Digital Medicine I Lists, strings, loops Hans-Joachim Bckenhauer - - PowerPoint PPT Presentation

Departement Informatik

Digital Medicine I

Lists, strings, loops

Hans-Joachim Böckenhauer Dennis Komm

Autumn 2020 – October 15, 2020

Strings

Repetition

Strings

Strings are “lists of characters” (there are differences) Characters correspond (mostly) to keys on keyboard Strings are written in quotation marks Access to single characters using brackets String word = "HELLO WORLD"

word[0] is first character word[1] is second character

. . .

word[len(word)-1] is last character

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 1 / 40

Strings – Operators

Addition Zahlen: Arithmetische Operation Listen und Strings: Zusammenfügen (bei Strings existiert kein append)

daten = [1, 4, 6] daten2 = daten + [5] satz = "Guten Tag" satz2 = satz + ", Urs" satz3 = satz2 + "."

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 2 / 40

Strings – Operators

Addition Zahlen: Arithmetische Operation Listen und Strings: Zusammenfügen (bei Strings existiert kein append)

daten = [1, 4, 6] daten2 = daten + [5] satz = "Guten Tag" satz2 = satz + ", Urs" satz3 = satz2 + "."

Multiplikation Zahlen: Arithmetische Operation Listen und Strings: Zusammenfügen

daten = [2, 3] * 5 satz = "HA" * 3

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 2 / 40

Characters – The Unicode Table

0–18 19–37 38–56 57–75 76–94 95–113 114–127 Dec. Char. Dec. Char. Dec. Char. Dec. Char. Dec. Char. Dec. Char. Dec. Char. NUL 19 DC3 38 & 57 9 76 L 95 _ 114 r 1 SOH 20 DC4 39 ’ 58 : 77 M 96 ‘ 115 s 2 STX 21 NAK 40 ( 59 ; 78 N 97 a 116 t 3 ETX 22 SYN 41 ) 60 < 79 O 98 b 117 u 4 EOT 23 ETB 42 * 61 = 80 P 99 c 118 v 5 ENQ 24 CAN 43 + 62 > 81 Q 100 d 119 w 6 ACK 25 EM 44 , 63 ? 82 R 101 e 120 x 7 BEL 26 SUB 45

• 64

@ 83 S 102 f 121 y 8 BS 27 ESC 46 . 65 A 84 T 103 g 122 z 9 HT 28 FS 47 / 66 B 85 U 104 h 123 { 10 LF 29 GS 48 67 C 86 V 105 i 124 | 11 VT 30 RS 49 1 68 D 87 W 106 j 125 } 12 FF 31 US 50 2 69 E 88 X 107 k 126 ~ 13 CR 32 SP 51 3 70 F 89 Y 108 l 127 DEL 14 SO 33 ! 52 4 71 G 90 Z 109 m . . . 15 SI 34 "’ 53 5 72 H 91 [ 110 n 16 DLE 35 # 54 6 73 I 92 \ 111

• 17

DC1 36 $ 55 7 74 J 93 ] 112 p 18 DC2 37 % 56 8 75 K 94 ˆ 113 q Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 3 / 40

Characters – The Unicode Table

Use functions ord() and chr()

• rd(x) returns position of character x in Unicode table

chr(y) returns character at position y in Unicode table

x = input("Enter a character: ") print("The character", x, "is at position", ord(x))

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 4 / 40

Exercise – Print Characters

Write a program that

• utputs the first 26 uppercase letters

uses a for-loop to this end Recall The letter A is located at position 65 in the Unicode table

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 5 / 40

Exercise – Print Characters

for i in range(65,91): print(chr(i))

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 6 / 40

Caesar Encryption

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 7 / 40

Gallia est omnis divisa in partes tres, quarum unam incolunt Belgae, aliam Aquitani, tertiam, qui ipsorum lingua Celtae, nostra Galli appellantur. Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 7 / 40

Gallia est omnis divisa in partes tres, quarum unam incolunt Belgae, aliam Aquitani, tertiam, qui ipsorum lingua Celtae, nostra Galli appellantur. Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 7 / 40

