Pacific Islands Applied Geoscience Commission

Disaster Risk Reduction and Disaster Disaster Risk Reduction and Disaster Management Management in the Pacific in the Pacific

2

Background

Pacific Islands Applied Geoscience Commission (SOPAC)

• Intergovernmental regional organisation
• 21 member countries (4 associates)
• 3 technical work programmes

– Ocean and Islands – Community Lifelines incl water, energy and ICT – Community Risk

• Mandate for the coordination of regional disaster

risk reduction and disaster management capacity building in the Pacific

Christmas Island Christmas Island Christmas Island Christmas Island Christmas Island Christmas Island Christmas Island Christmas Island Christmas Island Wake Island Wake Island Wake Island Wake Island Wake Island Wake Island Wake Island Wake Island Wake Island Federated States of Micronesia Federated States of Micronesia Federated States of Micronesia Federated States of Micronesia Federated States of Micronesia Federated States of Micronesia Federated States of Micronesia Federated States of Micronesia Federated States of Micronesia Palau Palau Palau Palau Palau Palau Palau Palau Palau Marshall Islands Marshall Islands Marshall Islands Marshall Islands Marshall Islands Marshall Islands Marshall Islands Marshall Islands Marshall Islands Kiribati Kiribati Kiribati Kiribati Kiribati Kiribati Kiribati Kiribati Kiribati Indonesia Indonesia Indonesia Indonesia Indonesia Indonesia Indonesia Indonesia Indonesia Papua New Guinea Papua New Guinea Papua New Guinea Papua New Guinea Papua New Guinea Papua New Guinea Papua New Guinea Papua New Guinea Papua New Guinea Tuvalu Tuvalu Tuvalu Tuvalu Tuvalu Tuvalu Tuvalu Tuvalu Tuvalu Solomon Islands Solomon Islands Solomon Islands Solomon Islands Solomon Islands Solomon Islands Solomon Islands Solomon Islands Solomon Islands Samoa Samoa Samoa Samoa Samoa Samoa Samoa Samoa Samoa American Samoa American Samoa American Samoa American Samoa American Samoa American Samoa American Samoa American Samoa American Samoa Vanuatu Vanuatu Vanuatu Vanuatu Vanuatu Vanuatu Vanuatu Vanuatu Vanuatu French Polynesia French Polynesia French Polynesia French Polynesia French Polynesia French Polynesia French Polynesia French Polynesia French Polynesia Fiji Fiji Fiji Fiji Fiji Fiji Fiji Fiji Fiji Niue Niue Niue Niue Niue Niue Niue Niue Niue Cook Islands Cook Islands Cook Islands Cook Islands Cook Islands Cook Islands Cook Islands Cook Islands Cook Islands New Caledonia New Caledonia New Caledonia New Caledonia New Caledonia New Caledonia New Caledonia New Caledonia New Caledonia Tonga Tonga Tonga Tonga Tonga Tonga Tonga Tonga Tonga Australia Australia Australia Australia Australia Australia Australia Australia Australia New Zealand New Zealand New Zealand New Zealand New Zealand New Zealand New Zealand New Zealand New Zealand Norfolk Island Norfolk Island Norfolk Island Norfolk Island Norfolk Island Norfolk Island Norfolk Island Norfolk Island Norfolk Island Guam Guam Guam Guam Guam Guam Guam Guam Guam Nauru Nauru Nauru Nauru Nauru Nauru Nauru Nauru Nauru Hawaii Hawaii Hawaii Hawaii Hawaii Hawaii Hawaii Hawaii Hawaii Tokelau Tokelau Tokelau Tokelau Tokelau Tokelau Tokelau Tokelau Tokelau Kiribati Kiribati Kiribati Kiribati Kiribati Kiribati Kiribati Kiribati Kiribati Kiribati Kiribati Kiribati Kiribati Kiribati Kiribati Kiribati Kiribati Kiribati Pitcairn Pitcairn Pitcairn Pitcairn Pitcairn Pitcairn Pitcairn Pitcairn Pitcairn Johnston Atoll Johnston Atoll Johnston Atoll Johnston Atoll Johnston Atoll Johnston Atoll Johnston Atoll Johnston Atoll Johnston Atoll

