CS573 Data Privacy and Security Secure Multiparty Computation

General Constructions Li Xiong

Last Lecture

• Symmetric & Public key encryption
• Secure Multiparty Computations
• Problem and security definitions
• General constructions
• Oblivious Transfer

Secure Multiparty Computation

• A set of parties with private inputs
• Parties wish to jointly compute a function of

their inputs so that certain security properties are preserved

• Properties must be ensured even if some of the

parties maliciously attack the protocol

• Can model any cryptographic task

Security Requirements

• Consider a secure auction (with secret bids):

–An adversary may wish to learn the bids of all parties – to prevent this, require PRIVACY –An adversary may wish to win with a lower bid than the highest – to prevent this, require CORRECTNESS –But, the adversary may also wish to ensure that it always gives the highest bid – to prevent this, require INDEPENDENCE OF INPUTS –An adversary may try to abort the execution if its bid is not the highest – require FAIRNESS

Security Requirements

• Privacy: only the output is revealed
• Correctness: the function is computed correctly
• Independence of inputs: parties cannot choose

inputs based on others’ inputs

• Fairness: if one party receives output, all receive
• utput
• Guaranteed output delivery

Defining Security

• Option 1: analyze security concerns for each

specific problem

– Auctions: as in previous slide – Elections: privacy, correctness and fairness only (?)

• Problems:

– How do we know that all concerns are covered? – Definitions are application dependent and need to be redefined from scratch for each task

Defining Security

• Option 2: general definition that captures all

(most) secure computation tasks

• Properties of any such definition

– Well-defined adversary model

• Semi-honest, Malicious

– Well-defined execution setting

• Stand-alone, concurrent general composition

– Security guarantees are clear and simple to understand

Defining Security: the Ideal/Real Paradigm

• What is the best we could hope for?

– An incorruptible trusted party – All parties send inputs to trusted party (over perfectly secure communication lines) – Trusted party computes output – Trusted party sends each party its output (over perfectly secure communication lines) – This is the ideal world

• What can an adversary do?

– Just choose its input…

• Semi-honest: simulator given input/output

generates the adversary’s view

Today

• Cont. Secure Multiparty Computations
• Problem and security definitions
• General constructions

Construction paradigms

• We sketch a couple of paradigms used in the

construction of secure multiparty protocols.

• Passively-secure computation for two-parties

– Use oblivious transfer to securely select a value

• Passively-secure computation with shares

– Use secret sharing scheme such that data can be reconstructed from some shares

• From passively-secure protocols to actively-

secure protocols

– Use zero-knowledge proofs to force parties to behave in a way consistent with the passively-secure protocol

Secret Sharing Scheme

• Distributing a secret amongst n participants,

each of whom is allocated a share of the secret

• The secret can be reconstructed only when a

sufficient number (t) of shares are combined together

– (t, n)-threshold scheme

Trivial Secret Sharing Scheme

• Splitting

– Encode the secret as an integer S. – Give to each player i (except one) a random integer ri. – Give to the last player the number 𝑇 − σ𝑗=1

𝑜−1 𝑠 𝑗

(t, n) threshold scheme

• Shamir’s scheme 1979

– It takes t points to define a polynomial of degree t-1 – Create a t-1 degree polynomial with secret as the first coefficient and the remaining coefficients picked at

• random. Find n points on the curve

and give one to each of the players. At least t points are required to fit the polynomial.

The GMW Paradigm

• “Can we design protocols that remain secure

even when some parties can behave maliciously? “*

• GMW (Goldreich, Micali and Wigderson)
• Paradigm for designing secure computation

protocols against malicious adversaries

• Secure computation for more than two

parties, computing Boolean circuits

Secure Multi-Party Computation, By M.M. Prabhakaran

The GMW Paradigm

• Construct a protocol for the semi-honest

model

• “Compile it” to obtain a protocol that is secure

for the malicious model

– Compilation involves forcing the parties to follow the protocol

• It may be more efficient to work differently

General GMW Construction

• For simplicity – consider two-party case
• Let f be the function that the parties wish to

compute

• Represent f as an arithmetic circuit with

addition and multiplication gates

• Aim – compute gate-by-gate, revealing only

random shares each time

Random Shares Paradigm

• Let a be some value:

– Party 1 holds a random value a1 – Party 2 holds a+a1 – Note that without knowing a1, a+a1 is just a random value revealing nothing of a. – We say that the parties hold random shares of a.

• The computation will be such that all

intermediate values are random shares (and so they reveal nothing).

