Discrete Sampling and Integration for the AI Practitioner Supratik - - PowerPoint PPT Presentation

Discrete Sampling and Integration for the AI Practitioner

Supratik Chakraborty, IIT Bombay Kuldeep S. Meel, Rice University Moshe Y. Vardi, Rice University

Agenda

Part 1: Boolean Satisfiability Solving (Vardi) Part 2(a): Applications (Chakraborty) Coffee Break Part 2(b): Prior Work (Chakraborty) Part 3: Hashing-based Approach (Meel)

Discrete Sampling and Integration for the AI Practitioner Part I: Boolean Satisfiability Solving

Supratik Chakraborty, IIT Bombay Kuldeep S. Meel, Rice University Moshe Y. Vardi, Rice University

Boolean Satisfiability

Boolean Satisfiability (SAT); Given a Boolean expression ϕ, using “and” (∧) “or”, (∨) and “not” (¬), is there a satisfying solution (an assignment

• f 0’s and 1’s to the variables that makes the expression equal 1)? That is,

is Sol(ϕ) nonempty? Example: (¬x1 ∨ x2 ∨ x3) ∧ (¬x2 ∨ ¬x3 ∨ x4) ∧ (x3 ∨ x1 ∨ x4) Solution: x1 = 0, x2 = 0, x3 = 1, x4 = 1

1

Discrete Sampling and Integration

Discrete Sampling: Given a Boolean formula ϕ, sample from Sol(ϕ) uniformly at random? Discrete Integration: Given a Boolean formula ϕ, compute |Sol(ϕ)|. Weighted Sampling and Integration: As above, but subject to a weight function w : Sol(ϕ) → R+

2

Basic Theoretical Background

Discrete Integration: #SAT Known:

• 1. #SAT is #P-complete.
• 2. In practice, #SAT is quite harder than SAT.
• 3. If you can solve #SAT, then you can sample uniformly using self-

reducibility. Desideratum: Solve discrete sampling and integration using a SAT solver.

3

Is This Time Different? The Opportunities and Challenges of Artificial Intelligence

Jason Furman, Chair, Council of Economic Advisers, July 2016: “Even though we have not made as much progress recently on other areas of AI, such as logical reasoning, the advancements in deep learning techniques may ultimately act as at least a partial substitute for these other areas.”

4

P vs. NP: An Outstanding Open Problem

Does P = NP?

• The major open problem in theoretical computer science
• A major open problem in mathematics

– A Clay Institute Millennium Problem – Million dollar prize! What is this about? It is about computational complexity – how hard it is to solve computational problems.

5

Rally To Restore Sanity, Washington, DC, October 2010

6

Computational Problems

Example: Graph – G = (V, E)

• V – set of nodes
• E – set of edges

Two notions:

• Hamiltonian Cycle: a cycle that visits every node exactly once.
• Eulerian Cycle: a cycle that visits every edge exactly once.

Question: How hard it is to find a Hamiltonian cycle? Eulerian cycle?

7

Figure 1: The Bridges of K¨

• nigsburg

8

Figure 2: The Graph of The Bridges of K¨

• nigsburg

9

Figure 3: Hamiltonian Cycle

10

Computational Complexity

Measuring complexity: How many (Turing machine) operations does it take to solve a problem of size n?

• Size of (V, E): number of nodes plus number of edges.

Complexity Class P: problems that can be solved in polynomial time – nc for a fixed c Examples:

• Is a number even?
• Is a number square?
• Does a graph have an Eulerian cycle?

What about the Hamiltonian Cycle Problem?

11

Hamiltonian Cycle

• Naive Algorithm: Exhaustive search – run time is n! operations
• “Smart” Algorithm: Dynamic programming – run time is 2n operations

Note: The universe is much younger than 2200 Planck time units! Fundamental Question: Can we do better?

• Is HamiltonianCycle in P?

12

Checking Is Easy!

Observation: Checking if a given cycle is a Hamiltonian cycle of a graph G = (V, E) is easy! Complexity Class NP: problems where solutions can be checked in polynomial time. Examples:

• HamiltonianCycle
• Factoring numbers

Significance: Tens of thousands of optimization problems are in NP!!!

• CAD, flight scheduling, chip layout, protein folding, . . .

13

P vs. NP

• P: efficient discovery of solutions
• NP: efficient checking of solutions

The Big Question: Is P = NP or P = NP?

• Is checking really easier than discovering?

Intuitive Answer: Of course, checking is easier than discovering, so P = NP!!!

• Metaphor: finding a needle in a haystack
• Metaphor: Sudoku
• Metaphor: mathematical proofs

Alas: We do not know how to prove that P = NP.

14

P = NP

Consequences:

• Cannot solve efficiently numerous important problems
• RSA encryption may be safe.

Question: Why is it so important to prove P = NP, if that is what is commonly believed? Answer:

• If we cannot prove it, we do not really understand it.
• May be P = NP and the “enemy” proved it and broke RSA!

15

P = NP

• S. Aaronson, MIT: “If P = NP, then the world would be a profoundly

different place than we usually assume it to be. There would be no special value in ‘creative leaps,’ no fundamental gap between solving a problem and recognizing the solution once it’s found. Everyone who could appreciate a symphony would be Mozart; everyone who could follow a step-by-step argument would be Gauss.” Consequences:

• Can solve efficiently numerous important problems.
• RSA encryption is not safe.

Question: Is it really possible that P = NP? Answer: Yes! It’d require discovering a very clever algorithm, but it took 40 years to prove that LinearProgramming is in P.

16

Sharpening The Problem

NP-Complete Problems: hardest problems is NP

• HamilatonianCycle is NP-complete! [Karp, 1972]

Corollary: P = NP if and only if HamiltonianCycle is in P There are thousands of NP-complete problems. To resolve the P = NP question, it’d suffice to prove that one of them is or is not in P.

17

History

• 1950-60s: Perebor Project – Futile effort to show hardness of search

problems.

• Stephen Cook, 1971: Boolean Satisfiability is NP-complete.
• Richard Karp, 1972: 20 additional NP-complete problems– 0-1 Integer

Programming, Clique, Set Packing, Vertex Cover, Set Covering, Hamiltonian Cycle, Graph Coloring, Exact Cover, Hitting Set, Steiner Tree, Knapsack, Job Scheduling, ... – All NP-complete problems are polynomially equivalent!

• Leonid Levin, 1973 (independently): Six NP-complete problems
• M. Garey and D. Johnson, 1979: “Computers and Intractability: A Guide

to NP-Completeness” - hundreds of NP-complete problems!

• Clay Institute, 2000: $1M Award!

18

Boole’s Symbolic Logic

Boole’s insight: Aristotle’s syllogisms are about classes of objects, which can be treated algebraically. “If an adjective, as ‘good’, is employed as a term of description, let us represent by a letter, as y, all things to which the description ‘good’ is applicable, i.e., ‘all good things’, or the class of ‘good things’. Let it further be agreed that by the combination xy shall be represented that class of things to which the name or description represented by x and y are simultaneously applicable. Thus, if x alone stands for ‘white’ things and y for ‘sheep’, let xy stand for ‘white sheep’.

19

Boolean Satisfiability

Boolean Satisfiability (SAT); Given a Boolean expression, using “and” (∧) “or”, (∨) and “not” (¬), is there a satisfying solution (an assignment

• f 0’s and 1’s to the variables that makes the expression equal 1)?

Example: (¬x1 ∨ x2 ∨ x3) ∧ (¬x2 ∨ ¬x3 ∨ x4) ∧ (x3 ∨ x1 ∨ x4) Solution: x1 = 0, x2 = 0, x3 = 1, x4 = 1

20

Complexity of Boolean Reasoning

History:

• William Stanley Jevons, 1835-1882: “I have given much attention,

therefore, to lessening both the manual and mental labour of the process, and I shall describe several devices which may be adopted for saving trouble and risk of mistake.”

• Ernst Schr¨
• der, 1841-1902: “Getting a handle on the consequences
• f any premises, or at least the fastest method for obtaining these

consequences, seems to me to be one of the noblest, if not the ultimate goal of mathematics and logic.”

• Cook, 1971, Levin, 1973: Boolean Satisfiability is NP-complete.

21

Algorithmic Boolean Reasoning: Early History

• Newell, Shaw, and Simon, 1955: “Logic Theorist”
• Davis

and Putnam, 1958: “Computational Methods in The Propositional calculus”, unpublished report to the NSA

• Davis and Putnam, JACM 1960:

“A Computing procedure for quantification theory”

• Davis, Logemman, and Loveland, CACM 1962: “A machine program

for theorem proving” DPLL Method: Propositional Satisfiability Test

• Convert formula to conjunctive normal form (CNF)
• Backtracking search for satisfying truth assignment
• Unit-clause preference

22

Modern SAT Solving

CDCL = conflict-driven clause learning

• Backjumping
• Smart unit-clause preference
• Conflict-driven clause learning
• Smart choice heuristic (brainiac vs speed demon)
• Restarts

Key Tools: GRASP, 1996; Chaff, 2001 Current capacity: millions of variables

23

• S. A. Seshia

1

Some Experience with SAT Solving

Sanjit A. Seshia

Speed-up of 2012 solver over other solvers

1 10 100 1,000

Solver Speed-up (log scale)

Figure 4: SAT Solvers Performance

24

Knuth Gets His Satisfaction

SIAM News, July 26, 2016: “Knuth Gives Satisfaction in SIAM von Neumann Lecture” Donald Knuth gave the 2016 John von Neumann lecture at the SIAM Annual Meeting. The von Neumann lecture is SIAM’s most prestigious prize. Knuth based the lecture, titled ”Satisfiability and Combinatorics”, on the latest part (Volume 4, Fascicle 6) of his The Art of Computer Programming book series. He showed us the first page of the fascicle, aptly illustrated with the quote ”I can’t get no satisfaction,” from the Rolling Stones. In the preface of the fascicle Knuth says ”The story of satisfiability is the tale of a triumph of software engineering, blended with rich doses of beautiful mathematics”.

