CPSC 533 Reinforcement Learning

Paul Melenchuk Eva Wong Winson Yuen Kenneth Wong

Outline

• Introduction
• Passive Learning in an Known Environment
• Passive Learning in an Unknown Environment
• Active Learning in an Unknown Environment
• Exploration
• Learning an Action Value Function
• Generalization in Reinforcement Learning
• Genetic Algorithms and Evolutionary Programming
• Conclusion
• Glossary

Introduction

In which we examine how an agent can learn from success and failure, reward and punishment.

Introduction

Learning to ride a bicycle:

The goal given to the Reinforcement Learning system is simply to ride the bicycle without falling

• ver

Begins riding the bicycle and performs a series of actions that result in the bicycle being tilted 45 degrees to the right

Photo:http://www.roanoke.com/outdoors/bikepages/bikerattler.html

Introduction

Learning to ride a bicycle:

RL system turns the handle bars to the LEFT Result: CRASH!!! Receives negative reinforcement RL system turns the handle bars to the RIGHT Result: CRASH!!! Receives negative reinforcement

Introduction

Learning to ride a bicycle:

RL system has learned that the “state” of being titled 45 degrees to the right is bad Repeat trial using 40 degree to the right By performing enough of these trial-and-error interactions with the environment, the RL system will ultimately learn how to prevent the bicycle from ever falling over

Passive Learning in a Known Environment

Passive Learner: A passive learner simply watches the world going by, and tries to learn the utility of being in various states. Another way to think of a passive learner is as an agent with a fixed policy trying to determine its benefits.

Passive Learning in a Known Environment

In passive learning, the environment generates state transitions and the agent perceives them. Consider an agent trying to learn the utilities of the states shown below:

Passive Learning in a Known Environment

Agent can move {North, East, South, West} Terminate on reading [4,2] or [4,3]

Passive Learning in a Known Environment

Agent is provided: Mi j = a model given the probability of reaching from state i to state j

Passive Learning in a Known Environment

the object is to use this information about rewards to learn the expected utility U(i) associated with each nonterminal state i Utilities can be learned using 3 approaches 1) LMS (least mean squares) 2) ADP (adaptive dynamic programming) 3) TD (temporal difference learning)

Passive Learning in a Known Environment

LMS LMS (Least Mean Squares) (Least Mean Squares)

Agent makes random runs (sequences of random moves) through environment [1,1]->[1,2]->[1,3]->[2,3]->[3,3]->[4,3] = +1 [1,1]->[2,1]->[3,1]->[3,2]->[4,2] = -1

Passive Learning in a Known Environment

LMS

Collect statistics on final payoff for each state

(eg. when on [2,3], how often reached +1 vs -1 ?) Learner computes average for each state Provably converges to

true expected value (utilities)

(Algorithm on page 602, Figure 20.3)

Passive Learning in a Known Environment

LMS

Main Drawback:

• slow convergence
• it takes the agent well over a 1000 training

sequences to get close to the correct value

Passive Learning in a Known Environment

ADP (Adaptive Dynamic Programming)

Uses the value or policy iteration algorithm to calculate exact utilities of states given an estimated model

Passive Learning in a Known Environment

ADP

In general:

• R(i) is reward of being in state i

(often non zero for only a few end states)

• Mij is the probability of transition from

state i to j

Passive Learning in a Known Environment

ADP

Consider U(3,3)

U(3,3) = 0.33 x U(4,3) + 0.33 x U(2,3) + 0.33 x U(3,2) = 0.33 x 1.0 + 0.33 x 0.0886 + 0.33 x -0.4430 = 0.2152

Passive Learning in a Known Environment

ADP

makes optimal use of the local constraints on utilities of states imposed by the neighborhood structure of the environment somewhat intractable for large state spaces

Passive Learning in a Known Environment

TD (Temporal Difference Learning) The key is to use the observed transitions to adjust the values of the observed states so that they agree with the constraint equations

Passive Learning in a Known Environment

TD Learning

Suppose we observe a transition from state i to state j U(i) = -0.5 and U(j) = +0.5

Suggests that we should increase U(i) to make it

agree better with it successor Can be achieved using the following updating rule

Passive Learning in a Known Environment

TD Learning

Performance: Runs “noisier” than LMS but smaller error Deal with observed states during sample runs (Not all instances, unlike ADP)

Passive Learning in an Unknown Environment

Least Mean Square(LMS) approach and Temporal-Difference(TD) approach operate unchanged in an initially unknown environment. Adaptive Dynamic Programming(ADP) approach adds a step that updates an estimated model of the environment.

