DATA MINING: NAVE BAYES 1 Nave Bayes Classifier Thomas Bayes 1702 - - PowerPoint PPT Presentation

1

DATA MINING: NAÏVE BAYES

2

Naïve Bayes Classifier

We will start off with some mathematical background. But first we start with some visual intuition. Thomas Bayes

1702 - 1761

3

Antenna Length

10 1 2 3 4 5 6 7 8 9 10 1 2 3 4 5 6 7 8 9

Grasshoppers Katydids

Abdomen Length Remember this example? Let’s get lots more data…

4

Antenna Length

10 1 2 3 4 5 6 7 8 9 10 1 2 3 4 5 6 7 8 9 Katydids Grasshoppers

With a lot of data, we can build a histogram. Let us just build one for “Antenna Length” for now…

We can leave the histograms as they are, or we can summarize them with two normal distributions. Let us us two normal distributions for ease of visualization in the following slides…

5

3 Antennae length is 3

• We want to classify an insect we have found. Its antennae are 3 units long.
• How can we classify it?
• We can just ask ourselves, give the distributions of antennae lengths we

have seen, is it more probable that our insect is a Grasshopper or a Katydid.

• There is a formal way to discuss the most probable classification…

6

P(cj|d) = probability of cj given that we have observed d

10 2 P(Grasshopper | 3 ) = 10 / (10 + 2)

= 0.833 P(Katydid | 3 ) = 2 / (10 + 2) = 0.166

3 Antennae length is 3

7

P(cj|d) = probability of cj given that we have observed d

9 3 P(Grasshopper | 7 ) = 3 / (3 + 9)

= 0.250 P(Katydid | 7 ) = 9 / (3 + 9) = 0.750

7 Antennae length is 7

8

P(cj|d) = probability of cj given that we have observed d

6 6 P(Grasshopper | 5 ) = 6 / (6 + 6)

= 0.500 P(Katydid | 5 ) = 6 / (6 + 6) = 0.500

5 Antennae length is 5

9

P(cj|d) = probability of cj given that we have observed d

Bayes Classifier

• A probabilistic framework for classification problems
• Often appropriate because the world is noisy and also some

relationships are probabilistic in nature

 Is predicting who will win a baseball game probabilistic in

nature?

• Before getting the heart of the matter, we will go over some

basic probability.

• We will review the concept of reasoning with uncertainty,

which is based on probability theory

 Should be review for many of you

10

Discrete Random Variables

• A is a Boolean-valued random variable if A denotes an

event, and there is some degree of uncertainty as to whether A occurs.

• Examples

 A = The next patient you examine is suffering from inhalational

anthrax

 A = The next patient you examine has a cough  A = There is an active terrorist cell in your city

• We view P(A) as “the fraction of possible

worlds in which A is true”

11

Visualizing A

12

Event space of all possible worlds Its area is 1

Worlds in which A is False Worlds in which A is true

P(A) = Area of reddish oval

The Axioms Of Probability

• 0 <= P(A) <= 1
• P(True) = 1
• P(False) = 0
• P(A or B) = P(A) + P(B) - P(A and B)

13

The area of A can’t get any smaller than 0 And a zero area would mean no world could ever have A true

Interpreting the axioms

• 0 <= P(A) <= 1
• P(True) = 1
• P(False) = 0
• P(A or B) = P(A) + P(B) - P(A and B)

14

The area of A can’t get any bigger than 1 And an area of 1 would mean all worlds will have A true

A B

Interpreting the axioms

• 0 <= P(A) <= 1
• P(True) = 1
• P(False) = 0
• P(A or B) = P(A) + P(B) - P(A and B)

15

P(A or B) B P(A and B) Simple addition and subtraction

Another Important Theorem

• 0 <= P(A) <= 1, P(True) = 1, P(False) = 0
• P(A or B) = P(A) + P(B) - P(A and B)

From these we can prove:

P(A) = P(A and B) + P(A and not B)

16

A B

Conditional Probability

• P(A|B) = Fraction of worlds in which B is true that

also have A true

17

F H

H = “Have a headache” F = “Coming down with Flu” P(H) = 1/10 P(F) = 1/40 P(H|F) = 1/2 “Headaches are rare and flu is rarer, but if you’re coming down with ‘flu there’s a 50-50 chance you’ll have a headache.”

