Course on Protocol Validation

Frits Vaandrager Institute for Computing and Information Sciences Radboud University Nijmegen http://www.cs.ru.nl/~fvaan/

Overview

• 1. Introduction
• 2. Model checking of (timed) automata
• 3. Safe IOAs, invariants, and composition
• 4. Fairness, liveness, and implementation
• 5. Simulation proof techniques

• 6. Real-time, hybrid and probabilistic extensions

Introduction

Reliability in System Design

• Computer systems are getting more complex and pervasive
• Safety-critical applications: bugs are unacceptable.

Mission control (ARIANE-5), medicine, etc, etc

• Bugs are expensive: earlier we catch them, the better.

E.g. FDIV in Pentium

• Testing takes more time than designing. Automation key to im-

prove time-to-market

• Increasing use of programmable components shifts focus from

low-level optimizations to high-level designs

Goal Formal Verification Provide tools and techniques as design aids to produce reliable systems

Coping with Complexity

• Design reuse
• Separation of concerns: logical vs physical, logical vs timing, etc
• Formalization – precise unambiguous semantics
• Abstraction – eliminate unnecessary details
• Decomposition – divide and conquer
• Incremental refinements

What is Formal Verification?

• Build mathematical model of system: what are possible behaviors?
• Write correctness requirements in specification language:

what are desirable behaviors?

• Analysis: check that model satisfies specification
• Formal ⇒ Correctness claim is precise mathematical statement
• Verification ⇒ Analysis either proves or disproves correctness claim

Limitations of FV

• Appropriate only for control-intensive applications with interesting

interaction among components

• Decidability and complexity remain obstacles; great progress in

finding heuristics; flexibility in setting up the problem

• Falsification rather than verification: model, and not system, is

verified; only stated requirements are checked

• Finding appropriate abstractions requires expertise

The Formal Methods Jungle ACL2, ACP, ACSR, Action Semantics, Argos, ASM, ADLT, BDDs, B, Boyer-Moore, Caesar/Aldebaran, CCS, Circal, COLD, Coq, COSPAN, CSP, FDR2, CWB, DisCo, DC, Estelle, EVES, GIL, HOL, HyTech, IMPS, I/O Automata, ITL, Isabelle, JAPE, KIV, Kronos, LAMBDA, Larch, LeanTaP, LEGO, LOTOS, Lustre, MALPAS, Meije, Mizar, µCRL, Murphi, NP-tools, Nqthm, Nuprl, OBJ, Otter, Petri Nets, Pi- calculus, Pobl, ProofPower, PVS, RAISE, Rapide, Refinement Calcu- lus, SDL, SGM, Signal, SMV, SPARK, SPIN, STeP, TAM, TAM97, Temporal-Rover, TLA, TPS, TRIO, TTM/RTTL, Unity, Uppaal, VeriSoft, VDM, VIS, Z, ..

The Trinity of Formal Methods Theory Tools Applications

❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅ ❅

I/O Automata (Lynch & Tuttle, ’87; Jonsson ’87) Purpose Formal model for specification+verification of distributed algorithms Characteristics:

• Both system and specification modelled as transition system
• Language inclusion as implementation relation

(⇒ stepwise refinement!)

• Compositionality
• Distinction between input and output actions
• Fairness/liveness
• Assertional reasoning (invariants, simulations, etc)
• Extensions deal with real-time, hybrid, and probabilistic aspects

Stepwise Refinement S2 S1 S0 ⊑ ⊑ ⊑ implementation preorder

✏ ✏ ✏ ✏ ✏ ✏ ✮

• ✠

❅ ❅ ❅ ❘

· · ·

Compositionality S1 S0 ⊑ S1 S0 ⊑ ⇒

Extensions and Restrictions of IOA model (S= Safe, F=Fair, L=Live, T=Timed, H=Hybrid, P=Probabilistic)

t t t t t t t t t t t t t t t ✲ ✲ ✲ ❄ ❄ ❄ ❄ ✲ ✲ ❄ ❄ ❄ ❩ ❩ ❩ ❩ ❩ ❩ ❩ ❩ ❩ ❩ ⑥ ❩ ❩ ❩ ❩ ❩ ❩ ❩ ❩ ❩ ❩ ⑥ ❩ ❩ ❩ ❩ ❩ ❩ ❩ ❩ ❩ ❩ ⑥ ❩ ❩ ❩ ❩ ❩ ❩ ❩ ❩ ❩ ❩ ⑥ ❩ ❩ ❩ ❩ ❩ ❩ ❩ ❩ ❩ ❩ ⑥ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✼ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✼ ✓ ✓ ✓ ✼

IOA FIOA LIOA LTIOA SIOA TIOA HIOA SPIOA PA A TA HA PTA PTIOA PIOA

Timed Automata

• Model of finite automata enriched with real-values clock variables

proposed by Rajeev Alur and David Dill in 1990

• Model checking tools under development since then; enormous

progress has been made!

• Especially UPPAAL has become quite mature (for an academic

prototype)

• Dozens of industrial applications: embedded controllers, distributed

algorithms and protocols, scheduling problems,...

Applications: Communication Protocols

• 1. At most once message delivery
• 2. Bounded retransmission
• 3. IEEE 1394 tree identify
• 4. Audio control
• 5. Biphase mark
• 6. Rambo

Applications: Transportation

• 1. Railroad crossing
• 2. Personal rapid transit
• 3. Automated highway systems (PATH)
• 4. Traffic Alert and Collision Avoidance System (TCAS)
• 5. Height control in BMW

More Applications

• 1. Distributed operating systems
• 2. Database concurrency control
• 3. Steam boiler controller
• 4. Lego car
• 5. etc. etc.