25

SAT Heuristic – Backjumping

Backtracking: go up one level in the search tree when both Boolean values for a variable have been tested. Backjumping [Stallman-Sussman, 1977]: jump back in the search tree, if jump is safe – use highest node to jump to. Key: Distinguish between

• Decision variable: Variable is that chosen and then assigned first c and

then 1 − c.

• Implication variable: Assignment to variable is forced by a unit clause.

Implication Graph: directed acyclic graph describing the relationships between decision variables and implication variables.

26

Smart Unit-Clause Preference

Boolean Constraint Propagation (BCP): propagating values forced by unit clauses.

• Empirical Observation: BCP can consume up to 80% of SAT solving

time! Requirement: identifying unit clauses

• Naive Method: associate a counter with each clause and update counter

appropriately, upon assigning and unassigning variables.

• Two-Literal Watching [Moskewicz-Madigan-Zhao-Zhang-Malik, 2001]:

“watch” two un-false literals in each unsatisfied clause – no overhead for backjumping.

27

SAT Heuristic – Clause Learning

Conflict-Driven Clause Learning: If assignment l1, . . . , ln is bad, then add clause ¬l1 ∨ . . . ∨ ¬ln to block it. Marques-Silva&Sakallah, 1996: This would add very long clauses! Instead:

• Analyze implication graph for chain of reasoning that led to bad

assignment.

• Add a short clause to block said chain.
• The “learned” clause is a resolvent of prior clauses.

Consequence:

• Combine search with inference (resolution).
• Algorithm uses exponential space; “forgetting” heuristics required.

28

Smart Decision Heuristic

Crucial: Choosing decision variables wisely! Dilemma: brainiac vs. speed demon

• Brainiac: chooses very wisely, to maximize BCP – decision-time overhead!
• Speed Demon: chooses very fast, to minimize decision time – many

decisions required! VSIDS [Moskewicz-Madigan-Zhao-Zhang-Malik, 2001]: Variable State Independent Decaying Sum – prioritize variables according to recent participation on conflicts – compromise between Brainiac and Speed Demon.

29

Randomized Restarts

Randomize Restart [Gomes-Selman-Kautz, 1998]

• Stop search
• Reset all variables
• Restart search
• Keep learned clauses

Aggressive Restarting: restart every ∼50 backtracks.

30

SMT: Satisfiability Modulo Theory

SMT Solving: Solve Boolean combinations of constraints in an underlying theory, e.g., linear constraints, combining SAT techniques and domain- specific techniques.

• Tremendous progress since 2000!

Example: SMTLA (x > 10) ∧ [((x > 5) ∨ (x < 8)] Sample Application: Bounded Model Checking of Verilog programs – SMT(BV).

31

SMT Solving

General Approach: combine SAT-solving techniques with theory-solving techniques

• Consider formula as Boolean formula ove theory atoms.
• Solve Boolean formula; obtain conjunction of theory atoms.
• Use theory solver to check if conjunction is satisfiable.

Crux: Interaction between SAT solver and theory solver, e.g., conflict-clause learning – convert unsatisfiable theory-atom conjection to a new Boolean clause.

32

Applications of SAT/SMT Solving in SW Engineering

Leonardo De Moura+Nikolaj Bj¨

• rner, 2012: Applications of Z3 at Microsoft
• Symbolic execution
• Model checking
• Static analysis
• Model-based design
• . . .

33

Reflection on P vs. NP

Old Clich´ e “What is the difference between theory and practice? In theory, they are not that different, but in practice, they are quite different.” P vs. NP in practice:

• P=NP: Conceivably, NP-complete problems can be solved in polynomial

time, but the polynomial is n1,000 – impractical!

• P=NP: Conceivably, NP-complete problems can be solved by nlog log log n
• perations – practical!

Conclusion: No guarantee that solving P vs. NP would yield practical benefits.

34

Are NP-Complete Problems Really Hard?

• When I was a graduate student, SAT was a “scary” problem, not to be

touched with a 10-foot pole.

• Indeed, there are SAT instances with a few hundred variables that cannot

be solved by any extant SAT solver.

• But today’s SAT solvers, which enjoy wide industrial usage, routinely

solve real-life SAT instances with millions of variables! Conclusion We need a richer and broader complexity theory, a theory that would explain both the difficulty and the easiness of problems like SAT. Question: Now that SAT is “easy” in practice, how can we leverage that?

• Is BPP NP the “new” PTIME?

35

Notation

• Given

– X1 , … Xn : variables with finite discrete domains D1, … Dn – Constraint (logical formula) ϕ over X1 , … Xn – Weight function W: D1 × … Dn → Q≥ 0

Sol(ϕ) : set of assignments of X1 , … Xn satisfying ϕ

– Determine W(ϕ) = ∑ y ∈ Sol(ϕ) W(y) If W(y) = 1 for all y, then W(ϕ) = | Sol(ϕ) | – Randomly sample from Sol(ϕ) such that Pr[y is sampled] ∝ W(y) If W(y) = 1 for all y, then uniformly sample from Sol(ϕ) For this tutorial: Initially, Di’s are {0,1} – Boolean variables Later, we’ll consider Di’s as {0, 1}n – Bit-vector variables

1

Discrete Integration (Model Counting) Discrete Sampling

Closer Look At Some Applications

• Discrete Integration

– Probabilistic Inference – Network (viz. electrical grid) reliability – Quantitative Information flow – And many more …

• Discrete Sampling

– Constrained random verification – Automatic problem generation – And many more …

2

Application 1: Probabilistic Inference

– An alarm rings if it’s in a working state when an earthquake happens

• r a burglary happens

– The alarm can malfunction and ring without earthquake or burglary happening – Given that the alarm rang, what is the likelihood that an earthquake happened? – Given conditional dependencies (and conditional probabilities) calculate Pr[event | evidence] – What is Pr [Earthquake | Alarm] ?

3

Probabilistic Inference: Bayes’ Rule

4

How do we represent conditional dependencies efficiently, and calculate these probabilities?

] Pr[ ] | Pr[ ] Pr[ ] Pr[ ] Pr[ ] Pr[ ] Pr[ ] | Pr[

j j j j j i i i

event event evidence evidence event evidence event evidence event evidence evidence event evidence event × = ∩ ∩ ∩ = ∩ =

∑

Probablistic Inference: Graphical Models

5

B E A

B E A Pr(A|E,B)

Conditional Probability Tables (CPT)

6

B E A

Pr 𝐹 ∩ 𝐵 = Pr 𝐹 ∗ Pr ¬𝐶 ∗ Pr 𝐵 𝐹, ¬𝐶 + Pr 𝐹 ∗ Pr 𝐶 ∗ Pr 𝐵 𝐹, 𝐶]

Probabilistic Inference: First Principle Calculation

B E A Pr(A|E,B)

Probabilisitc Inference: Logical Formulation

V = {vA, v~A, vB, v~B, vE, v~E} Prop vars corresponding to events T = {tA|B,E , t~A|B,E , tA|B,~E …} Prop vars corresponding to CPT entries Formula encoding probabilistic graphical model (ϕPGM): (vA ⊕ v~A) ∧ (vB ⊕ v~B) ∧ (vE ⊕ v~E) Exactly one of vA and v~A is true

∧

(tA|B,E ⇔ vA ∧ vB ∧ vE) ∧ (t~A|B,E ⇔ v~A ∧ vB ∧ vE) ∧ … If vA , vB , vE are true, so must tA|B,E and vice versa

7

Probabilistic Inference: Logic and Weights

V = {vA, v~A, vB, v~B, vE, v~E} T = {tA|B,E , t~A|B,E , tA|B,~E …} W(v~B) = 0.2, W(vB) = 0.8 Probabilities of indep events are weights of +ve literals W(v~E) = 0.1, W(vE) = 0.9 W(tA|B,E) = 0.3, W(t~A|B,E) = 0.7, … CPT entries are weights of +ve literals W(vA) = W(v~A) = 1 Weights of vars corresponding to dependent events W(¬v~B) = W(¬vB) = W(¬ tA|B,E) … = 1 Weights of -ve literals are all 1 Weight of assignment (vA = 1, v~A= 0, tA|B,E = 1, …) = W(vA) * W(¬v~A)* W( tA|B,E)* … Product of weights of literals in assignment

8

Probabilistic Inference: Discrete Integration

V = {vA, v~A, vB, v~B, vE, v~E} T = {tA|B,E , t~A|B,E , tA|B,~E …} Formula encoding combination of events in probabilistic model (Alarm and Earthquake) F = ϕPGM ∧ vA ∧ vE Set of satisfying assignments of F:

RF = { (vA= 1, vE = 1, vB = 1, tA|B,E = 1, all else 0), (vA = 1, vE = 1, v~B = 1, tA|~B,E = 1, all else 0) }

Weight of satisfying assignments of F:

W(RF) = W(vA) * W(vE) * W(vB) * W(tA|B,E ) + W(vA) * W(vE) * W(v~B) * W(tA|~B,E ) = 1* Pr[E] * Pr[B] * Pr[A | B,E] + 1* Pr[E] * Pr[~B] * Pr[A | ~B,E] = Pr[ A ∩ E]

9

Application 2: Network Reliability

Graph G = (V, E) represents a (power-grid) network

• Nodes (V) are towns, villages, power stations
• Edges (E) are power lines
• Assume each edge e fails with prob g(e) ∈ [0,1]
• Assume failure of edges statistically

independent

• What is the probability that s and t become

disconnected?

