Decision trees

PRISM - Nicolas Sutton-Charani 20/01/2020

• N. Sutton-Charani

Artificial intelligence Decision trees 1 / 47

• 1. Introduction
• 2. Use of decision trees

2.1 Prediction 2.2 Interpretability : Descriptive data analysis

• 3. Learning of decision trees

3.1 Purity criteria 3.2 Stopping criteria 3.3 Learning algorithm

• 4. Pruning of decision trees

4.1 Cost-complexity trade-off

• 5. Extension : Random forest
• N. Sutton-Charani

Artificial intelligence Decision trees 2 / 47

Introduction

What is a decision tree ?

attribute J1 attribute J2 label prediction label prediction attribute J3 attribute J4 label prediction label prediction label prediction

• N. Sutton-Charani

Artificial intelligence Decision trees 3 / 47

Introduction

What is a decision tree ?

attribute J1 attribute J2 label prediction label prediction attribute J3 attribute J4 label prediction label prediction label prediction

• N. Sutton-Charani

Artificial intelligence Decision trees 4 / 47

Introduction

What is a decision tree ? → supervised learning

attribute J1 attribute J2 label prediction

values

label prediction

values values

attribute J3 attribute J4 label prediction

values

label prediction

values values

label prediction

values values

• N. Sutton-Charani

Artificial intelligence Decision trees 5 / 47

Introduction

A little history

!

△machine learning (or data mining) decision trees

= decision theory decision trees

• N. Sutton-Charani

Artificial intelligence Decision trees 6 / 47

Introduction

Types of decision trees

type of class label numerical → regression tree nominal → classification tree type of algorithm (→ structure) CART : statistics, binary tree C4.5 : computer science, small tree

• N. Sutton-Charani

Artificial intelligence Decision trees 7 / 47

Use of decision trees Prediction

Plan

• 1. Introduction
• 2. Use of decision trees

2.1 Prediction 2.2 Interpretability : Descriptive data analysis

• 3. Learning of decision trees

3.1 Purity criteria 3.2 Stopping criteria 3.3 Learning algorithm

• 4. Pruning of decision trees

4.1 Cost-complexity trade-off

• 5. Extension : Random forest
• N. Sutton-Charani

Artificial intelligence Decision trees 8 / 47

Use of decision trees Prediction

Classification trees

Will the badminton match take place ?

• N. Sutton-Charani

Artificial intelligence Decision trees 9 / 47

Use of decision trees Prediction

Classification trees

What fruit is it ?

• N. Sutton-Charani

Artificial intelligence Decision trees 10 / 47

Use of decision trees Prediction

Classification trees

What he/she come to my party ?

• N. Sutton-Charani

Artificial intelligence Decision trees 11 / 47

Use of decision trees Prediction

Classification trees

Will they wait ?

• N. Sutton-Charani

Artificial intelligence Decision trees 12 / 47

Use of decision trees Prediction

Classification trees

Who will win he election in this county ?

• N. Sutton-Charani

Artificial intelligence Decision trees 13 / 47

Use of decision trees Prediction

Regression trees

What grade will a student get (given his homework average grade) ?

• N. Sutton-Charani

Artificial intelligence Decision trees 14 / 47

Use of decision trees Interpretability : Descriptive data analysis

Plan

• 1. Introduction
• 2. Use of decision trees

2.1 Prediction 2.2 Interpretability : Descriptive data analysis

• 3. Learning of decision trees

3.1 Purity criteria 3.2 Stopping criteria 3.3 Learning algorithm

• 4. Pruning of decision trees

4.1 Cost-complexity trade-off

• 5. Extension : Random forest
• N. Sutton-Charani

Artificial intelligence Decision trees 15 / 47

Use of decision trees Interpretability : Descriptive data analysis

Data analysis tool

Trees are very interpretable : attributes spaces partitioning → a tree can be resumed by its leaves which define a law mixture → wonderful collaboration tool with experts

!

△INSTABILITY ← overfitting

• N. Sutton-Charani

Artificial intelligence Decision trees 16 / 47

Learning of decision trees

Formalism

Learning dataset (supervised learning)    x1, y1 . . . xN, yN    =    x1

1

. . . xJ

1

y1 . . . . . . . . . x1

N

. . . xJ

N

yN    samples are assumed to be i.i.d Attributes X = (X 1, . . . , X J) ∈ X = X 1 × · · · × X J Spaces X j can be categorical or numerical Class label Y ∈ Ω = {ω1, . . . , ωK} (∈ RK for regression) Tree PH = {t1, . . . , tH}

and πh = P(th) ≈ |th|

N

with |th| = #{i : xi ∈ th}

• N. Sutton-Charani

Artificial intelligence Decision trees 17 / 47

Learning of decision trees

Recursive partitioning

• N. Sutton-Charani

Artificial intelligence Decision trees 18 / 47

Learning of decision trees

Recursive partitioning

• N. Sutton-Charani

Artificial intelligence Decision trees 19 / 47

Learning of decision trees

Recursive partitioning

• N. Sutton-Charani

Artificial intelligence Decision trees 20 / 47

Learning of decision trees

Recursive partitioning

• N. Sutton-Charani

Artificial intelligence Decision trees 21 / 47

Learning of decision trees

Learning principle

Start with all the dataset in the initial node Chose the best splits (on attributes) in order to get pure leaves Classification trees purity = homogeneity in term of class labels

