Compressed RDF: Practical Uses & Hands-on

Antonio Fariña, Javier D. Fernández and Miguel A. Martinez-Prieto

23TH AUGUST 2017

3rd KEYSTONE Training School Keyword search in Big Linked Data

• Session I (09:00 - 10:30) "Basics of Compression for Big Linked Data Management“
• Big (Linked) Semantic Data Compression: motivation & challenges
• Compact Data Structures
• Session II (13:30 - 15:00) “RDF Compression“
• RDF Compression. HDT
• RDF Dictionaries
• RDF Triples
• Session III (15:30-17:00) “Compressed RDF: Practical Uses & Hands-on”
• Practical Uses (LOD-a-lot, RDF Archiving, etc.)
• Hands on

PAGE 2

General agenda

images: zurb.com

• Practical uses
• LOD-a-lot: Web-scale queries in your pocket
• RDF archiving
• Linked Data markets (Linked Close Data)
• Hands on
• HDT-it
• Command line tools
• HDT and Fuseki
• HDT and Linked Data Fragments
• HDT and C++/Java
• HDT and Jena

PAGE 3

Agenda of this session

images: zurb.com

LOD-a-lot

Use case 1

• E.g. retrieve all entities in LOD with the label “Axel Polleres“
• Options:
• Crawl and index LOD locally (-no-)
• Follow-your-nose (where should I start?)
• Federated querying (as good as the endpoints you query)
• Use LOD Laundromat as a “good approximation” (still querying 650K datasets)

5

Still… what about Web-scale queries

select distinct ?x { ?x rdfs:label “Axel Polleres" }

6

LOD Laundromat

Dataset 1

N-Triples (zip)

Dataset 650K

N-Triples (zip)

Linked Open Data

SPARQL endpoint (metadata)

LOD Laundromat

LOD-a-lot

7

But what about Web-scale queries

• flashback -

The real motivation

consume

The real motivation

http://www.kunsan.af.mil/News/ Article/413995/serving-the-masses/

Oh man I’m hungry and I don’ t even know if I will like whatever you are cooking

consume

The real motivation

Oh man I’m hungry and I don’ t even know if I will like whatever you are cooking

consume

http://www.kunsan.af.mil/News/ Article/413995/serving-the-masses/

LOD-a-lot

11

But what about Web-scale queries But one could be really hungry

https://hwy55burgers.wordpress.com/tag/food-challenge/

12

LOD Laundromat

Dataset 1

N-Triples (zip)

Dataset 650K

N-Triples (zip)

Linked Open Data

LOD-a-lo lot

SPARQL endpoint (metadata)

LOD-a-lot

Kudos Javier D. Fernandez, Wouter Beek, Miguel A. Martínez-Prieto, and Mario Arias

28B triples

• Disk size:
• HDT: 304 GB
• HDT-FoQ (additional indexes): 133 GB
• Memory footprint (to query):
• 15.7 GB of RAM (3% of the size)
• 144 seconds loading time
• 8 cores (2.6 GHz), RAM 32 GB, SATA HDD on Ubuntu 14.04.5 LTS
• LDF page resolution in milliseconds.

13

LOD-a-lot (some numbers)

305€

(LOD-a-lot creation took 64 h & 170GB RAM. HDT-FoQ took 8 h & 250GB RAM)

14

LOD-a-lot

https://datahub.io/dataset/lod-a-lot http://purl.org/HDT/lod-a-lot

• Query resolution at Web scale
• Evaluation and Benchmarking
• No excuse 
• RDF metrics and analytics

15

LOD-a-lot (some use cases)

subjects predicates

• bjects

16

ACKs LOD-a-lot

Archiving

Use case 2

ANDREAS HARTH - STREAM REASONING IN MIXED REALITY APPLICATIONS, STREAM REASONING WORKSHOP 2015

So far so good... But RDF is evolving

Number

• f

sources Update rate month year week day hour minute second 104 105 106 101 100 102 103

DBpedia BTC Dyldo Internet

• f Things

Virtual/Augmented Reality

versions?

