SLIDE 1
Delta Pointers: Buffer Overflow Checks Without the Checks
Tadde¨ us Kroes & Koen Koning Erik van der Kouwe Herbert Bos Cristiano Giuffrida
June 19, 2018
Preview
buffer[10] secret
2
Delta Pointers: Buffer Overflow Checks Without the Checks Tadde us - - PowerPoint PPT Presentation
Delta Pointers: Buffer Overflow Checks Without the Checks Tadde us - - PowerPoint PPT Presentation
Delta Pointers: Buffer Overflow Checks Without the Checks Tadde us Kroes & Koen Koning Erik van der Kouwe Herbert Bos Cristiano Giuffrida June 19, 2018 Preview buffer[10] secret 2 Preview buffer[10] secret buffer[5] 2 Preview
SLIDE 2
SLIDE 3
Preview
buffer[10] secret
buffer[5]
2
SLIDE 4
Preview
buffer[10] secret
buffer[5] buffer[11]
2
SLIDE 5
Preview
buffer[10] secret
buffer[5] buffer[11]
secret
2
SLIDE 6
Preview
buffer[10] secret
buffer[5] buffer[11]
2
SLIDE 7
Preview
buffer[10] secret
buffer[5] buffer[11]
Automatic! FAST!
- no branches
- no mem access
2
SLIDE 8
Buffer overflows still very common today
3
SLIDE 9
Bounds checking is slow
139%
MPX
94%
SGXBounds
80%
ASan
72%
BaggyBounds
64%
Low-Fat Pointers
% overhead
100 150 50
4
SLIDE 10
What is bounds checking?
void foo(char *buffer, size_t n) { buffer[n] = 10; }
5
SLIDE 11
What is bounds checking?
void foo(char *buffer, size_t n) { buffer[n] = 10; } Attacker-controlled?
5
SLIDE 12
What is bounds checking?
void foo(char *buffer, size_t n) { if (n >= SIZE(buffer)) ERROR("overflow"); buffer[n] = 10; }
A u t
- m
a t i c a l l y i n s e r t e d
5
SLIDE 13
What is bounds checking?
void foo(char *buffer, size_t n) { if (n >= SIZE(buffer)) ERROR("overflow"); buffer[n] = 10; }
Needs metadata
5
SLIDE 14
What is bounds checking?
void foo(char *buffer, size_t n) { if (n >= SIZE(buffer)) ERROR("overflow"); buffer[n] = 10; }
Needs metadata Branching check
5
SLIDE 15
What is bounds checking?
void foo(char *buffer, size_t n) { if (n >= SIZE(buffer)) ERROR("overflow"); buffer[n] = 10; }
Needs metadata Branching check
Overhead!
5
SLIDE 16
What is bounds checking?
void foo(char *buffer, size_t n) { if (n >= SIZE(buffer)) ERROR("overflow"); buffer[n] = 10; }
Needs metadata Branching check
Overhead!
Efficient solution: pointer tagging
5
SLIDE 17
What is bounds checking?
void foo(char *buffer, size_t n) { if (n >= SIZE(buffer)) ERROR("overflow"); buffer[n] = 10; }
Needs metadata Branching check
Overhead!
Efficient solution: pointer tagging Still slow
5
SLIDE 18
Our approach: Delta Pointers
◮ Use pointer tagging
◮ No memory access for metadata lookup
◮ No need for branches
◮ Delegate checks to (off-the-shelf) hardware instead
◮ Focus on common case: upper bound on x86 64
◮ Mitigates all CVEs reported by related work 6
SLIDE 19
Our approach: Delta Pointers
◮ Use pointer tagging
◮ No memory access for metadata lookup
◮ No need for branches
◮ Delegate checks to (off-the-shelf) hardware instead
◮ Focus on common case: upper bound on x86 64
◮ Mitigates all CVEs reported by related work 6
SLIDE 20
Our approach: Delta Pointers
◮ Use pointer tagging
◮ No memory access for metadata lookup
◮ No need for branches
◮ Delegate checks to (off-the-shelf) hardware instead
◮ Focus on common case: upper bound on x86 64
◮ Mitigates all CVEs reported by related work 6
SLIDE 21
Our approach: Delta Pointers
139%
MPX
94%
SGXBounds
80%
ASan
72%
BaggyBounds
64%
Low-Fat Pointers
35%
Delta Pointers
% overhead
100 150 50
7
SLIDE 22
Regular pointers
00 e8 02 0c 40 10 00 00
virtual address ext
48 bit 16 bit
8
SLIDE 23
Regular pointers
00 e8 02 0c 40 10 00 00
virtual address ext
48 bit 16 bit
U p p e r 1 6 b i t s m u s t b e z e r
- 8
SLIDE 24
Regular pointers
00 e8 02 0c 40 10 00 00
virtual address ext
48 bit 16 bit
00 e8 02 0c 40 10 00 01
virtual address ext
48 bit 16 bit
Non-canonical, MMU faults!