CART → Gini impurity : i(th) =

K

• k=1

pk(1 − pk) ID3, C4.5 → Shanon entropy : i(th) = −

K

• k=1

pk log2(pk) whith pk = P(Y = ωk|th)

Regression trees purity = low variance of class labels

→ i(th) = Var(Y |th) =

1 |th|

• xi ∈th

(yi − E(Y |th))2 with E(Y |th) =

1 |th|

• xi ∈th

yi

• N. Sutton-Charani

Artificial intelligence Decision trees 22 / 47

Learning of decision trees

Impurity measures

• N. Sutton-Charani

Artificial intelligence Decision trees 23 / 47

Learning of decision trees Purity criteria

Plan

• 1. Introduction
• 2. Use of decision trees

2.1 Prediction 2.2 Interpretability : Descriptive data analysis

• 3. Learning of decision trees

3.1 Purity criteria 3.2 Stopping criteria 3.3 Learning algorithm

• 4. Pruning of decision trees

4.1 Cost-complexity trade-off

• 5. Extension : Random forest
• N. Sutton-Charani

Artificial intelligence Decision trees 24 / 47

Learning of decision trees Purity criteria

Purity criteria

leaf to split

th

Impurity measure + tree structure → criteria CART, ID3 : purity gain C4.5 : information gain ratio Regression trees CART : Variance minimisation

• N. Sutton-Charani

Artificial intelligence Decision trees 25 / 47

Learning of decision trees Purity criteria

Purity criteria

attribute ? prediction ?

values ?

prediction ?

values ?

th tL tR

Impurity measure + tree structure → criteria CART, ID3 : purity gain → ∆i = i(th) − πLi(tL) − πRi(tR) C4.5 : information gain ratio → IGR =

∆i H(πL,πR)

Regression trees CART : Variance minimisation → ∆i = i(th) − πLi(tL) − πRi(tR)

• N. Sutton-Charani

Artificial intelligence Decision trees 26 / 47

Learning of decision trees Stopping criteria

Plan

• 1. Introduction
• 2. Use of decision trees

2.1 Prediction 2.2 Interpretability : Descriptive data analysis

• 3. Learning of decision trees

3.1 Purity criteria 3.2 Stopping criteria 3.3 Learning algorithm

• 4. Pruning of decision trees

4.1 Cost-complexity trade-off

• 5. Extension : Random forest
• N. Sutton-Charani

Artificial intelligence Decision trees 27 / 47

Learning of decision trees Stopping criteria

Stopping criteria (pre-pruning)

For all leaves {th}h=1,...,H and their potential children : leaves purity : ∃k ∈ {1, . . . , K} : pk = 1 leaves and children sizes : |th| ≤ minLeafSize leaves and children weights : πh = |th|

t0 ≤ minLeafProba

leaves number : H ≥ maxNumberLeaves tree depth : depth(PH) ≥ maxDepth purity gain : ∆i ≤ minPurityGain

• N. Sutton-Charani

Artificial intelligence Decision trees 28 / 47

Learning of decision trees Learning algorithm

Plan

• 1. Introduction
• 2. Use of decision trees

2.1 Prediction 2.2 Interpretability : Descriptive data analysis

• 3. Learning of decision trees

3.1 Purity criteria 3.2 Stopping criteria 3.3 Learning algorithm

• 4. Pruning of decision trees

4.1 Cost-complexity trade-off

• 5. Extension : Random forest
• N. Sutton-Charani

Artificial intelligence Decision trees 29 / 47

Learning of decision trees Learning algorithm

Learning algorithm

Result: Learnt tree Start with all the learning data in an initial node (single leaf); while Stopping criteria not verified for all leaves do for each splitable leaf do compute the purity gains obtained from all possible split; end SPLIT : select the split achieving the maximum purity gain; end prune the obtained tree;

Recursive partitioning

• N. Sutton-Charani

Artificial intelligence Decision trees 30 / 47

Learning of decision trees Learning algorithm

ID3 - Training Examples – [9+,5-]

