SLIDE 1

Dark Energy: Observations

Gil Holder

slide-2
SLIDE 2

Outline

  • How dark energy affects cosmological
  • bservables
  • a(t) => distances(z), growth of structure(z)
  • Dark energy probes
  • cosmic microwave background
  • supernovae (type IA)
  • galaxy clustering
  • weak gravitational lensing
  • galaxy cluster number counts

Warning: not a comprehensive list of experiments!

slide-3
SLIDE 3

+cmb

supernovae galaxy clustering

Sullivan et al 2011

w=-1.06 +-0.07

slide-4
SLIDE 4

Energy Densities in Cosmology

d(ln a)/dt matter dark energy

a=1/(1+z)

scale factor

redshift

slide-5
SLIDE 5

The expanding universe

  • spatially flat FRW: dt2=a2(t) dr2
  • mapping between comoving distance

between points and time depends on expansion history

slide-6
SLIDE 6

Dark Energy from Distances

  • distance

sensitive to expansion rate

slide-7
SLIDE 7

Gravity at work

simulations carried out by the Virgo Supercomputing Consortium using computers based at Computing Centre of the Max-Planck Society in Garching and at the Edinburgh Parallel Computing Centre. The data are publicly available at www.mpa-garching.mpg.de/NumCos

t=400 000 yrs t=20 million yrs t=500 million yrs t=13.7 billion yrs

simulated density contrast at different times

1 billion light years

slide-8
SLIDE 8
  • Growth of

structure sensitive to expansion rate

Amplitude of density fluctuations in linear theory:

Amplitude of linear density fluctuations

w=-1/3

Λ

Dark Energy Studies with Growth Tests

slide-9
SLIDE 9

! !!! !

  • Fig. VI-2: The primary observables for dark-energy – the distance-redshift relation DDz)!
  • Characterizing

Dark Energy

from Dark Energy Task Force report

w=-0.9 w=-1

slide-10
SLIDE 10

Cosmic Microwave Background

  • acoustic scale (in cm)

set by physics unrelated to dark energy

–angular scale depends

  • n expansion history
  • provides

normalization of fluctuation amplitude at z~1100

10

WMAP (all sky)

South Pole Telescope (total 2500 sq deg)

8o

slide-11
SLIDE 11

CMB Power Spectrum

SPT power spectra: Ryan Keisler; Christian Reichardt; Erik Shirokoff

characteristic spacing set by angular size of sound horizon at z=1089

slide-12
SLIDE 12

! !!! !

  • Fig. VI-2: The primary observables for dark-energy – the distance-redshift relation DDz)!
  • Characterizing

Dark Energy

from Dark Energy Task Force report CMB

slide-13
SLIDE 13

Exploding stars: Supernovae

nearby (Type II) distant (Type IA) It appears that some supernovae (IA) all have the same intrinsic brightness

slide-14
SLIDE 14

Supernova!

slide-15
SLIDE 15

SNe Multi-color Light Curves

15

Conley et al 2008

slide-16
SLIDE 16

Standardized Candles

16

each panel is a different wavelength range

Conley et al 2008

slide-17
SLIDE 17

SNe Hubble Diagram

17

14 16 18 20 22 24 26 mcorr = mB + ! (s − 1) − " C

Low−z SDSS SNLS HST

0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 z

−0.6 −0.4 −0.2 0.0 0.2 0.4 0.6 mcorr

5 l

  • g

1

( d i s t a n c e )

Conley et al 2011

slide-18
SLIDE 18

Forecast & Wish List for SNe

  • need more SNe both at low-z and at z>1

–population studies to ensure that there isn’t some evolution in either each SN or in the demographics of the SN population

  • more colors would be nice (IR, UV?)

–space-based? (WFIRST)

  • a strong theoretical understanding of

spectra & light curves would be reassuring

18

slide-19
SLIDE 19

! !!! !

  • Fig. VI-2: The primary observables for dark-energy – the distance-redshift relation DDz)!
  • Characterizing

Dark Energy

from Dark Energy Task Force report CMB

SNe

slide-20
SLIDE 20

BAO

  • Baryon

Acoustic Oscillations leave imprint in matter distribution

Eisenstein, Seo & White 2006

slide-21
SLIDE 21

Galaxy Clustering

  • galaxies are

clustered

  • amplitude a bit tricky

to use because galaxies live at peaks

  • f density field

(``biased’’)

  • BAO signature

leads to boosted clustering on acoustic scale (~100 h-1Mpc) slice through SDSS survey

slide-22
SLIDE 22

Baryon Oscillations imprinted in Galaxy Clustering

  • first detected in

Eisenstein et al 2005 using SDSS LRG sample (extends to z~0.5)

  • actually detected

in angular & radial clustering

  • standard

ruler

slide-23
SLIDE 23

The BAO Hubble Diagram

  • BAO

measurements at different z allow a test of the distance- redshift relation

Blake et al 2011

slide-24
SLIDE 24

The BAO Hubble Diagram

  • BAO

measurements at different z allow a test of the distance- redshift relation

Blake et al 2011

slide-25
SLIDE 25

Forecast & Wish List for BAO

  • minimal (but not completely negligible) non-

linear physics

  • mainly need more volume
  • 100 Mpc/h scale + 1% precision requires at least

a few Gpc on a side surveys (cH0-1~3 Gpc/h)

  • lots of ideas & new surveys
  • e.g.., quasar absorption lines/optical galaxies

(BigBoss); CHIME (21cm intensity mapping)

just my personal favorites, no offense to the many others...

slide-26
SLIDE 26

! !!! !