8
SLIDE 25
Tagged pointers
00 e8 02 0c 40 10 12 34
virtual address tag
48 bit 16 bit
E n c
- d
e i n f
- r
m a t i
- n
i n u n u s e d b i t s !
9
SLIDE 26
Tagged pointers
02 0c 40 10 12 34 56 78
virtual address tag
32 bit 32 bit
Shrink address space for bigger tags
9
SLIDE 27
Delta Pointers
02 0c 40 10 00 00 00 18
virtual address tag
32 bit 32 bit
size Size=24
10
SLIDE 28
Delta Pointers
02 0c 40 1c 00 00 00 18
virtual address tag
32 bit 32 bit
size Size=24
W h a t a b
- u
t i n t e r n a l p
- i
n t e r s ?
10
SLIDE 29
Delta Pointers
02 0c 40 1c 00 00 00 0c
virtual address tag
32 bit 32 bit
distance
Check upper bound for any pointer
Distance=12
10
SLIDE 30
Delta Pointers
02 0c 40 1c ff ff ff f4
virtual address tag
32 bit 32 bit
- distance
10
SLIDE 31
Delta Pointers
02 0c 40 1c 7f ff ff f4
virtual address tag
32 bit 32 bit
- distance
- verflow bit
Set to 1 if
- ut-of-bounds
10
SLIDE 32
Delta Pointers
02 0c 40 1c 7f ff ff f4
virtual address delta tag
32 bit 32 bit
- distance
- verflow bit
Set to 1 if
- ut-of-bounds
10
SLIDE 33
Instrumentation 02 0c 40 10 0 00 00 00 00
char *p = malloc(24);
11
SLIDE 34
Instrumentation 02 0c 40 10 0 00 00 00 00
char *p = malloc(24);
Distance=24
11
SLIDE 35
Instrumentation 02 0c 40 10 0 00 00 00 00
char *p = malloc(24);
Distance=24
- distance
0 00 00 00 00
11
SLIDE 36
Instrumentation 02 0c 40 10 0 00 00 00 00
char *p = malloc(24);
Distance=24
| (-24 << 32);
0 7f ff ff e8
- 24
11
SLIDE 37
Instrumentation 02 0c 40 27 0 7f ff ff e8
p += 23;
+23
11
SLIDE 38
Instrumentation 02 0c 40 27 0 7f ff ff e8
p += 23;
+23
Replicate arithmetic on tag
11
SLIDE 39
Instrumentation 02 0c 40 27 0 7f ff ff e8
p += 23;
+23
+ (23 << 32);
+23 0 7f ff ff ff
D i s t a n c e = 1
11
SLIDE 40
Instrumentation 02 0c 40 28 1 00 00 00 00
carry
p += 1 + (1 << 32);
+1 +1
Distance=0,
- verflowed!
11
SLIDE 41
Instrumentation 02 0c 40 27 0 7f ff ff ff
p += -1 + (-1 << 32);
- 1
- 1
carry
Distance=1, in-bounds again
11
SLIDE 42
Instrumentation 02 0c 40 27 0 7f ff ff ff
p += -1 + (-1 << 32);
- 1
- 1
carry
Distance=1, in-bounds again
- ne operation!
