Decision Trees Gavin Brown Every Learning Method has Limitations Linear model? KNN ? SVM ? Explain your decisions Sometimes we need interpretable results from our techniques. How do you explain the above decision? Different types of data Rugby
SLIDE 2
SLIDE 3
Explain your decisions
Sometimes we need interpretable results from our techniques. How do you explain the above decision?
SLIDE 4
Different types of data
Rugby players - height, weight can be plotted in 2-d. How do you plot hair colour? (Black, Brown, Blonde?) Predicting heart disease - how do you plot blood type? (A, B, O)? In general, how do you deal with categorical data?
SLIDE 5
The Tennis Problem
You are working for the local tennis club. They want a program that will advise inexperienced new members
- n whether they are likely to enjoy a game today, given the current
weather conditions. However they need the program to pop out interpretable rules so they can be sure it’s not giving bad advice. They provide you with some historical data....
SLIDE 6
The Tennis Problem
Outlook Temperature Humidity Wind Play Tennis? 1 Sunny Hot High Weak No 2 Sunny Hot High Strong No 3 Overcast Hot High Weak Yes 4 Rain Mild High Weak Yes 5 Rain Cool Normal Weak Yes 6 Rain Cool Normal Strong No 7 Overcast Cool Normal Strong Yes 8 Sunny Mild High Weak No 9 Sunny Cool Normal Weak Yes 10 Rain Mild Normal Weak Yes 11 Sunny Mild Normal Strong Yes 12 Overcast Mild High Strong Yes 13 Overcast Hot Normal Weak Yes 14 Rain Mild High Strong No
Note: 9 examples say ’yes’, 5 examples say ’no’.
SLIDE 7
A Decision Tree for the Tennis Problem
This tree works for any example in the table — try it!
SLIDE 8
Learning a Decision Tree : Basic recursive algorithm
tree ← learntree( data ) if all examples in data have same label, return leaf node with that label else pick the most “important” feature, call it F for each possible value v of F data(v) ← all examples where F == v add branch ← learntree( data(v) ) endfor return tree endif
SLIDE 9
Example: partitioning data by “wind” feature
Outlook Temp Humid Wind Play? 2 Sunny Hot High Strong No 6 Rain Cool Normal Strong No 7 Overcast Cool Normal Strong Yes 11 Sunny Mild Normal Strong Yes 12 Overcast Mild High Strong Yes 14 Rain Mild High Strong No
3 examples say yes, 3 say no.
Outlook Temp Humid Wind Play? 1 Sunny Hot High Weak No 3 Overcast Hot High Weak Yes 4 Rain Mild High Weak Yes 5 Rain Cool Normal Weak Yes 8 Sunny Mild High Weak No 9 Sunny Cool Normal Weak Yes 10 Rain Mild Normal Weak Yes 13 Overcast Hot Normal Weak Yes
6 examples say yes, 2 examples say no.
SLIDE 10
Learning a Decision Tree : Basic recursive algorithm
tree ← learntree( data ) if all examples in data have same label, return leaf node with that label else pick the most “important” feature , call it F for each possible value v of F data(v) ← all examples where F == v add branch ← learntree( data(v) ) endfor return tree endif Which is the most important feature?
SLIDE 11
Thinking in Probabilities...
Before the split : 9 ’yes’, 5 ’no’, ......... p(′yes′) = 9
14 ≈ 0.64
On the left branch : 3 ’yes’, 3 ’no’, ....... p(′yes′) = 3
6 = 0.5
On the right branch : 6 ’yes’, 2 ’no’, ...... p(′yes′) = 6
8 = 0.75
Remember... p(′no′) = 1 − p(′yes′)
SLIDE 12
The ‘Information’ contained in a variable - Entropy
More uncertainty = Less information H(X) = 1.0
SLIDE 13
The ‘Information’ contained in a variable - Entropy
Lower uncertainty = More information H(X) = 0.72193
SLIDE 14
Entropy
The amount of randomness in a variable X is called the ’entropy’. H(X) = −
- i
p(xi) log p(xi) (1) The log is base 2, giving us units of measurement ’bits’.