Insecure channel

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 7 / 40

Symmetric Encryption

Sender Recipient

plaintext Encryption ciphertext Communication medium

(messenger, internet, . . . )

ciphertext Decryption plaintext

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 8 / 40

Caesar Encryption

Situation Parties A and B want to communicate over an insecure channel, this time using Caesar encryption Shared key k as number between 1 and 25

A encrypts message by adding k to each character A sends encrypted message to B B decrypts message by subtracting k from each character

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 9 / 40

Caesar Encryption

Shift characters by fixed value k by adding k

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 10 / 40

Caesar Encryption

Shift characters by fixed value k by adding k Example A B C D E F G H I J K L M W X Y Z A B C D E F G H I N O P Q R S T U V W X Y Z J K L M N O P Q R S T U V

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 10 / 40

Caesar Encryption

Shift characters by fixed value k by adding k Example A B C D E F G H I J K L M W X Y Z A B C D E F G H I N O P Q R S T U V W X Y Z J K L M N O P Q R S T U V Plaintext: HELLO WORLD Ciphertext: DAHHK SKNHZ

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 10 / 40

Caesar Encryption

• 1. Entered letter is Unicode character between A and Z

A B . . . W X Y Z 65 66 . . . 87 88 89 90

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 11 / 40

Caesar Encryption

• 1. Entered letter is Unicode character between A and Z

A B . . . W X Y Z 65 66 . . . 87 88 89 90

• 2. Subtract 65 so that the result is between 0 and 25

A B . . . W X Y Z 1 . . . 22 23 24 25

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 11 / 40

Caesar Encryption

• 1. Entered letter is Unicode character between A and Z

A B . . . W X Y Z 65 66 . . . 87 88 89 90

• 2. Subtract 65 so that the result is between 0 and 25

A B . . . W X Y Z 1 . . . 22 23 24 25

• 3. Now add key (for instance, 3) and compute modulo 26

A B . . . W X Y Z 3 4 . . . 25 1 2

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 11 / 40

Caesar Encryption

• 1. Entered letter is Unicode character between A and Z

A B . . . W X Y Z 65 66 . . . 87 88 89 90

• 2. Subtract 65 so that the result is between 0 and 25

A B . . . W X Y Z 1 . . . 22 23 24 25

• 3. Now add key (for instance, 3) and compute modulo 26

A B . . . W X Y Z 3 4 . . . 25 1 2

• 4. Finally add 65 to the result

A B . . . W X Y Z 68 69 . . . 90 65 66 67

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 11 / 40

Euclidean Division (Modulo Operation)

Using “%, ” we obtain the residue of the integer division Analogously, “//” the part before the decimal point

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 12 / 40

Euclidean Division (Modulo Operation)

Using “%, ” we obtain the residue of the integer division Analogously, “//” the part before the decimal point

10 % 3 = 1,

because 9 = 3 · 3

10 % 4 = 2,

because 8 = 4 · 2

11 // 5 = 2,

because 10 = 5 · 2

23 // 4 = 5,

because 20 = 4 · 5

12 % 3 = 0,

because 12 = 4 · 3

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 12 / 40

Euclidean Division (Modulo Operation)

Using “%, ” we obtain the residue of the integer division Analogously, “//” the part before the decimal point

10 % 3 = 1,

because 9 = 3 · 3

10 % 4 = 2,

because 8 = 4 · 2

11 // 5 = 2,

because 10 = 5 · 2

23 // 4 = 5,

because 20 = 4 · 5

12 % 3 = 0,

because 12 = 4 · 3 If x % y == 0, x is divided by y

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 12 / 40

Exercise – Caesar Encryption

Write a program that runs through a given string decrypts each letter with a key k tries out each key k uses the following formula e = (v − 65 − k) % 26 + 65 Decrypt the ciphertext

DLUUQLTHUKSHBAOLBYLRHYBMANPIALZZJOVNNP

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 13 / 40

Exercise – Caesar Encryption

for k in range(0, 26): for item in ciphertext: print(chr((ord(item) - 65 - k) % 26 + 65), end="") print() for k in range(0, 26): for i in range(0, len(ciphertext)): print(chr((ord(ciphertext[i]) - 65 - k) % 26 + 65), end="") print()