10

s t

Network Reliability: First Principles Modeling

π : E → {0, 1} … configuration of network

• - π(e) = 0 if edge e has failed, 1 otherwise

Prob of network being in configuration π Pr[ π ] = Π g(e) ×

Π (1 - g(e))

Prob of s and t being disconnected Pds,t = Σ Pr [π]

11

e: π(e) = 0 e: π(e) = 1

s t

π : s, t disconnected in π May need to sum over numerous (> 2100) configurations

Network Reliability: Discrete Integration

• pv: Boolean variable for each v in V
• qe: Boolean variable for each e in E
• ϕs,t (pv1, … pvn, qe1, … qem) :

Boolean formula such that sat assignments σ of ϕs,t have 1-1 correspondence with configs π that disconnect s and t

• W(σ) = Pr[ π ]

12

s t Pds,t = Σ Pr [π] = Σ W(σ) = W(ϕ)

π : s, t disconnected in π

𝜏 ⊨ 𝜒𝑡, 𝑢

Application 3: Quantitative Information Flow

• A password-checker PC takes a secret password (SP) and a

user input (UI) and returns “Yes” iff SP = UI [Bang et al 2016]

– Suppose passwords are 4 characters (‘0’ through ‘9’) long

13

PC1 (char[] SP, char[] UI) { for (int i=0; i<SP.length(); i++) { if(SP[i] != UI[i]) return “No”; } return “Yes”; } PC2 (char[] H, char[] L) { match = true; for (int i=0; i<SP.length(); i++) { if (SP[i] != UI[i]) match=false; else match = match; } if match return “Yes”; else return “No”; }

Which of PC1 and PC2 is more likely to leak information about the secret key through side-channel observations?

QIF: Some Basics

• Program P receives some “high” input (H) and produces a

“low” (L) output

– Password checking: H is SP, L is time taken to answer “Is SP = UI?” – Side-channel observations: memory, time …

• Adversary may infer partial information about H on seeing L

– E.g. in password checking, infer: 1st char is password is not 9.

• Can we quantify “leakage of information”?

“initial uncertainty in H” = “info leaked” + “remaining uncertainty in H” [Smith 2009]

• Uncertainty and information leakage usually quantified using

information theoretic measures, e.g. Shannon entropy

14

QIF: First Principles Approach

• Password checking: Observed time to answer “Yes”/“No”

– Depends on # instructions executed

• E.g. SP = 00700700

UI = N2345678, 𝑂 ≠ 0 PC1 executes for loop once UI = 02345678 PC1 executes for loop at least twice Observing time to “No” gives away whether 1st char is not N, 𝑂 ≠ 0 In 10 attempts, 1st char can of SP can be uniquely determined. In max 40 attempts, SP can be cracked.

15

PC1 (char[] SP, char[] UI) { for (int i=0; i<SP.length(); i++) { if(SP[i] != UI[i]) return “No”; } return “Yes”; }

QIF: First Principles Approach

• Password checking: Observed time to answer “Yes”/“No”

– Depends on # instructions executed

• E.g. SP = 00700700

UI = N2345678, 𝑂 ≠ 0 PC1 executes for loop 4 times UI = 02345678 PC1 executes for loop 4 times Cracking SP requires max 104 attempts !!! (“less leakage”)

16

PC2 (char[] H, char[] L) { match = true; for (int i=0; i<SP.length(); i++) { if (SP[i] != UI[i]) match=false; else match = match; } if match return “Yes”; else return “No”; }

QIF: Partitioning Space of Secret Password

• Observable time effectively partitions values of SP [Bultan2016]

17

T

PC1 (char[] SP, char[] UI) { for (int i=0; i<SP.length(); i++) { if(SP[i] != UI[i]) return “No”; } return “Yes”; }

SP[0] != UI[0] “No” F

SP[0] != UI[0]

t = 3 SP[1] != UI[1] “No” F T

SP[1] != UI[1] SP[0] = UI[0]

t = 5 SP[2] != UI[2] “No” F T

SP[2] != UI[2] SP[1] = UI[1] SP[0] = UI[0]

t = 7 SP[3] != UI[3] “No” T “Yes”

SP[3] = UI[3] SP[1] = UI[1] SP[2] = UI[2] SP[0] = UI[0]

F

SP[3] != UI[3] SP[2] = UI[2] SP[1] = UI[1] SP[0] = UI[0]

t = 9 t = 11

QIF: Probabilities of Observed Times

18

SP[0] != UI[0] SP[1] != UI[1] SP[2] != UI[2] SP[3] != UI[3] “No” “No” “No” “No” F F F T T T T

SP[0] != UI[0]

“Yes”

SP[3] = UI[3] SP[1] = UI[1] SP[2] = UI[2] SP[0] = UI[0]

F

SP[1] != UI[1] SP[0] = UI[0] SP[2] != UI[2] SP[1] = UI[1] SP[0] = UI[0] SP[3] != UI[3] SP[2] = UI[2] SP[1] = UI[1] SP[0] = UI[0]

t = 3 t = 5 t = 7 t = 9 t = 11

𝜒567 ∶ 𝑇𝑄 1 ≠ 𝑉𝐽 1 ∧ 𝑇𝑄 0 = 𝑉𝐽 0 Pr [ t = 5 ]=

|@AB CDEF | GHI

Model Counting if UI uniformly chosen

QIF: Probabilities of Observed Times

19

SP[0] != UI[0] SP[1] != UI[1] SP[2] != UI[2] SP[3] != UI[3] “No” “No” “No” “No” F F F T T T T

SP[0] != UI[0]

“Yes”

SP[3] = UI[3] SP[1] = UI[1] SP[2] = UI[2] SP[0] = UI[0]

F

SP[1] != UI[1] SP[0] = UI[0] SP[2] != UI[2] SP[1] = UI[1] SP[0] = UI[0] SP[3] != UI[3] SP[2] = UI[2] SP[1] = UI[1] SP[0] = UI[0]

t = 3 t = 5 t = 7 t = 9 t = 11

𝜒567 ∶ 𝑇𝑄 1 ≠ 𝑉𝐽 1 ∧ 𝑇𝑄 0 = 𝑉𝐽 0 Pr [ t = 5 ] = W(𝜒567) Discrete Integration if UI chosen according to weight function

QIF: Quantifying Leakage via Integration

–Exp information leakage = Shannon entropy of obs times = –Information leakage in password checker example PC1: 0.52 (more “leaky”) PC2: 0.0014 (less “leaky”) Discrete integration crucial in obtaining Pr[t = k]

20

K Pr 𝑢 = 𝑙 . log1/Pr [𝑢 = 𝑙]

S∈{V,7,W,X,GG}

Unweighted Counting Suffices in Principle

Weighted Model Counting 21

Weighted Model Counting Unweighted Model Counting

Reduction polynomial in #bits representing weights

IJCAI 2015

Probabilistic Inference Network Reliability Quantified Information Flow

DMPV 2017 KML 1989, Karger 2000

Application 4: Constr Random Verification

Functional Verification

• Formal verification

–Challenges: formal requirements, scalability –~10-15% of verification effort

• Dynamic verification: dominant approach

22

CRV: Dynamic Verification

§Design is simulated with test vectors

• Test vectors represent different verification scenarios

§Results from simulation compared to intended results §How do we generate test vectors?

Challenge: Exceedingly large test input space! Can’t try all input combinations 2128 combinations for a 64-bit binary operator!!!

23

CRV: Sources of Constraints

24

§ Test vectors: solutions of constraints § Proposed by Lichtenstein, Malka, Aharon (IAAI 94)

a b

c

64 bit 64 bit 64 bit

c = f(a,b)

• Designers:
• 1. a +64 11 *32 b = 12
• 2. a <64 (b >> 4)
• Past Experience:
• 1. 40 <64 34 + a <64 5050
• 2. 120 <64 b <64 230
• Users:
• 1. 232 *32 a + b != 1100
• 2. 1020 <64 (b /64 2) +64 a <64 2200

CRV: Why Existing Solvers Don’t Suffice

25

a b

c

64 bit 64 bit 64 bit

c = f(a,b)

Constraints

• Designers:
• 1. a +64 11 *32 b = 12
• 2. a <64 (b >> 4)
• Past Experience:
• 1. 40 <64 34 + a <64 5050
• 2. 120 <64 b <64 230
• Users:
• 1. 232 *32 a + b != 1100
• 2. 1020 <64 (b /64 2) +64 a <64 2200

Modern SAT/SMT solvers are complex systems Efficiency stems from the solver automatically “biasing” search Fails to give unbiased or user-biased distribution of test vectors

CRV: Need To Go Beyond SAT Solvers

26

Set of Constraints Sample satisfying assignments uniformly at random SAT Formula

Scalable Uniform Generation of SAT Witnesses

a b

c

64 bit 64 bit 64 bit

c = f(a,b)

Constrained Random Verification

Application 5: Automated Problem Generation

• Large class sizes, MOOC offerings require automated

generation of related but randomly different problems

• Discourages plagiarism between students
• Randomness makes it hard for students to guess what the

solution would be

• Allows instructors to focus on broad parameters of problems,

rather than on individual problem instances

• Enables development of automated intelligent tutoring

systems

27

Auto Prob Gen: Using Problem Templates

• A problem template is a partial specification of a problem

– “Holes” in the template must be filled with elements from specified sets – Constraints on elements chosen to fill various “holes” restricts problem instances so that undesired instances are eliminated

• Example:

– Non-deterministic finite automata to be generated for complementation Holes: States, alphabet size, transitions for (state, letter) pairs, final states, initial states Constraints: Alphabet size = 2 Min/max transitions for a (state, letter) pair = 0/4 Min/max states = 3/5 Min/max number of final states = 1/3 Min/max initial states = 1/2

28

Auto Prob Gen: An Illustration

– Non-det finite automaton encoded as a formula on following variables s1, s2, s3, s4, s5 : States f1, f2, f3, f4, f5: Final states n1, n2, n3, n4, n5: Initial states s1a1s2, s1a2s2, … : Transitions 𝜒 Z[Z5 = \ 𝑜Z → 𝑡Z ∧ 1 ≤ K 𝑜Z

Z

≤ 2

Z

𝜒 5ab[c = \ 𝑡Z𝑏e𝑡S → 𝑡Z ∧ 𝑡S ∧ \ 0 ≤ K 𝑡Z𝑏e𝑡S ≤ 4

S Z,e Z

𝜒 c5gAh[5 = 3 ≤ ∑ 𝑡Z

Z

≤ 5 𝜒 lZ[c5 = \ 𝑔

Z → 𝑡Z ∧ 1 ≤ K 𝑔 Z Z

≤ 3

Z

29

Every solution of 𝜒 Z[Z5 ∧ 𝜒 5ab[c ∧ 𝜒 c5gAh[5 ∧ 𝜒 lZ[c5 gives an automaton satisfying specified constraints

Auto Prob Gen: An Illustration

– Non-det finite automaton encoded as a formula on following variables s1 = 1, s2 = 0, s3 = 1, s4 = 1, s5 = 1: States f1 = 0, f2 = 0, f3 = 1, f4 = 1, f5 = 0: Final states n1 = 1, n2 = 0, n3 = 0, n4 = 0, n5 = 0: Initial states s1a1s3 = 1, s1a1s4 = 1, s4a2s4 = 1, s4a1s5 = 1, … : Transitions

30

s1 s3 s4 s5 a1 a1 a1 a5

Auto Prob Gen: Discrete Sampling

• Uniform random generation of solutions of constraints gives

automata satisfying constraints randomly

• Weighted random generation of solutions gives automata

satisfying constraints with different priorities/weightages.