Circuit Computation

• Stage 1: each party randomly shares its input with

the other party

• Stage 2: compute gates of circuit as follows

– Given random shares to the input wires, compute random shares of the output wires

• Stage 3: combine shares of the output wires in order

to obtain actual output

AND OR AND NOT OR AND

Alice’s inputs Bob’s inputs

Addition Gates

• Input wires to gate have values a and b:

– Party 1 has shares a1 and b1 – Party 2 has shares a2 and b2 – Note: a1+a2=a and b1+b2=b

• To compute random shares of output c=a+b

– Party 1 locally computes c1=a1+b1 – Party 2 locally computes c2=a2+b2 – Note: c1+c2=a1+a2+b1+b2=a+b=c

Multiplication Gates

• Input wires to gate have values a and b:

– Party 1 has shares a1 and b1 – Party 2 has shares a2 and b2 – Wish to compute c = ab = (a1+a2)(b1+b2)

• Party 1 knows its concrete share values a1 and

b1.

• Party 2’s shares a2 and b2 are unknown to

Party 1, but there are only 4 possibilities (00,01,10,11)

Multiplication (cont)

• Party 1 prepares a table as follows:

– Row 1 corresponds to Party 2’s input 00 – Row 2 corresponds to Party 2’s input 01 – Row 3 corresponds to Party 2’s input 10 – Row 4 corresponds to Party 2’s input 11

Multiplication (cont)

• Party 1 prepares a table as follows (Let r be

a random bit chosen by Party 1):

– Row 1 contains the value ab+r when a2=0,b2=0 – Row 2 contains the value ab+r when a2=0,b2=1 – Row 3 contains the value ab+r when a2=1,b2=0 – Row 4 contains the value ab+r when a2=1,b2=1

Concrete Example

• Assume: a1=0, b1=1
• Assume: r=1

Row Party 2’s shares Output value

1 a2=0,b2=0 (0+0).(1+0)+1=1 2 a2=0,b2=1 (0+0).(1+1)+1=1 3 a2=1,b2=0 (0+1).(1+0)+1=0 4 a2=1,b2=1 (0+1).(1+1)+1=1

The Gate Protocol

• The parties run a 1-out-of-4 oblivious transfer

protocol

• Party 1 plays the sender: message i is row i of

the table.

• Party 2 plays the receiver: it inputs 1 if a2=0

and b2=0, 2 if a2=0 and b2=1, and so on…

• Output:

– Party 2 receives c2=c+r – this is its output – Party 1 outputs c1=r – Note: c1 and c2 are random shares of c, as required

Summary

• By computing each gate these way, at the end

the parties hold shares of the output wires

• Function output generated by simply sending

shares to each other.

Security

• Reduction to the oblivious transfer protocol
• Assuming security of the OT protocol, parties only

see random values until the end. Therefore, simulation is straightforward.

• Note: correctness relies heavily on semi-honest

behavior (otherwise can modify shares).

• Theorem: any functionality f can be securely

computed in the semi-honest model.

Remark

• The semi-honest model is often used as a tool

for obtaining security against malicious parties.

• In many (most?) settings, security against

semi-honest adversaries does not suffice.

• In some settings, it may suffice.

– One example: hospitals that wish to share data.

Lecture 3

Generalize to n parties

• The setting:
• Parties P1,…,Pn
• Inputs x1,…,xn (bits, but can be easily generalized)
• Outputs y1,…,yn
• The protocol:
• Each party shares its input bit
• Scan the circuit gate by gate

– Input values of gate are shared by the parties – Run a protocol computing a sharing of the output value of the gate – Repeat

• Publish outputs

Protocol for semi-honest setting

• The protocol:
• Each party shares its input bit
• The sharing procedure:

– Pi has input bit xi – It chooses random bits ri,j for all i≠j. – Sends bit ri,j to Pj. – Sets its own share to ri,i = xi + (Σj≠i ri,j ) mod 2 – Therefore Σj=1…n ri,j = xi mod 2.

• Now every Pj has n shares, one for each input xi of

each Pi.

Protocol for semi-honest setting

• The protocol computes shares of the output

wires.

• Each party sends its share of an output wire

to the party Pi that should learn that output.

• Pi can then sum the shares, obtain the value

and output it.