Passive Learning in an Unknown Environment

• The environment model is learned by direct
• bservation of transitions
• The environment model M can be updated

by keeping track of the percentage of times each state transitions to each of its neighbors ADP Approach

Passive Learning in an Unknown Environment

• The ADP approach and the TD approach

are closely related

• Both try to make local adjustments to the

utility estimates in order to make each state “agree” with its successors ADP & TD Approaches

Passive Learning in an Unknown Environment

Minor differences :

• TD adjusts a state to agree with its observed

successor

• ADP adjusts the state to agree with all of the

successors

Important differences :

• TD makes a single adjustment per observed

transition

• ADP makes as many adjustments as it needs to

restore consistency between the utility estimates U and the environment model M

Passive Learning in an Unknown Environment

To make ADP more efficient :

• directly approximate the algorithm for value

iteration or policy iteration

• prioritized-sweeping heuristic makes

adjustments to states whose likely successors have just undergone a large adjustment in their

• wn utility estimates

Advantage of the approximate ADP :

• efficient in terms of computation
• eliminate long value iterations occur in early

stage

Active Learning in an Unknown Environment

An active agent must consider :

• what actions to take
• what their outcomes may be
• how they will affect the rewards received

Active Learning in an Unknown Environment

Minor changes to passive learning agent :

• environment model now incorporates the

probabilities of transitions to other states given a particular action

• maximize its expected utility
• agent needs a performance element to

choose an action at each step

Active Learning in an Unknown Environment

• need to learn the probability Ma

ij of a

transition instead of Mij

• the input to the function will include the

action taken Active ADP Approach

Active Learning in an Unknown Environment

• the model acquisition problem for the TD

agent is identical to that for the ADP agent

• the update rule remains unchanged
• the TD algorithm will converge to the same

values as ADP as the number of training sequences tends to infinity Active TD Approach

Exploration

Learning also involves the exploration of unknown areas

Photo:http://www.duke.edu/~icheese/cgeorge.html

Exploration

An agent can benefit from actions in 2 ways immediate rewards received percepts

Exploration

Wacky Approach Vs. Greedy Approach

• 0.038

0.089 0.215

• 0.165
• 0.443
• 0.418
• 0.544
• 0.772

Exploration

The Bandit Problem

Photos: www.freetravel.net

Exploration

The Exploration Function a simple example

u= expected utility (greed) n= number of times actions have been tried(wacky) R+ = best reward possible

Learning An Action Value-Function

What Are Q-Values?

Learning An Action Value-Function

The Q-Values Formula

Learning An Action Value-Function

The Q-Values Formula Application

• just an adaptation of the active learning equation

Learning An Action Value-Function

The TD Q-Learning Update Equation

• requires no model
• calculated after each transition from state .i to j

Learning An Action Value-Function

The TD Q-Learning Update Equation in Practice The TD-Gammon System(Tesauro) Program:Neurogammon

• attempted to learn from self-play and

implicit representation

Generalization In Reinforcement Learning

• we have assumed that all the functions

learned by the agents(U,M,R,Q) are represented in tabular form

• explicit representation involves one output

value for each input tuple.

Explicit Representation

Generalization In Reinforcement Learning

• good for small state spaces, but the time to

convergence and the time per iteration increase rapidly as the space gets larger

• it may be possible to handle 10,000 states or

more

• this suffices for 2-dimensional, maze-like

environments

Explicit Representation

Generalization In Reinforcement Learning

• Problem: more realistic worlds are out of

question

• eg. Chess & backgammon are tiny subsets of

the real world, yet their state spaces contain

• n the order of 10 to 10 states. So it

would be absurd to suppose that one must visit all these states in order to learn how to play the game.

Explicit Representation

50 120

Generalization In Reinforcement Learning

Implicit Representation

• Overcome the explicit problem
• a form that allows one to calculate the output

for any input, but that is much more compact than the tabular form.

Generalization In Reinforcement Learning

Implicit Representation

• For example ,

an estimated utility function for game playing can be represented as a weighted linear function of a set of board features f1………fn: U(i) = w1f1(i)+w2f2(i)+….+wnfn(i)

Generalization In Reinforcement Learning

Implicit Representation

• The utility function is characterized by n

weights.

• A typical chess evaluation function might
• nly have 10 weights, so this is enormous

compression

Generalization In Reinforcement Learning

Implicit Representation

• enormous compression : achieved by an

implicit representation allows the learning agents to generalize from states it has visited to states it has not visited

• the most important aspect : it allows for

inductive generalization over input states.

