Cyber Security Research on Industrial Control Systems SM Yiu Department of Computer Science The University of Hong Kong Cyber-security for industry 4.0 conference 23 June, 2017 1 Will the followings only be seen in movies? Movies: Cyber


slide-1
SLIDE 1

Cyber Security Research on Industrial Control Systems

SM Yiu Department of Computer Science The University of Hong Kong

1

Cyber-security for industry 4.0 conference 23 June, 2017

slide-2
SLIDE 2

2

Will the followings only be seen in movies?

Movies: Cyber Hacking (2015); Italian Job (2003)

slide-3
SLIDE 3

3

IT IS REAL!

(Defcon Hacking conference 2014)

slide-4
SLIDE 4

4

2016 (US): 295 reports of ICS attacks (20% ) Mar: New York dam (control system accessed) April: German nuclear power plant (malware) Light-rail system, ….

slide-5
SLIDE 5

5

The purpose of the talk is to raise the awareness of the community on the security issues of ICS.

slide-6
SLIDE 6

6

Key components of an ICS

(Guide to Industrial Control System (ICS) Security, NIST, 2015)

slide-7
SLIDE 7

7

Numerous attack points SCADA – a typical ICS

(Guide to Industrial Control System (ICS) Security, NIST, 2015)

slide-8
SLIDE 8

8

PLC (programmable logic controller)

  • A small digital computer used for

automation of various electro- mechanical process in industries.

  • Specially designed to

survive in harsh conditions

  • Programs can be written in a computer and

downloaded to PLC via a communication link (e.g. cable)

  • “hard” real-time system: output produced in

response to input conditions within limited time.

slide-9
SLIDE 9

9

Is PLC critical? In what systems they are used?

slide-10
SLIDE 10

10

Yueng Long Sewage Treatment system

slide-11
SLIDE 11

11

Ventilation Control and Monitoring System for Tunnel of subway/railway

(pictures from MTR report)

slide-12
SLIDE 12

How easy to hack in PLC?

  • PLC are NOT secure:
  • PLC has no proper protection

built in, no authentication nor encryption for the communication protocol.

  • Able to discover PLC by

packet sniffing.

12

slide-13
SLIDE 13

Touch panel for floor selection PLC to control the lift

slide-14
SLIDE 14

A Touch panel to control the lift

slide-15
SLIDE 15

Sensor to detect the current floor

slide-16
SLIDE 16

Switch that connects the PLC and Touch Panel

slide-17
SLIDE 17

The PLC that controls the Lift system

slide-18
SLIDE 18

Attack to the Lift System

19

Hacker

Connect to the PLC and control the lift directly NO authentication

Q: Some engineers feel that it is not easy to connect to it because it is a “closed” system, do you agree? Network capability

slide-19
SLIDE 19

Five attacks (4 with demos)

  • 1. DoS attack

– 100 MB/s is already enough to disable PLC to receive any valid commands – No advanced hacking knowledge needed. Packet generation program – free from Internet

slide-20
SLIDE 20
  • 2. Command injection attack

– We connect to PLC directly and generate random commands to PLC – A little bit more knowledge needed: replay attack!

slide-21
SLIDE 21
  • 3. Control the lift

– Take control of the PLC, attacker can

  • rder to lift to whatever level.

– Understand the commands from touch panel to PLC.

slide-22
SLIDE 22
  • 4. Manipulate the sensor values

–Actively modify the sensor values –More knowledge about the sensor variables stored in PLC

slide-23
SLIDE 23
  • 5. Time bomb: hack the traffic lights

– Build a time bomb to turn both lights for cars and pedestrian green at the same time ONCE A WHILE.

slide-24
SLIDE 24

25

Again, a real case in US (Dec 2015).

They examined the traffic light and performed forensic analysis on the PLC …........

slide-25
SLIDE 25

26

Surprisingly…..

Event/log Date/time Program last modified Dec 08 2015 3:05pm Program last compiled Dec 08 2015 5:46pm Program last uploaded (by engineer) Dec 08 2015 5:46pm Program last uploaded (by ????) Dec 26 2015 4:18am Accident Dec 26 2015 pm

slide-26
SLIDE 26

27

What we can do (our research directions besides attack) ?

  • Build a protection layer

* Difficulty: low processing power, limited memory/buffer of PLC.

  • Add-in a forensic module

* For detection and investigation.

slide-27
SLIDE 27

28

Building a protection layer

…....... E.g. firewall (i) (ii) Light-weight detection module inside the PLC. Remark: We also have some interesting methods to do forensics (e.g. how to log the events with limited buffers/power)

slide-28
SLIDE 28

29

Acknowledgements

<Thank you>

  • Dr. KP Chow, leader of our research group

Our talented research students/engineers

  • Raymond Chan *
  • Chun Fai Chan, Ken Yau
  • Han Yu, Bo Zhang, Yuan Zhang

Our partner: Cisco

** We are more than willing to collaborate with industry for related R&D problems ** Alex Choy, PolyU