Examples: Weighing final state variables more gives automata with more final states Weighing transitions on letter a1 more gives automata with more transitions labeled a1

31

Discrete Sampling and Integration for the AI Practitioner

Supratik Chakraborty, IIT Bombay Kuldeep S. Meel, Rice University Moshe Y. Vardi, Rice University

Part 2b: Survey of Prior Work

How Hard is it to Count/Sample?

• Trivial if we could enumerate RF: Almost always impractical
• Computational complexity of counting (discrete integration):

Exact unweighted counting: #P-complete [Valiant 1978] Approximate unweighted counting: Deterministic: Polynomial time det. Turing Machine with Σ2

p oracle [Stockmeyer 1983]

Randomized: Poly-time probabilistic Turing Machine with NP oracle [Stockmeyer 1983; Jerrum,Valiant,Vazirani 1986] Probably Approximately Correct (PAC) algorithm Weighted versions of counting: Exact: #P-complete [Roth 1996], Approximate: same class as unweighted version [follows from Roth 1996]

33

for ), 1 ( | | ) e(F, DetEstimat 1 | | > + × ≤ ≤ + ε ε ε ε

F F

R R

1 , for , 1 ) 1 ( | | ) , te(F, RandEstima 1 | | Pr ≤ < > − ≥ ⎥ ⎦ ⎤ ⎢ ⎣ ⎡ + ⋅ ≤ ≤ + δ ε δ ε δ ε ε

F F

R R

How Hard is it to Count/Sample?

• Computational complexity of sampling:

Uniform sampling: Poly-time prob. Turing Machine with NP oracle

[Bellare,Goldreich,Petrank 2000]

Almost uniform sampling: Poly-time prob. Turing Machine with NP

• racle [Jerrum,Valiant,Vazirani 1986, also from Bellare,Goldreich,Petrank 2000]

34

R if

• f

indep and R if where , erator(F)] UniformGen Pr[

F F

⎩ ⎨ ⎧ ∈ > ∉ = = = y y c y c c y ⎩ ⎨ ⎧ ∈ > ∉ = + ⋅ ≤ = ≤ +

F F

R if

• f

indep and R if where , ) 1 ( )] r(F, AUGenerato Pr[ 1 y y c y c c y c ε ε ε

Pr[Algorithm outputs some y] ≥ ½, if F is satisfiable

Markov Chain Monte Carlo Techniques

• Rich body of theoretical work with applications to sampling and counting

[Jerrum,Sinclair 1996]

• Some popular (and intensively studied) algorithms:

– Metropolis-Hastings [Metropolis et al 1953, Hastings 1970], Simulated Annealing [Kirkpatrick et al 1982]

• High-level idea:

– Start from a “state” (assignment of variables) – Randomly choose next state using “local” biasing functions (depends on target distribution & algorithm parameters) – Repeat for an appropriately large number (N) of steps – After N steps, samples follow target distribution with high confidence

• Convergence to desired distribution guaranteed only after N (large) steps
• In practice, steps truncated early heuristically

Nullifies/weakens theoretical guarantees [Kitchen,Keuhlman 2007]

35

Exact Counters

• DPLL based counters [CDP: Birnbaum,Lozinski 1999]

– DPLL branching search procedure, with partial truth assignments – Once a branch is found satisfiable, if t out of n variables assigned, add 2n-t to model count, backtrack to last decision point, flip decision and continue – Requires data structure to check if all clauses are satisfied by partial assignment Usually not implemented in modern DPLL SAT solvers – Can output a lower bound at any time

36

Exact Counters

• DPLL + component analysis [RelSat: Bayardo, Pehoushek 2000]

– Constraint graph G: Variables of F are vertices An edge connects two vertices if corresponding variables appear in some clause of F – Disjoint components of G lazily identified during DPLL search – F1, F2, … Fn : subformulas of F corresponding to components |RF| = |RF1| * |RF2| * |RF3| * … – Heuristic optimizations: Solve most constrained sub-problems first Solving sub-problems in interleaved manner

37

Exact Counters

• DPLL + Caching [Bacchus et al 2003, Cachet: Sang et al 2004,

sharpSAT: Thurley 2006] If same sub-formula revisited multiple times during DPLL search, cache result and re-use it “Signature” of the satisfiable sub-formula/component must be stored Different forms of caching used: Simple sub-formula caching Component caching Linear-space caching Component caching can also be combined with clause learning and

• ther reasoning techniques at each node of DPLL search tree

WeightedCachet: DPLL + Caching for weighted assignments

38

Exact Counters

• Knowledge Compilation based

– Compile given formula to another form which allows counting models in time polynomial in representation size – Reduced Ordered Binary Decision Diagrams (ROBDD) [Bryant 1986]: Construction can blow up exponentially – Deterministic Decomposable Negation Normal Form (d-DNNF) [c2d: Darwiche 2004] Generalizes ROBDDs; can be significantly more succinct Negation normal form with following restrictions: Decomposability: All AND operators have arguments with disjoint support Determinizability: All OR operators have arguments with disjoint solution sets – Sentential Decision Diagrams (SDD) [Darwiche 2011]

39

Exact Counters: How far do they go?

• Work reasonably well in small-medium sized problems, and

in large problem instances with special structure

• Use them whenever possible

– #P-completeness hits back eventually – scalability suffers!

40

Bounding Counters

[MBound: Gomes et al 2006; SampleCount: Gomes et al 2007; BPCount: Kroc et al 2008]

– Provide lower and/or upper bounds of model count – Usually more efficient than exact counters – No approximation guarantees on bounds Useful only for limited applications

41

Hashing-based Sampling

• Bellare, Goldreich, Petrank (BGP 2000)
• Uniform generator for SAT witnesses:
• Polynomial time randomized algorithm with access to an NP oracle
• Employs n-universal hash functions
• Works well for small values of n
• For high dimensions (large n), significant computational overheads

42

⎩ ⎨ ⎧ ∈ > ∉ = = y c y c y y

• f

t independen is where , R if ) ( R if BGP(F)] Pr[

F F

Much more on this coming in Part 3

Approximate Integration and Sampling: Close Cousins

Almost-Uniform Generator PAC Counter

Polynomial reduction

• Yet, no practical algorithms that scale to large problem

instances were derived from this work

• No scalable PAC counter or almost-uniform generator

existed until a few years back

• The inter-reductions are practically computation intensive
• Think of O(n) calls to the counter when n = 100000

43

• Seminal paper by Jerrum, Valiant, Vazirani 1986

Prior Work

44

Performance

Guarantees

MCMC SAT- Based BGP BDD/

• ther

exact tech.

Techniques using XOR hash functions

• Bounding counters MBound, SampleCount [Gomes et al.

2006, Gomes et al 2007] used random XORs

– Algorithms geared towards finding bounds without approximation guarantees – Power of 2-universal hashing not exploited

• In a series of papers [2013: ICML, UAI, NIPS; 2014: ICML;

2015: ICML, UAI; 2016: AAAI, ICML, AISTATS, …] Ermon et al used XOR hash functions for discrete counting/sampling

– Random XORs, also XOR constraints with specific structures – 2-universality exploited to provide improved guarantees – Relaxed constraints (like short XORs) and their effects studied

45

An Interesting Combination: XOR + MAP Optimization

• WISH: Ermon et al 2013
• Given a weight function W: {0,1}n → ℜ≥0

– Use random XORs to partition solutions into cells – After partitioning into 2, 4, 8, 16, … cells Use Max Aposteriori Probability (MAP) optimizer to find solution with max weight in a cell (say, a2, a4, a8, a16, …) – Estimated W(RF) = W(a2)*1 + W(a4)*2 + W(a8)* 4 + …

• Constant factor approximation of W(RF) with high confidence
• MAP oracle needs repeated invokation O(n.log2n)

– MAP is NP-complete – Being optimization (not decision) problem), MAP is harder to solve in practice than SAT

46

XOR-based Counting and Sampling

• Remainder of tutorial

– Deeper dive into XOR hash-based counting and sampling – Discuss theoretical aspects and experimental observations – Based on work published in [2013: CP, CAV; 2014: DAC, AAAI; 2015: IJCAI, TACAS; 2016: AAAI, IJCAI, 2017: AAAI]

47

Discrete Sampling and Integration for the AI Practitioner Part III: Hashing-based Approach to Sampling and Integration

Supratik Chakraborty, IIT Bombay Kuldeep S. Meel, Rice University Moshe Y. Vardi, Rice University

Discrete Integration and Sampling

• Given

– Variables X1, X2, · · · Xn over finite discrete domains D1, D2, · · · Dn – Formula ϕ over X1, X2, · · · Xn – Weight Function W : D1 × D2 · · · × Dn → [0, 1]

• Sol(ϕ) = {solutions of F}
• Discrete Integration: Determine W (ϕ) = Σy∈Sol(ϕ)W (y)

– If W (y) = 1 for all y, then W (ϕ) = |Sol(ϕ)|

• Discrete Sampling: Randomly sample from Sol(ϕ) such that

Pr[y is sampled] ∝ W (y)

– If W (y) = 1 for all y, then uniformly sample from Sol(ϕ)

Part I Discrete Integration

From Weighted to Unweighted Integration

Boolean Formula ϕ and weight function W : {0, 1}n → Q≥0

From Weighted to Unweighted Integration

Boolean Formula ϕ and weight function W : {0, 1}n → Q≥0 Boolean Formula F ′ W (ϕ) = c(W ) × |Sol(F ′)|

From Weighted to Unweighted Integration

Boolean Formula ϕ and weight function W : {0, 1}n → Q≥0 Boolean Formula F ′ W (ϕ) = c(W ) × |Sol(F ′)|

• Key Idea: Encode weight function as a set of constraints

(CFMV, IJCAI15)

From Weighted to Unweighted Integration

Boolean Formula ϕ and weight function W : {0, 1}n → Q≥0 Boolean Formula F ′ W (ϕ) = c(W ) × |Sol(F ′)|

• Key Idea: Encode weight function as a set of constraints

(CFMV, IJCAI15)

How do we estimate |Sol(F ′)|?

