SLIDE 1
Xiyang Hu Cynthia Rudin Margo Seltzer
Carnegie Mellon University Duke University University of British Columbia
Optimal Sparse Decision Trees Xiyang Hu Cynthia Rudin Margo - - PowerPoint PPT Presentation
Optimal Sparse Decision Trees Xiyang Hu Cynthia Rudin Margo - - PowerPoint PPT Presentation
Optimal Sparse Decision Trees Xiyang Hu Cynthia Rudin Margo Seltzer Carnegie Mellon Duke University University of British University Columbia Decision Trees Decision Trees Decision Trees Should I click on the link in this email? Do I
SLIDE 2
SLIDE 3
Decision Trees
SLIDE 4
Decision Trees
Do I recognize the from address? Do the contents seem
- dd?
Can I see the URL for the link?
Should I click on the link in this email?
SLIDE 5
Decision Trees
Can I see the URL for the link? Do the contents seem
- dd?
Do I recognize the from address?
Should I click on the link in this email?
SLIDE 6
Why not just find the Best Tree?
SLIDE 7
Why not just find the Best Tree?
SLIDE 8
Could we Effectively Search that Space?
SLIDE 9
Could we Effectively Search that Space?
SLIDE 10
Could we Effectively Search that Space?
SLIDE 11
Could we Effectively Search that Space?
SLIDE 12
Could we Effectively Search that Space?
SLIDE 13
Could we Effectively Search that Space?
SLIDE 14
Could we Effectively Search that Space?
SLIDE 15
Could we Effectively Search that Space?
Optimal!
SLIDE 16
The Optimization Problem
ˆ L(tree,{(xi, yi)}i) = 1 n i=1
n
å1
[tree(xi )¹yi] + C(#leaves in tree)
SLIDE 17
The Optimization Problem
Misclassification error
ˆ L(tree,{(xi, yi)}i) = 1 n i=1
n
å1
[tree(xi )¹yi] + C(#leaves in tree)
SLIDE 18
The Optimization Problem
Misclassification error Sparsity
ˆ L(tree,{(xi, yi)}i) = 1 n i=1
n
å1
[tree(xi )¹yi] + C(#leaves in tree)
SLIDE 19
Optimal Sparse Decision Tree
(Broward County Recidivism Data)
Prior offenses > 3
no yes
Predict Arrest Age < 26 Predict No Arrest
yes no
Prior Offenses > 1
no yes
Any juvenile crimes? Predict Arrest Predict No Arrest
yes no
Predict Arrest
SLIDE 20
Optimal Sparse Decision Trees
Branch and Bound Good Scheduling Order Strong Bounds Incremental Computation
SLIDE 21
Optimal Sparse Decision Trees
Branch and Bound Good Scheduling Order Strong Bounds FAST Incremental Computation
SLIDE 22
Optimal Sparse Decision Trees
Branch and Bound Good Scheduling Order Strong Bounds Accurate Incremental Computation
SLIDE 23
Bounding the Search Space
Lower Bound on Node Support Theorem: For an optimal tree, the support of each node must be above 2C.
Prior offenses > 3
no yes
Predict Arrest Age > 70
yes no
Prior Offenses > 2
SLIDE 24
Bounding the Search Space
Lower Bound on Node Support Theorem: For an optimal tree, the support of each node must be above 2C.
Prior offenses > 3
no yes
Predict Arrest Age > 70
yes no
Prior Offenses > 2
x
Node support insufficient to produce
- ptimal solution
SLIDE 25
Bounding the Search Space
Lower Bound on Node Support Theorem: For an optimal tree, the support of each node must be above 2C.
Prior offenses > 3
no yes
Predict Arrest Age > 70
yes no
Prior Offenses > 2
x
Node support insufficient to produce
- ptimal solution
x
SLIDE 26
Bounding the Search Space
Lower Bound on Classification Accuracy Theorem: Each leaf of an
- ptimal tree correctly classifies
at least fraction C of the data
Prior offenses > 3
no yes
Predict Arrest Felony > 5
yes no
Predict Arrest
SLIDE 27
Bounding the Search Space
Lower Bound on Classification Accuracy Theorem: Each leaf of an
- ptimal tree correctly classifies
at least fraction C of the data
Prior offenses > 3
no yes
Predict Arrest Felony > 5
yes no
Predict Arrest
x
Doesn’t classify at least Cn points correctly.
SLIDE 28
Bounding the Search Space
Lower Bound on Classification Accuracy Theorem: Each leaf of an
- ptimal tree correctly classifies
at least fraction C of the data
Prior offenses > 3
no yes
Predict Arrest Felony > 5
yes no
Predict Arrest
x
Doesn’t classify at least Cn points correctly.
x
SLIDE 29
Bounding the Search Space
Permutation Bound Theorem: If two trees have the same leaves, up to a permutation, all their child trees will be the same, so one
- f them can be pruned.
Prior offenses > 3
no yes
Age > 18
yes no
Predict Arrest Predict No Arrest Age > 18
yes no
Predict No Arrest Predict Arrest Age > 18
no yes
Prior offenses > 3
yes no
Predict Arrest Predict No Arrest Prior offenses > 3
yes no
Predict No Arrest Predict Arrest
SLIDE 30
Bounding the Search Space
Permutation Bound Theorem: If two trees have the same leaves, up to a permutation, all their child trees will be the same, so one
- f them can be pruned.
Prior offenses > 3
no yes
Age > 18
yes no
Predict Arrest Predict No Arrest Age > 18
yes no
Predict No Arrest Predict Arrest Age > 18
no yes
Prior offenses > 3
yes no
Predict Arrest Predict No Arrest Prior offenses > 3
yes no
Predict No Arrest Predict Arrest
SLIDE 31
Bounding the Search Space
Permutation Bound Theorem: If two trees have the same leaves, up to a permutation, all their child trees will be the same, so one
- f them can be pruned.
Prior offenses > 3
no yes
Age > 18
yes no
Predict Arrest Predict No Arrest Age > 18
yes no
Predict No Arrest Predict Arrest Age > 18
no yes
Prior offenses > 3
yes no
Predict Arrest Predict No Arrest Prior offenses > 3
yes no
Predict No Arrest Predict Arrest
SLIDE 32
Bounding the Search Space
Permutation Bound Theorem: If two trees have the same leaves, up to a permutation, all their child trees will be the same, so one
- f them can be pruned.
Prior offenses > 3
no yes
Age > 18
yes no
Predict Arrest Predict No Arrest Age > 18
yes no
Predict No Arrest Predict Arrest Age > 18
no yes
Prior offenses > 3
yes no
Predict Arrest Predict No Arrest Prior offenses > 3
yes no
Predict No Arrest Predict Arrest
SLIDE 33
Bounding the Search Space
Permutation Bound Theorem: If two trees have the same leaves, up to a permutation, all their child trees will be the same, so one
- f them can be pruned.
Prior offenses > 3
no yes
Age > 18
yes no
Predict Arrest Predict No Arrest Age > 18
yes no
Predict No Arrest Predict Arrest Age > 18
no yes
Prior offenses > 3
yes no
Predict Arrest Predict No Arrest Prior offenses > 3
yes no
Predict No Arrest Predict Arrest
SLIDE 34
Bounding the Search Space
- Other bounds enable even more pruning
– Equivalent points bound: Samples with the same features, but different predictions will produce misclassifications regardless of model. – Bound on the number of leaves: Regularization value bounds the number of leaves.
SLIDE 35
Optimal Sparse Decision Trees
https://github.com/xiyanghu/OSDT
