Data Integration

Sam Birch & Alex Leblang

Two faces of data integration

• Businesses

○ Have relatively more structured databases which they need to organize

• Research on integrating less structured data

○ Databases coming from different organizations without common architecture

Businesses have a lot of data …in many different databases

One safe place: the data warehouse

Businesses want to control and access their

• perational data in a single place:
• 1. Backups and versioning
• 2. Single query interface
• 3. Quality & consistency
• 4. Separation of analytic and
• perational workloads

Data warehouse design

Bill Inmon, a data warehouse means:

• 1. All data about a single real-world thing are

linked;

• 2. Data are never over-written or deleted;
• 3. Comprises all (or nearly all) an organization's

data in a consistent way;

• 4. Comprises all versions of the data in the
• perational system;
• 5. Not virtualized

Update methods

• 1. ETL
• 2. Virtual / federated databases
• 3. Change data capture

ETL

• Extract, Transform, Load
• Take data from one data source, transform it,

and load it into another location, usually a data warehouse

• Generally periodic (hourly, daily…)

Virtual (federated) DBs

• A method for integrating data virtually
• No actual (physical) data integration
• Virtual database systems give you the feel of

data integration without the need for maintaining one single data warehouse

How they work

• Federated databases map autonomous

database systems into a single database

• This is done over a computer network and has

the advantage of possible geographic distribution

• Federated databases can be loosely or tightly

coupled

Loosely / Tightly Coupled

• Loosely coupled databases require each

component to construct their own schema

○ ...forces the user to have knowledge of the schema when using the database

• Tightly coupled databases use independent

processes to create a schema used across the federated database

○ …removes much of the work from the user or DBA to the software itself

Change data capture

• Keep track of diffs, like version control for

your database

• Helpful for large data with smaller changes
• Different Implementations:

○ Timestamps on rows ○ Version number on rows ○ Triggers on tables

Reforming unstructured data

Large and unstructured

The 4 Vs (according to Dong)

○ large Volume of sources ○ changing at a high Velocity ○ as well as a huge Variety of sources ○ with lots of question regarding data Veracity

Dong et al.

Goals

• Schema alignment
• Record linkage
• Data fusion

Schema Alignment

Dong et al

Schema Alignment

• Mediated Schema

○ Identify domain specific modeling

• Attribute Matching

○ Identify similarities between schema attributes

• Schema Mapping

○ Specify how to specifically map records in different schemas

Dong et al

Record Linkage

Dong et al

Record Linkage

Dong et al

Data Fusion

Dong et al

Data Fusion

Dong et al

Data Fusion

• Reconciliation of conflicting non-identifying

content

○ Voting ○ Source Quality ○ Copy Detection

Dong et al

Dealing With Different Data Sources

• Semantic Heterogeneity
• Access Pattern Limitations
• Integrity Constraints
• Data-level Heterogeneity

http://research.cs.wisc.edu/dibook/ Chapter 3: Data Source

Semantic Heterogeneity

• Data integration can suffer from many issues
• Differences in:

○ organization of tables ○ naming of schemas ○ data-level representation

http://research.cs.wisc.edu/dibook/ Chapter 3: Data Source

Data-level Heterogeneity

• “115 Waterman St. 02912” / “Brown

University CIT”

• “Tim Kraska” / “Timothy Kraska” /

“tim_kraska@brown.edu”

• IRA: Individual Retirement Account or Irish

Republican Army?

• Arbitrarily hard: different descriptions /

photos of the same place

Entity resolution (ER)

“[The] problem of identifying and linking/grouping different manifestations of the same real world object.”

Getoor, 2012.

Ironically, AKA: deduplication, entity clustering, merge/purge, fuzzy match, record linkage, approximate match...

Motivating examples

• Mining unstructured data (e.g. webpages)
• Governance (census, intelligence)
• Generally, when data comes from different
• rganizations

Getoor, 2012.

ER Challenges

• Fundamental ambiguity
• Diversity in representations (format,

truncation, ambiguity)

• Errors
• Missing data
• Records from different times
• Relationships in addition to equality

Getoor, 2012.

Normalization

• Transform data into a format which is more

likely to match other similar data

○ Splitting / combining rows

• Canonicalization (e.g. phone numbers, URLs,

case of text, expanding truncations)

○ Maximally informative, but standard format

• Logic is specific to data

Getoor, 2012.

Pairwise matching

Raw data Normalized data Matching features

Getoor, 2012.

Matching features

• Edit distance (e.g. Levenstein) for typos
• Set/vector similarity (Jaccard index, TF/IDF,

dot-product) for

• Alignment (e.g. Monge-Elkan)
• Phonetic (e.g. Soundex)

Getoor, 2012.

Record linkage

• Matching record to record rather than datum

to datum

○ May also require schema alignment

• Average of component similarities
• Specific rules about each column
• Probabilistic models with ML

○ Training data not trivial: most pairs are obviously not matches

Getoor, 2012.

Collective matching and constraints

• Some data matching operations aren’t

independent of the other data in the record

○ e.g. two research papers in the same venue are more likely to be by the same authors

• Expressed in constraints over the matching

relationships of columns in a record

○ Transitivity (if A = B, and B = C then A = C) ○ Exclusivity (if A = B then B != C)

Getoor, 2012.

Getoor, 2012.

AscDB

• Developed at Google
• The authors looked at 14.1 billion HTML

tables and from that found 154 million that they considered to contain high quality relational data

• Work was done in 2008

Cafarella et al

AscDB

• The authors created the attribute correlation

statistics database

• AscDB is “a set of statistics about the schemas

in the corpus”

Cafarella et al

AscDB

• AscBD makes possible:

○ schema auto-complete ○ attribute synonym finding ○ join-graph traversal

Cafarella et al

ASCDb

Cafarella et al

ASCDb

Cafarella et al

2013 Follow Up

Extracting Tabular Data on the Web VLDB 2013 paper discusses the idea of row classes that have a more flexible method towards determining the table schema

Adelfio et al

Conclusion

• For businesses there are tradeoffs between

specialized systems and integration

• Lots of research is being done involving

combining very large amounts of disparate data

References

• Luna Dong and Divesh Srivastava, Big Data Integration,

Tutorial in Proceedings of the IEEE International Conference on Database Engineering (ICDE), 2013

• Lise Getoor, Ashwin Machanavajjhala, Entity

Resolution: Theory, Practice & Open Challenges, PVLDB 5(12): 2018-2019 (2012)

• Michael J. Cafarella, Alon Y. Halevy, Daisy Zhe Wang,

Eugene Wu, Yang Zhang: WebTables: exploring the power of tables on the web. PVLDB 1(1): 538-549 (2008)

• Marco D. Adelfio, Hanan Samet, Schema Extraction for

Tabular Data on the Web, In International Conference

• n Very Large Data Bases (VLDB), 2013
• http://research.cs.wisc.edu/dibook/
