SLIDE 1

CPSC 481 – Tutorial 7

More WPF

Brennan Jones bdgjones@ucalgary.ca (based on tutorials by Alice Thudt, Fateme Rajabiyazdi, and David Ledo)

SLIDE 2

Plan for Today

More WPF material, examples, and coding exercises
Mostly stuff that will be applicable to implementing your

vertical prototypes

SLIDE 3

Reminder

Horizontal prototype due Monday Nov. 2 in lecture:

1. Write-up – including redesign rational (i.e.,

changes from the first prototype), screen snapshots, and a grading sheet (from assignment handout)

2. Horizontal prototype presentation freeze
Either email your slides to me

(bdgjones@ucalgary.ca) OR submit them on a USB along with your write-up.

SLIDE 4

Horizontal Prototype Presentations

Tuesday, November 3 in tutorial (T03)
Monday, November 9 in tutorial (T01)

SLIDE 5

More WPF!

SLIDE 6

User Controls

Controls are interactive elements in WPF
Elements such as Buttons, TextBoxes, etc. are

Microsoft Controls

If you want to reuse specific elements in your

interface, you can create User Controls

User Controls can be composites of Microsoft

Elements

SLIDE 7

User Controls

Create your own User Control

SLIDE 8

Exercise

Create your own User Control, and try to add an instance of it to your MainWindow.xaml.

SLIDE 9

Transitions

Create three buttons XAML

SLIDE 10

Transitions

Create a user control

SLIDE 11

Transitions

Name it

SLIDE 12

Transitions

Fill it with content

SLIDE 13

Transitions

Create two additional user controls and do the same.

SLIDE 14

Transitions

Add a StackPanel to the Main Window Give it a name

SLIDE 15

Transitions

Add the following code to your MainWindow.xaml.cs before the public MainWindow(){ … } constructor:

// Initialize user controls. UserControl1 page1 = new UserControl1(); UserControl2 page2 = new UserControl2(); UserControl3 page3 = new UserControl3();

SLIDE 16

Transitions

Result:

SLIDE 17

Exercise

Make it so that clicking the buttons at the top changes the current user control.

SLIDE 18

Solution

Add the following click-event handlers:

private void page1Button_Click(object sender, RoutedEventArgs e) { stackPanel1.Children.Clear(); stackPanel1.Children.Add(page1); } private void page2Button_Click(object sender, RoutedEventArgs e) { stackPanel1.Children.Clear(); stackPanel1.Children.Add(page2); } private void page3Button_Click(object sender, RoutedEventArgs e) { stackPanel1.Children.Clear(); stackPanel1.Children.Add(page3); }

SLIDE 19

User Controls – Exercise

Create a User Control for an Email that looks like this:

SLIDE 20

Solution – User Control XAML

SLIDE 21

Exercise

Make the Sender a property that can be different in

each instance of an email.

When the delete Button is clicked, the email should

be removed from the view.

SLIDE 22

Solution – User Control C#

public partial class Email : UserControl { private string sender; public string Sender { get { return sender; } set { sender = value; this.SenderText.Content = this.sender; } } private string body; public string Body { get { return body; } set { body = value; this.BodyText.Content = this.body; } } public Email() { InitializeComponent(); } private void DeleteGroup_MouseDown(object sender, MouseButtonEventArgs e) { (this.Parent as Panel).Children.Remove(this); } }

SLIDE 23

Scroll Viewers

SLIDE 24

Exercise

Create a scroll viewer in your main window that shows 20

emails (using the Email User Control that you just created).

Create a for loop that initializes 20 Email User Controls.
To make it easy, make the Sender of each email “Sender “ + i
I.e., “Sender 1,” “Sender 2,” “Sender 3,” etc.

SLIDE 25

Solution – Main Window C#

public MainWindow() { InitializeComponent(); for(int i = 0; i < 20; i++) { Email email = new Email(); email.Sender = "Sender " + i.ToString(); this.Emails.Children.Add(email); }

}

SLIDE 26

Remaining Topics

Which of these do you want me to go over?