As Simple as Counting Dots

As Simple as Counting Dots

As Simple as Counting Dots

Pick a random cell Estimate = Number of solutions in a cell × Number of cells

Challenges

Challenge 1 How to partition into roughly equal small cells of solutions without knowing the distribution of solutions?

Challenges

Challenge 1 How to partition into roughly equal small cells of solutions without knowing the distribution of solutions? Challenge 2 How large is a “small” cell?

Challenges

Challenge 1 How to partition into roughly equal small cells of solutions without knowing the distribution of solutions? Challenge 2 How large is a “small” cell? Challenge 3 How many cells?

Challenges

Challenge 1 How to partition into roughly equal small cells of solutions without knowing the distribution of solutions?

• Designing function h : assignments → cells (hashing)
• Solutions in a cell α: Sol(ϕ) ∩ {y | h(y) = α}

Challenges

Challenge 1 How to partition into roughly equal small cells of solutions without knowing the distribution of solutions?

• Designing function h : assignments → cells (hashing)
• Solutions in a cell α: Sol(ϕ) ∩ {y | h(y) = α}
• Deterministic h unlikely to work

Challenges

Challenge 1 How to partition into roughly equal small cells of solutions without knowing the distribution of solutions?

• Designing function h : assignments → cells (hashing)
• Solutions in a cell α: Sol(ϕ) ∩ {y | h(y) = α}
• Deterministic h unlikely to work
• Choose h randomly from a large family H of hash

functions Universal Hashing (Carter and Wegman 1977)

r-Universal Hashing

• Let H be family of r−universal hash functions mapping {0, 1}n to

{0, 1}m ∀y1, y2, · · · yr ∈ {0, 1}n, α1, α2, · · · αr ∈ {0, 1}m, h

R

← − H Pr[h(y1) = α1] = · · · Pr[h(yr) = αr] = 1 2m

• Pr[h(y1) = α1 ∧ · · · ∧ h(yr) = αr] =

1 2m r

Desired Properties

• Let h be randomly picked a family of hash function H and Z be

the number of solutions in a randomly chosen cell α

– What is E[Z] and how much does Z deviate from E[Z]?

• For every y ∈ Sol(ϕ), we define Iy =
• 1

h(y) = α(y is in cell)

• therwise
• Z =

y∈Sol(ϕ) Iy

– Desired: E[Z] = |Sol(ϕ)|

2m

and σ2[Z] ≤ E[Z]

Desired Properties

• Let h be randomly picked a family of hash function H and Z be

the number of solutions in a randomly chosen cell α

– What is E[Z] and how much does Z deviate from E[Z]?

• For every y ∈ Sol(ϕ), we define Iy =
• 1

h(y) = α(y is in cell)

• therwise
• Z =

y∈Sol(ϕ) Iy

– Desired: E[Z] = |Sol(ϕ)|

2m

and σ2[Z] ≤ E[Z] – It suffices to have H to be 2-universal

Desired Properties

• Let h be randomly picked a family of hash function H and Z be

the number of solutions in a randomly chosen cell α

– What is E[Z] and how much does Z deviate from E[Z]?

• For every y ∈ Sol(ϕ), we define Iy =
• 1

h(y) = α(y is in cell)

• therwise
• Z =

y∈Sol(ϕ) Iy

– Desired: E[Z] = |Sol(ϕ)|

2m

and σ2[Z] ≤ E[Z] – It suffices to have H to be 2-universal – Pr

• E[Z]

1+ε ≤ Z ≤ E[Z](1 + ε)

• ≥ 1 −

σ2[Z] (

Desired Properties

• Let h be randomly picked a family of hash function H and Z be

the number of solutions in a randomly chosen cell α

– What is E[Z] and how much does Z deviate from E[Z]?

• For every y ∈ Sol(ϕ), we define Iy =
• 1

h(y) = α(y is in cell)

• therwise
• Z =

y∈Sol(ϕ) Iy

– Desired: E[Z] = |Sol(ϕ)|

2m

and σ2[Z] ≤ E[Z] – It suffices to have H to be 2-universal – Pr

• E[Z]

1+ε ≤ Z ≤ E[Z](1 + ε)

• ≥ 1 −

σ2[Z] (

1 (

Desired Properties

• Let h be randomly picked a family of hash function H and Z be

the number of solutions in a randomly chosen cell α

– What is E[Z] and how much does Z deviate from E[Z]?

• For every y ∈ Sol(ϕ), we define Iy =
• 1

h(y) = α(y is in cell)

• therwise
• Z =

y∈Sol(ϕ) Iy

– Desired: E[Z] = |Sol(ϕ)|

2m

and σ2[Z] ≤ E[Z] – It suffices to have H to be 2-universal – Pr

• E[Z]

1+ε ≤ Z ≤ E[Z](1 + ε)

• ≥ 1 −

σ2[Z] (

1 (

2-Universal Hash Functions

• Variables: X1, X2, · · · Xn
• To construct h : {0, 1}n → {0, 1}m, choose m random XORs
• Pick every Xi with prob. 1

2 and XOR them

– X1 ⊕ X3 ⊕ X6 · · · ⊕ Xn−2 ⊕ 1 – Expected size of each XOR: n

2

2-Universal Hash Functions

• Variables: X1, X2, · · · Xn
• To construct h : {0, 1}n → {0, 1}m, choose m random XORs
• Pick every Xi with prob. 1

2 and XOR them

– X1 ⊕ X3 ⊕ X6 · · · ⊕ Xn−2 ⊕ 1 – Expected size of each XOR: n

2

• To choose α ∈ {0, 1}m, set every XOR equation to 0 or 1 randomly

X1 ⊕ X3 ⊕ X6 · · · ⊕ Xn−2 ⊕ 1 = 0 (Q1) X2 ⊕ X5 ⊕ X6 · · · ⊕ Xn−1 ⊕ 1 = 1 (Q2) · · · (· · · ) X1 ⊕ X2 ⊕ X5 · · · ⊕ Xn−2 = 1 (Qm)

• Solutions in a cell: F ∧ Q1 · · · ∧ Qm

2-Universal Hash Functions

• Variables: X1, X2, · · · Xn
• To construct h : {0, 1}n → {0, 1}m, choose m random XORs
• Pick every Xi with prob. 1

2 and XOR them

– X1 ⊕ X3 ⊕ X6 · · · ⊕ Xn−2 ⊕ 1 – Expected size of each XOR: n

2

• To choose α ∈ {0, 1}m, set every XOR equation to 0 or 1 randomly

X1 ⊕ X3 ⊕ X6 · · · ⊕ Xn−2 ⊕ 1 = 0 (Q1) X2 ⊕ X5 ⊕ X6 · · · ⊕ Xn−1 ⊕ 1 = 1 (Q2) · · · (· · · ) X1 ⊕ X2 ⊕ X5 · · · ⊕ Xn−2 = 1 (Qm)

• Solutions in a cell: F ∧ Q1 · · · ∧ Qm
• Finding a solution is NP-complete

2-Universal Hash Functions

• Variables: X1, X2, · · · Xn
• To construct h : {0, 1}n → {0, 1}m, choose m random XORs
• Pick every Xi with prob. 1

2 and XOR them

– X1 ⊕ X3 ⊕ X6 · · · ⊕ Xn−2 ⊕ 1 – Expected size of each XOR: n

2

• To choose α ∈ {0, 1}m, set every XOR equation to 0 or 1 randomly

X1 ⊕ X3 ⊕ X6 · · · ⊕ Xn−2 ⊕ 1 = 0 (Q1) X2 ⊕ X5 ⊕ X6 · · · ⊕ Xn−1 ⊕ 1 = 1 (Q2) · · · (· · · ) X1 ⊕ X2 ⊕ X5 · · · ⊕ Xn−2 = 1 (Qm)

• Solutions in a cell: F ∧ Q1 · · · ∧ Qm
• Finding a solution is NP-complete

Modern SAT solvers are able to deal routinely with practical problems that involve many thousands of variables, although such problems were regarded as hopeless just a few years ago. (Knuth, 2016)

2-Universal Hash Functions

• Variables: X1, X2, · · · Xn
• To construct h : {0, 1}n → {0, 1}m, choose m random XORs
• Pick every Xi with prob. 1

2 and XOR them

– X1 ⊕ X3 ⊕ X6 · · · ⊕ Xn−2 ⊕ 1 – Expected size of each XOR: n

2

• To choose α ∈ {0, 1}m, set every XOR equation to 0 or 1 randomly

X1 ⊕ X3 ⊕ X6 · · · ⊕ Xn−2 ⊕ 1 = 0 (Q1) X2 ⊕ X5 ⊕ X6 · · · ⊕ Xn−1 ⊕ 1 = 1 (Q2) · · · (· · · ) X1 ⊕ X2 ⊕ X5 · · · ⊕ Xn−2 = 1 (Qm)

