www.dgmachine.com State of Maine www.dgmachine.com Steve Sullivan Vice President Steve@dgmachine.com Cell: 207-653-7922 John Doran Sales Manager Johnd@dgmachine.com Cell: 207-233-4830 Precision Machining Center Welding Technology Center

slide-1
SLIDE 1

www.dgmachine.com

slide-2
SLIDE 2

Welding Technology Center 20 Hutcherson Drive Gorham, Me 04038 (207) 854-9766 Precision Machining Center 50 Eisenhower Drive Westbrook, Me 04092 (207) 854-1500 State of Maine

www.dgmachine.com Steve Sullivan Vice President Steve@dgmachine.com Cell: 207-653-7922 John Doran Sales Manager Johnd@dgmachine.com Cell: 207-233-4830

slide-3
SLIDE 3

D&G by the Sea

Portland Maine How to reach us: Portland International Jetport (PWM)

slide-4
SLIDE 4

D&G Machine Products Inc.

DUNS number: 04-736-3932 Federal ID: 01-0282435 Cage Code: 1WUK2

NAICS Codes: 332710 / 333518 / 332322 / 336992 / 336600 / 336400 Market Sector Approvals:

Aerospace / Launch Programs - Aircraft Component Manufacturing - Military Defense Contracts Power Generation – Turbine Component Supplier - Semi-conductor – Vacuum Components Pulp and Paper Industry - Sheet Metal Supplier to Industrial America

slide-5
SLIDE 5

D&G Products Presentation

V 501 Launch – Nrol-39 Mission D&G Precision Component Takes-off

slide-6
SLIDE 6

Introduction

 D&G Machine was incorporated in 1967.

Classified as a Small Business

 Currently staffed with 120 employees with continued growth in

both facilities.

 D&G Westbrook Facility is 95,000 Sq. ft.

Precision Manufacturing Center

 D&G Gorham Facility is 55,000 Sq. ft.

Welding Technology Center

 Certified ISO9001:2008 + AS9001C Company + ITAR compliant.

slide-7
SLIDE 7

Market Sectors

 Aerospace – Launch Programs

Sikorsky / United Launch Alliance / Klune / Bombardier / GKN / Gulfstream

 Military Defense Contracts

BAE Systems / General Dynamics / Raytheon IDS / Raytheon SAS

 Power Generation – Turbine Component Supplier

General Electric / Siemens

 Semi-conductor – Vacuum Components

Axcelis / Varian

 Pulp and Paper Industry

International Paper / Sappi

 Sheet Metal Supplier to Industrial America

Military / Defense / Medical / Commercial / Industrial

slide-8
SLIDE 8

Westbrook Facility Capabilities

 CNC 3-4-5 Axis Milling  CNC Turning Centers  CMM inspection Equipment (50” x 118” x 39.4” high)  Project Management – JoBBoss MRP System  Engineering Services - Solid Works, Katia, Pro-E, Autocad  Quality Management – CMM: 59” x 118” x 40” – accuracy .0005”  System Integration / Commercial Solutions

slide-9
SLIDE 9

Gorham Facility Capabilities

 CNC Plasma Cutting  CNC Laser Cutting (3/8” Alum. – 5/8” Steel)  Plate Shearing and Cutting  Metal Rolling and Mechanical Forming  Welders are certified to ASME, AWS, NAVSEA  Sheet Metal and Fabrication Assemblies

slide-10
SLIDE 10

Material Capabilities

 Specialty Alloys

 Titanium, Inconel, Magnesium

 Aluminum

 Plate and Castings

 High Strength Alloys

 4100 Series, Chrome Molly

 Stainless Steels

 17-4, 15-5, 400 series, 300 series

 Carbon Steel

slide-11
SLIDE 11

Value Added Capabilities

 Wet Paint and Prime  Sand Blasting / Glass Bead Blasting  Heat Treat Oven / Stress relief  NDT and Load testing  Liquid / Dye Penetrant Testing  Magnetic Partial Inspection

slide-12
SLIDE 12

Aerospace – Aluminum Casting Program CMM – Brown & Sharp Excel 50” x 118” x 39.4” work envelope

slide-13
SLIDE 13

Aerospace – Precision sheet metal assembly.

slide-14
SLIDE 14

Precision Aluminum Machining – from solid 6061T6 Plate

slide-15
SLIDE 15

Aerospace – Precision machining from solid aluminum block Nitrogen retro fairing relief valves – Delta Rocket

slide-16
SLIDE 16

Program Work - Machining, Fabricating, Assembly, Markings.

slide-17
SLIDE 17

Precision Turning – 64” diameter thin wall Aluminum– Rocket Inter-stage Spacer

slide-18
SLIDE 18

Aluminum Floor Plate – 6” x 98” x 98”

slide-19
SLIDE 19

Aluminum mold – Mirror Finished Grooves

slide-20
SLIDE 20
slide-21
SLIDE 21

Defense – Multi Component Bolt Together assembly

slide-22
SLIDE 22

Precision Finished Assembly

slide-23
SLIDE 23

Defense – Multi component Bolt together Assembly

slide-24
SLIDE 24

Precision Finished Assembly

slide-25
SLIDE 25

Aerospace Panels – Machined from solid billet

slide-26
SLIDE 26

Aerospace Propulsion Panels Machining , Hardware Insertion

slide-27
SLIDE 27

Aerospace – Machined Aircraft Door

slide-28
SLIDE 28

Semi-conductor - 18” Thick Cast Machined

slide-29
SLIDE 29

Machine gun silencer – Solid Bar Machining

slide-30
SLIDE 30

Solid Forge Machining

slide-31
SLIDE 31
slide-32
SLIDE 32

Precision Finished Assembly

slide-33
SLIDE 33

Defense – Precision Finished Assembly

slide-34
SLIDE 34

Oil & Gas – Impeller

slide-35
SLIDE 35

Magnesium Casting – Helicopter Rotor Hub

slide-36
SLIDE 36

Gas Turbine Combustion Case

slide-37
SLIDE 37

Heavy Duty Gas Turbine Engine

slide-38
SLIDE 38

Semi-conductor Vacuum Chamber Heliarc Fusion Welding

slide-39
SLIDE 39

Military Application – Radar Radom

slide-40
SLIDE 40

Radar Application – Precision Finished Assembly

slide-41
SLIDE 41

AGS Firing Shape Assembly – 5 pc. Assy. / 300lbs each

slide-42
SLIDE 42

Firing Shape Assembly – Program Machining / over 600 Assemblies

slide-43
SLIDE 43

Pulp and Paper Application: Machining, Fabrication, Assembly

slide-44
SLIDE 44

Aerospace: Engine Alignment Fixture Stand

slide-45
SLIDE 45

Defense: Gun Test Stand

slide-46
SLIDE 46

Aerospace: Engine Alignment Fixture

slide-47
SLIDE 47

Launch Programs: Assembly Rotation Fixture

slide-48
SLIDE 48

Commercial Application - 5D Carbon Fiber Loom Assy.

slide-49
SLIDE 49

Defense: AGS Gun Test Stand

slide-50
SLIDE 50
slide-51
SLIDE 51
slide-52
SLIDE 52
slide-53
SLIDE 53

D&G Machine – Project Machining, Fabricating, Assembly, and Quality Management

slide-54
SLIDE 54

The Perfect Fit…..

D&G Machine Products Inc. Westbrook, Me Precision Machining

D&G Machine Products Inc. Gorham, Me Welding Technology Center