  • Fig. VI-2: The primary observables for dark-energy – the distance-redshift relation DDz)!
  • Characterizing

Dark Energy

from Dark Energy Task Force report CMB

SNe BAO

slide-27
SLIDE 27

Gravitational Lensing

  • Distortion, multiple

imaging of distant sources

http://imagine.gsfc.nasa.gov/docs/features/news/grav_lens.html

www.hubblesite.org

slide-28
SLIDE 28

Gravitational Lensing

  • Distortion, multiple

imaging of distant sources

  • amount of lensing

depends on source/ lens/observer geometry (distances)

http://imagine.gsfc.nasa.gov/docs/features/news/grav_lens.html

slide-29
SLIDE 29
slide-30
SLIDE 30

Weak Lensing

  • gravitational potentials

distort shapes by stretching, squeezing, shearing

  • typical cosmic shear

signal ~1%

Gravity

slide-31
SLIDE 31

Galaxies are not round

  • individual galaxies have

complex morphologies

  • solution: average over

many galaxies

slide-32
SLIDE 32

Cosmic Shear Measurements

  • very strong

detections are now being made

  • e.g., CFHTLS has

published results from 57 sq deg of single-band ground- based imaging

$ [arcmin]

  • 2.0!10-5

0.0!100 2.0!10-5 4.0!10-5 6.0!10-5 8.0!10-5 1.0!10-4 1.2!10-4 1.4!10-4 1 10 100

<|%|2> $ [arcmin]

  • 5.0!10-6

0.0!100 5.0!10-6 1.0!10-5 1.5!10-5 50 100 150 200 250

CFHTLS

Fu et al 2008

(error bars are correlated)

shear variance in top hat window

slide-33
SLIDE 33
slide-34
SLIDE 34

Weak lensing tomography

  • using source galaxies at

different redshifts allows

  • ne to reconstruct the 3D

mass distribution

  • mass, not galaxy, density

means you can measure the time evolution of the density fluctuations

  • recent results using Hubble
  • ver ~1 sq deg

Massey et al

slide-35
SLIDE 35

Weak lensing tomography

  • using source galaxies at

different redshifts allows

  • ne to reconstruct the

3D mass distribution

  • mass, not galaxy, density

means you can measure the time evolution of the density fluctuations Schrabback et al 2010

0.2 0.4 0.6 0.8 1.0 −2.0 −1.5 −1.0 −0.5 0.0

!m w

slide-36
SLIDE 36
  • CMB is a unique source for lensing
  • Gaussian, with well-understood

power spectrum (contains all info)

  • At redshift which is (a) unique,

(b) known, and (c) highest

T L(ˆ n) = T U(ˆ n + ∇φ(ˆ n))

CMB Lensing

Broad kernel, peaks at z ~ 2

Photons get shifted

ˆ n

T

ˆ n + ∇φ

strong detections now exist

Power spectrum of density fluctuations

slide-37
SLIDE 37

Forecast & Wish List for lensing

  • cosmic shear requires large areas, good redshift

discrimination, good telescope understanding

  • space-based may be easier (high resolution, broad

wavelength coverage, very dark sky)

  • large surveys coming soon: 1000s of square

degrees of deep imaging (DES, Pan- Starrs, ...,LSST)

slide-38
SLIDE 38

! !!! !

  • Fig. VI-2: The primary observables for dark-energy – the distance-redshift relation DDz)!
  • Characterizing

Dark Energy

from Dark Energy Task Force report CMB

SNe BAO

Lensing

slide-39
SLIDE 39

Number counts of rare objects

  • simulated 2x2 degree

map showing projected thermal pressure

  • number of most

massive objects highly sensitive to amplitude

  • f density fluctuations
  • 10%

ref fluctuation amplitude

+10%

+20%

slide-40
SLIDE 40

Image by Will High in recent paper by Williamson et al

One of the heaviest objects in the universe >1015 solar masses

patch of isolated cosmic fog

CMB map made with South Pole Telescope

slide-41
SLIDE 41

Cluster dN/dz

41

Vanderlinde et al 2010

First SPT Cosmological result (Vanderlinde et al 2010), used SPT’s first 21 clusters to constrain cosmology 100 steps from WMAP7 wCDM MCMC chain with SPT dN/dz overplotted

slide from Brad Benson

slide-42
SLIDE 42

Constraints on dark energy from X-ray selected galaxy clusters

  • Vikhlinin et al 2009

(see also Mantz et al)

  • ~60 clusters at z<0.7
slide-43
SLIDE 43

Forecast & Wish List for galaxy clusters

  • need larger samples: 1% requires 1000s of

clusters just to beat Poisson noise: eROSITA (X- ray), DES (optical)

  • need strong validation campaign to ensure the

sample properties are well-understood (i.e., make sure that the number of objects is changing, not the type of object that is being found)

slide-44
SLIDE 44

! !!! !

  • Fig. VI-2: The primary observables for dark-energy – the distance-redshift relation DDz)!
  • Characterizing

Dark Energy

from Dark Energy Task Force report CMB

SNe BAO

Lensing Clusters

slide-45
SLIDE 45

Summary

  • dark energy is being observed in many

different ways

  • first discovered through supernovae, but many independent

cross-checks!

  • distances & structure formation are two

fundamentally different tests

  • all methods have strengths and weaknesses

but great promise for figuring out dark energy