Conditional Probability

18

F H

H = “Have a headache” F = “Coming down with Flu” P(H) = 1/10 P(F) = 1/40 P(H|F) = 1/2 P(H|F) = Fraction of flu-inflicted worlds in which you have a headache = #worlds with flu and headache

• #worlds with flu

= Area of “H and F” region

• Area of “F” region

= P(H and F)

• P(F)

Definition of Conditional Probability

19

P(A and B)

P(A|B) = ----------- P(B)

Corollary: The Chain Rule

P(A and B) = P(A|B) P(B)

Probabilistic Inference

20

F H

H = “Have a headache” F = “Coming down with Flu” P(H) = 1/10 P(F) = 1/40 P(H|F) = 1/2

One day you wake up with a headache. You think: “Drat! 50% of flus are associated with headaches so I must have a 50-50 chance

• f coming down with flu”

Is this reasoning good?

Probabilistic Inference

21

F H

H = “Have a headache” F = “Coming down with Flu” P(H) = 1/10 P(F) = 1/40 P(H|F) = 1/2

P(F and H) = … P(F|H) = …

Probabilistic Inference

22

F H

H = “Have a headache” F = “Coming down with Flu” P(H) = 1/10 P(F) = 1/40 P(H|F) = 1/2

8 1 10 1 80 1 ) ( ) and ( ) | (    H P H F P H F P 80 1 40 1 2 1 ) ( ) | ( ) and (      F P F H P H F P

What we just did…

P(A & B) P(A|B) P(B) P(B|A) = ----------- = --------------- P(A) P(A) This is Bayes Rule

23

Bayes, Thomas (1763) An essay towards solving a problem in the doctrine of

• chances. Philosophical Transactions of the

Royal Society of London, 53:370-418

More Terminology

• The Prior Probability is the probability

assuming no specific information.

 Thus we would refer to P(A) as the prior

probability of even A occurring

 We would not say that P(A|C) is the prior

probability of A occurring

• The Posterior probability is the probability

given that we know something

 We would say that P(A|C) is the posterior

probability of A (given that C occurs)

24

Example of Bayes Theorem

• Given:

 A doctor knows that meningitis causes stiff neck 50% of the time  Prior probability of any patient having meningitis is 1/50,000  Prior probability of any patient having stiff neck is 1/20

• If a patient has stiff neck, what’s the probability

he/she has meningitis?

25

0002 . 20 / 1 50000 / 1 5 . ) ( ) ( ) | ( ) | (     S P M P M S P S M P

Why Bayes Theorem at All?

• Why model P(C|A) via P(A|C)



We will see it is easier, but only with significant assumptions

• In classification, what is C and what is A?

 C is class and A is the example, a vector of attribute values

• Why not model P(C|A) directly? How would we compute it?



We would need to observe A at least once and probably many times in

• rder to come up with reasonable probability estimates. If we observe it
• nce, we would have a probability of 1 for some C and 0 for rest.



We cannot expect to see every attribute vector even once!

26

) ( ) ( ) | ( ) | ( A P C P C A P A C P 

Bayes Classifiers

27

That was a visual intuition for a simple case of the Bayes classifier, also called:

• Idiot Bayes
• Naïve Bayes
• Simple Bayes

We are about to see some of the mathematical formalisms, and more examples, but keep in mind the basic idea. Find out the probability of the previously unseen instance belonging to each class, then simply pick the most probable class.

Bayesian Classifiers

• Bayesian classifiers use Bayes theorem, which says

p(cj | d ) = p(d | cj ) p(cj) p(d)

p(cj | d) = probability of instance d being in class cj, This is what we are trying to compute

• p(d | cj) = probability of generating instance d given class cj,

We can imagine that being in class cj, causes you to have feature d with some probability

• p(cj) = probability of occurrence of class cj,

This is just how frequent the class cj, is in our database

• p(d) = probability of instance d occurring

This can actually be ignored, since it is the same for all classes

28

Bayesian Classifiers

• Given a record with attributes (A1, A2,…,An)

 The goal is to predict class C  Actually, we want to find the value of C that maximizes

P(C| A1, A2,…,An )

• Can we estimate P(C| A1, A2,…,An ) directly (w/o Bayes)?