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 14 / 40

Changing the Step Size

Loops over Lists – Larger Steps

Traverse a list with steps of length 2

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 15 / 40

Loops over Lists – Larger Steps

Traverse a list with steps of length 2

data = [5, 1, 4, 3] for i in range(0, len(data), 2): print(data[i])

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 15 / 40

Loops over Lists – Larger Steps

Traverse a list with steps of length 2

data = [5, 1, 4, 3] for i in range(0, len(data), 2): print(data[i])

Output All elements at even positions from 0 up to at most len(data) are output

➯ 5,4

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 15 / 40

The Syntax of range

for i in range(start, end, step)

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 16 / 40

The Syntax of range

for i in range(start, end, step)

Iteration over all positions from start up to end-1 with step length of step

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 16 / 40

The Syntax of range

for i in range(start, end, step)

Iteration over all positions from start up to end-1 with step length of step Shorthand notation

for i in range(start,end) ⇐ ⇒ for i in range(start,end,1)

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 16 / 40

The Syntax of range

for i in range(start, end, step)

Iteration over all positions from start up to end-1 with step length of step Shorthand notation

for i in range(start,end) ⇐ ⇒ for i in range(start,end,1)

Another shorthand notation

for i in range(end) ⇐ ⇒ for i in range(0, end)

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 16 / 40

Improvement of Caesar Encryption

Use two keys alternatingly for even and odd positions

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 17 / 40

Improvement of Caesar Encryption

Use two keys alternatingly for even and odd positions

k = int(input("First key: ")) l = int(input("Second key: ")) x = input("Text (only uppercase, even length): ") for i in range(0, len(x), 2): print(chr((ord(text[i])-65 + k) % 26 + 65), end="") print(chr((ord(text[i+1])-65 + l) % 26 + 65), end="") print()

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 17 / 40

Improvement of Caesar Encryption

Use two keys alternatingly for even and odd positions

k = int(input("First key: ")) l = int(input("Second key: ")) x = input("Text (only uppercase, even length): ") for i in range(0, len(x), 2): print(chr((ord(text[i])-65 + k) % 26 + 65), end="") print(chr((ord(text[i+1])-65 + l) % 26 + 65), end="") print()

Still Caesar encryption remains insecure

➯ Project 1

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 17 / 40

Logical Values

Boolean Values and Relational Operators

Boolean Values and Variables

Boolean expressions can take on one of two values F or T

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 18 / 40

Boolean Values and Variables

Boolean expressions can take on one of two values F or T F corresponds to “false” T corresponds to “true”

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 18 / 40

Boolean Values and Variables

Boolean expressions can take on one of two values F or T F corresponds to “false” T corresponds to “true”

George Boole [Wikimedia] Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 18 / 40

Boolean Values and Variables

Boolean expressions can take on one of two values F or T F corresponds to “false” T corresponds to “true”

George Boole [Wikimedia]

Boolean variables in Python represent “logical values” Domain {False, True}

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 18 / 40

Boolean Values and Variables

Boolean expressions can take on one of two values F or T F corresponds to “false” T corresponds to “true”

George Boole [Wikimedia]

Boolean variables in Python represent “logical values” Domain {False, True} Example

b = True # Variable with value True

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 18 / 40

Relational Operators

x < y

(smaller than) number type × number type → {False, True}

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 19 / 40

Relational Operators

x < y

(smaller than)

b = (1 < 3) # b =

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 19 / 40

Relational Operators

x < y

(smaller than)

b = (1 < 3) # b = True

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 19 / 40

Relational Operators

x >= y

(greater than)

x = 0 b = (x >= 3) # b =

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 19 / 40

Relational Operators

x >= y

(greater than)

x = 0 b = (x >= 3) # b = False

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 19 / 40

Relational Operators

x == y

(equals)

x = 4 b = (x % 3 == 1) # b =

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 19 / 40

Relational Operators

x == y

(equals)

x = 4 b = (x % 3 == 1) # b = True

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 19 / 40

Relational Operators

x != y

(unequal to)

x = 1 b = (x != 2 * x - 1) # b =

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 19 / 40

Relational Operators

x != y

(unequal to)

x = 1 b = (x != 2 * x - 1) # b = False

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 19 / 40

Logical Values

Boolean Functions and Logical Operators

Boolean Functions in Mathematics

Boolean function

f : {F, T}2 → {F, T}

F corresponds to “false” T corresponds to “true”

