Deep Learning in Computer Vision

Deep Learning in Action


• 24. June ’15

Caner Hazırbaş

Deep Learning in Computer Vision Caner Hazırbaş | vision.in.tum.de

Computer Vision Group

2

6 Postdocs, 16 PhD students

Deep Learning in Computer Vision Caner Hazırbaş | vision.in.tum.de

Research in Computer Vision

3

Image-based 3D
 Reconstruction Shape Analysis Robot Vision RGB-D Vision Image
 Segmentation Convex
 Relaxation
 Methods Visual SLAM Optical Flow

Deep Learning
 in Computer Vision

Deep Learning in Computer Vision Caner Hazırbaş | vision.in.tum.de

How to teach a machine ?

5

edges classifier (or any other hand-crafted features) Person

Deep Learning in Computer Vision Caner Hazırbaş | vision.in.tum.de

How to teach a machine ?

6

edges classifier Person (or any other hand-crafted features)

N

• t

a g

• d

r e p r e s e n t a t i

• n

Deep Learning in Computer Vision Caner Hazırbaş | vision.in.tum.de

What is deep learning ?

• Representation learning method


Learning good features automatically from raw data

• Learning representations of data with multiple levels of abstraction

7

Google’s cat detection neural network

Deep Learning in Computer Vision Caner Hazırbaş | vision.in.tum.de

Construction of higher
 levels of abstraction

8

w1 w2 w3 “non-linear”
 transformation 1 b

Deep Learning in Computer Vision Caner Hazırbaş | vision.in.tum.de

Going deeper in the network

9

Input
 ‘Pixels’ 1st and 2nd Layers ‘Edges’ 3rd Layer ‘Object Parts’ 4th Layer ‘Objects’

third layer

faces faces cars airplanes motorbikes

Deep Learning in Computer Vision Caner Hazırbaş | vision.in.tum.de

Deep Learning Methods

Unsupervised Methods

• Restricted Boltzmann Machines
• Deep Belief Networks
• Auto encoders: unsupervised feature extraction/learning

10

encode decode

Deep Learning in Computer Vision Caner Hazırbaş | vision.in.tum.de

Deep Learning Methods

Supervised Methods

• Deep Neural Networks
• Recurrent Neural Networks
• Convolutional Neural Networks

11

Vision Deep CNN Language Generating RNN A group of people shopping at an outdoor market. There are many vegetables at the fruit stand.

Deep Learning in Computer Vision Caner Hazırbaş | vision.in.tum.de

How to train a deep network ?

Stochastic Gradient Descent — supervised learning

• show input vector of few examples
• compute the output and the errors
• compute average gradient
• update the weights accordingly

12

Deep Learning in Computer Vision Caner Hazırbaş | vision.in.tum.de

Convolutional Neural Networks

• CNNs are designed to process the data in the form of multiple arrays

(e.g. 2D images, 3D video/volumetric images)

• Typical architecture is composed of series of stages: convolutional layers

and pooling layers

• Each unit is connected to local patches in the feature maps of the

previous layer

13

20 15 x 54 15 x 54 8 x 27 4 x 14 50 500 x 1 378 x 1 E A q y B 4 conv1 pool1 conv pool2 10% 20 8 x 27 50

Deep Learning in Computer Vision Caner Hazırbaş | vision.in.tum.de

• local connections

Key Idea behind
 Convolutional Networks

14

Convolutional networks take advantage of the properties of natural signals:

Deep Learning in Computer Vision Caner Hazırbaş | vision.in.tum.de

• local connections

Key Idea behind
 Convolutional Networks

15

• shared weights

Convolutional networks take advantage of the properties of natural signals:

Deep Learning in Computer Vision Caner Hazırbaş | vision.in.tum.de

• local connections

Key Idea behind
 Convolutional Networks

16

• shared weights
• pooling

Convolutional networks take advantage of the properties of natural signals:

Deep Learning in Computer Vision Caner Hazırbaş | vision.in.tum.de

• local connections

Key Idea behind
 Convolutional Networks

Convolutional networks take advantage of the properties of natural signals:

17

• shared weights
• pooling
• the use of many layers

Person

Deep Learning in Computer Vision Caner Hazırbaş | vision.in.tum.de

Pros & Cons

• Best performing method in many

Computer Vision tasks

• No need of hand-crafted features
• Most applicable method for large-

scale problems, e.g. classification

• f 1000 classes
• Easy parallelization on GPUs

18

• Need of huge amount of training

data

• Hard to train (local minima problem,

tuning hyper-parameters)