Transitions (Method 2)
Styles and Templates
List Boxes
Simple Animations
Click & Drag
Triggers
Image as a Button
Timer

SLIDE 27

Transitions (Method 2)

1. Create three User Controls. Name them:

MainMenu, Page1, and Page2.

2. Add a Switcher.cs class to the project. This class

will handle switching between different User Controls.

SLIDE 28

Transitions (Method 2)

using System.Windows.Controls; public static MainWindow pageSwitcher; public static void Switch(UserControl newPage) { pageSwitcher.Navigate(newPage); }

SLIDE 29

Transitions (Method 2)

3. Add the following code to MainWindow.xaml.cs

public MainWindow() { InitializeComponent(); Switcher.pageSwitcher = this; Switcher.Switch(new MainMenu()); } public void Navigate(UserControl nextPage) { this.Content = nextPage; }

SLIDE 30

Transitions (Method 2)

4. Design MainMenu, Page1, and Page2 to look like this:

SLIDE 31

Transitions (Method 2)

5. For MainMenu, Page1, and Page2, add the

following events:

private void Button_Click(object sender, RoutedEventArgs e) { Switcher.Switch(new MainMenu()); } private void Button_Click_1(object sender, RoutedEventArgs e) { Switcher.Switch(new Page1()); } private void Button_Click_2(object sender, RoutedEventArgs e) { Switcher.Switch(new Page2()); }

SLIDE 32

Transitions (Method 2)

6. If you ever want to save the state of a page while

transitioning (e.g., to save the contents of textboxes, the states of checkboxes etc.), keep the same User Control object. For example:

Page1 page1 = new Page1(); ... private void Button_Click_1(object sender, RoutedEventArgs e) { Switcher.Switch(page1); }

Always use this ‘Page1’ object

SLIDE 33

Styles and Templates

Source (and excellent resource): http://www.codeproject.com/Articles/84630/WPF- Customize-your-Application-with-Styles-and-Con

SLIDE 34

Styles and Templates

Start by creating a button

SLIDE 35

Styles and Templates

Add this ‘Resources’ block

SLIDE 36

Styles and Templates

Insert this code: This defines the style of buttons in your XAML. The button’s appearance changes

SLIDE 37

Styles and Templates

You can also give it a key… …and set specific buttons to the particular style.

SLIDE 38

Styles and Templates

You can create define Control Templates

These define how a control is drawn

SLIDE 39

Styles and Templates

Example:

<UserControl.Resources> <Style x:Key="MyButtonStyle" TargetType="{x:Type Button}"> <Setter Property="Template"> <Setter.Value> <ControlTemplate TargetType="{x:Type Button}"> <Border Name="fondoboton" BorderBrush="DarkGray" BorderThickness="5" CornerRadius="10,0,10,0" Background="LightGray"> <ContentPresenter Name="contenido" Content="{Binding Path=Content, RelativeSource={RelativeSource TemplatedParent}}"></ContentPresenter> </Border> </ControlTemplate> </Setter.Value> </Setter> </Style> </UserControl.Resources>

SLIDE 40

Styles and Templates

Result:

SLIDE 41

Styles and Templates

You can also define a default background colour:

<UserControl.Resources> <Style x:Key="MyButtonStyle" TargetType="{x:Type Button}"> <Setter Property="Background" Value="Orange" /> <Setter Property="Template"> <Setter.Value> <ControlTemplate TargetType="{x:Type Button}"> <Border Name="fondoboton" BorderBrush="DarkGray" BorderThickness="5" CornerRadius="10,0,10,0" Background="{TemplateBinding Background}"> <ContentPresenter Name="contenido" Content="{Binding Path=Content, RelativeSource={RelativeSource TemplatedParent}}"></ContentPresenter> </Border> </ControlTemplate> </Setter.Value> </Setter> </Style> </UserControl.Resources>

Add this line Add this

SLIDE 42

Styles and Templates

Result:

SLIDE 43

Styles and Templates

For a specific button, you can set the background colour to something other than the ‘default’, while keeping everything else the same as the template.

