1 Control Structure Design for Optimal Operation of 4-Product Thermally Coupled Columns Deeptanshu Dwivedi 1 , Ivar J. Halvorsen 2 , Sigurd Skogestad 1 1) Department of Chemical Engineering, Norwegian University of Science & Technology

slide-1
SLIDE 1

16/03/2011 Control Structure Design for Optimal Operation of Thermally Coupled Columns Distillation Columns

1

Control Structure Design for Optimal Operation of 4-Product Thermally Coupled Columns

Deeptanshu Dwivedi1, Ivar J. Halvorsen2, Sigurd Skogestad1

1) Department of Chemical Engineering, Norwegian University of Science & Technology (NTNU), Trondheim Norway 2) SINTEF ICT, Applied Cybernetics, Trondheim Norway

slide-2
SLIDE 2

16/03/2011 Control Structure Design for Optimal Operation of Thermally Coupled Columns Distillation Columns

2

  • Introduction
  • System 1: 4- Product Kaibel Column

– Previous Work – Control Structure – Experimental Setup – Experimental Runs- Steady state profiles – Experimental Runs- Vapor Split Experiment

  • System 2: 4- Product Extended Petlyuk Column

– Model Details – Control Structure – Close Loop Results

  • Conclusions

Outline

slide-3
SLIDE 3

16/03/2011 Control Structure Design for Optimal Operation of Thermally Coupled Columns Distillation Columns

3

Introduction

  • Distillation is energy intensive process.
  • Exergetic analysis requires minimizing irreversibilities:
  • mixing effect
  • large ΔT across column
  • This leads to Complex distillation arrangement:
  • Kaibel Arrangement
  • Petlyuk Arrangement
  • intermediate Reboilers & Coolers etc
  • HIDIC distillation
  • Potential Energy Savings up to ~50 % for 4 product extended

Petlyuk & up to ~30 % in Kaibel Arrangement*

* Halvorsen et. al. (2003)

slide-4
SLIDE 4

16/03/2011 Control Structure Design for Optimal Operation of Thermally Coupled Columns Distillation Columns

4

Kaibel Arrangement *

* Kaibel. G (1987)

D ABCD CD A B C AB ABCD AB CD D A B C

4-Product Separation in single shell Sharp B/C Split in Prefractionator

slide-5
SLIDE 5

16/03/2011 Control Structure Design for Optimal Operation of Thermally Coupled Columns Distillation Columns

5

Extended Petlyuk Arrangement *

D ABCD BCD A B C ABC AB BC CD

*Petlyuk, F.B. et al (1965)

Non-Sharp B/C Split in Prefractionator

C31 C32 C33 ABCD ABC BCD D A B C C22 C1 AB CD BC C21

slide-6
SLIDE 6

16/03/2011 Control Structure Design for Optimal Operation of Thermally Coupled Columns Distillation Columns

6

  • Introduction
  • System 1: 4- Product Kaibel Column

– Previous Work – Control Structure – Experimental Setup – Experimental Runs- Steady state profiles – Experimental Runs- Vapor Split Experiment

  • System 2: 4- Product Extended Petlyuk Column

– Model Details – Control Structure – Close Loop Results

  • Conclusions

Outline

slide-7
SLIDE 7

16/03/2011 Control Structure Design for Optimal Operation of Thermally Coupled Columns Distillation Columns

7

Simulation based studies carried with a plant wide perspective – Stabilizing operation of a 4-product Kaibel column *

  • Close 4 temperature loops for stabilization &

Inventory Control – Optimal steady-state solutions for operating under economic objectives** – Model predictive control of the 4-product kaibel column *** Thus there is an incentive to carry out experimental studies

  • n operation of 4-product column

* Strandberg, J. et. al (2006) ** Ghadrdan, M. et. al (2010) *** Kverland M. et. Al (2010)

Previous works

slide-8
SLIDE 8

16/03/2011 Control Structure Design for Optimal Operation of Thermally Coupled Columns Distillation Columns

8

  • Introduction
  • System 1: 4- Product Kaibel Column

– Previous Work – Control Structure – Experimental Setup – Experimental Runs- Steady state profiles – Experimental Runs- Vapor Split Experiment

  • System 2: 4- Product Extended Petlyuk Column

– Model Details – Control Structure – Close Loop Results

  • Conclusions

Outline

slide-9
SLIDE 9

16/03/2011 Control Structure Design for Optimal Operation of Thermally Coupled Columns Distillation Columns