The Malicious Case

• The above protocol is not secure against

malicious adversaries:

• What can go wrong with malicious behavior?
• Using shares other than those defined by the

protocol, using arbitrary inputs to the OT protocol and sending wrong shares of output wires…

• In the OT protocol we saw, the receiver can easily

and undetectably learn both of the sender’s inputs

Proving Security

• Recall the definition

– Simulator interacts with a trusted party

• Simulator sends corrupted parties’ inputs
• Simulator receives corrupted parties’ outputs

– Output distribution of simulator and the honest parties is like in a real execution

• Input extraction

– In order for the honest parties to output the same in a real and ideal execution, the simulator must extract the input used by the adversary

Malicious Adversaries

• We will show a compiler which forces the

parties to operate as in the semi-honest model (GMW)

• The basic idea:
• In every step, each Pi proves in zero knowledge

that its messages were computed according to the protocol

Forcing Good Behavior

• AIM: a party should prove that the

message it is sending is correct.

–That is, it is consistent with the protocol instructions, given the input and random- tape that are committed and the incoming messages (that are public).

Tool: Zero Knowledge

• Problem setting: a prover wishes to prove a

statement to the verifier so that:

– Zero knowledge: the verifier will learn nothing beyond the fact that the statement is correct – Soundness: the prover will not be able to convince the verifier of a wrong statement

Zero Knowledge

• Prover P, verifier V, language 𝑀
• P proves that 𝑦 ∈ 𝑀 without revealing anything
• Completeness: V always accepts when 𝑦 ∈ 𝑀 , and an

honest P and V interact

• Soundness: V accepts with negligible probability when

𝑦 ∉ 𝑀, for any P*

– Computational soundness: only holds when P is polynomial-time

• Zero-knowledge:
• there exists a simulator S such that S(x) is indistinguishable

from the verifier’s output after a real proof execution.

A Warmup

• Assume that each 𝑄𝑗 runs a deterministic program Π𝑗

The compiler is the following:

• Each 𝑄𝑗 commits to its input 𝑦𝑗 by sending 𝐷𝑗 (𝑠

𝑗 , 𝑦𝑗 ),

where 𝑠

𝑗 is a random string used for the commitment

• Let 𝑈𝑗

𝑡 be the transcript of 𝑄𝑗 at step s, i.e. all messages

received and sent by 𝑄𝑗 until that step.

• Define the language 𝑀𝑗 = {𝑈𝑗

𝑡 𝑡. 𝑢, ∃𝑦𝑗 , 𝑠 𝑗 so that all

messages sent by 𝑄𝑗 until step s are the output

• f Π𝑗 applied to 𝑦𝑗 , 𝑠

𝑗 and to all messages received

by 𝑄𝑗 up to that step}

• When sending a message in step s prove in zero-

knowledge that 𝑈𝑗

𝑡 ∈ 𝑀𝑗

Recall: GMW

• General methodology takes any secure semi-honest

two-party computation protocol and compiles it into a protocol that is secure against malicious adversaries

• Two stages:
• Stage 1: Show a protocol for securely computing any

functionality in the semi-honest adversarial model

• Stage 2: Construct a protocol compiler that takes any

semi-honest protocol and “converts” it into a protocol that is secure in the malicious model

• As this compiler is generic, it can be applied to any

semi-honest protocol

Obtaining Security

Three goals:

• Force the adversary to use a fixed input

– Furthermore, make it possible for the ideal-model simulator/adversary to extract this input.

• Force the adversary to use a uniform random

tape

• Force the adversary to follow the protocol

exactly (consistently with their fixed input and random tape)

The compiler

• Transformation from security against honest-but-curious

adversaries to security against malicious (active) adversaries works by combining three building blocks:

• Input commitment scheme

– Each party commits to its input

• Coin tossing protocol
• The parties generate random tapes for each other

– Initial idea: random tape of Pi is defined as S1,i⨁S2,i⨁ …⨁Sn,i, where Sj,i is chosen by Pj

• Protocol emulation phase:

– Run the protocol while proving that parties operations comply with their inputs and random tapes

Stage 1: Input Commitment

Preliminaries: bit commitment Sender holds an item that receiver does not know

• Commit Stage:

– Committer has a bit  ∈ 0,1 – Receiver obtains a commitment string c

• Commitments of 0 and bit 1 appear identical to the receiver
• Reveal Stage:

– Committer sends a decommit message to receiver – Receiver uses decommit message and c to obtain 

Bit Commitment

Security Properties:

• Binding: for every c, there exists only one value  for

which decommitment is accepted

– Given commitment cannot be opened in more than one way – The committer cannot change the commitment value by sending a different key in the reveal phase

• Hiding: the receiver cannot distinguish a commitment

string that is to 0 from a commitment string that is to 1.

– Commitments of different bits look indistinguishable to the receiver

Protocols

• Commitment using public-key encryption:

– Committer chooses a key-pair (pk,sk). – Committer sends (pk,c=Epk()) to the receiver.