3

Setting the Scene Setting the Scene

4

DRM Investment into Future

• Disasters are a development issue, affects

– Economic costs

• assets and infrastructure
• basic service delivery – water, health, education
• opportunity costs

– Government’s capacity to meet National Development Goals – Capacity of households to meet their basic needs – water, food and shelter (poverty and hardship)

5

DRM Challenges

• Disaster treated as environmental and or

humanitarian issue

• Sectoral and piece-meal approaches
• Weak national institutions and governance

structures

• Disaster management seen as government/aid

donor responsibility

• > reliance on donor support
• Limited national budget allocated for DRR
• Perverse incentive to wait for disaster

management support post disaster

6

Setting the Scene

• Ongoing and increasing vulnerability of

Pacific Island nations and communities to the impacts of disasters.

• Led to increased national and regional

commitments to disaster risk reduction and disaster management on an ‘all hazards’ basis in support of sustainable development

7

Regional and International Commitments wrt DRM

• Yokohama Strategy for a Safer World (1994) and the International

Strategy for Disaster Reduction (ISDR).

• Forum Economic Ministers and the Forum Leaders acknowledged

disaster as a development issue in 2003

• Hyogo Framework for Action 2005 – 2015
• Regional Framework for Action for DRR and DM 2005 -2015
• Pacific Islands Framework of Action on Climate Change (PIFAC)

2006-2015

• Kalibobo Road Map of the Pacific Plan approved by Forum Leaders

in 2005, called for operationalisation of regional frameworks at the national level to assist member countries to develop national capacity for an integrated DRM approach that focuses on

– preventative measures to minimise risks, – preparedness in the event of a hazardous event, – effective and timely post disaster response and rehabilitation

8

Regional Framework for Action

The Framework has an all hazards approach supporting sustainable

• development. All phases of disaster risk management cycle are

reflected in the six thematic areas of the Framework: 1) Governance – Organisational, Institutional, Policy and Decision- making Frameworks 2) Knowledge, Information, Public Awareness and Education 3) Analysis And Evaluation Of Hazards, Vulnerabilities and Elements at Risk 4) Effective Preparedness, Response And Recovery 5) Effective, Integrated And People-focused Early Warning Systems 6) Reduction Of Underlying Risk Factors

9

• Established in February 2006 to assist PICs implement the Pacific DRM

Framework for Action

• ~ thirty regional and international organisations.
• committed to assist and support PICs to develop and to implement their

DRM National Action Plans (NAP), which will seek to identify and address national DRM priority needs.

• Main objectives are to:

– Provide regional support for the development and implementation of National Action Plans – Establish and sustain a regional network of partners working in disaster risk management to improve regional cooperation, coordination and collaboration. – Strengthen the key thematic areas identified in the Pacific Framework for Action – Monitor and evaluate national progress against the targets of these national action plans. – Reduce duplication of effort and to ensure that assistance is built on the efforts and experiences of each other

10

National Action Plan (NAP)

• National adaptation of the Regional Framework

for Action

• Whole-of-country approach to ensure

commitment at national, local and community or village level

• Identify DRR and DM priorities
• Develop a 3-year implementation programme

– In line with reporting requirements under the Kalibobo Roadmap of the Pacific Plan

• Develop an national indicative programme with

specific activities and costs

11

Example from Vanuatu

• Theme: Information, Information System and Knowledge

Management

• Strategy: Understand hazards, vulnerabilities, and

communities at risk (hazard-scape) as a basis for disaster risk reduction and disaster management

• Action: Conduct hazard and vulnerability assessments,

including assessment of potential impacts of particular scale

• f disaster event on ‘at risk’ communities, for input to sector

planning for disaster risk reduction and disaster management.

• Result: Understanding the extent and scale of community

vulnerability to hazards, to inform decisions related to DRR&DM.

• Indicator: Adaptation and risk reduction measures

implemented.