9

B TC L F D V

V> V min Single point control can stabilize the profiles

Control Structure (Ordinary Distillation)

L F D V

V= V min

TC TC

Two point control can stabilize column profiles

B

slide-10
SLIDE 10

16/03/2011 Control Structure Design for Optimal Operation of Thermally Coupled Columns Distillation Columns

10

4-point temperature control with one temperature in prefractionator

V>Vmin

Rv Loop can be added

  • when V=Vmin, 2

temperatures may needed in prefractionator

  • or, as DOF for any
  • ther economic
  • bjective

V=Vmin

Control Structure (Kaibel Column)

slide-11
SLIDE 11

16/03/2011 Control Structure Design for Optimal Operation of Thermally Coupled Columns Distillation Columns

11

Control Structure (As used in experiments)

  • Decentralized Control with 4 PI Controllers
  • 4 temperature sections 2, 3, 5, 7 in

regulatory layer with R/l, D, S1 & S2

  • V=Vmax, Vapor Split (Rv) not part of

regulatory layer

Next couple of slides summarize experimental validation

slide-12
SLIDE 12

16/03/2011 Control Structure Design for Optimal Operation of Thermally Coupled Columns Distillation Columns

12

  • Introduction
  • System 1: 4- Product Kaibel Column

– Previous Work – Control Structure – Experimental Setup – Experimental Runs- Steady state profiles – Experimental Runs- Vapor Split Experiment

  • System 2: 4- Product Extended Petlyuk Column

– Model Details – Control Structure – Close Loop Results

  • Conclusions

Outline

slide-13
SLIDE 13

16/03/2011 Control Structure Design for Optimal Operation of Thermally Coupled Columns Distillation Columns

13

Experimental Set up

  • 4 products
  • Atmospheric pressure
  • Packed Column
  • Magnetic funnel-liquid split &

Product valves

  • Vapor split: Rack and Pinion
  • Number of theoretical stages

(experimentally determined):

– Total stages in Prefractionator = 17 – Total Stages in main column = 21 – High Purity is impossible with given number of stages and flooding limitation

  • Labview interface

Feed ABCD A (Methanol) B (Ethanol) C (Propanol) D (Butanol)

slide-14
SLIDE 14

16/03/2011 Control Structure Design for Optimal Operation of Thermally Coupled Columns Distillation Columns

14

Experimental Set up (Labview Interface)…

slide-15
SLIDE 15

16/03/2011 Control Structure Design for Optimal Operation of Thermally Coupled Columns Distillation Columns

15

Steady Profiles with 4 temperature loops

50 100 80 81 T, C 50 100 0.4 0.45 50 100 68 69 70 T, C 50 100 0.85 0.9 0.95 50 100 86 87 88 T, C 50 100 0.8 0.9 1 50 100 110 111 time, min T, C 50 100 0.7 0.8 time, min

R/l Loop D/l Loop S1 Loop S2 Loop Output

TEMPERATURES Output

slide-16
SLIDE 16

16/03/2011 Control Structure Design for Optimal Operation of Thermally Coupled Columns Distillation Columns

16

Liquid Split Loop -2 C

Steady Profiles with 4 temperature loops..

10 20 30 40 80 85 T,C 10 20 30 40 0.35 0.4 0.45 10 20 30 40 68.5 69 69.5 T,C 10 20 30 40 0.9 0.95 1 10 20 30 40 86 87 88 T,C 10 20 30 40 0.7 0.8 0.9 10 20 30 40 111 112 113 time, min T,C 10 20 30 40 0.5 1 time, min

R/l Loop D/l Loop S1 Loop S2 Loop Output

TEMPERATURES Output

slide-17
SLIDE 17

16/03/2011 Control Structure Design for Optimal Operation of Thermally Coupled Columns Distillation Columns

17

Distillate Loop ±1 C

Steady Profiles with 4 temperature loops..