• Solutions in a cell: F ∧ Q1 · · · ∧ Qm
• Finding a solution is NP-complete
• Performance of state of the art SAT solvers degrade with increase

in the size of XORs (SAT Solvers != SAT oracles)

Improved Universal Hash Functions

• Not all variables are required to specify solution space of ϕ

– F := X3 ⇐ ⇒ (X1 ∨ X2) – X1 and X2 uniquely determines rest of the variables (i.e., X3)

• Formally: if I is independent support, then ∀σ1, σ2 ∈ Sol(ϕ), if σ1

and σ2 agree on I then σ1 = σ2

– {X1, X2} is independent support but {X1, X3} is not

Improved Universal Hash Functions

• Not all variables are required to specify solution space of ϕ

– F := X3 ⇐ ⇒ (X1 ∨ X2) – X1 and X2 uniquely determines rest of the variables (i.e., X3)

• Formally: if I is independent support, then ∀σ1, σ2 ∈ Sol(ϕ), if σ1

and σ2 agree on I then σ1 = σ2

– {X1, X2} is independent support but {X1, X3} is not

• Random XORs need to be constructed only over I

(CMV DAC14)

Improved Universal Hash Functions

• Not all variables are required to specify solution space of ϕ

– F := X3 ⇐ ⇒ (X1 ∨ X2) – X1 and X2 uniquely determines rest of the variables (i.e., X3)

• Formally: if I is independent support, then ∀σ1, σ2 ∈ Sol(ϕ), if σ1

and σ2 agree on I then σ1 = σ2

– {X1, X2} is independent support but {X1, X3} is not

• Random XORs need to be constructed only over I

(CMV DAC14)

• Typically I is 1-2 orders of magnitude smaller than X
• Auxiliary variables introduced during encoding phase are

dependent

(Tseitin 1968)

Improved Universal Hash Functions

• Not all variables are required to specify solution space of ϕ

– F := X3 ⇐ ⇒ (X1 ∨ X2) – X1 and X2 uniquely determines rest of the variables (i.e., X3)

• Formally: if I is independent support, then ∀σ1, σ2 ∈ Sol(ϕ), if σ1

and σ2 agree on I then σ1 = σ2

– {X1, X2} is independent support but {X1, X3} is not

• Random XORs need to be constructed only over I

(CMV DAC14)

• Typically I is 1-2 orders of magnitude smaller than X
• Auxiliary variables introduced during encoding phase are

dependent

(Tseitin 1968)

Algorithmic procedure to determine I?

Independent Support

• I ⊆ X is an independent support:

∀σ1, σ2 ∈ Sol(ϕ), σ1 and σ2 agree on I then σ1 = σ2

Independent Support

• I ⊆ X is an independent support:

∀σ1, σ2 ∈ Sol(ϕ), σ1 and σ2 agree on I then σ1 = σ2

• F(x1, · · · xn) ∧ F(y1, · · · yn) ∧

i|xi∈I(xi = yi) =

⇒

i(xi = yi)

where F(y1, · · · yn) := F(x1 ֌ y1, · · · xn ֌ yn)

Independent Support

• I ⊆ X is an independent support:

∀σ1, σ2 ∈ Sol(ϕ), σ1 and σ2 agree on I then σ1 = σ2

• F(x1, · · · xn) ∧ F(y1, · · · yn) ∧

i|xi∈I(xi = yi) =

⇒

i(xi = yi)

where F(y1, · · · yn) := F(x1 ֌ y1, · · · xn ֌ yn)

• QF,I := F(x1, · · · xn) ∧ F(y1, · · · yn) ∧

i|xi∈I(xi = yi) ∧ ¬( i(xi =

yi))

Independent Support

• I ⊆ X is an independent support:

∀σ1, σ2 ∈ Sol(ϕ), σ1 and σ2 agree on I then σ1 = σ2

• F(x1, · · · xn) ∧ F(y1, · · · yn) ∧

i|xi∈I(xi = yi) =

⇒

i(xi = yi)

where F(y1, · · · yn) := F(x1 ֌ y1, · · · xn ֌ yn)

• QF,I := F(x1, · · · xn) ∧ F(y1, · · · yn) ∧

i|xi∈I(xi = yi) ∧ ¬( i(xi =

yi))

• Lemma: QF,I is UNSAT if and only if I is independent support

Independent Support

H1 := {x1 = y1}, H2 := {x2 = y2}, · · · Hn := {xn = yn} Ω = F(x1, · · · xn) ∧ F(y1, · · · yn) ∧ ¬(

• i

(xi = yi)) Lemma I = {xi} is independent support iif HI ∧ Ω is UNSAT where HI = {Hi|xi ∈ I}

Minimal Unsatisfiable Subset

Given Ψ = H1 ∧ H2 · · · ∧ Hm ∧ Ω Unsatisfiable Subset Find subset {Hi1, Hi2, · · · Hik} of {H1, H2, · · · Hm} such that Hi1 ∧ Hi2 ∧ Hik ∧ Ω is UNSAT

Minimal Unsatisfiable Subset

Given Ψ = H1 ∧ H2 · · · ∧ Hm ∧ Ω Unsatisfiable Subset Find subset {Hi1, Hi2, · · · Hik} of {H1, H2, · · · Hm} such that Hi1 ∧ Hi2 ∧ Hik ∧ Ω is UNSAT Minimal Unsatisfiable Subset Find minimal subset {Hi1, Hi2, · · · Hik}

• f {H1, H2, · · · Hm} such that Hi1 ∧ Hi2 ∧ Hik ∧ Ω is

UNSAT

Minimal Unsatisfiable Subset

Given Ψ = H1 ∧ H2 · · · ∧ Hm ∧ Ω Unsatisfiable Subset Find subset {Hi1, Hi2, · · · Hik} of {H1, H2, · · · Hm} such that Hi1 ∧ Hi2 ∧ Hik ∧ Ω is UNSAT Minimal Unsatisfiable Subset Find minimal subset {Hi1, Hi2, · · · Hik}

• f {H1, H2, · · · Hm} such that Hi1 ∧ Hi2 ∧ Hik ∧ Ω is

UNSAT

Minimal Independent Support

H1 := {x1 = y1}, H2 := {x2 = y2}, · · · Hn := {xn = yn} Ω = F(x1, · · · xn) ∧ F(y1, · · · yn) ∧ ¬(

• i

(xi = yi)) Lemma I = {xi} is Minimal Independent Support iif HI is Minimal Unsatisfiable Subset where HI = {Hi|xi ∈ I}

MIS MUS

Minimal Independent Support

H1 := {x1 = y1}, H2 := {x2 = y2}, · · · Hn := {xn = yn} Ω = F(x1, · · · xn) ∧ F(y1, · · · yn) ∧ ¬(

• i

(xi = yi)) Lemma I = {xi} is Minimal Independent Support iif HI is Minimal Unsatisfiable Subset where HI = {Hi|xi ∈ I}

MIS MUS

Two orders of magnitude improvement in runtime

Challenges

Challenge 1 How to partition into roughly equal small cells of solutions without knowing the distribution of solutions?

• Independent Support-based 2-Universal Hash

Functions Challenge 2 How large is a “small” cell? Challenge 3 How many cells?

Challenge 2: How large is a “small” cell

• Too large ֌ Hard to enumerate

Challenge 2: How large is a “small” cell

• Too large ֌ Hard to enumerate
• Too small ֌ Weaker probabilistic guarantees

Challenge 2: How large is a “small” cell

• Too large ֌ Hard to enumerate
• Too small ֌ Weaker probabilistic guarantees

– Pr

• E[Z]

1+ε ≤ Z ≤ E[Z](1 + ε)

• ≥ 1 −

1 (

Challenge 2: How large is a “small” cell

• Too large ֌ Hard to enumerate
• Too small ֌ Weaker probabilistic guarantees

– Pr

• E[Z]

1+ε ≤ Z ≤ E[Z](1 + ε)

• ≥ 1 −

1 (

We want a “small” cell to have roughly thresh solutions, where thresh = 5

• 1 + 1

ε2

• 16 / 41

Challenges

Challenge 1 How to partition into roughly equal small cells of solutions without knowing the distribution of solutions?

• Independent Support-based 2-Universal Hash

Functions Challenge 2 How large is a “small” cell?

• Independent Support-based 2-Universal Hash

Functions Challenge 3 How many cells?

Challenge 3: How many cells?

• A cell is small if it has less than thresh = 5(1 + 1

ε)2 solutions

• We want to partition into 2m∗ cells such that 2m∗ = |Sol(ϕ)|

thresh

Challenge 3: How many cells?

• A cell is small if it has less than thresh = 5(1 + 1

ε)2 solutions

• We want to partition into 2m∗ cells such that 2m∗ = |Sol(ϕ)|

thresh

– Check for every m = 0, 1, · · · n if the number of solutions ≤ thresh

Challenge 3: How many cells?

• A cell is small if it has less than thresh = 5(1 + 1

ε)2 solutions

• We want to partition into 2m∗ cells such that 2m∗ = |Sol(ϕ)|

thresh

– Check for every m = 0, 1, · · · n if the number of solutions ≤ thresh – XORs for each m must be independently chosen

Challenge 3: How many cells?

• A cell is small if it has less than thresh = 5(1 + 1

ε)2 solutions

• We want to partition into 2m∗ cells such that 2m∗ = |Sol(ϕ)|

thresh

– Check for every m = 0, 1, · · · n if the number of solutions ≤ thresh – XORs for each m must be independently chosen

Challenge 3: How many cells?

• A cell is small if it has less than thresh = 5(1 + 1

ε)2 solutions

• We want to partition into 2m∗ cells such that 2m∗ = |Sol(ϕ)|

thresh

– Check for every m = 0, 1, · · · n if the number of solutions ≤ thresh – XORs for each m must be independently chosen

– Stop at the first m where Query m returns YES and return estimate as #(F ∧ Qm

1 · · · ∧ Qm m) × 2m

Challenge 3: How many cells?

