Controllable Infrasound Source Doug Fox Daxton Ruger Jerad Wunder What is Infrasound? Frequencies below 20hz Human hearing lower limit - 12hz Common sources Helicopters Elephant Vocalizations Earthquakes

slide-1
SLIDE 1

Controllable Infrasound Source

Doug Fox Daxton Ruger Jerad Wunder

slide-2
SLIDE 2

What is Infrasound?

  • Frequencies below

20hz

  • Human hearing

lower limit - 12hz

  • Common sources

○ Helicopters ○ Elephant Vocalizations ○ Earthquakes

  • Can be detected over

large distances

http://people.ece.cornell.edu/land/courses/ece5030/FinalProjects/s2014/kkp37_rjs483/kkp37_rjs483/AudioGram.html

slide-3
SLIDE 3

Infrasonic Detection

  • Dr. Brian Elbing

○ Research in infrasound possibly emitted by a tornado

  • Infrasound microphone array located in the North Campus Lab area
  • Dr. Brian Elbing,

Oklahoma State University

https://www.wired.com/story/a-tornados-secret-sounds/

slide-4
SLIDE 4

Objective

  • To design and construct a compact, mobile

device capable of generating controllable infrasonic tones. ○ Used to calibrate infrasonic microphone array to ensure accuracy of collected data

slide-5
SLIDE 5

Subwoofers

  • Coil in magnetic field - current direction determines

cone movement direction

  • Placed in enclosure - separates + and - pressure waves
  • Not efficient below 20Hz
slide-6
SLIDE 6

Rotary Subwoofers

  • Efficient output from <1Hz to 20Hz
  • Fan motor spins blades
  • Helicopter rotor head actuates blade pitch

○ Controlled by subwoofer motor

  • Baffle separates pressure waves
  • Relatively compact

Eminent Technologies TRW-17

slide-7
SLIDE 7

Final Design

slide-8
SLIDE 8

Final Design

slide-9
SLIDE 9

Final Design

slide-10
SLIDE 10

Final Design

slide-11
SLIDE 11

Bill of Materials

slide-12
SLIDE 12

Sourced Materials

Subwoofer - Kicker CompR 12”

slide-13
SLIDE 13

Sourced Materials

Amplifier power supply - 75A DC power supply Subwoofer amplifier - Modified Kicker CXA1200.1

slide-14
SLIDE 14

Sourced Materials

R/C helicopter rotorhead

slide-15
SLIDE 15

Sourced Materials

3-phase A/C motor VFD Controller

slide-16
SLIDE 16

Design Needs Frame

slide-17
SLIDE 17

Design Needs Blade and adapter

slide-18
SLIDE 18

Design Needs Coupling shaft

slide-19
SLIDE 19

Design Needs Motor stand

slide-20
SLIDE 20

Design Needs Swashplate adapter

slide-21
SLIDE 21

Design Alternatives Blade

slide-22
SLIDE 22

Design Alternatives Shaft

slide-23
SLIDE 23

Design Alternatives Blade adapter

slide-24
SLIDE 24
slide-25
SLIDE 25

Small building used as enclosure ○ “Infinite baffle” Frequency response (SPL) recorded 4- 20Hz ○ Larson Davis 831 microphone

Test Setup .

slide-26
SLIDE 26

Results

  • Microphone

~20ft axial distance

  • Amp gain

halfway

  • Motor @ 300

rpm

slide-27
SLIDE 27

References

[1] Olson, Harry F, (1967). “Music, Physics and Engineering,” Dover Publications, 1967. ISBN 0-486-21769-8.

[2] M. Simon, “A Tornado's Secret Sounds Could Reveal Where It'll Strike,” Wired, 08-May-2018. [Online]. Available: https://www.wired.com/story/a-tornados-secret-sounds/. [Accessed: 03-Dec-2018].
