CSE 3341: Principles of Programming Languages Syntax

Jeremy Morris

Syntax vs. Semantics

 Syntax:

 What kinds of symbols are allowed in a language?

 Semantics

 What do the symbols in a language mean? 2

Language Terminology

 Alphabet

 Finite set of symbols

 String

 Sequence of symbols

 Language

 Set of strings over an alphabet

 Grammar

 Rules that define which strings over an alphabet are in the

language and which ones are not

3

Terminology Example

 Consider the Java programming language

 Alphabet 

The tokens in the Java language.



if, then, while, do, >, <, String, variable names, etc.



Note: Not the individual characters

• Not your intuitive understanding of the term “alphabet”.

 String 

A sequence of tokens from the alphabet

 Language 

The set of all syntactically correct Java programs.

 Grammar 

The rules for producing syntactically correct Java programs.



https://docs.oracle.com/javase/specs/jls/se8/html/index.html



(It’s a nearly 800 page book – you don’t need to read it)

4

Language Terminology

 We typically talk about languages in mathematical terms

as sets

 Alphabet – finite set of symbols 

Often denoted as Σ

 String – finite set of symbol sequences 

Empty string: ε – a sequence of length 0



Σ* - the set of all strings over Σ (including ε)



The * represents the “Kleene closure” – we’ll discuss this more later



Σ+ - the set of all non-empty strings over Σ



The + represents “one or more” where the * represents “zero or more”

 Language – set of strings 

Language L ⊆ Σ*



Defined by a grammar



Probably will not contain everything in Σ*

5

Syntax - Specification

 We use syntax rules to specify the syntax of a language

 Language – set of all strings

 Some rules for non-negative integers:

number → digit digit* digit → 0 | 1 | 2 | 3 | 4 | 5| 6 | 7 | 8 | 9

 With these we can specify any non-negative integer.

6

Syntax Rule Terminology

 Terminal symbol

 Any symbol that represents a member of the alphabet for the

language



i.e. Any symbol that is in the set of all possible tokens for the language



Will only appear on the right hand side of a syntax rule



(At least for our purposes – not strictly true)  Non-terminal symbol

 Any symbol that represents a rule to be expanded 

Non-terminal – meaning “we need to keep going”



Can appear on either the left or the right hand side of a syntax rule

 Meta-symbols

 Symbols used to write the rules, but not part of the alphabet or

non-terminals



→, |, *, etc.

7

Terminology Example

number → digit digit* digit → 0 | 1 | 2 | 3 | 4 | 5| 6 | 7 | 8 | 9 Which of these are terminal symbols? Non-terminal? Meta?

8

Syntax – Types of Grammars

 Chomsky Hierarchy

 Outlines how complex formal languages are based on their rules  Type-0 – Unrestricted (aka Recursively enumerable)  Type-1 – Context-sensitive  Type-2 – Context-free  Type-3 – Regular  We will focus on those last two 9

Regular Languages (aka Regular Expressions)

 The simplest kind of grammar

 Requires only 3 kinds of rules: 

Concatenation



Join two things together



Alternation



Select between two choices



“Kleene closure”



Repeat something zero or more times.

 No recursion is allowed 

If we allow recursion, then we get Context-free grammars

10

Regular Languages (aka Regular Expressions)

 Assume an alphabet Σ. A regular expression over Σ is:

 Φ – the empty set  ε – the empty string  Any member of Σ (i.e. R = { r | r ϵ Σ})  Concatenation 

If R and S are both regular expressions over Σ, then so is RS



RS = {r.s | r ϵ Σ and s ϵ Σ}

 Alternation 

If R and S are both regular expressions over Σ, then so is R ∪ S



Written as R|S – choose between R or S

 “Kleene closure” 

If R is a regular expression over Σ, then so is R*



R repeated 0 or more times – R concatenated with itself

11

Regular Languages

 In syntax rules we can define a regular language like

this: number → digit digit* digit → 0 | 1 | 2 | 3 | 4 | 5| 6 | 7 | 8 | 9

 Another way of saying:

Σ = {0, 1, 2, 3, 4, 5, 6, 7, 8, 9} number = {dd*, d ϵ Σ}

(There might be a problem with this definition of a natural number – can you spot it?)

12

Regular Languages

 Another example (from the textbook)

 Numeric constants

number → integer | real integer → digit digit* real → integer exp | decimal (exp | ε) decimal → digit* (. digit | digit .) digit* exp → (e | E) (+ | - | ε) integer digit → 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 |0

13

Derivations

 Using syntax rules we can derive strings that are in our

language

 Using the previous set of rules, can we show that 655 is in our

language of “numeric constants”? number ⇒ integer ⇒ digit digit* ⇒ 6 digit* ⇒ 6 5 digit* ⇒ 6 5 5 digit* ⇒ 6 5 5

14

Derivations Example

 Using the rules on the previous slide, determine if the

following strings are in the language for numeric constants:

 10e5  .65e30  .65e0.30  10.0e5.0  10.0e-5 15

Context-Free Languages

 The Chomsky Hierarchy mentioned above is a hierarchy

 All Regular Languages are also Context-Free, but not all Context-

Free Languages are Regular

 Consider the language L = { anbn | n ≥ 0 } 

Empty string, ab, aabb, aaabbb, etc. are all in this language



aabbb, aaabb, a, etc. are not.



Can we derive the rules for this language using only the rules set out for regular languages?



No, as it turns out.