SLIDE 15
Reducing Entropy = Maximise Information Gain
The variable of interest is “T” (for tennis), taking on ’yes’ or ’no’
- values. Before the split : 9 ’yes’, 5 ’no’, .........
p(′yes′) = 9
14 ≈ 0.64
In the whole dataset, the entropy is: H(T) = −
- i
p(xi) log p(xi) = − 5 14log 5 14 + 9 14log 9 14
- = 0.94029
H(T) is the entropy before we split. See worked example in the supporting material.
SLIDE 16
Reducing Entropy = Maximise Information Gain
H(T) is the entropy before we split. H(T|W = strong) is the entropy of the data on the left branch. H(T|W = weak) is the entropy of the data on the right branch. H(T|W ) is the weighted average of the two. Choose the feature with maximum value of H(T) − H(T|W ). See worked example in the supporting material.
SLIDE 17
Learning a Decision Tree : the ID3 algorithm
tree ← learntree( data ) if all examples in data have same label, return leaf node with that label else pick the most “important” feature , call it F for each possible value v of F data(v) ← all examples where F == v add branch ← learntree( data(v) ) endfor return tree endif Or, in very simple terms: Step 1. Pick the feature that maximises information gain. Step 2. Recurse on each branch.
SLIDE 18
The ID3 algorithm
function id3( examples ) returns tree T if all the items in examples have the same conclusion, return a leaf node with value = majority conclusion let A be the feature with the largest information gain Create a blank tree T let s(1), s(2), s(3) etc be the data subsets produced by splitting examples on feature A For each subset s(n), tree t(n) = id3( s(n) ) add t(n) as a new branch of T Endfor return T
SLIDE 19
A Decision Tree for the Tennis Problem
Following each path down the tree, we can make up a list of rules. if ( sunny AND high ) → NO if ( sunny AND normal ) → YES if ( overcast ) → YES if ( rain AND strong ) → NO if ( rain AND weak ) → YES
SLIDE 20
’Overfitting’ a tree
◮ The number of possible paths tells you the number of rules. ◮ More rules = more complicated. ◮ We could have N rules where N is the size of the dataset.
This would mean no generalisation outside of the training data, or the tree is overfitted Overfitting = fine tuning
SLIDE 21
Overfitting
What if it’s rainy and hot?
Outlook Temperature Humidity Wind Play Tennis? 1 Sunny Hot High Weak No 2 Sunny Hot High Strong No 3 Overcast Hot High Weak Yes 4 Rain Mild High Weak Yes 5 Rain Cool Normal Weak Yes 6 Rain Cool Normal Strong No 7 Overcast Cool Normal Strong Yes 8 Sunny Mild High Weak No 9 Sunny Cool Normal Weak Yes 10 Rain Mild Normal Weak Yes 11 Sunny Mild Normal Strong Yes 12 Overcast Mild High Strong Yes 13 Overcast Hot Normal Weak Yes 14 Rain Mild High Strong No
SLIDE 22
Overfitting
How do you know if you’ve overfitted?
◮ “Validation” dataset - another dataset that you do not use to
train, but just to check whether you’ve overfitted or not. How can we avoid it?
◮ Stop after a certain depth (i.e. keep the tree short) ◮ Post-Prune the final tree ◮ ... both in order to control validation error
SLIDE 23
Overfitting
SLIDE 24
Missing data?
Outlook Temperature Humidity Wind Play Tennis? 1 Sunny Hot High Weak No 2 Sunny Hot High Strong No 3 Overcast High Weak Yes 4 Rain Mild High Weak Yes 5 Rain Cool Normal Weak Yes 6 Rain Normal No 7 Overcast Cool Normal Yes 8 Sunny High No 9 Sunny Cool Normal Weak Yes 10 Rain Mild Normal Weak Yes 11 Sunny Normal Strong Yes 12 Overcast High Strong Yes 13 Overcast Normal Weak Yes 14 Rain Mild High Strong No Insert average (mean, median or mode) of the available values. Or other more complex strategies such as using Bayes Rule... NEXT WEEK... Ultimately best strategy is problem dependent.