 Yes, we simply need to count up the number of times we see

A1, A2,…,An and then see what fraction belongs to each class

 For example, if n=3 and the feature vector “4,3,2” occurs 10

times and 4 of these belong to C1 and 6 to C2, then:

 What is P(C1|”4,3,2”)?  What is P(C2|”4,3,2”)?

• Unfortunately, this is generally not feasible since not every

feature vector will be found in the training set (as we just said)

29

Bayesian Classifiers

• Indirect Approach: Use Bayes Theorem

 compute the posterior probability P(C | A1, A2, …, An) for all

values of C using the Bayes theorem

 Choose value of C that maximizes

P(C | A1, A2, …, An)

 Equivalent to choosing value of C that maximizes

P(A1, A2, …, An|C) P(C)

 Since the denominator is the same for all values of C

30

) ( ) ( ) | ( ) | (

2 1 2 1 2 1 n n n

A A A P C P C A A A P A A A C P    

Naïve Bayes Classifier

• How can we estimate P(A1, A2, …, An |C)?

 We can measure it directly, but only if the training set

samples every feature vector. Not practical! Not easier than measuring P(C| P(A1, A2, …, An)

• So, we must assume independence among attributes Ai

when class is given:

 P(A1, A2, …, An |C) = P(A1| Cj) P(A2| Cj)… P(An| Cj)  Then can we directly estimate P(Ai| Cj) for all Ai and Cj?

 Yes because we are looking only at one feature at a time. We can expect each feature value to appear many times in training data.

• New point is classified to Cj if P(Cj)  P(Ai| Cj) is maximal.

31

Assume that we have two classes

c1 = male, and c2 = female.

We have a person whose sex we do not know, say “drew” or d. Classifying drew as male or female is equivalent to asking is it more probable that drew is male or female, I.e which is greater p(male | drew) or p(female | drew)

32

p(male | drew) = p(drew | male ) p(male) p(drew)

(Note: “Drew can be a male

• r female

name”) What is the probability of being called “drew” given that you are a male? What is the probability

• f being a male?

What is the probability of being named “drew”?

(actually irrelevant, since it is that same for all classes) Drew Carey Drew Barrymore

p(cj | d) = p(d | cj ) p(cj) p(d)

Officer Drew

Name Sex Drew Male Claudia Female Drew Female Drew Female Alberto Male Karin Female Nina Female Sergio Male

This is Officer Drew (who arrested me in 1997). Is Officer Drew a Male or Female?

Luckily, we have a small database with names and sex. We can use it to apply Bayes rule…

33

p(male | drew) = 1/3 * 3/8 = 0.125 = 0.333 3/8 3/8 p(female | drew) = 2/5 * 5/8 = 0.250 = .666 3/8 3/8 Officer Drew

p(cj | d) = p(d | cj ) p(cj) p(d)

Name Sex Drew Male Claudia Female Drew Female Drew Female Alberto Male Karin Female Nina Female Sergio Male

Officer Drew is more likely to be a Female.

34

Officer Drew IS a female!

Officer Drew So far we have only considered Bayes Classification when we have one attribute (the “antennae length”,

• r the “name”). In this case there is no real benefit

for using Naïve Bayes. But in classification we usually have many features. How do we use all the features?

35

36

Name Over 170CM Eye Hair length Sex Drew No Blue Short Male Claudia Yes Brown Long Female Drew No Blue Long Female Drew No Blue Long Female Alberto Yes Brown Short Male Karin No Blue Long Female Nina Yes Brown Short Female Sergio Yes Blue Long Male

p(cj | d) = p(d | cj ) p(cj) p(d)

• To simplify the task, naïve Bayesian classifiers assume attributes

have independent distributions, and thereby estimate

p(d|cj) = p(d1|cj) * p(d2|cj) * ….* p(dn|cj)

37

The probability of class cj generating instance d, equals….

