Chair of Network Architectures and Services Department of Informatics Technical University of Munich Crowdsourced IoT Data Modeling Friederike Groschupp Final Talk for Bachelors Thesis Advisors: Marc-Oliver Pahl, Stefan Liebald March 19,

slide-1
SLIDE 1

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

Crowdsourced IoT Data Modeling

Friederike Groschupp Final Talk for Bachelor’s Thesis Advisors: Marc-Oliver Pahl, Stefan Liebald

March 19, 2018 Chair of Network Architectures and Services Department of Informatics Technical University of Munich

slide-2
SLIDE 2

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

Contents

Motivation: Crowdsourced Context Modeling Demo Analysis Related Work Design Evaluation Performance Usability Conclusion

  • F. Groschupp

– Crowdsourced IoT Data Modeling 2

slide-3
SLIDE 3

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

Motivation: Crowdsourced Context Modeling [4]

<model type =myModel> value <subnode type= mySubnode /> </myModel> <model type =myModel> value <subnode type= mySubnode /> </myModel> <model type =myModel> value <subnode type= mySubnode /> </myModel> <model type =myModel> value <subnode type= mySubnode /> </myModel> <model type =myModel> value <subnode type= mySubnode /> </myModel> <model type =myModel> value <subnode type= mySubnode /> </myModel>

Context Model Repository (CMR)

<model type =myModel> value <subnode type= mySubnode /> </myModel> <model type =myModel> value <subnode type= mySubnode /> </myModel> <model type =myModel> value <subnode type= mySubnode /> </myModel>

  • F. Groschupp

– Crowdsourced IoT Data Modeling 3

slide-4
SLIDE 4

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

Background: the Data Model

  • Four basic types: number, text, list, composed
  • List and composed nodes can contain other nodes
  • Restrictions can limit the value of a node
  • (Multi-)inheritance
  • F. Groschupp

– Crowdsourced IoT Data Modeling 4

slide-5
SLIDE 5

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

Background: the Data Model

  • Four basic types: number, text, list, composed
  • List and composed nodes can contain other nodes
  • Restrictions can limit the value of a node
  • (Multi-)inheritance
  • F. Groschupp

– Crowdsourced IoT Data Modeling 5

slide-6
SLIDE 6

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

Invariants to be checked

  • All types exist
  • All access rights groups exist
  • Restrictions are valid and only narrowed through inheritance
  • Default values match restrictions and types
  • Subnodes must be valid
  • F. Groschupp

– Crowdsourced IoT Data Modeling 6

slide-7
SLIDE 7

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

Demo

  • F. Groschupp

– Crowdsourced IoT Data Modeling 7

slide-8
SLIDE 8

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

Analysis – Requirements Analysis

Functional requirements:

  • R1: context models in the CMR must be valid.
  • R2: context models in the CMR must be minimized.
  • R3: possibility to browse and search the models.
  • R4: convergence for standardization of models.

Non-functional requirements:

  • R5: validation process shall be interactive.
  • R6: helpful error reports.
  • F. Groschupp

– Crowdsourced IoT Data Modeling 8

slide-9
SLIDE 9

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

Analysis

  • VSL information model: semantics distributed over several models
  • Standard solutions for XML validation
  • Document Type Definition (DTD) [1], XML Schema (XSD) [5]
  • Can validate syntax and restrict attributes
  • Cannot validate semantic aspects of the VSL information model:

inheritance, attributes restricting value and elements of a node

  • VSL information model is independent from XML

→ Implement semantic validation process independent from XML

  • F. Groschupp

– Crowdsourced IoT Data Modeling 9

slide-10
SLIDE 10

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

Related Work – CellML Repository [3]

  • repository for biological models
  • quality control is performed manually
  • models can be browsed through web application, extended search

functions

  • F. Groschupp

– Crowdsourced IoT Data Modeling 10

slide-11
SLIDE 11

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

  • F. Groschupp

– Crowdsourced IoT Data Modeling 11

slide-12
SLIDE 12

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

Design - Steps Required for Adding a Model

Validation Minimization Produce Error Message Add Model Produce Success Message

valid invalid new model

Resolve parent model

  • F. Groschupp

– Crowdsourced IoT Data Modeling 12

slide-13
SLIDE 13

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

Resolving (1/2)

Retrieve the model "myType" from the repository.