Without changing the template, change the

button’s XAML code to something like this:

Background is ‘Red’

SLIDE 44

Styles and Templates

Result:

SLIDE 45

Exercise

Define a template for a button (like the one shown in the previous slides) that has a default border colour

f black, and create a button of that template that

has the border colour blue.

SLIDE 46

Solution

<UserControl.Resources> <Style x:Key="MyButtonStyle" TargetType="{x:Type Button}"> <Setter Property="BorderBrush" Value="Black" /> <Setter Property="Template"> <Setter.Value> <ControlTemplate TargetType="{x:Type Button}"> <Border Name="fondoboton" BorderBrush="{TemplateBinding BorderBrush}" BorderThickness="5" CornerRadius="10,0,10,0"> <ContentPresenter Name="contenido" Content="{Binding Path=Content, RelativeSource={RelativeSource TemplatedParent}}"></ContentPresenter> </Border> </ControlTemplate> </Setter.Value> </Setter> </Style> </UserControl.Resources>

SLIDE 47

Solution

Result:

SLIDE 48

Solution (cont’d)

SLIDE 49

Solution

Result:

SLIDE 50

List Boxes

Drag a ListBox into the XAML

SLIDE 51

List Boxes

Click to modify items

SLIDE 52

List Boxes

Click to add Select ‘ListBoxItem’

SLIDE 53

List Boxes

Change content

SLIDE 54

List Boxes

Result:

SLIDE 55

List Boxes

Can get the currently-selected index:

listbox1.SelectedIndex

SLIDE 56

Exercise

Write code that changes the text in a textbox

whenever a listbox’s selection is changed.

SLIDE 57

Solution – C#

Add ‘SelectionChanged’ event handler.

private void listBox1_SelectionChanged(object sender, SelectionChangedEventArgs e) { textbox1.Text = (String)((ListBoxItem)listBox1.SelectedItem).Content; }

SLIDE 58

Simple Animations

Insert an ellipse into your XAML

SLIDE 59

Simple Animations

XAML code:

SLIDE 60

Simple Animations

Add this code to the top of your C# file:

using System.Windows.Media.Animation;

Add this inside your user control class before the constructor:

private Storyboard myStoryboard;

SLIDE 61

Simple Animations

Add this code to your user control constructor:

// animate fade in and fade out DoubleAnimation animation = new DoubleAnimation(); animation.From = 1.0; animation.To = 0.0; animation.Duration = new Duration(TimeSpan.FromSeconds(5)); animation.AutoReverse = true; animation.RepeatBehavior = RepeatBehavior.Forever; myStoryboard = new Storyboard(); myStoryboard.Children.Add(animation); Storyboard.SetTargetName(animation, ellipse1.Name); Storyboard.SetTargetProperty(animation, new PropertyPath(Ellipse.OpacityProperty)); // Use the Loaded event to start the Storyboard. ellipse1.Loaded += new RoutedEventHandler(myEllipseLoaded);

SLIDE 62

Simple Animations

Add this function:

private void myEllipseLoaded(object sender, RoutedEventArgs e) { myStoryboard.Begin(this); }

SLIDE 63

Exercise

Change the animation so that the width of the

ellipse is animated.

SLIDE 64

Solution

// animate fade in and fade out DoubleAnimation animation = new DoubleAnimation(); animation.From = 120.0; animation.To = 240.0; animation.Duration = new Duration(TimeSpan.FromSeconds(5)); animation.AutoReverse = true; animation.RepeatBehavior = RepeatBehavior.Forever; myStoryboard = new Storyboard(); myStoryboard.Children.Add(animation); Storyboard.SetTargetName(animation, ellipse1.Name); Storyboard.SetTargetProperty(animation, new PropertyPath(Ellipse.WidthProperty)); // Use the Loaded event to start the Storyboard. ellipse1.Loaded += new RoutedEventHandler(myEllipseLoaded);