The probability of class cj generating the observed value for feature 1, multiplied by.. The probability of class cj generating the observed value for feature 2, multiplied by..

• To simplify the task, naïve Bayesian classifiers

assume attributes have independent distributions, and thereby estimate p(d|cj) = p(d1|cj) * p(d2|cj) * ….* p(dn|cj)

38

p(officer drew|cj) = p(over_170cm = yes|cj) * p(eye =blue|cj) * ….

Officer Drew is blue-eyed,

• ver 170cm

tall, and has long hair

p(officer drew| Female) = 2/5 * 3/5 * …. p(officer drew| Male) = 2/3 * 2/3 * ….

Naïve Bayes is fast and space efficient

We can look up all the probabilities with a single scan of the database and store them in a (small) table…

Sex Over190cm Male Yes 0.15 No 0.85 Female Yes 0.01 No 0.99

…

39

Sex Long Hair Male Yes 0.05 No 0.95 Female Yes 0.70 No 0.30 Sex Male Female

Naïve Bayes is NOT sensitive to irrelevant features... Suppose we are trying to classify a persons sex based on several features, including eye color. (eye color is irrelevant to a persons gender)

p(Jessica | Female) = 9,000/10,000 * 9,975/10,000 * …. p(Jessica | Male) = 9,001/10,000 * 2/10,000 * …. p(Jessica |cj) = p(eye = brown|cj) * p( wears_dress = yes|cj) * …. However, this assumes that we have good enough estimates of the probabilities, so the more data the better. Almost the same!

40

An obvious point. I have used a simple two class problem, and two possible values for each example, for my previous examples. However we can have an arbitrary number of classes, or feature values

Animal Mass >10kg Cat Yes 0.15 No 0.85 Dog Yes 0.91 No 0.09 Pig Yes 0.99 No 0.01

41

Animal Cat Dog Pig Animal Color Cat Black 0.33 White 0.23 Brown 0.44 Dog Black 0.97 White 0.03 Brown 0.90 Pig Black 0.04 White 0.01 Brown 0.95

Naïve Bayesian Classifier

42

Problem! Naïve Bayes assumes independence of features… Are height and weight independent? Naïve Bayes tends to work well anyway and is competitive with other methods

Sex Over 6 foot Male Yes 0.15 No 0.85 Female Yes 0.01 No 0.99 Sex Over 200 pounds Male Yes 0.20 No 0.80 Female Yes 0.05 No 0.95

43

10 1 2 3 4 5 6 7 8 9 10 1 2 3 4 5 6 7 8 9

The Naïve Bayesian Classifier has a quadratic decision boundary

How to Estimate Probabilities from Data?

• Class: P(C) = Nc/N

 e.g., P(No) = 7/10,

P(Yes) = 3/10

For discrete attributes: P(Ai | Ck) = |Aik|/ Nc

 where |Aik| is number of

instances having attribute Ai and belongs to class Ck

 Examples:

P(Status=Married|No) = 4/7 P(Refund=Yes|Yes)=0

44

k Tid Refund Marital Status Taxable Income Evade 1 Yes Single 125K No 2 No Married 100K No 3 No Single 70K No 4 Yes Married 120K No 5 No Divorced 95K Yes 6 No Married 60K No 7 Yes Divorced 220K No 8 No Single 85K Yes 9 No Married 75K No 10 No Single 90K Yes

c a c a c

• c

How to Estimate Probabilities from Data?

• For continuous attributes:

 Discretize the range into bins  Two-way split: (A < v) or (A > v)  choose only one of the two splits as new attribute  Creates a binary feature  Probability density estimation:  Assume attribute follows a normal distribution and use the data to fit this distribution  Once probability distribution is known, can use it to estimate the conditional probability P(Ai|c)

• We will not deal with continuous values on HW or exam

 Just understand the general ideas above

45

k

Example of Naïve Bayes

• We start with a test example and want to

know its class. Does this individual evade their taxes: Yes or No?