• N. Sutton-Charani

Artificial intelligence Decision trees 31 / 47

Learning of decision trees Learning algorithm

ID3 - Selecting Next Attribute

• N. Sutton-Charani

Artificial intelligence Decision trees 32 / 47

Learning of decision trees Learning algorithm

ID3 - Selecting Next Attribute

• N. Sutton-Charani

Artificial intelligence Decision trees 33 / 47

Learning of decision trees Learning algorithm

ID3 - Selecting Next Attribute

• N. Sutton-Charani

Artificial intelligence Decision trees 34 / 47

Learning of decision trees Learning algorithm

ID3 - Best Attribute - Outlook

• N. Sutton-Charani

Artificial intelligence Decision trees 35 / 47

Learning of decision trees Learning algorithm

ID3 - Ssunny

• N. Sutton-Charani

Artificial intelligence Decision trees 36 / 47

Learning of decision trees Learning algorithm

ID3 - Results

• N. Sutton-Charani

Artificial intelligence Decision trees 37 / 47

Pruning of decision trees

Overfitting

• N. Sutton-Charani

Artificial intelligence Decision trees 38 / 47

Pruning of decision trees

Overfitting

Remark : decision trees do not need variable selection or dimension reduction (in term of accuracy).

• N. Sutton-Charani

Artificial intelligence Decision trees 39 / 47

Pruning of decision trees Cost-complexity trade-off

Plan

• 1. Introduction
• 2. Use of decision trees

2.1 Prediction 2.2 Interpretability : Descriptive data analysis

• 3. Learning of decision trees

3.1 Purity criteria 3.2 Stopping criteria 3.3 Learning algorithm

• 4. Pruning of decision trees

4.1 Cost-complexity trade-off

• 5. Extension : Random forest
• N. Sutton-Charani

Artificial intelligence Decision trees 40 / 47

Pruning of decision trees Cost-complexity trade-off

Cost-Complexity Pruning

The idea trade-off between predictive efficiency and complexity find a subtree that fulfills this trade-off Metrics ’Err’ ← misclassification rate or MSE Criterion : Rα = Err + αH Steps Find a useful sequence of nested subtrees Choose the right subtree

• N. Sutton-Charani

Artificial intelligence Decision trees 41 / 47

Pruning of decision trees Cost-complexity trade-off

Cost-Complexity Pruning

Sequence of subtrees creation Result: sequence of trees that are all sub-trees of T0 : T0 ≫ T1 ≫ T2 ≫ T3 ≫ . . . ≫ Tk ≫ P1(initialnode) Learn the biggest tree Ts = T0 := PHmax obtained for α0 = 0 (s=0); while Ts = P1 do Ts+1 = argmin

t∈subtrees(Ts)

[Rαs(t) − Rαs(Ts)]; αs+1 = Rαs(Ts+1) − Rαs(Ts); end We get 2 bijective sets : {T0, . . . , TS} and {α0, . . . , αS} (with TS = P1) Selection : Ts∗ = argmin

Ts∈{T0,...,TS}

Err(Ts) ← pruning set or cross validation

• N. Sutton-Charani

Artificial intelligence Decision trees 42 / 47

Pruning of decision trees Cost-complexity trade-off

Cost-Complexity Pruning

Figure – Sequence of nested subtrees

Here, α2 < α1 = ⇒ T − T1 ⊂ T − T2

• N. Sutton-Charani

Artificial intelligence Decision trees 43 / 47

Extension : Random forest

Random forest

Motivation trees instability bias-variance trade-off Averaging reduces variance : Var(X) = Var(X) N (for independant predictions) → Average models to reduce model variance One problem :

• only one training set
• where do multiple models come from ?
• N. Sutton-Charani

Artificial intelligence Decision trees 44 / 47

Extension : Random forest

Bagging : Bootstrap Aggregation

Tin Kam Ho (1995) → Leo Breiman (2001) Take repeated bootstrap samples from the training set Bootstrap sampling : Given a training set D containing N examples, draw N examples at random with replacement from D. Bagging :

• create B bootstrap samples D1, . . . , DB
• train distinct classifier on each Db
• classify new instance by majority vote / averaging / aggregating

predictions

• N. Sutton-Charani

Artificial intelligence Decision trees 45 / 47

Extension : Random forest

Random forest

• N. Sutton-Charani

Artificial intelligence Decision trees 46 / 47

Extension : Random forest

References

* L. Breiman, J. Friedman, C. J. Stone, and R. A. Olshen, Classification And Regression Trees, 1984. * J. Quinlan, “Induction of decision trees,” Machine Learning, vol. 1,

• pp. 81–106, Oct. 1986

* L. Breiman. Random forests. Statistics, pages 1–33, 2001. * G. Biau, L. Devroye, and G. Lugosi. Consistency of random forests and other averaging classifiers. J. Mach. Learn. Res., 9 :2015–2033, jun 2008.