10 20 30 40 81 82 83 T,C 10 20 30 40 0.35 0.4 0.45 10 20 30 40 68 70 72 T,C 10 20 30 40 0.7 0.8 0.9 10 20 30 40 86 87 88 T,C 10 20 30 40 0.7 0.8 0.9 10 20 30 40 111 112 113 time, min T,C 10 20 30 40 0.5 1 time, min

R/l Loop D/l Loop S1 Loop S2 Loop Output

TEMPERATURES Output

slide-18
SLIDE 18

16/03/2011 Control Structure Design for Optimal Operation of Thermally Coupled Columns Distillation Columns

18 10 20 30 81.5 82 82.5 T ,C 10 20 30 0.36 0.38 0.4 10 20 30 68.5 69 69.5 T ,C 10 20 30 0.9 0.95 1 10 20 30 86 88 90 T ,C 10 20 30 0.7 0.8 0.9 10 20 30 111.5 112 112.5 time, min T,C 10 20 30 0.5 0.6 0.7 time, min

R/l Loop D/l Loop S1 Loop S2 Loop Output

S1 Loop ± 1 C

Steady Profiles with 4 temperature loops..

TEMPERATURES Output

slide-19
SLIDE 19

16/03/2011 Control Structure Design for Optimal Operation of Thermally Coupled Columns Distillation Columns

19

Steady Profiles with 4 temperature loops..

S2 Loop ± 1 C

10 20 30 81.5 82 82.5 T ,C 10 20 30 0.38 0.4 0.42 10 20 30 68.5 69 69.5 T ,C 10 20 30 0.9 0.95 1 10 20 30 86.5 87 87.5 T ,C 10 20 30 0.8 0.9 1 10 20 30 111 112 113 time, min T ,C 10 20 30 0.5 1 time, min

R/l Loop D/l Loop S1 Loop S2 Loop Output

TEMPERATURES Output

slide-20
SLIDE 20

16/03/2011 Control Structure Design for Optimal Operation of Thermally Coupled Columns Distillation Columns

20

Steady Profiles with 4 temperature loops..

10 20 30 40 80 82 84 T ,C 10 20 30 40 0.35 0.4 0.45 10 20 30 40 68 70 72 T ,C 10 20 30 40 0.6 0.8 1 10 20 30 40 86 88 90 T ,C 10 20 30 40 0.7 0.8 0.9 10 20 30 40 110 112 114 time, min T ,C 10 20 30 40 0.5 1 time, min

R/l Loop D/l Loop S1 Loop S2 Loop Output

All Loops ± 1 C

TEMPERATURES Output

slide-21
SLIDE 21

16/03/2011 Control Structure Design for Optimal Operation of Thermally Coupled Columns Distillation Columns

21

  • Introduction
  • System 1: 4- Product Kaibel Column

– Previous Work – Control Structure – Experimental Setup – Experimental Runs- Steady state profiles – Experimental Runs- Vapor Split Experiment

  • System 2: 4- Product Extended Petlyuk Column

– Model Details – Control Structure – Close Loop Results

  • Conclusions

Outline

slide-22
SLIDE 22

16/03/2011 Control Structure Design for Optimal Operation of Thermally Coupled Columns Distillation Columns

22

Vapor Split Experiment

  • Total reflux operation
  • Liquid Split Valve (R/l) in Manual
  • Manipulated valve: Vapor Split Valve V1 & V2
  • Controlled variable: T2-T5
  • Split Range logic

Output Valve Opening 0 50% 100% 100 %

V1 V2

slide-23
SLIDE 23

16/03/2011 Control Structure Design for Optimal Operation of Thermally Coupled Columns Distillation Columns

23

From top left: Valve in fully open position Top right: Rack and pinion arrangement. Schematic of the vapor split valve

Vapor Split Experiment..

slide-24
SLIDE 24

16/03/2011 Control Structure Design for Optimal Operation of Thermally Coupled Columns Distillation Columns

24 50 100

  • 5

5 T, C 50 100 0.5 1 50 100 70 75 80 T, C 50 100 70 75 80 50 100 5 10 Steps 50 100 5 10 50 100

  • 2

2 time, min Valve o/p 50 100 1.5 2 2.5 time, min KW

T2 R/l Output Reboiler Duty PF Valve MC Valve Rv O/p T7 delT T2-T5

Vapor Split Experimental run (Total Reflux, two component)

slide-25
SLIDE 25

16/03/2011 Control Structure Design for Optimal Operation of Thermally Coupled Columns Distillation Columns

25

  • Introduction
  • System 1: 4- Product Kaibel Column

– Previous Work – Control Structure – Experimental Setup – Experimental Runs- Steady state profiles – Experimental Runs- Vapor Split Experiment

  • System 2: 4- Product Extended Petlyuk Column

– Model Details – Control Structure – Close Loop Results

  • Conclusions

Outline

slide-26
SLIDE 26

16/03/2011 Control Structure Design for Optimal Operation of Thermally Coupled Columns Distillation Columns