• Decommitment:

– Committer sends the secret-key sk to the receiver – Receiver verifies that sk is associated with pk and decrypts, obtaining .

Proving Security

• Proof of security
• 𝑄1 is corrupted: verify proof and extract

“witness”; send (𝑦, 𝑠) to the trusted party

• 𝑄2 is corrupted: commit to garbage and run

zero knowledge simulator

Coin Tossing

• Aim: fix uniform random tape of each party

– Allow a pair of distrustful parties to agree on a common random value

• In honest-but-curious adversary model: (Trivial)

– Alice can choose a random bit and send it to Bob.

• In malicious adversary model: does not work

– Instead of selecting a random bit, Alice can choose a bit that is favorable to her and affect the bias of the output

• Coin tossing of a bit:

– Alice and Bob agree on a common random bit – Alice and Bob obtain the same uniform (pseudorandom) bit r

Coin Tossing

• To ensure the output is random, need to make the outcome dependent
• n both parties
• Idea: Alice chooses a random bit rA, Bob chooses a random bit rB, and

they output rA +rB

– Then even if one of the parties tries to cheat, as long as the other party plays fairly the outcome will be truly random

• Problem: this protocol cannot be realized in the communication model

– When Alice and Bob communicate, one of them has to go first. But if Alice sends her bit rA first, then Bob can make his choice rB dependent of rA

• if Bob wants the outcome to be zero, he can set rB = rA
• Solution: with help of commitment

Coin Tossing Protocol [Blum]

• Protocol:

– Make use of a commitment scheme – Alice chooses a random bit rA, computes a commitment cA to rA and sends cA to Bob – Bob chooses a random bit rB and sends it to Alice – Alice decommits, revealing rA

• Outputs:

– Both parties output r=rArB

Augmented Coin Tossing

• Recall: coin tossing is for choosing

random tapes of parties.

• But, Party 1 does not know Party 2’s

random tape in reality!

• Augmented coin-tossing:

– Party 1 obtains a random string r – Party 2 obtains a commitment to r

Security

• 𝑸𝟐 is corrupted
• Simulator receives (𝑐, 𝑠) from trusted party
• Simulator rewinds in each iteration to make each bit

correct

– Note that the simulator does not get the decommitment of 𝑐𝑗 like in Blum – However, it can run all the way to the end and run the extractor for the proof – Quite complex

• 𝑸𝟑 is corrupted
• Simulator receives 𝑑 from trusted party
• Simulator runs first part honestly with adversary
• Simulator gives 𝑑 at end and simulates the zero knowledge

Protocol Emulation

• At this stage, each party holds a commitment

to the other party’s input and random tape.

• A protocol is a deterministic function of a

party’s input, random tape and series of incoming messages.

• Therefore, the commitments can be used to

force the parties to follow the protocol instructions.

Protocol Compilation

• Given any protocol, construct a new protocol

as follows:

– Both parties commit to inputs – Both parties generate uniform random tape – Parties send messages to each other, each message is proved “correct” with respect to the

• riginal protocol, with zero-knowledge proofs.

Resulting Protocol

• Theorem: if the initial protocol was secure

against semi-honest adversaries, then the compiled protocol is secure against malicious adversaries.

• Proof:

– Show that even malicious adversaries are limited to semi-honest behavior. – Show that the additional messages from the compilation all reveal nothing.

Summary

• GMW paradigm:

– First, construct a protocol for semi-honest adv. – Then, compile it so that it is secure also against malicious adversaries

• There are many other ways to construct secure

protocols – some of them significantly more efficient.

• Efficient protocols against semi-honest

adversaries are far easier to obtain than for malicious adversaries.

Slides credits

• Tutorial on secure multi-party computation, Lindell

www.cs.biu.ac.il/~lindell/research-statements/tutorial-secure-computation.ppt

• Introduction to secure multi-party computation, Vitaly Shmatikov, UT Austin

http://www.cs.utexas.edu/~shmat/courses/cs380s_fall09/15smc.ppt

• Introduction to Cryptography, Yehuda Lindell, Bar Ilan University, IL

http://crypto.biu.ac.il/sites/default/files/

• Information Security Management, UTC
• Cryptography fall 2012, Andrej Bogdanov, the Chinese University of Hong Kong

http://www.cse.cuhk.edu.hk/~andrejb/csc5440/

• Parallel Coin-Tossing and Constant-Round Secure Two-Party Computation, Yehuda

Lindell, https://www.iacr.org/archive/crypto2001/21390170.pdf