12

Samoa - Natural Disasters from 1964 - 2005

• * Reported

Source of data: "EM-DAT: The OFDA/CRED International Disaster Database Université catholique de Louvain, Brussels, Belgium" / Data version: v06.06

13

Samoa – Recent Events

Damage USD??

power lines on Savai'I Extensive tidal damage coastal areas Faleolo International Airport closed during and after cyclone

TC Olaf (2005)

~ US$30 million (about 12% of GDP) [World Bank, 2004] trees, crops and coastal infrastructure damaged Power, water, transport and other services disrupted several houses destroyed no fatalities

TC Heta (2004)

~ USD 4 million [Yeo, 2001] ~ 5,000 affected

Flood (2001) Estimated Economic Costs (Reported) Impacts Disaster Type

14

Flood Modelling and Mapping

Flood hydrology

• Records of annual maximum flow
• >100 years Rainfall intensity data

Model as peak flow (m3/s) Flood modeling

• 1-D model – cross sections

Floodplain mapping

• Flood depths and flood hazard map

15

Model of the Vaisigano

River transect across the floodplain using RTK GPS

Vaisig 3bridges + 4weirs Plan: 3brdge+4weir 03/08/2006

Cross sections Leone Bridge Vaisigano Bridge Leone Bridge

River flow 1D HEC-RAS Output of model/CS = water depth, velocity

16

Flood Depth Maps

1 in 20 year 1 in 100 year

Depth of Flooding (m)

0 - 0.5 0.5 - 1.0 1.0 - 2.0 > 2.0

17

Flood Hazard Maps

1 in 20 years 1 in 100 years

Degree of Flood Hazard

Low - Caution Moderate - Dangerous for children Significant - Dangerous for most people Extreme - Dangerous for all

Vertical Mapper Create TIN: Flood depth (d) Flood velocity (v) Grid Tools H = d x v

18

Assessing Flood Risks

350 1634 1 in 100 342 1596 1 in 50 329 1536 1 in 20 296 1382 1 in 5 244 1139 1 in 2 Buildings @ risk (Pacific Cities) People @ risk (Census) Return period

• Estimate impacts to

people and infrastructure

• Benefit-Cost Analysis

19

Assessing Mitigation Options

• Structural :

– Flood walls and embankments. – By-pass channel. – Upstream flood storage. – Increasing channel conveyance. – Flood proofing of houses – Improving channel maintenance. – Pumping.

• Non-Structural

– Floodplain zoning & Development control – Flood forecasting and warning – Flood insurance – Flood preparedness and response plans – Public Awareness – Land use change

20

Flood proofing of buildings

• design and construction of buildings.
• Raised floor levels above a flood with a

specified return period.

1in 50 year flood level (2% chance of occurring in a year)

Raised floor height

21

• 44.38

2.22 8.07 0.53 Elevated floor heights: Existing homes New homes 1.92 1.72 Improved forecasting system 0.09 0.01 Diversion channel 0.64 0.11 Floodwalls Maximum Minimum Flood measure

E.g. Estimated for every tala invested in constructing homes with raised floor heights, a minimum WST$2.22 and a maximum of WST$44 is avoided in future flood damages

22

Wave Impacts of TC Heta 2004 at Alofi, Niue

22

Coastal Development Policy Other activities Review of the Niue National Disaster Plan Including an operational exercise to test National, government and village response plans

23

Landslides Solomon Islands 2007 Landslides Solomon Islands 2007

23

Hazard and vulnerability mapping Hazard and vulnerability mapping to support to support Earthquake and Tsunami Earthquake and Tsunami -

• Recovery and Rehabilitation effort

Recovery and Rehabilitation effort

24

Monitoring Coastal Changes

Development planning Feasibility of structural coastal protection, constructing permanent structures near coast

25

Pacific Islands Applied Geoscience Commission

Regional DRM Resources Regional DRM Resources

26

Resources

• TA for post disaster assessments
• TA for hazard mapping/risk assessment
• Support of NAP process
• GIS, GPS and remote sensing training
• High-resolution satellite imagery
• Educational resource materials
• Pacific Disaster Net

www.pacificdisaster.net

• MapServers
• Pacific DRM Training

Programme (TAF/OFD)