11
SLIDE 43
Dereferencing an in-bounds pointer
02 0c 40 27 0 7f ff ff ff
12
SLIDE 44
Dereferencing an in-bounds pointer
02 0c 40 27 0 7f ff ff ff ff ff ff ff 1 00 00 00 00
&
Strips away distance
12
SLIDE 45
Dereferencing an in-bounds pointer
02 0c 40 27 0 7f ff ff ff ff ff ff ff 1 00 00 00 00
&
02 0c 40 27 0 00 00 00 00
12
SLIDE 46
Dereferencing an in-bounds pointer
02 0c 40 27 0 7f ff ff ff ff ff ff ff 1 00 00 00 00
&
02 0c 40 27 0 00 00 00 00
Normal (in-bounds) pointer, access OK!
12
SLIDE 47
Dereferencing an out-of-bounds pointer
02 0c 40 2c 1 00 00 00 04
13
SLIDE 48
Dereferencing an out-of-bounds pointer
02 0c 40 2c 1 00 00 00 04 ff ff ff ff 1 00 00 00 00
&
13
SLIDE 49
Dereferencing an out-of-bounds pointer
02 0c 40 2c 1 00 00 00 04 ff ff ff ff 1 00 00 00 00
&
02 0c 40 2c 1 00 00 00 00
13
SLIDE 50
Dereferencing an out-of-bounds pointer
02 0c 40 2c 1 00 00 00 04 ff ff ff ff 1 00 00 00 00
&
Non-canonical pointer, MMU faults!
02 0c 40 2c 1 00 00 00 00
13
SLIDE 51
Implementation
◮ LLVM based prototype for C/C++ ◮ Stack + heap + globals ◮ 32-bit address → 4GB address space ◮ 31-bit distance → 2GB allocations ◮ Instrument NULL pointer with distance = −1 ◮ Optimizations: omit instrumentation on in-bounds pointers
14
SLIDE 52
Pointer tagging breaks things
◮ Uninstrumented libraries
// strdup(ptr); TAG(strdup(MASK(ptr)));
◮ Non-zero NULL pointer ◮ Subtraction, addition, multiplication, vectors, etc. ◮ Incomplete type information (e.g., unions) ◮ Compiler quirks ◮ . . . and more
◮ Solved with TBAA + def-use chain analysis ◮ Details in paper 15
SLIDE 53
Pointer tagging breaks things
◮ Uninstrumented libraries
// strdup(ptr); TAG(strdup(MASK(ptr)));
◮ Non-zero NULL pointer ◮ Subtraction, addition, multiplication, vectors, etc. ◮ Incomplete type information (e.g., unions) ◮ Compiler quirks ◮ . . . and more
◮ Solved with TBAA + def-use chain analysis ◮ Details in paper 15
SLIDE 54
Pointer tagging breaks things
◮ Uninstrumented libraries
// strdup(ptr); TAG(strdup(MASK(ptr)));
◮ Non-zero NULL pointer ◮ Subtraction, addition, multiplication, vectors, etc. ◮ Incomplete type information (e.g., unions) ◮ Compiler quirks ◮ . . . and more
◮ Solved with TBAA + def-use chain analysis ◮ Details in paper 15
SLIDE 55
Pointer tagging breaks things
◮ Uninstrumented libraries
// strdup(ptr); TAG(strdup(MASK(ptr)));
◮ Non-zero NULL pointer ◮ Subtraction, addition, multiplication, vectors, etc. ◮ Incomplete type information (e.g., unions) ◮ Compiler quirks ◮ . . . and more
◮ Solved with TBAA + def-use chain analysis ◮ Details in paper 15
SLIDE 56
Pointer tagging breaks things
◮ Uninstrumented libraries
// strdup(ptr); TAG(strdup(MASK(ptr)));
◮ Non-zero NULL pointer ◮ Subtraction, addition, multiplication, vectors, etc. ◮ Incomplete type information (e.g., unions) ◮ Compiler quirks ◮ . . . and more
◮ Solved with TBAA + def-use chain analysis ◮ Details in paper 15
SLIDE 57
Pointer tagging breaks things
◮ Uninstrumented libraries
// strdup(ptr); TAG(strdup(MASK(ptr)));
◮ Non-zero NULL pointer ◮ Subtraction, addition, multiplication, vectors, etc. ◮ Incomplete type information (e.g., unions) ◮ Compiler quirks ◮ . . . and more
◮ Solved with TBAA + def-use chain analysis ◮ Details in paper 15
SLIDE 58
Evaluation
16
SLIDE 59
Nginx
0.1 0.2 0.3 0.4 0.5 0.6 5 10 15 20 25 30 35 40 45 50 55 60 Latency (ms) Throughput (x1000 reqs/s) Baseline Delta Pointers
3-6% (I/O bound)
17
SLIDE 60
SPEC CPU2006 (C/C++)
0% 25% 50% 75% 100% 400.perlbench 401.bzip2 403.gcc 429.mcf 433.milc 444.namd 445.gobmk 447.dealII 450.soplex 453.povray 456.hmmer 458.sjeng 462.libquantum 464.h264ref 470.lbm 471.omnetpp 473.astar 482.sphinx3 483.xalancbmk masking tagging arithmetic
35% geomean with optimizations
18
SLIDE 61
Is that any good?