26

Petlyuk Arrangement- Model Details

Model Assumptions

  • Ideal vapor liquid equilibria
  • 40 Theoretical stages in each

column

  • The base flows calculated

from the Vmin diagram* which calculated the minimum

C31 C32 C33 ABCD ABC BCD D A B C C22 C1 AB CD BC C21

* Halvosen, I.J. & Skogestad, S. (2003)

slide-27
SLIDE 27

16/03/2011 Control Structure Design for Optimal Operation of Thermally Coupled Columns Distillation Columns

27

Control Structure: Petlyuk Column

  • Two Liquid Levels & 6

Sensitive Temperatures are CVs in Regulatory layer

  • The loops were closed and

tuned sequentially from left to right

  • All loops tuned by the SIMC

rules

slide-28
SLIDE 28

16/03/2011 Control Structure Design for Optimal Operation of Thermally Coupled Columns Distillation Columns

28

Close loop results: Petlyuk Column

+10 % Feed Disturbance

500 1000 1500 0.93 0.94 0.95 0.96 0.97 0.98 0.99 1 time Purity Top Purity S1 Purity S2 Purity Bottoms

slide-29
SLIDE 29

16/03/2011 Control Structure Design for Optimal Operation of Thermally Coupled Columns Distillation Columns

29

  • Introduction
  • System 1: 4- Product Kaibel Column

– Previous Work – Control Structure – Experimental Setup – Experimental Runs- Steady state profiles – Experimental Runs- Vapor Split Experiment

  • System 2: 4- Product Extended Petlyuk Column

– Model Details – Control Structure – Close Loop Results

  • Conclusions

Outline

slide-30
SLIDE 30

16/03/2011 Control Structure Design for Optimal Operation of Thermally Coupled Columns Distillation Columns

30

Conclusion

  • 4 – Product Kaibel Column

– Experimental Studies Confirm Stable Profiles with 4 point temperature control – A lab scale prototype of vapor split valve effectively controlled vapor flow between prefractionator and main column

  • 4- Product Extended Petlyuk Column

– Simulation studies suggest that 4-product extended petlyuk column can be controlled and operated with 6 point temperature control in the regulatory layer

slide-31
SLIDE 31

16/03/2011 Control Structure Design for Optimal Operation of Thermally Coupled Columns Distillation Columns

31

Acknowledgements

  • Jens Strandberg for building the column
  • Prof Heinz Presig
  • Dr Mohammad Shamsuzuhha
  • Jon Anta Buljo Hansen
  • Terje Mugaas
  • Filip Voss
slide-32
SLIDE 32

16/03/2011 Control Structure Design for Optimal Operation of Thermally Coupled Columns Distillation Columns

32

References

  • Halvorsen, I.J.; Skogestad, S; “Minimum Energy Consumption in Multicomponent
  • Distillation. 3.More Than Three Products and Generalized Petlyuk Arrangements”, Ind.
  • Eng. Chem. Res. 2003, 42, 616-629
  • Kaibel, G. Distillation Columns with Vertical Partitions.Chem. Eng. Technol. 1987, 10, 92-

98.

  • Petlyuk, FB. Platonv, VM. Slavinskii, DM. (1965), Thermodynamically Optimal Methods for

Separating Multicomponent Mixtures. Int. Chem. Eng. 1965, 5(3), 555.

  • Strandberg, J., Skogestad, S., Stablizing Operation of a 4-Product Iintegerated Kaibel
  • Column. SYMPOSIUM SERIES NO. 152, Distillation & Absorption
  • Ghadrdan, M., Halvosen I.J., Skogestad, S., Optimal Operation of Kaibel Distillation

Columns, Chemical Engineering Research and Design (2010), doi:10.1016/j.cherd.2011.02.007

  • Kverland M, Halvorsen I.J., Skogestad. S,: Model Predictive Control of a Kaibel Distillation

Column., Proceed. of the 9th Intern. Symp. on Dynam. and Control of Process Systems (DYCOPS 2010)

  • Halvorsen, I.J., Skogestad, S. (2003) Minimum Energy Consumption in Multicomponent
  • Distillation. 1. Vmin Diagram for a Two-Product Column, Ind. Eng. Chem. Res., 2003, 42 (3),

pp 596–604

slide-33
SLIDE 33

16/03/2011 Control Structure Design for Optimal Operation of Thermally Coupled Columns Distillation Columns

33

Thank you!!