• A cell is small if it has less than thresh = 5(1 + 1

ε)2 solutions

• We want to partition into 2m∗ cells such that 2m∗ = |Sol(ϕ)|

thresh

– Check for every m = 0, 1, · · · n if the number of solutions ≤ thresh – XORs for each m must be independently chosen

– Stop at the first m where Query m returns YES and return estimate as #(F ∧ Qm

1 · · · ∧ Qm m) × 2m

• Number of SAT calls is O(n)

(CMV, CP13) (CFMSV, AAAI14)

ApproxMC(F, ε, δ)

# of sols ≤ thresh?

ApproxMC(F, ε, δ)

# of sols ≤ thresh? # of sols ≤ thresh? No

ApproxMC(F, ε, δ)

# of sols ≤ thresh? # of sols ≤ thresh? No No

ApproxMC(F, ε, δ)

# of sols ≤ thresh? # of sols ≤ thresh? # of sols ≤ thresh? # of sols ≤ thresh? · · · No No No

ApproxMC(F, ε, δ)

# of sols ≤ thresh? # of sols ≤ thresh? # of sols ≤ thresh? Estimate = # of sols × # of cells # of sols ≤ thresh? · · · No No No Yes

ApproxMC(F, ε, δ)

Theoretical Guarantees Theorem (Correctness) Pr

• |Sol(ϕ)|

1+ε

≤ ApproxMC(F, ε, δ) ≤ |Sol(ϕ)|(1 + ε)

• ≥ 1 − δ

Theorem (Complexity) ApproxMC(F, ε, δ) makes O(

n log( 1

ε2

) calls to SAT oracle.

• Prior work required O(

n log n log( 1

ε

) calls to SAT oracle

(Stockmeyer 1983)

ApproxMC(F, ε, δ)

Theoretical Guarantees Theorem (Correctness) Pr

• |Sol(ϕ)|

1+ε

≤ ApproxMC(F, ε, δ) ≤ |Sol(ϕ)|(1 + ε)

• ≥ 1 − δ

Theorem (Complexity) ApproxMC(F, ε, δ) makes O(

n log( 1

ε2

) calls to SAT oracle.

• Prior work required O(

n log n log( 1

ε

) calls to SAT oracle

(Stockmeyer 1983)

Runtime performance

ApproxMC(F, ε, δ)

Theoretical Guarantees Theorem (Correctness) Pr

• |Sol(ϕ)|

1+ε

≤ ApproxMC(F, ε, δ) ≤ |Sol(ϕ)|(1 + ε)

• ≥ 1 − δ

Theorem (Complexity) ApproxMC(F, ε, δ) makes O(

n log( 1

ε2

) calls to SAT oracle.

• Prior work required O(

n log n log( 1

ε

) calls to SAT oracle

(Stockmeyer 1983)

Runtime performance Handles thousands of variables in few hours but insufficient to solve practical applications

ApproxMC(F, ε, δ)

Theoretical Guarantees Theorem (Correctness) Pr

• |Sol(ϕ)|

1+ε

≤ ApproxMC(F, ε, δ) ≤ |Sol(ϕ)|(1 + ε)

• ≥ 1 − δ

Theorem (Complexity) ApproxMC(F, ε, δ) makes O(

n log( 1

ε2

) calls to SAT oracle.

• Prior work required O(

n log n log( 1

ε

) calls to SAT oracle

(Stockmeyer 1983)

Runtime performance Handles thousands of variables in few hours but insufficient to solve practical applications How to scale to hundreds of thousands of variables and beyond?

ApproxMC(F, ε, δ)

Theoretical Guarantees Theorem (Correctness) Pr

• |Sol(ϕ)|

1+ε

≤ ApproxMC(F, ε, δ) ≤ |Sol(ϕ)|(1 + ε)

• ≥ 1 − δ

Theorem (Complexity) ApproxMC(F, ε, δ) makes O(

n log( 1

ε2

) calls to SAT oracle.

• Prior work required O(

n log n log( 1

ε

) calls to SAT oracle

(Stockmeyer 1983)

Runtime performance Handles thousands of variables in few hours but insufficient to solve practical applications How to scale to hundreds of thousands of variables and beyond? Efficient SAT oracle calls?

Beyond ApproxMC

• Query 1: Is #(F ∧ Q1

1) ≤ thresh

• Query 2: Is #(F ∧ Q2

1 ∧ Q2 2) ≤ thresh

• · · ·
• Query n: Is #(F ∧ Qn

1 · · · ∧ Qn n) ≤ thresh

Classical View

• Every NP query requires equal amount of time

Beyond ApproxMC

• Query 1: Is #(F ∧ Q1

1) ≤ thresh

• Query 2: Is #(F ∧ Q2

1 ∧ Q2 2) ≤ thresh

• · · ·
• Query n: Is #(F ∧ Qn

1 · · · ∧ Qn n) ≤ thresh

Classical View

• Every NP query requires equal amount of time

Practitioner’s View

• Solving (F ∧ Q1

1) followed by (F ∧ Q2 1 ∧ Q2 2) requires larger

runtime than solving (F ∧ Q1

1) followed by (F ∧ Q1 1 ∧ Q2 2)

Beyond ApproxMC

• Query 1: Is #(F ∧ Q1

1) ≤ thresh

• Query 2: Is #(F ∧ Q2

1 ∧ Q2 2) ≤ thresh

• · · ·
• Query n: Is #(F ∧ Qn

1 · · · ∧ Qn n) ≤ thresh

Classical View

• Every NP query requires equal amount of time

Practitioner’s View

• Solving (F ∧ Q1

1) followed by (F ∧ Q2 1 ∧ Q2 2) requires larger

runtime than solving (F ∧ Q1

1) followed by (F ∧ Q1 1 ∧ Q2 2)

– If (F ∧ Q1

1) =

⇒ L then (F ∧ Q1

1 ∧ Q2 2) =

⇒ L – But, If (F ∧ Q1

1) =

⇒ L then it is not always the case that (F ∧ Q2

1 ∧ Q2 2) =

⇒ L

Beyond ApproxMC

• What if we modify our queries to:

– Query 1: Is #(F ∧ Q1) ≤ thresh – Query 2: Is #(F ∧ Q1 ∧ Q2) ≤ thresh – · · · – Query n: Is #(F ∧ Q1 ∧ Q2 · · · ∧ Qn) ≤ thresh

• Stop at the first m where Query m returns YES and return

estimate as #(F ∧ Q1 ∧ Q2 · · · ∧ Qm) × 2m

• Observation: #(F ∧ Q1 · · · ∧ Qi ∧ Qi+1) ≤ #(F ∧ Q1 · · · ∧ Qi)

– If Query i returns YES, then Query i + 1 must return YES

Beyond ApproxMC

• What if we modify our queries to:

– Query 1: Is #(F ∧ Q1) ≤ thresh – Query 2: Is #(F ∧ Q1 ∧ Q2) ≤ thresh – · · · – Query n: Is #(F ∧ Q1 ∧ Q2 · · · ∧ Qn) ≤ thresh

• Stop at the first m where Query m returns YES and return

estimate as #(F ∧ Q1 ∧ Q2 · · · ∧ Qm) × 2m

• Observation: #(F ∧ Q1 · · · ∧ Qi ∧ Qi+1) ≤ #(F ∧ Q1 · · · ∧ Qi)

– If Query i returns YES, then Query i + 1 must return YES – Galloping search (# of SAT calls: O(log n)) – Incremental solving

Beyond ApproxMC

• What if we modify our queries to:

– Query 1: Is #(F ∧ Q1) ≤ thresh – Query 2: Is #(F ∧ Q1 ∧ Q2) ≤ thresh – · · · – Query n: Is #(F ∧ Q1 ∧ Q2 · · · ∧ Qn) ≤ thresh

• Stop at the first m where Query m returns YES and return

estimate as #(F ∧ Q1 ∧ Q2 · · · ∧ Qm) × 2m

• Observation: #(F ∧ Q1 · · · ∧ Qi ∧ Qi+1) ≤ #(F ∧ Q1 · · · ∧ Qi)

– If Query i returns YES, then Query i + 1 must return YES – Galloping search (# of SAT calls: O(log n)) – Incremental solving

• But Query i and Query j are no longer independent

Beyond ApproxMC

• What if we modify our queries to:

– Query 1: Is #(F ∧ Q1) ≤ thresh – Query 2: Is #(F ∧ Q1 ∧ Q2) ≤ thresh – · · · – Query n: Is #(F ∧ Q1 ∧ Q2 · · · ∧ Qn) ≤ thresh

• Stop at the first m where Query m returns YES and return

estimate as #(F ∧ Q1 ∧ Q2 · · · ∧ Qm) × 2m

• Observation: #(F ∧ Q1 · · · ∧ Qi ∧ Qi+1) ≤ #(F ∧ Q1 · · · ∧ Qi)

– If Query i returns YES, then Query i + 1 must return YES – Galloping search (# of SAT calls: O(log n)) – Incremental solving

• But Query i and Query j are no longer independent

– Independence crucial to analysis (Stockmeyer 1983, · · · )

Beyond ApproxMC

• What if we modify our queries to:

– Query 1: Is #(F ∧ Q1) ≤ thresh – Query 2: Is #(F ∧ Q1 ∧ Q2) ≤ thresh – · · · – Query n: Is #(F ∧ Q1 ∧ Q2 · · · ∧ Qn) ≤ thresh

• Stop at the first m where Query m returns YES and return

estimate as #(F ∧ Q1 ∧ Q2 · · · ∧ Qm) × 2m

• Observation: #(F ∧ Q1 · · · ∧ Qi ∧ Qi+1) ≤ #(F ∧ Q1 · · · ∧ Qi)

– If Query i returns YES, then Query i + 1 must return YES – Galloping search (# of SAT calls: O(log n)) – Incremental solving

• But Query i and Query j are no longer independent

– Independence crucial to analysis (Stockmeyer 1983, · · · )

• Key Insight: The probability of making a bad choice of Qi is very

small for i ≪ m∗

– Dependence of Query j upon Query i (i < j) does not hurt

(CMV, IJCAI16)

Taming the Curse of Dependence

Let 2m∗ = |Sol(ϕ)|

thresh

Lemma (1) ApproxMC (F, ε, δ) terminates with m ∈ {m∗ − 1, m∗} with probability ≥ 0.8 Lemma (2) For m ∈ {m∗ − 1, m∗}, estimate obtained from a randomly picked cell lies within a tolerance of ε of |Sol(ϕ)| with probability ≥ 0.8

Optimized ApproxMC(F, ε, δ)

Theorem (Correctness) Pr

• |Sol(ϕ)|

1+ε

≤ ApproxMC(F, ε, δ) ≤ |Sol(ϕ)|(1 + ε)

• ≥ 1 − δ

Theorem (Complexity) ApproxMC(F, ε, δ) makes O(

log n log( 1

ε2

) calls to SAT oracle.