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 20 / 40

a ∧ b

“logical and”

f : {F, T}2 → {F, T}

F corresponds to “false” T corresponds to “true” a b a ∧ b

F F F F T F T F F T T T

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 21 / 40

Logical Operator and

a and b

(logical and)

{False, True} × {False, True} → {False, True}

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 22 / 40

Logical Operator and

a and b

(logical and)

n = -1 p = 3 c = (n < 0) and (0 < p) # c =

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 22 / 40

Logical Operator and

a and b

(logical and)

n = -1 p = 3 c = (n < 0) and (0 < p) # c = True

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 22 / 40

a ∨ b

“logical or”

f : {F, T}2 → {F, T}

F corresponds to “false” T corresponds to “true” a b a ∨ b

F F F F T T T F T T T T

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 23 / 40

a ∨ b

“logical or”

f : {F, T}2 → {F, T}

F corresponds to “false” T corresponds to “true” a b a ∨ b

F F F F T T T F T T T T

The logical or is always inclusive: a or b or both

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 23 / 40

Logical Operator or

a or b

(logical or)

{False, True} × {False, True} → {False, True}

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 24 / 40

Logical Operator or

a or b

(logical or)

n = 1 p = 0 c = (n < 0) or (0 < p) # c =

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 24 / 40

Logical Operator or

a or b

(logical or)

n = 1 p = 0 c = (n < 0) or (0 < p) # c = False

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 24 / 40

¬b

“logical not”

f : {F, T} → {F, T}

F corresponds to “false” T corresponds to “true” b ¬b

F T T F

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 25 / 40

Logical Operator not

not b

(logical not)

{False, True} → {False, True}

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 26 / 40

Logical Operator not

not b

(logical not)

n = 1 a = not (n < 0) # a =

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 26 / 40

Logical Operator not

not b

(logical not)

n = 1 a = not (n < 0) # a = True

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 26 / 40

Logical Values

Precedences

Precedences

not b and a

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 27 / 40

Precedences

not b and a

• (not b) and a

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 27 / 40

Precedences

a and b or c and d

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 27 / 40

Precedences

a and b or c and d

• (a and b) or (c and d)

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 27 / 40

Precedences

a or b and c or d

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 27 / 40

Precedences

a or b and c or d

• a or (b and c) or d

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 27 / 40

Precedences

7 + x < y and y != 3 * z or not b

The unary logical operator not

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 28 / 40

Precedences

7 + x < y and y != 3 * z or (not b)

The unary logical operator not

➯ provides a stronger binding than binary arithmetic operators

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 28 / 40

Precedences

(7 + x) < y and y != (3 * z) or (not b)

The unary logical operator not

➯ provides a stronger binding than binary arithmetic operators ➯ These bind stronger than relational operators

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 28 / 40

Precedences

((7 + x) < y) and (y != (3 * z)) or (not b)

The unary logical operator not

➯ provides a stronger binding than binary arithmetic operators ➯ These bind stronger than relational operators ➯ and these bind stronger than binary logical operators

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 28 / 40

Precedences

(((7 + x) < y) and (y != (3 * z))) or (not b)

The unary logical operator not

➯ provides a stronger binding than binary arithmetic operators ➯ These bind stronger than relational operators ➯ and these bind stronger than binary logical operators

Some parentheses on the previous slides were actually redundant, but should still be used

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 28 / 40

DeMorgan Rules

not (a and b) == (not a or not b)

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 29 / 40

DeMorgan Rules

not (a and b) == (not a or not b) not (a or b) == (not a and not b)