 Here is the feature vector:

 Refund = No, Married, Income = 120K

 Now what do we do?

 First try writing out the thing we want to measure

46

Example of Naïve Bayes

• We start with a test example and want to

know its class. Does this individual evade their taxes: Yes or No?

 Here is the feature vector:

 Refund = No, Married, Income = 120K

 Now what do we do?

 First try writing out the thing we want to measure  P(Evade|[No, Married, Income=120K])

 Next, what do we need to maximize?

47

Example of Naïve Bayes

• We start with a test example and want to

know its class. Does this individual evade their taxes: Yes or No?

 Here is the feature vector:

 Refund = No, Married, Income = 120K

 Now what do we do?

 First try writing out the thing we want to measure  P(Evade|[No, Married, Income=120K])

 Next, what do we need to maximize?

 P(Cj)  P(Ai| Cj)

48

Example of Naïve Bayes

• Since we want to maximize P(Cj)  P(Ai| Cj)

 What quantities do we need to calculate in order to

use this equation?

 Someone come up to the board and write them out,

without calculating them

 Recall that we have three attributes:

 Refund: Yes, No  Marital Status: Single, Married, Divorced  Taxable Income: 10 different “discrete” values

 While we could compute every P(Ai| Cj) for all Ai, we only need to do it for the attribute values in the test example

49

Values to Compute

• Given we need to compute P(Cj)  P(Ai| Cj)
• We need to compute the class probabilities

 P(Evade=No)  P(Evade=Yes)

• We need to compute the conditional

probabilities

 P(Refund=No|Evade=No)  P(Refund=No|Evade=Yes)  P(Marital Status=Married|Evade=No)  P(Marital Status=Married|Evade=Yes)  P(Income=120K|Evade=No)  P(Income=120K|Evade=Yes)

50

Computed Values

• Given we need to compute P(Cj)  P(Ai| Cj)
• We need to compute the class probabilities

 P(Evade=No) = 7/10 = .7  P(Evade=Yes) = 3/10 = .3

• We need to compute the conditional

probabilities

 P(Refund=No|Evade=No) = 4/7  P(Refund=No|Evade=Yes) 3/3 = 1.0  P(Marital Status=Married|Evade=No) = 4/7  P(Marital Status=Married|Evade=Yes) =0/3 = 0  P(Income=120K|Evade=No) = 1/7  P(Income=120K|Evade=Yes) = 0/7 = 0

51

Finding the Class

• Now compute P(Cj)  P(Ai| Cj) for both classes for

the test example [No, Married, Income = 120K]

 For Class Evade=No we get:

 .7 x 4/7 x 4/7 x 1/7 = 0.032

 For Class Evade=Yes we get:

 .3 x 1 x 0 x 0 = 0

 Which one is best?

 Clearly we would select “No” for the class value  Note that these are not the actual probabilities of each class, since we did not divide by P([No, Married, Income = 120K])

52

Naïve Bayes Classifier

• If one of the conditional probability is zero,

then the entire expression becomes zero

 This is not ideal, especially since probability estimates

may not be very precise for rarely occurring values

 We use the Laplace estimate to improve things.

Without a lot of observations, the Laplace estimate moves the probability towards the value assuming all classes equally likely

 Solution  smoothing

53

Smoothing

• To account for estimation from small samples, probability

estimates are adjusted or smoothed.

• Laplace smoothing using an m-estimate assumes that each

feature is given a prior probability, p, that is assumed to have been previously observed in a “virtual” sample of size m.

• For binary classes, p is assumed to be 0.5 (equal probability)
• The value of m determines how much of a “push” there is to the

prior probability. We usually use m=1.