19
SLIDE 62
Is that any good? Is it better than branches?
19
SLIDE 63
Is that any good? Is it better than branches?
Branching implementation: 48% overhead
19
SLIDE 64
Is that any good? Is it better than branches?
Branching implementation: 48% overhead > 35%!
19
SLIDE 65
Is that any good? Is it better than branches?
Branching implementation: 48% overhead > 35%!
Yes
19
SLIDE 66
Conclusion
◮ Reliable pointer tagging implementation ◮ We can check (upper) bounds without checks ◮ Faster than existing solutions
https://github.com/vusec/deltapointers
VUSec VUSec
20
SLIDE 67
Related work
System C++ Metadata Checks Passing OoB pointers Non-linear Runtime Memory Softbound ✗ Table Deref ✓ ✓ 67% 64% Baggy Bounds ✗ Layout Arith ✓a ✓ 72% 11% PAriCheck ✗ Shadow Arith ✓ ✓b 96% 18% LBC ✗ Shadow Deref ✓ ✗ 22% 7.7% ASan ✓ Shadow Deref ✓ ✗ 80% 237% Intel MPX ✓ Table Deref ✓ ✓ 139% 90% LowFat ✓ Layout Deref ✗ ✓ 54% 5.2% SGXBounds ✓ Tag Deref ✓ ✓ 89% 0.1% Delta Pointers ✓ Tag — ✓ ✓ 35% 0%
a Only up to alloc size/2 on 32-bit. b Unless wrap-around on 16-bit labels occurs. 21
SLIDE 68
Impact of optimization with static analysis
0% 25% 50% 75% 100% 400.perlbench 401.bzip2 403.gcc 429.mcf 433.milc 444.namd 445.gobmk 447.dealII 450.soplex 453.povray 456.hmmer 458.sjeng 462.libquantum 464.h264ref 470.lbm 471.omnetpp 473.astar 482.sphinx3 483.xalancbmk unoptimized
- ptimized
41% ⇒ 35%
22
SLIDE 69
Statistics
◮ 72% of SPEC offsets are dynamic ◮ 80% increase in code size with Delta Pointers
23
SLIDE 70
Branching implementation
void foo(int n) { char *buffer = malloc(24); char *p = buffer + n; *p = 'x'; }
24
SLIDE 71
Branching implementation
S t
- r
e e n d p
- i
n t e r d i s t a n c e i n t a g
void foo(int n) { char *buffer = malloc(24); buffer |= (buffer + 24) << 32; char *p = buffer + n; *p = 'x'; }
24
SLIDE 72
Branching implementation
E x t r a c t t a g
- n
l
- a
d / s t
- r
e
void foo(int n) { char *buffer = malloc(24); buffer |= (buffer + 24) << 32; char *p = buffer + n; tag = p >> 32; p = p & 0xffffffff; *p = 'x'; }
24
SLIDE 73
Branching implementation
B r a n c h i n g c h e c k
void foo(int n) { char *buffer = malloc(24); buffer |= (buffer + 24) << 32; char *p = buffer + n; tag = p >> 32; p = p & 0xffffffff; if (p >= tag) ERROR("overflow"); *p = 'x'; }
24
SLIDE 74
Some pointer tagging challenges
◮ Some operations need masking to preserve semantics
char a[10]; // size_t len = &a[10] - &a[0]; size_t len = MASK (&a[10]) - MASK (&a[0]);
◮ Pointers that look like integers
union { char *buf; uint64_t foo; } field; field.buf += 42; // should instrument field.foo += 42; // should NOT
25