  • F. Groschupp

– Crowdsourced IoT Data Modeling 13

slide-14
SLIDE 14

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

Resolving (2/2)

And resolve it.

  • F. Groschupp

– Crowdsourced IoT Data Modeling 14

slide-15
SLIDE 15

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

R1: Validation - Second Step: Compare Information

  • F. Groschupp

– Crowdsourced IoT Data Modeling 15

slide-16
SLIDE 16

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

R1: Validation - Policies for the Restrictions

  • "minimumValue", "maximumValue": simple comparison
  • "minimumEntries", "maximumEntries": simple comparison
  • "allowedIDs": must be subset
  • "regularExpression": No efficient methods known for deciding if

L(R1) ⊆ L(R2).

Policy: value has to comply with all regular expressions inherited.

L(R1) ∩ L(R2) ⊆ L(R2)

is always true.

  • F. Groschupp

– Crowdsourced IoT Data Modeling 16

slide-17
SLIDE 17

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

R2: Minimization

  • performed when a model is valid
  • remove all redundant information
  • reuse the already created resolved parent model
  • F. Groschupp

– Crowdsourced IoT Data Modeling 17

slide-18
SLIDE 18

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

  • F. Groschupp

– Crowdsourced IoT Data Modeling 18

slide-19
SLIDE 19

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

R6: Error Reports

  • line and identifier of the invalid (sub)node
  • error type
  • error reason
  • F. Groschupp

– Crowdsourced IoT Data Modeling 19

slide-20
SLIDE 20

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

Evaluation – R5: Performance

Impact of

  • number of subnodes
  • inheritance depth
  • f a model on resolving, validation, and minimization.

Expectation:

  • resolving depends on inheritance depth
  • validation and minimization depend on model complexity
  • F. Groschupp

– Crowdsourced IoT Data Modeling 20

slide-21
SLIDE 21

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

Evaluation – R5: Performance

Resolving

100 200 100 200

Inheritance Depth Time in ms

100 200 0.2 0.4 0.6 0.8 1

Inheritance Depth per inheritance step

Figure 1: Time in milliseconds required for resolving context models with inheritance depth 10, 100, and 200.

  • F. Groschupp

– Crowdsourced IoT Data Modeling 21

slide-22
SLIDE 22

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

Evaluation – R5: Performance

Validation 21 341 5461

1,000 2,000 3,000

Number of subnodes Time in ms 21 341 5461

0.5 1 1.5 2

Number of subnodes Time in ms per node

  • F. Groschupp

– Crowdsourced IoT Data Modeling 22

slide-23
SLIDE 23

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

Evaluation – R5: Performance

Conclusion:

  • bottleneck: retrieving and parsing models
  • caching component can significantly improve performance
  • total runtime of below 50ms for models of expected size (depth 5,

40 subnodes)

  • F. Groschupp

– Crowdsourced IoT Data Modeling 23

slide-24
SLIDE 24

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

Evaluation – R6: Helpfulness of Error Reports

  • survey with 10 participants, questionnaire with invalid models and

error reports

  • F. Groschupp

– Crowdsourced IoT Data Modeling 24

slide-25
SLIDE 25

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

Evaluation – R6: Helpfulness of Error Reports

  • very good feedback for finding the error
  • suggestions for resolving the error would improve the helpfulness

further error finding error resolving error type correct +

  • +
  • containing subnode

8 7 1 4 4 relaxing restriction 9 7 2 7 2 wrong restriction 9 9 6 3 undefined accessID 10 9 1 5 5

Table 1: Number of the correct answers for each context model, together with the rating of those participants who answered correctly.

  • F. Groschupp

– Crowdsourced IoT Data Modeling 25

slide-26
SLIDE 26

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

Conclusion – Contribution

First step towards enabling crowdsourced context model creation. Requirement R1: Validation ++ implemented and tested R2: Minimization ++ implemented and tested R3: Browsing and Searching R4: Convergence Mechanisms R5: Fast Validation Process ++ < 50ms for models of ex- pected size R6: Helpful Error Reports + basic

Table 2: Fulfillment of the requirements.