• You can prove this mathematically using a theorem known as the

pumping lemma, but that’s outside the scope of this class

• see CSE 3321 – Formal Languages and Automata



But if we allow recursion we can do it easily

16

Context-Free Grammars (CFGs)

 A grammar that defines a Context-Free language has

the same properties as a Regular grammar…

 Concatenation, Alternation, Kleene Closure

 …but allows for recursion in its rules

 Either immediate recursion – the non-terminal on both the right

and left hand side of the same rule



We’ll see an example of this on the next slide

 Or mutal recursion – a non-terminal on the left expands a rule

that eventually expands that non-terminal



We’ll see an example of this in a moment – hang in there

17

Context Free Grammars (CFGs)

The following grammar is not Regular, but is Context-Free: expr → number | expr op expr | ( expr )

• p → + | - | / | *

number → digit digit* digit → 0 | 1 | 2 | 3 | 4 | 5| 6 | 7 | 8 | 9

 Note the recursion in the rule for expanding expr  This grammar is problematic…

 Let’s derive 1+3*2 using the previous rules 18

Context-Free Grammars

 We can represent a derivation graphically as a parse

tree or syntax tree

 The root of the tree is the start symbol for the grammar  The internal nodes are non-terminal symbols  The leaf nodes are terminal symbols 19

expr expr

• p

expr number + expr

• p

expr number * number 1 3 2

Context-Free Grammars

 Consider these two trees, both derived from the above

grammar:

20

expr expr

• p

expr number + expr

• p

expr number * number 1 3 2 expr

• p

* expr number 2 expr expr

• p

expr number + number 1 3

Context-Free Grammars

 A better, unambiguous grammar:

expr → term | expr add_op term term → factor | term mult_op factor factor → number | ( expr ) mult_op → * | / add_op → + | - number → digit digit* digit → 0 | 1 | 2 | 3 | 4 | 5| 6 | 7 | 8 | 9

 Still not Regular, but Context-Free

 Recursion is still there 21

Languages in Compilers & Interpreters

22

Stream of Characters Tokenizer/ Scanner Stream of tokens Parser Parse Tree Next Steps

Syntax - Specification

 The previous syntax rules are one type on notation for a

syntax. number → digit digit* digit → 0 | 1 | 2 | 3 | 4 | 5| 6 | 7 | 8 | 9

 Here’s another:

<number> ::= <digit> | <digit> <number> <digit> ::= 0 | 1 | 2 | 3 | 4 | 5| 6 | 7 | 8 | 9



Backus-Naur Form (aka Backus normal form aka BNF)



Note that pure BNF does not use Kleene-star or Kleene-plus



Other extensions provide shorthand to allow these, but it doesn't change the expressiveness to not have them (see above for how to replace Kleene star)

23

BNF Specification

<number> ::= <digit> | <digit> <number> <digit> ::= 0 | 1 | 2 | 3 | 4 | 5| 6 | 7 | 8 | 9

 Special symbols: <, >, | and ::=

 Reserved (or ‘meta’) symbols

 Non-terminals

 Wrapped in <> tags - <digit> or <number>  Indicate rules that need to be expanded

 Terminals

 Not wrapped in <> tags  Indicate “terminal” symbols – no more expansion 24

CORE: Imperative Language

<prog> ::= program <decl-seq> begin <stmt-seq> end <decl-seq>::= <decl> | <decl> <decl-seq> <stmt-seq>::= <stmt> | <stmt> <stmt-seq> <decl> ::= int <id-list>; <id-list> ::= <id> | <id>, <id-list> <stmt> ::= <assign> | <if> | <loop> | <in> | <out> <assign> ::= <id> = <exp>; <if> ::= if <cond> then <stmt-seq> end; | if <cond> then <stmt-seq> else <stmt-seq> end; <loop> ::= while <cond> loop <stmt-seq> end; <in> ::= read <id-list>; <out> ::= write <id-list>;

25

CORE: Imperative Language

<cond> ::= <comp> | !<cond> | [ <cond> and <cond> ] | [ <cond> or <cond> ] <comp> ::= ( <fac> <comp-op> <fac> ) <exp> ::= <term> | <term> + <exp> | <term> - <exp> <term> ::= <fac> | <fac> * <term> <fac> ::= <int> | <id> | ( <exp> ) <comp-op> ::= != | == | < | > | <= | >= <id> ::= <let-seq> | <let-seq><int> <let-seq> ::= <let> | <let><let-seq> <let> ::= A | B | C | ... | X | Y | Z <int> ::= <digit> | <digit><int> <digit> ::= 0 | 1 | 2 | 3 | ... | 9

26

CORE syntax tree practice

program int X; begin X = 25; write X; end

27

Concrete Syntax Tree

28

<prog> program <decl-seq> begin <stmt-seq> end <decl> <id> X <stmt> <stmt-seq> <assign> <id> = <expr> ; <stmt> <out> X <term> <fac> <int> 25 write int <id-list> <id-list> <id> X ;

Abstract Syntax Tree

29

<prog> <decl-seq> <stmt-seq> <decl> <id> X <stmt> <stmt-seq> <assign> <id> <expr> <stmt> <out> X <term> <fac> <int> 25 <id-list> <id-list> <id> X

CORE parse tree practice

program int Y,Z; begin Y = 20; Z = 5; Y = Y – Z; write Y; end

30

CORE parse tree practice

program int X,Y,Z; begin Y = 20; Z = 5; X = 21; if Y < Z then if Y < X then Y=Z; else Y=X; end; end; write Y; end

31

Takeaways

 Syntax vs. Semantics  Regular Languages vs. Context Free Languages  Parsing and ambiguity  Abstract vs. Concrete Parse Trees

32

Readings

 Chapter 2.1 – Syntax  For next time: Chapter 2.3 – Parsing

 Skim Chapter 2.2 - Scanning 33