Optimized ApproxMC(F, ε, δ)

Theorem (Correctness) Pr

• |Sol(ϕ)|

1+ε

≤ ApproxMC(F, ε, δ) ≤ |Sol(ϕ)|(1 + ε)

• ≥ 1 − δ

Theorem (Complexity) ApproxMC(F, ε, δ) makes O(

log n log( 1

ε2

) calls to SAT oracle. Theorem (FPRAS for DNF) If ϕ is a DNF formula, then ApproxMC is FPRAS – fundamentally different from the only other known FPRAS for DNF (Karp, Luby 1983)

Beyond Boolean: Handling bit-vectors

• Bit-vector: fixed-width integers

– Bit-vector constraints can be translated into a Boolean formula

• Significant advancements in bit-vector solving over the past decade
• Challenge: Hash functions for bit vectors
• Lifting hashing from (mod 2) to (mod p) constraints
• p: smallest prime grater than domain of variables

Beyond Boolean: Handling bit-vectors

• Bit-vector: fixed-width integers

– Bit-vector constraints can be translated into a Boolean formula

• Significant advancements in bit-vector solving over the past decade
• Challenge: Hash functions for bit vectors
• Lifting hashing from (mod 2) to (mod p) constraints
• p: smallest prime grater than domain of variables
• Linear equality (mod p) constraints to hash into cells
• Amenable to Gaussian Elimination

Beyond Boolean: Handling bit-vectors

• Bit-vector: fixed-width integers

– Bit-vector constraints can be translated into a Boolean formula

• Significant advancements in bit-vector solving over the past decade
• Challenge: Hash functions for bit vectors
• Lifting hashing from (mod 2) to (mod p) constraints
• p: smallest prime grater than domain of variables
• Linear equality (mod p) constraints to hash into cells
• Amenable to Gaussian Elimination
• Number of cells: pm
• Large p does not give finer control on the number of cells

– Few cells ֌ too many solutions in a cell – Too many cells ֌ No solutions in most of the cells

HSMT: Efficient word-level Hash Function

• Use different primes to control the number of cells
• Choose appropriate N and express as product of preferred primes,

i.e., N = pc1

1 pc2 2 pc3 3 · · · pcn n

• HSMT:

– c1 (mod p) constraints – c2 (mod p) constraints – · · ·

• HSMT satisfies guarantees of 2-universality

From Timeouts to under 40 seconds

Performance of RDA Performance of ApproxMC

(DMPV, AAAI17)

Highly Accurate Estimates

Observed relative error (G5)

10 20 30 40 50 60

Terminal Node

10 20 30 40 50 60

Source Node

0.02 0.04 0.06 0.08 0.1 0.12 0.14

Relative Error

(ε = 0.8, δ = 0.1)

Beyond Network Reliability

ApproxMC

Network Reliability Probabilistic Inference Decision Making Under Uncertainty Quantified Information Flow Program Synthesis

Part II Discrete Sampling

Discrete Sampling

• Given

– Boolean Variables X1, X2, · · · Xn – Formula ϕ over X1, X2, · · · Xn

• Uniform Generator

Pr[y is output] = 1 |Sol(ϕ)|

• Almost-Uniform Generator

1 (1 + ε)|Sol(ϕ)| ≤ Pr[y is output] = 1 + ε |Sol(ϕ)|

As simple as sampling dots

As simple as sampling dots

As simple as sampling dots

Pick a random cell Enumerate all the solutions and pick a random solution

As simple as sampling dots

Pick a random cell Enumerate all the solutions and pick a random solution Challenge: How many cells?

How many cells?

• Desired Number of cells: 2m∗ = |Sol(ϕ)|

thresh

– But determining |Sol(ϕ)| is expensive – ApproxMC(F, ε, δ) returns C such that Pr

• |Sol(ϕ)|

1+ε

≤ C ≤ |Sol(ϕ)|(1 + ε)

• ≥ 1 − δ

– ˜ m = log

C thresh ( m∗ = log |Sol(ϕ)| thresh )

– Check for m = ˜ m − 1, ˜ m, ˜ m + 1 if a randomly chosen cell is small

How many cells?

• Desired Number of cells: 2m∗ = |Sol(ϕ)|

thresh

– But determining |Sol(ϕ)| is expensive – ApproxMC(F, ε, δ) returns C such that Pr

• |Sol(ϕ)|

1+ε

≤ C ≤ |Sol(ϕ)|(1 + ε)

• ≥ 1 − δ

– ˜ m = log

C thresh ( m∗ = log |Sol(ϕ)| thresh )

– Check for m = ˜ m − 1, ˜ m, ˜ m + 1 if a randomly chosen cell is small – Not just a practical hack required non-trivial proof

(CMV, CAV13) (CMV, DAC14) (CFMSV, TACAS15)

Theoretical Guarantees

Theorem (Almost-Uniformity) ∀y ∈ Sol(ϕ),

1 (1+ε)|Sol(ϕ)| ≤ Pr[y is output] ≤ 1+ε |Sol(ϕ)|

Theoretical Guarantees

Theorem (Almost-Uniformity) ∀y ∈ Sol(ϕ),

1 (1+ε)|Sol(ϕ)| ≤ Pr[y is output] ≤ 1+ε |Sol(ϕ)|

Theorem (Query) For a formula ϕ over n variables, to generate m samples, UniGen makes

• ne call to approximate counter

Theoretical Guarantees

Theorem (Almost-Uniformity) ∀y ∈ Sol(ϕ),

1 (1+ε)|Sol(ϕ)| ≤ Pr[y is output] ≤ 1+ε |Sol(ϕ)|

Theorem (Query) For a formula ϕ over n variables, to generate m samples, UniGen makes

• ne call to approximate counter
• JVV (Jerrum, Valiant and Vazirani 1986) makes n × m calls

Theoretical Guarantees

Theorem (Almost-Uniformity) ∀y ∈ Sol(ϕ),

1 (1+ε)|Sol(ϕ)| ≤ Pr[y is output] ≤ 1+ε |Sol(ϕ)|

Theorem (Query) For a formula ϕ over n variables, to generate m samples, UniGen makes

• ne call to approximate counter
• JVV (Jerrum, Valiant and Vazirani 1986) makes n × m calls

Universality

• JVV employs 2-universal hash functions
• UniGen employs 3-universal hash functions

Theoretical Guarantees

Theorem (Almost-Uniformity) ∀y ∈ Sol(ϕ),

1 (1+ε)|Sol(ϕ)| ≤ Pr[y is output] ≤ 1+ε |Sol(ϕ)|

Theorem (Query) For a formula ϕ over n variables, to generate m samples, UniGen makes

• ne call to approximate counter
• JVV (Jerrum, Valiant and Vazirani 1986) makes n × m calls

Universality

• JVV employs 2-universal hash functions
• UniGen employs 3-universal hash functions

Random XORs are 3-universal

Three Orders of Improvement

Relative Runtime SAT Solver 1 Desired Uniform Generator 10 UniGen 20 XORSample (2012 state of the art) 50000 Experiments over 200+ benchmarks

Three Orders of Improvement

Relative Runtime SAT Solver 1 Desired Uniform Generator 10 UniGen 20 XORSample (2012 state of the art) 50000 Experiments over 200+ benchmarks UniGen is highly parallelizable – achieves linear speedup i.e., runtime decreases linearly with number of processors.

Three Orders of Improvement

Relative Runtime SAT Solver 1 Desired Uniform Generator 10 UniGen (two cores) 10 XORSample (2012 state of the art) 50000 Experiments over 200+ benchmarks UniGen is highly parallelizable – achieves linear speedup i.e., runtime decreases linearly with number of processors. Closer to technical transfer

Uniformity

• Benchmark: case110.cnf; #var: 287; #clauses: 1263
• Total Runs: 4 × 106; Total Solutions : 16384

Statistically Indistinguishable

• Benchmark: case110.cnf; #var: 287; #clauses: 1263
• Total Runs: 4 × 106; Total Solutions : 16384

Beyond Verification

UniGen

Hardware Validation Music Improvisation Probabilistic Reasoning Program Analysis Problem Generation

Towards Discrete Sampling and Integration Revolution

Towards Discrete Sampling and Integration Revolution

• Tighter integration between solvers and algorithms

Towards Discrete Sampling and Integration Revolution

• Tighter integration between solvers and algorithms
• Exploring solution space structure of CNF+XOR formulas

(DMV, IJCAI16)

Towards Discrete Sampling and Integration Revolution

• Tighter integration between solvers and algorithms
• Exploring solution space structure of CNF+XOR formulas

(DMV, IJCAI16)

• Can we handle real variables without discretization?

Summary

• Counting and Sampling are fundamental problems in Computer

Science

– Applications from network reliability, probabilistic inference, side-channel attacks to hardware verification

• Hashing-based approaches provide theoretical guarantees and

demonstrate scalability

– From problems with tens of variables to hundreds of thousands of variables

Generator Relative Runtime SAT Solver 1 Desired Uniform Generator 10 UniGen 20 UniGen (two cores) 10 XORSample 50000
