Corporate presentation

Swiss Quality Mechanical Engineering for highest precision

Facts

Basic informations Company structure: Stock company Location: Niederdorf (BL), near Basel, Switzerland Our strengths: everything from a single source

• Engineering
• Conception
• Engine building
• Mechanical production
• Toolmaking
• Assembling
• Control engineering
• Software engineering
• Service and support

Customer segments

• Watch industry
• Medical technology
• Micromechanics
• Electromechanics
• Optoelectronics

SMS is a specialist and technology partner for automation systems and system solutions in the field of micromechanics.

2

Reference customers

Watch industry Medical technology Micromechanics

3

Technologie center

The company SMS Spinnler Fleury AG has a state of the art technology center, who is a real added value for itselfs and it customers. This technologie center has enough space for the own machines as well as for customers developpement machines. The possibility is now given with the technologie center to provide developpement tests on existing or future machines. New processes and technologies can efficiently be tested and evaluated. Furthermore we can execute tests for our customers or run small productions

• f pieces.

4

Modular concept

Without additonnal costs, our modular concept is designed to provide a machine which meets the individuals production and automatisation needs of our customers.

5

Technologies - Pressing, riveting, assembling, flanging, feeding

PRESSING, RIVETING, ASSEMBLING, FLANGING

Those tasks were accomplished with our home developped force-displacement controlled servopress. Through the years, we gained a lot of useful work exprience and know-how that we included in each of ours machines.

• Reliable quality inspection with 100% documentation
• Iterative assembling process => Pressing + Measuring + corrections until the precision is reached
• Integrated force-displacement control
• Automatic selection of the appropriate assembly process
• Press in position
• Press up to the stop
• Press with definite amount iterations
• Press with definite Force
• Force-displacement nominal froce up to 1000 N
• High precise slide guides
• Force measurement with Piezo force transducer
• Pressing precision < 5 µ
• Repetition accuracy < 2 µ

Technical datas Software Types

• Fixed assembly axis or with X+Y handling
• with 1 assembly tool or turret head with 4 or 12 tools

Our focus is on different technologies integrated in individual machine concepts and successful applications, in use at our customers or partners.

6

Technologies - Feeding, sorting, orientating

We developped a wide range of moduls for the feeding, sorting and

• rientating of pieces to insure the best handling of customers pieces.

For every parts we have the best solution!

Application examples

7

Technologie - Assembly

• Smallest parts, (pins, gears or gemstones, diamonds, jewels, …….)
• Full contact probe assembly
• Platine, bridge, anchor, mobile, minute wheel
• Full assemblies, such as bearings, dental implants, mini-motors, seals, watch crown, watch bracelets, etc.

 We are able to guarantee a monitored and perfect assembly process with a high degre of precision

Application examples:

8

Technologie - Control

• Force measurements, offset control
• Optical surface inspection
• Pieces presence, dimensions measuring, proper mounting direction
• Measuring and setting of the torque
• Leak test of assemblies

We can guarantee a monitored and perfect control with a high degre of precision and reliability

Applications examples

9

Technologie – Laser welding

The combination of a laser source and self developped Feedingsystems such as Feeder, spiral conveyors, blister or tubes, enable the assembly of an assemblies consiting of single bulk parts. Application in

• Watch- and jewelry-industrie, micromechanics, microelectronic such as medical technology

Assembly example of a Z axis mounted laser

 Precision processing by the use of 400W laser power  Laser positionning through SMS-Vision  Focal diameter from 10 – 50 µm  Possible incline for the laser welding ±45°  Flexibility due to modulation frequencies up to 50 kHz  Traval path of Z axis: 150mm  Vision system incling camera  Welding zone: Ø56mm (without axis movement) 10

Reference systems

Linear systems Rotary system Semi-automatic

The best concept for your needs!

11

Why SMS Spinnler Fleury AG

High-precision Swiss quality Process reliability Precision