• Difficult to analyse (to be solved)

Deep Learning Applications
 in Computer Vision

Deep Learning in Computer Vision Caner Hazırbaş | vision.in.tum.de

Handwritten Digit Recognition

20

Deep Learning in Computer Vision Caner Hazırbaş | vision.in.tum.de

ImageNet Classification with Deep Convolutional Neural Networks (AlexNet)

21

Deep Learning in Computer Vision Caner Hazırbaş | vision.in.tum.de

FlowNet: Learning Optical Flow with Convolutional Networks

22

in collaboration with University of Freiburg
 lmb.informatik.uni-freiburg.de

Deep Learning in Computer Vision Caner Hazırbaş | vision.in.tum.de

FlowNet: Learning Optical Flow with Convolutional Networks

23

Deep Learning in Computer Vision Caner Hazırbaş | vision.in.tum.de

FlowNet: Learning Optical Flow with Convolutional Networks

24

96 x 128 9 192 x 256 6 64 128 256 256 512 512 512 512 1024 5 x 5 5 x 5 3 x 3 conv6 prediction conv5_1 conv5 conv4_1 conv4 conv3_1 conv3 conv2 conv1 136 x 320 7 x 7 384 x 512 refine- ment conv1 conv2 conv3 corr conv_redir conv3_1 conv4 conv4_1 conv5 conv5_1 conv6 3 64 128 256 441 32 473 256 512 512 512 512 1024 384 x 512 sqrt prediction 136 x 320 refine- ment 4 x 512 4 x 512 2 kernel 7 x 7 5 x 5 1 x 1 1 x 1 3 x 3

FlowNetSimple FlowNetCorr

Deep Learning in Computer Vision Caner Hazırbaş | vision.in.tum.de

FlowNet: Learning Optical Flow with Convolutional Networks

25

corr conv_redir 441 256 sqrt kernel 1 x 1 1 x 1 3 x 3

Deep Learning in Computer Vision Caner Hazırbaş | vision.in.tum.de

FlowNet: Learning Optical Flow with Convolutional Networks

26

Deep Learning in Computer Vision Caner Hazırbaş | vision.in.tum.de

From Image to Caption

27

Vision Deep CNN Language Generating RNN A group of people shopping at an outdoor market. There are many vegetables at the fruit stand.

A woman is throwing a frisbee in a park. A little girl sitting on a bed with a teddy bear. A group of people sitting on a boat in the water. A girafge standing in a forest with trees in the background. A dog is standing on a hardwood fmoor. A stop sign is on a road with a mountain in the background

Vision Deep CNN Language Generating RNN A group of people shopping at an outdoor market. There are many vegetables at the fruit stand.

Deep Learning in Computer Vision

Questions ?

End of
 Presentation

Caner Hazırbaş | hazirbas@cs.tum.edu

Deep Learning in Computer Vision Caner Hazırbaş | vision.in.tum.de

References

• Building High-level Features Using Large Scale Unsupervised Learning


Quoc V. Le , Rajat Monga , Matthieu Devin , Kai Chen , Greg S. Corrado , Jeff Dean , Andrew Y. Ng ICML’12

• Convolutional Deep Belief Networks for Scalable Unsupervised Learning of

Hierarchical Representations


Honglak Lee Roger Grosse Rajesh Ranganath Andrew Y. Ng ICML’09

• ImageNet Classification with Deep Convolutional Neural Networks


Alex Krizhevsky, Ilya Sutskever, Geoffrey E. Hinton NIPS’12

• Gradient-based learning applied to document recognition.

• Y. LeCun, L. Bottou, Y. Bengio, and P. Haffner Proceedings of the IEEE’98
• FlowNet: Learning Optical Flow with Convolutional Networks


Philipp Fischer, Alexey Dosovitskiy, Eddy Ilg, Philip Häusser, Caner Hazırbaş, Vladimir Golkov, Patrick van der Smagt, Daniel Cremers, Thomas Brox

29

Deep Learning in Computer Vision Caner Hazırbaş | vision.in.tum.de

References

• Google’s cat detection neural network http://www.resnap.com/image-

selection-technology/deep-learning-image-classification/

• Example auto-encoder : http://nghiaho.com/?p=1765
• SGD : http://blog.datumbox.com/tuning-the-learning-rate-in-gradient-

descent/

30
