SLIDE 1
June 16th - Internet Measurement Village 2020
Detecting
- utages with
telemetry
Alessio Placitelli - @dexterp37
2
Italy, March 11th - 2020
Tales from a mid-pandemic network outage
Public
Detecting outages with telemetry Alessio Placitelli - @dexterp37 - - PowerPoint PPT Presentation
Detecting outages with telemetry Alessio Placitelli - @dexterp37 - - PowerPoint PPT Presentation
Detecting outages with telemetry Alessio Placitelli - @dexterp37 June 16th - Internet Measurement Village 2020 Italy, March 11th - 2020 Tales from a mid-pandemic network outage Public 2 ...failure on a foreign network... Source :
SLIDE 2
SLIDE 3
3
“...failure on a foreign network...”
Source: “Sharing data on Italy’s mid-pandemic internet outage” - https://mzl.la/italy-outage
SLIDE 4
4
Network outage in Italy
How many Firefox desktop users were affected by the mid-pandemic outage?
Public
SLIDE 5
5
NOPE.
These were for something completely different!
Public
SLIDE 6
6
Mozilla Manifesto
Principle 2 https://www.mozilla.org/about/manifesto/
“The internet is a global public resource that must remain open and accessible.”
Public
SLIDE 7
1. Our methodology is open 2. What happened in Italy on March 11th, 2020? 3. What showed up in Jammu & Kashmir in 2019?
Key takeaways
Public
SLIDE 8
8
Telemetry
A quick overview
1. Performance metrics for our products 2. Packaged in pings sent at controlled schedules 3. Following our Lean Data Practices (www.leandatapractices.com)
Public
SLIDE 9
9
Firefox telemetry
How does it work?
Public
1. Relevant metrics travel in the main and health pings. 2. Documentation for metrics and pings is publicly available. 3. probes.telemetry.mozilla.org
SLIDE 10
10
The “main” ping
Schedule and properties
Public
1. Ideally sent once per day around local midnight. 2. Is the main transport for Firefox telemetry. 3. Includes DNS, SSL and TLS metrics...
SLIDE 11
11
The “main” ping
Interesting metrics
Public
1. dns_failed_lookup_time 2. dns_lookup_time 3. ssl_cert_verification_errors 4. http_page_tls_handshake 5. ...
SLIDE 12
12
The “health” ping
Schedule and properties
Public
1. Telemetry health about... telemetry. 2. Extremely small (~800 bytes). 3. Collected at most once per hour in case of problems. 4. Includes the reason why the HTTPS upload failed.
SLIDE 13
13
Our open methodology
From raw data to pretty graphs
Public
SLIDE 14
14
Throw away that IP address!
Right after matching the IP with a country lookup, at ingestion! https://github.com/mozilla/gcp-ingestion/blob/fbfb5d28490a17d4 3329b44a1a8259bbcc0d7b20/ingestion-beam/src/main/java/com/ mozilla/telemetry/Decoder.java#L64L69
Public
SLIDE 15
15
Cleanup: remove “inactive” sessions
Not all the “main” pings are representative. “Who can even open 100 websites in 1 second?”
Public
SLIDE 16
16
Aggregation: step 1 - geographical
Group the data by Country. Drop the data for Countries with too few samples.
Public
SLIDE 17
17
Aggregation: step 2 - counting things!
Count how many sessions reported a metric, within the given timeframe. Example: how many sessions had DNS_LOOKUP_TIME?
Public
SLIDE 18
18
Aggregation: step 3 - create timing profiles
Combine the user-reported time distributions in a single distribution, for a given timeframe. Example: what’s the shape of DNS_LOOKUP_TIME in Italy, today?
Public
SLIDE 19
19
Investigation: look for anomalies in the data
How do certain measures compare against a baseline? Were there anomalous spikes, surges, holes in the time series?
Public
SLIDE 20
20
Jammu & Kashmir - 2019
Network interferences starting from August 5th
Public
SLIDE 21
21
Jammu & Kashmir
How many Firefox desktop users were affected (normalized count)?
Public
Telemetry creation date
Jammu & Kashmir Outside of Jammu & Kashmir
Scaled Daily Active Users
SLIDE 22
22
Jammu & Kashmir
The average time it takes for an unsuccessful DNS resolution, in milliseconds
Public
Telemetry creation date
Jammu & Kashmir Outside of Jammu & Kashmir
Log Scale Time (ms)
SLIDE 23
23
Jammu & Kashmir
The proportion of active session with no DNS resolved
Public
Telemetry creation date
Jammu & Kashmir Outside of Jammu & Kashmir
- Prop. Daily Active Users
SLIDE 24
24
What’s next?
How are we moving this project forward
Public
SLIDE 25
Productionize
- ur datasets
01
SLIDE 26
Validate the data
02
SLIDE 27
Community collaboration
03
SLIDE 28
28
Our team
Special thanks to Rebecca Weiss for advising on the project, and to Hamilton Ulmer for the graphics on the Italian focus Solana Larsen
Editor, Internet Health Report
Saptarshi Guha
Data Scientist
Jochai Ben-Avie
Head of International Public Policy
Alessio Placitelli
Telemetry Engineer, Project Lead
Public
SLIDE 29
Thank you!
Reach out to: outages@mozilla.com
