49

O(n2.5)

exponential 0.21

O(n2.4)

exponential

McDonald et al 05 - MST Koo et al 08 baseline* Zhang & Clark 08 single this work Charniak 00 Petrov & Klein 07 89 91 93 92.4 92.5 92.1 91.4 92.0 90.2

DP for Incremental Parsing (Huang and Sagae)

Final Results

• much faster than major parsers (even with Python!)
• first linear-time incremental dynamic programming parser
• best reported dependency accuracy on Penn Treebank

time

complexity trees searched

0.12

O(n2)

exponential

• O(n4)

exponential 0.11

O(n)

constant 0.04

O(n)

exponential 0.49

O(n2.5)

exponential 0.21

O(n2.4)

exponential

McDonald et al 05 - MST Koo et al 08 baseline* Zhang & Clark 08 single this work Charniak 00 Petrov & Klein 07 89 91 93 92.4 92.5 92.1 91.4 92.0 90.2

*at this ACL: Koo & Collins 10: 93.0 with O(n4)

DP for Incremental Parsing (Huang and Sagae)

Final Results on Chinese

• also the best parsing accuracy on Chinese
• Penn Chinese Treebank (CTB 5)
• all numbers below use gold-standard POS tags

41

Duan et al. 2007 Zhang & Clark 08 (single) this work 70 85

78.3 76.7 73.7

85.5 84.7 84.4

85.2 84.3 83.9

word non-root root

DP for Incremental Parsing (Huang and Sagae)

Conclusion

42

greedy search principled search

incremental parsing

(e.g. shift-reduce)

☺✓

full dynamic programming

(e.g. CKY)

fast (linear-time) slow (cubic-time)

DP for Incremental Parsing (Huang and Sagae)

Conclusion

42

greedy search principled search

incremental parsing

(e.g. shift-reduce)

☺✓

full dynamic programming

(e.g. CKY)

fast (linear-time) slow (cubic-time)

linear-time

shift-reduce parsing

w/ dynamic programming

DP for Incremental Parsing (Huang and Sagae)

Thank You

• a general theory of DP for shift-reduce parsing
• as long as features are bounded and monotonic
• fast, accurate DP parser release coming soon:
• http://www.isi.edu/~lhuang
• http://www.ict.usc.edu/~sagae
• future work
• adapt to constituency parsing (straightforward)
• other grammar formalisms like CCG and TAG
• integrate POS tagging into the parser

43