  • F. Groschupp

– Crowdsourced IoT Data Modeling 26

slide-27
SLIDE 27

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

Conclusion – Next Steps

  • 1. Improve error reporting
  • 2. R3 (browsing and searching): graphical interface/web application
  • 3. Adapted editor for VSL information model
  • 4. R4 (standardization of models): similarity detections, semantic

tagging system

  • F. Groschupp

– Crowdsourced IoT Data Modeling 27

slide-28
SLIDE 28

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

Thank you for your attention!

Do you have any questions?

  • F. Groschupp

– Crowdsourced IoT Data Modeling 28

slide-29
SLIDE 29

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

References

[1] Extensible markup language (xml) 1.0 (fifth edition), https://www.w3.org/tr/xml/, 18.02.2018. [2] Project haystack, https://project-haystack.org/, 25.01.2018. [3] The cellml project, https://www.cellml.org/, 28.01.2018. [4] M.-O. Pahl and G. Carle. Crowdsourced context-modeling as key to future smart spaces. In 2014 IEEE Network Operations and Management Symposium (NOMS), pages 1–8. IEEE, 2014. [5] World Wide Web Consortium. Xml schema, https://www.w3.org/xml/schema, 13.01.2018.

  • F. Groschupp

– Crowdsourced IoT Data Modeling 29

slide-30
SLIDE 30

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

Parsing Models

fully dependent on data model dependent on data model and parser independent from data model and parser existing parsers Custom- written connector model represented in text file model represented in Java model represented in Java

  • F. Groschupp

– Crowdsourced IoT Data Modeling 30

slide-31
SLIDE 31

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

R1: Validation

Two different approaches: retrieve information one-by-one or resolve parent model completely

What is the first maximum Value?

1

Resolve the model „derived/boolean“ What is the first minimumValue?

CMR CMR

Resolve model

<model type =myModel> value <subnode type=“mySubnode“ /> </myModel>

  • F. Groschupp

– Crowdsourced IoT Data Modeling 31

slide-32
SLIDE 32

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

Handling Multi-Inheritance

  • 1. merge the information

contained by the referenced types from left to right

  • 2. validate the combination
  • f types
  • 3. validate the new model

against the temporary model Id: derived/boolean Type: basic/number Restriction: minimumValue = 1, maximumValue = 2 Id: basic/composed Id: derived/boolean,basic/composed Type: derived/boolean, basic/number, basic/composed Restriction: minimumValue = 0, maximumValue = 1 Id: myMultiInheritanceModel Type: derived/boolean, basic/composed Value: 0

  • F. Groschupp

– Crowdsourced IoT Data Modeling 32

slide-33
SLIDE 33

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

  • F. Groschupp

– Crowdsourced IoT Data Modeling 33

slide-34
SLIDE 34

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

  • F. Groschupp

– Crowdsourced IoT Data Modeling 34

slide-35
SLIDE 35

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

  • F. Groschupp

– Crowdsourced IoT Data Modeling 35

slide-36
SLIDE 36

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

  • F. Groschupp

– Crowdsourced IoT Data Modeling 36

slide-37
SLIDE 37

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

  • F. Groschupp

– Crowdsourced IoT Data Modeling 37

slide-38
SLIDE 38

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

Related Work – Project Haystack [2]

  • same domain, same goal, different approach
  • data base with tags to describe entities
  • consensus finding based on discussions

id: @whitehouse dis: "White House" site area: 55000sqft geoAddr: "1600 Pennsylvania Avenue NW, Washington, DC" tz: "New_York" weatherRef: @weather.washington

Listing 1: Entity in Project Haystack’s meta model for the whitehouse. [2]

  • F. Groschupp

– Crowdsourced IoT Data Modeling 38

slide-39
SLIDE 39

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

Demo

  • F. Groschupp

– Crowdsourced IoT Data Modeling 39

slide-40
SLIDE 40

Chair of Network Architectures and Services Department of Informatics Technical University of Munich

  • F. Groschupp

– Crowdsourced IoT Data Modeling 40