• Therefore, such method are said to perform

input generalization

Game-playing : Galapagos

• Mendel is a four-legged

spider-like creature

• he has goals and desires,

rather than instructions

• through trial and error,

he programs himself to satisfy those desires

• he is born not even

knowing how to walk, and he has to learn to identify all of the deadly things in his environment

• he has two basic drives;

move and avoid pain (negative reinforcement)

Game-playing : Galapagos

• player has no direct

control over Mendel

• player turns various
• bjects on and off and

activates devices in order to guide him

• player has to let Mendel

die a few times, otherwise he’ll never learn

• each death proves to be a

valuable lesson as the more experienced Mendel begins to avoid the things that cause him pain

Developer : Anark Software.

Generalization In Reinforcement Learning

Input Generalisation

• The cart pole

problem:

• set up the problem of

balancing a long pole upright on the top of a moving cart.

Generalization In Reinforcement Learning

Input Generalisation

• The cart can be jerked left or right by a

controller that observes x, x’, θ, and θ’

• the earliest work on learning for this problem

was carried out by Michie and Chambers(1968)

• their BOXES algorithm was able to balance the

pole for over an hour after only about 30 trials.

Generalization In Reinforcement Learning

Input Generalisation

• The algorithm first discretized the 4-

dimensional state into boxes, hence the name

• it then ran trials until the pole fell over or the

cart hit the end of the track.

• Negative reinforcement was associated with

the final action in the final box and then propagated back through the sequence

Generalization In Reinforcement Learning

Input Generalisation

• The discretization causes some problems

when the apparatus was initialized in a different position

• improvement : using the algorithm that

adaptively partitions that state space according to the observed variation in the reward

Genetic Algorithms And Evolutionary Programming

• Genetic algorithm starts with a set of one or

more individuals that are successful, as measured by a fitness function

• several choices for the individuals exist, such

as:

• Entire Agent function’s

the fitness function is a performance measure

• r reward function - the analogy to natural

selection is greatest

Genetic Algorithms And Evolutionary Programming

• Genetic algorithm simply searches directly in

the space of individuals, with the goal of finding one that maximizes the fitness function in a performance measure or reward function

• search is parallel because each individual in

the population can be seen as a separate search

Genetic Algorithms And Evolutionary Programming

• component function of an agent
• the fitness function is the critic or they can be

anything at all that can be framed as an

• ptimization problem
• Evolutionary process: learn an agent function

based on occasional rewards as supplied by the selection function, it can be seen as a form

• f reinforcement learning

Genetic Algorithms And Evolutionary Programming

• Before we can apply Genetic algorithm to a

problem, we need to answer 4 questions :

• 1. What is the fitness function?
• 2. How is an individual represented?
• 3. How are individuals selected?
• 4. How do individuals reproduce?

Genetic Algorithms And Evolutionary Programming

What is fitness function?

• Depends on the problem, but it is a function

that takes an individual as input and returns a real number as output

Genetic Algorithms And Evolutionary Programming

• In the classic genetic algorithm, an individual

is represented as a string over a finite alphabet

• each element of the string is called a gene
• in genetic algorithm, we usually use the binary

alphabet(1,0) to represent DNA

How is an individual represented?

Genetic Algorithms And Evolutionary Programming

How are individuals selected ?

• The selection strategy is usually randomized,

with the probability of selection proportional to fitness

• for example, if an individual X scores twice as

high as Y on the fitness function, then X is twice as likely to be selected for reproduction than is Y.

• selection is done with replacement

Genetic Algorithms And Evolutionary Programming

How do individuals reproduce?

• By cross-over and mutation
• all the individuals that have been selected for

reproduction are randomly paired

• for each pair, a cross-over point is randomly

chosen

• cross-over point is a number in the range 1 to

N

Genetic Algorithms And Evolutionary Programming

How do individuals reproduce?

• One offspring will get genes 1 through 10

from the first parent, and the rest from the second parent

• the second offspring will get genes 1 through

10 from the second parent, and the rest from the first

• however, each gene can be altered by random

mutation to a different value

Conclusion

• Passive Learning in a Known Environment
• Passive Learning in an Unknown Environment
• Active Learning in an Unknown Environment
• Exploration
• Learning an Action Value Function
• Generalization in Reinforcement Learning
• Genetic Algorithms and Evolutionary

Programming

Resources And Glossary

Information Source Russel, S. and P. Norvig (1995). Artificial Intelligence - A Modern Approach. Upper Saddle River, NJ, Prentice Hall Addition Information and Glossary of Keywords Available at http://www.cpsc.ucalgary.ca/~paulme/533