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 29 / 40

DeMorgan Rules

not (a and b) == (not a or not b) not (a or b) == (not a and not b)

Examples (not black and not white) == not (black or white) not (rich and beautiful) == (poor or ugly)

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 29 / 40

Application – either . . . or (XOR)

(a or b) and not (a and b)

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 30 / 40

Application – either . . . or (XOR)

(a or b) and not (a and b)

a or b, and not both

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 30 / 40

Application – either . . . or (XOR)

(a or b) and not (a and b)

a or b, and not both

(a or b) and (not a or not b)

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 30 / 40

Application – either . . . or (XOR)

(a or b) and not (a and b)

a or b, and not both

(a or b) and (not a or not b)

a or b, and one of them not

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 30 / 40

Application – either . . . or (XOR)

(a or b) and not (a and b)

a or b, and not both

(a or b) and (not a or not b)

a or b, and one of them not

not (not a and not b) and not (a and b)

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 30 / 40

Application – either . . . or (XOR)

(a or b) and not (a and b)

a or b, and not both

(a or b) and (not a or not b)

a or b, and one of them not

not (not a and not b) and not (a and b)

not none and not both

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 30 / 40

Application – either . . . or (XOR)

(a or b) and not (a and b)

a or b, and not both

(a or b) and (not a or not b)

a or b, and one of them not

not (not a and not b) and not (a and b)

not none and not both

not ((not a and not b) or (a and b))

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 30 / 40

Application – either . . . or (XOR)

(a or b) and not (a and b)

a or b, and not both

(a or b) and (not a or not b)

a or b, and one of them not

not (not a and not b) and not (a and b)

not none and not both

not ((not a and not b) or (a and b))

not: both or none

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 30 / 40

Control Structures

Control Flow

So far. . . Up to now linear (from top to bottom)

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 31 / 40

Control Flow

So far. . . Up to now linear (from top to bottom)

for loop to repeat blocks x = int(input("Input: ")) for i in range(1, x+1): print(i*i)

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 31 / 40

Control Structures

Selection Statements

Selection Statements

Implement branches

if statement if-else statement if-elif-else statement (later)

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 32 / 40

if Statement

if condition:

statement

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 33 / 40

if Statement

if condition:

statement

x = int(input("Input: ")) if x % 2 == 0: print("even")

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 33 / 40

if Statement

if condition:

statement

x = int(input("Input: ")) if x % 2 == 0: print("even")

If condition is true, then statement is executed

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 33 / 40

if Statement

if condition:

statement

x = int(input("Input: ")) if x % 2 == 0: print("even")

If condition is true, then statement is executed statement:

arbitrary statement body of the if-Statement

condition: Boolean expression

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 33 / 40

if-else Statement

if condition:

statement1

else:

statement2

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 34 / 40

if-else Statement

if condition:

statement1

else:

statement2

x = int(input("Input: ")) if x % 2 == 0: print("even") else: print("odd")

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 34 / 40

if-else Statement

if condition:

statement1

else:

statement2

x = int(input("Input: ")) if x % 2 == 0: print("even") else: print("odd")

If condition is true, then statement1 is executed,

• therwise statement2 is executed

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 34 / 40

if-else Statement

if condition:

statement1

else:

statement2

x = int(input("Input: ")) if x % 2 == 0: print("even") else: print("odd")

If condition is true, then statement1 is executed,

• therwise statement2 is executed

condition: Boolean expression statement1: body of the if-branch statement2: body of the else-branch

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 34 / 40

Layout

x = int(input("Input: ")) if x % 2 == 0: print("even") else: print("odd")

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 35 / 40

Layout

x = int(input("Input: ")) if x % 2 == 0: print("even") else: print("odd")

Indentation Indentation

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 35 / 40

Control Structures

while Loops

while Loops

while condition:

statement statement:

arbitrary statement body of the while loop

condition: Boolean expression

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 36 / 40

while Loops

while condition:

statement

Indentation

statement:

arbitrary statement body of the while loop

condition: Boolean expression

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 36 / 40

while Loops

while condition:

statement condition is evaluated True: iteration starts

statement is executed

False: while loop ends

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 37 / 40

while Loops

s = 0 i = 1 while i <= 2: s = s + i i = i + 1 i

condition

s

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 38 / 40

while Loops

s = 0 i = 1 while i <= 2: s = s + i i = i + 1 i

condition

s i = 1

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 38 / 40

while Loops

s = 0 i = 1 while i <= 2: s = s + i i = i + 1 i

condition

s i = 1 i <= 2?

