LANDMARKS PRESENTATION SET | FEBRUARY 21, 2017 DUMBO 5 0 W a s h i n g t o n S t r e e t , B r o o k l y n , N Y 1 1 2 0 1 50 WASHINGTON ST - AERIAL PLAN - SATELLITE 50 WASHINGTON ST - AERIAL PLAN ADDRESS: 50 WASHINGTON STREET BROOKLYN,

SLIDE 1

5 0 W a s h i n g t o n S t r e e t , B r o o k l y n , N Y 1 1 2 0 1

LANDMARKS PRESENTATION SET | FEBRUARY 21, 2017

DUMBO

SLIDE 2

LANDMARKS PRESENTATION SET | FEBRUARY 21, 2017

DUMBO

ADDRESS: 50 WASHINGTON STREET BROOKLYN, NY 11201 BLOCK: 37 LOT: 1 MAP #: 12D ZONING: M1-2/R8A BLDG NAME: GAIR NO. 6 STYLE: INDUSTRIAL NEO-CLASSICAL CONSTRUCTION: REINFORCED CONCRETE

L O C A T I O N A N D S I T E C O N T E X T

50 WASHINGTON ST - AERIAL PLAN - SATELLITE 50 WASHINGTON ST - AERIAL PLAN NE CORNER FROM WASHINGTON & WATER

NW CORNER FROM WATER & MAIN (NYC DEPARTMENT OF TAXES - 1939)

SLIDE 3

LANDMARKS PRESENTATION SET | FEBRUARY 21, 2017

DUMBO

E X I S T I N G S T O R E F R O N T - S C O P E O F W O R K EXISTING STOREFRONT - SCOPE OF WORK

1. REMOVE EXISTING SIGNAGE OVER ENTRY DOOR

PATCH AND REPAIR EXISTING STOREFRONT AS REQUIRED DURING REMOVAL

2. REMOVE EXISTING (2) BLADE SIGNS ON EXISTING BUILDING FACADE

PATCH AND REPAIR BUILDING FACADE AS REQUIRED DURING REMOVAL TO

MATCH EXISTING CONDITION

3. REMOVE EXISTING SIGNAGE OVER DELIVERY DOOR

PATCH AND REPAIR TRANSOME TO MATCH EXISTING ADJACENT BUILDING

FACADE AS REQUIRED.

1 2 3 2

SLIDE 4

LANDMARKS PRESENTATION SET | FEBRUARY 21, 2017

DUMBO

P R O P O S E D S T O R E F R O N T - S C O P E O F W O R K PROPOSED STOREFRONT - SCOPE OF WORK

1. NEW “FAUX” LOUVER PANEL

INSTALLED OVER EXISTING STOREFRONT.

FABRICATED TO MATCH ADJACENT EXISTING LOUVER PROFILE AND COLOR

2. NEW ALUMINUM SIGN BAND WITH HALO-LIT PIN LETTERS.

INSTALLED OVER EXISTING STOREFRONT SYSTEM.

FABRICATED TO MATCH EXISTING STOREFRONT FINISH AND COLOR.

3. NEW ILLUMINATED PROJECTING BLADE SIGN.

INSTALLED ON EXISTING BULDING FACADE.

PATCH AND REPAIR FACADE AS NECCESSARY TO MATCH EXISTING CONDITION

1 3 2

SLIDE 5

LANDMARKS PRESENTATION SET | FEBRUARY 21, 2017

DUMBO

D E T A I L S : S I G N B A N D + H A L O - L I T L E T T E R S

S I G N A G E D U R I N G D A Y A T N I G H T

SLIDE 6

LANDMARKS PRESENTATION SET | FEBRUARY 21, 2017

DUMBO

D E T A I L S : I L L U M I N A T E D B L A D E S I G N

S I G N A G E D U R I N G D A Y A T N I G H T

SLIDE 7

LANDMARKS PRESENTATION SET | FEBRUARY 21, 2017

DUMBO

S I M I L A R S I G N A G E A R O U N D D U M B O

1 1 7 F R O N T S T 4 5 W A T E R S T 5 5 W A T E R S T 5 0 W A S H I N G T O N S T 6 0 W A T E R S T N E O F M A I N S T & F R O N T S T

SLIDE 8

LANDMARKS PRESENTATION SET | FEBRUARY 21, 2017

DUMBO

S W E E T G R E E N S I G N A G E E X A M P L E S