54

m n mp n y Y x X P

k ijk k ij i

     ) | (

Laplace Smothing Example

• Assume training set contains 10 positive examples:

 4: small  0: medium  6: large

• Estimate parameters as follows

 Let m = 1; p = prior probability = 1/3 (all equally likely)

• Smoothed estimates

 P(small | positive) = (4 + 1/3) / (10 + 1) = 0.394  P(medium | positive) = (0 + 1/3) / (10 + 1) = 0.03  P(large | positive) = (6 + 1/3) / (10 + 1) = 0.576  P(small or medium or large | positive) = 1.0

55

Naïve Bayes Classifier(Summary)

• Description



Statistical method for classification based on Bayes theorem

• Advantages



Robust to isolated noise points



Robust to irrelevant attributes



Fast to train and to apply



Can handle high dimensionality problems



Generally does not require a lot of training data to estimate values



Appropriate for problems that may be inherently probabilistic

• Disadvantages



Independence assumption will not always hold

 But works surprisingly well in practice for many problems



Modest expressive power



Not very interpretable

56

More Examples

• There are several detailed examples provided

 Go over them before trying the HW, unless you

are clear on Bayesian Classifiers

57

Play-tennis example: estimate P(xi|C)

Outlook Temperature Humidity Windy Class sunny hot high false N sunny hot high true N

• vercast hot

high false P rain mild high false P rain cool normal false P rain cool normal true N

• vercast cool

normal true P sunny mild high false N sunny cool normal false P rain mild normal false P sunny mild normal true P

• vercast mild

high true P

• vercast hot

normal false P rain mild high true N

• utlook

P(sunny|p) = 2/9 P(sunny|n) = 3/5 P(overcast|p) = 4/9 P(overcast|n) = 0 P(rain|p) = 3/9 P(rain|n) = 2/5 Temperature P(hot|p) = 2/9 P(hot|n) = 2/5 P(mild|p) = 4/9 P(mild|n) = 2/5 P(cool|p) = 3/9 P(cool|n) = 1/5 Humidity P(high|p) = 3/9 P(high|n) = 4/5 P(normal|p) = 6/9 P(normal|n) = 2/5 windy P(true|p) = 3/9 P(true|n) = 3/5 P(false|p) = 6/9 P(false|n) = 2/5

P(p) = 9/14 P(n) = 5/14

58

Play-tennis example: classifying X

• An unseen sample X = <rain, hot, high, false>

<outlook, temp, humid, wind>

• P(X|p)·P(p) =

P(rain|p)·P(hot|p)·P(high|p)·P(false|p)·P(p) = 3/9 · 2/9 · 3/9 · 6/9 · 9/14 = 0.010582

• P(X|n)·P(n) =

P(rain|n)·P(hot|n)·P(high|n)·P(false|n)·P(n) = 2/5 · 2/5· 4/5 · 2/5 · 5/14 = 0.018286

• Sample X is classified in class n (don’t play)

59

Example of Naïve Bayes Classifier

60

Name Give Birth Can Fly Live in Water Have Legs Class

human yes no no yes mammals python no no no no non-mammals salmon no no yes no non-mammals whale yes no yes no mammals frog no no sometimes yes non-mammals komodo no no no yes non-mammals bat yes yes no yes mammals pigeon no yes no yes non-mammals cat yes no no yes mammals leopard shark yes no yes no non-mammals turtle no no sometimes yes non-mammals penguin no no sometimes yes non-mammals porcupine yes no no yes mammals eel no no yes no non-mammals salamander no no sometimes yes non-mammals gila monster no no no yes non-mammals platypus no no no yes mammals

• wl

no yes no yes non-mammals dolphin yes no yes no mammals eagle no yes no yes non-mammals

Give Birth Can Fly Live in Water Have Legs Class

yes no yes no ?

0027 . 20 13 004 . ) ( ) | ( 021 . 20 7 06 . ) ( ) | ( 0042 . 13 4 13 3 13 10 13 1 ) | ( 06 . 7 2 7 2 7 6 7 6 ) | (                 N P N A P M P M A P N A P M A P

A: attributes M: mammals N: non-mammals P(A|M)P(M) > P(A|N)P(N) => Mammals

61

• Advantages:

– Fast to train (single scan). Fast to classify – Not sensitive to irrelevant features – Handles real and discrete data – Handles streaming data well

• Disadvantages:

– Assumes independence of features

Advantages/Disadvantages

• f Naïve Bayes