SLIDE 65

Click & Drag

Create an ellipse Give it a name

SLIDE 66

Click & Drag

Give the grid a name too

SLIDE 67

Click & Drag

Add MouseDown Add MouseMove Add MouseUp

SLIDE 68

Click & Drag

In your C# file:

bool captured = false; ... private void Ellipse_MouseDown_1(object sender, MouseButtonEventArgs e) { captured = true; } private void Ellipse_MouseUp_1(object sender, MouseButtonEventArgs e) { captured = false; } private void Ellipse_MouseMove_1(object sender, MouseEventArgs e) { if (captured) { Thickness margin = ellipse1.Margin; margin.Left = e.GetPosition(_mainGrid).X - (ellipse1.Width / 2); margin.Top = e.GetPosition(_mainGrid).Y - (ellipse1.Height / 2); ellipse1.Margin = margin; } }

SLIDE 69

Triggers

Source (and excellent resource): http://www.wpf- tutorial.com/styles/trigger-datatrigger-event-trigger/

SLIDE 70

Triggers

Allow you to change the value of a given property
nce a certain condition changes
Allow you to do this entirely in XAML
Three types:
1. Property trigger
2. Data trigger
3. Event trigger

SLIDE 71

Triggers

Property trigger

Defined by <Trigger> element.
Watches a specific property on the owner control,

and whenever that property has a specific value, it changes other properties.

SLIDE 72

Triggers

Property trigger example

SLIDE 73

Triggers

Property trigger example

Result:
Underlines and colours the text red on mouse-over.

SLIDE 74

Triggers

Data trigger

Defined by <DataTrigger> element.
Watches a specific property that can be anywhere

(not specifically on the owner control), and whenever that property has a specific value, it changes other properties.

SLIDE 75

Triggers

Data trigger example

SLIDE 76

Triggers

Data trigger example

Result:
Changes the text to “Yes!” and the text colour to green

when the checkbox is checked.

SLIDE 77

Triggers

Event trigger

Defined by <EventTrigger> element.
Triggers in response to an event being called.
Triggers exactly once that event is called.

SLIDE 78

Triggers

Event trigger example

<TextBlock Name="lblStyled" Text="Hello, styled world!" FontSize="18" HorizontalAlignment="Center" VerticalAlignment="Center"> <TextBlock.Style> <Style TargetType="TextBlock"> <Style.Triggers> <EventTrigger RoutedEvent="MouseEnter"> <EventTrigger.Actions> <BeginStoryboard> <Storyboard> <DoubleAnimation Duration="0:0:0.300" Storyboard.TargetProperty="FontSize" To="28" /> </Storyboard> </BeginStoryboard> </EventTrigger.Actions> </EventTrigger> ...

SLIDE 79

Triggers

Event trigger example (cont’d)

... <EventTrigger RoutedEvent="MouseLeave"> <EventTrigger.Actions> <BeginStoryboard> <Storyboard> <DoubleAnimation Duration="0:0:0.800" Storyboard.TargetProperty="FontSize" To="18" /> </Storyboard> </BeginStoryboard> </EventTrigger.Actions> </EventTrigger> </Style.Triggers> </Style> </TextBlock.Style> </TextBlock>

SLIDE 80

Triggers

Event trigger example

Result:
Animation enlarges the text on mouse-over, and shrinks

it back to its original size on mouse-leave.

SLIDE 81

Image as Button

Exercise: Create a button that displays as an image.

SLIDE 82

Image as Button

Solution:

SLIDE 83

Timer

We are going to make use of a DispatchTimer.
Make sure you are using the Threading

namespace.

Add a TextBlock on your code. We will change the

value every time the timer ticks.

SLIDE 84

XAML

SLIDE 85

C#

using System.Windows.Threading; public void DispatcherTimerSample() { InitializeComponent(); DispatcherTimer timer = new DispatcherTimer(); timer.Interval = TimeSpan.FromSeconds(1); timer.Tick += timer_Tick; timer.Start(); } void timer_Tick(object sender, EventArgs e) { timerText.Content = DateTime.Now.ToLongTimeString(); }