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 38 / 40

while Loops

s = 0 i = 1 while i <= 2: s = s + i i = i + 1 i

condition

s i = 1

true

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 38 / 40

while Loops

s = 0 i = 1 while i <= 2: s = s + i i = i + 1 i

condition

s i = 1

true

s = 1

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 38 / 40

while Loops

s = 0 i = 1 while i <= 2: s = s + i i = i + 1 i

condition

s i = 1

true

s = 1 i = 2

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 38 / 40

while Loops

s = 0 i = 1 while i <= 2: s = s + i i = i + 1 i

condition

s i = 1

true

s = 1 i = 2 i <= 2?

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 38 / 40

while Loops

s = 0 i = 1 while i <= 2: s = s + i i = i + 1 i

condition

s i = 1

true

s = 1 i = 2

true

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 38 / 40

while Loops

s = 0 i = 1 while i <= 2: s = s + i i = i + 1 i

condition

s i = 1

true

s = 1 i = 2

true

s = 3

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 38 / 40

while Loops

s = 0 i = 1 while i <= 2: s = s + i i = i + 1 i

condition

s i = 1

true

s = 1 i = 2

true

s = 3 i = 3

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 38 / 40

while Loops

s = 0 i = 1 while i <= 2: s = s + i i = i + 1 i

condition

s i = 1

true

s = 1 i = 2

true

s = 3 i = 3 i <= 2?

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 38 / 40

while Loops

s = 0 i = 1 while i <= 2: s = s + i i = i + 1 i

condition

s i = 1

true

s = 1 i = 2

true

s = 3 i = 3

false

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 38 / 40

while Loops

s = 0 i = 1 while i <= 2: s = s + i i = i + 1 i

condition

s i = 1

true

s = 1 i = 2

true

s = 3 i = 3

false

s = 3

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 38 / 40

Incrementation of Variables

Use simplified syntax for changing values of variables

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 39 / 40

Incrementation of Variables

Use simplified syntax for changing values of variables

n = n + 1 is written as n += 1

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 39 / 40

Incrementation of Variables

Use simplified syntax for changing values of variables

n = n + 1 is written as n += 1 n = n + i is written as n += i

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 39 / 40

Incrementation of Variables

Use simplified syntax for changing values of variables

n = n + 1 is written as n += 1 n = n + i is written as n += i n = n - 15 is written as n -= 15

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 39 / 40

Incrementation of Variables

Use simplified syntax for changing values of variables

n = n + 1 is written as n += 1 n = n + i is written as n += i n = n - 15 is written as n -= 15 n = n * j is written as n *= j

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 39 / 40

Incrementation of Variables

Use simplified syntax for changing values of variables

n = n + 1 is written as n += 1 n = n + i is written as n += i n = n - 15 is written as n -= 15 n = n * j is written as n *= j n = n ** 4 is written as n **= 4

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 39 / 40

Incrementation of Variables

Use simplified syntax for changing values of variables

n = n + 1 is written as n += 1 n = n + i is written as n += i n = n - 15 is written as n -= 15 n = n * j is written as n *= j n = n ** 4 is written as n **= 4

. . .

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 39 / 40

The Jump Statements break

break

Immediately leave the enclosing loop Useful in order to be able to break a loop “in the middle”

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 40 / 40

The Jump Statements break

break

Immediately leave the enclosing loop Useful in order to be able to break a loop “in the middle”

s = 0 while True: x = int(input("Enter a positive number, abort with 0: ")) if x == 0: break s += x print(s)

Digital Medicine I – Lists, strings, loops Autumn 2020 Böckenhauer, Komm 40 / 40

Thanks for your attention