LOD-a-lot

3

Most semantic Web/Linked Data tools are focused on this “static view” but do not consider versioning/evolution

Linked Data Archives: The missing link in the RDF evolution

Sindice, SWSE, Swoogle, LOD Cache, LOD-Laundromat… so far, no versions!

• Web archives: Common Crawl, Internet Memory, Internet Archive, …

20

Preservation matters

21

…in the last few years:

Managing the Evolution and Preservation of the Data Web (FP7) Preserving Linked Data (FP7)

Research projects Archives Tools Benchmarking

• ne of the fundamental problems in the Web of Data

BEnchmark of RDF ARchives

RDF evolution at Scale

v-RDFCSA

22

…in the last few years:

Managing the Evolution and Preservation of the Data Web (FP7) Preserving Linked Data (FP7)

Research projects Archives Tools Benchmarking

• ne of the fundamental problems in the Web of Data

BEnchmark of RDF ARchives

RDF evolution at Scale

v-RDFCSA

23

RDF Archiving. Archiving policies

V1

ex:C1 ex:hasProfessor ex:P1 . ex:S1 ex:study ex:C1 . ex:S3 ex:study ex:C1 . ex:C1 ex:hasProfessor ex:P2 . ex:C1 ex:hasProfessor ex:S2 . ex:S1 ex:study ex:C1 . ex:S3 ex:study ex:C1 .

V2 V3

ex:C1 ex:hasProfessor ex:P1 . ex:S1 ex:study ex:C1 . ex:S2 ex:study ex:C1 .

V1

ex:C1 ex:hasProfessor ex:P1 . ex:S1 ex:study ex:C1 . ex:S2 ex:study ex:C1 . ex:S3 ex:study ex:C1 . ex:S2 ex:study ex:C1 . ex:C1 ex:hasProfessor ex:P1 . ex:C1 ex:hasProfessor ex:P2 . ex:C1 ex:hasProfessor ex:S2 .

V1,2,

3

ex:C1 ex:hasProfessor ex:P1 [V1,V2]. ex:C1 ex:hasProfessor ex:P2 [V3]. ex:C1 ex:hasProfessor ex:S2 [V3]. ex:S1 ex:study ex:C1 [V1,V2,V3]. ex:S2 ex:study ex:C1 [V1]. ex:S3 ex:study ex:C1 [V2,V3].

a) Independent Copies/Snapshots (IC) b) Change-based approach (CB) c) Timestamp-based approach (TB)

RETRIEVAL MEDIATOR RETRIEVAL MEDIATOR

RETRIEVAL MEDIATOR

24

BEAR

https://aic.ai.wu.ac.at/qadlod/bear.html

• Queries and systems
• We implemented and evaluate archiving systems on Jena-TDB and HDT,

based on IC, CB and TB policies.

• Serve as an initial baseline to compare archiving systems
• More info: https://aic.ai.wu.ac.at/qadlod/bear.html

25

BEAR: Benchmarking the Efficiency of RDF Archiving

26

RDF Archiving. Archiving policies

V1

ex:C1 ex:hasProfessor ex:P1 . ex:S1 ex:study ex:C1 . ex:S3 ex:study ex:C1 . ex:C1 ex:hasProfessor ex:P2 . ex:C1 ex:hasProfessor ex:S2 . ex:S1 ex:study ex:C1 . ex:S3 ex:study ex:C1 .

V2 V3

ex:C1 ex:hasProfessor ex:P1 . ex:S1 ex:study ex:C1 . ex:S2 ex:study ex:C1 .

V1

ex:C1 ex:hasProfessor ex:P1 . ex:S1 ex:study ex:C1 . ex:S2 ex:study ex:C1 . ex:S3 ex:study ex:C1 . ex:S2 ex:study ex:C1 . ex:C1 ex:hasProfessor ex:P1 . ex:C1 ex:hasProfessor ex:P2 . ex:C1 ex:hasProfessor ex:S2 .

V1,2,

3

ex:C1 ex:hasProfessor ex:P1 [V1,V2]. ex:C1 ex:hasProfessor ex:P2 [V3]. ex:C1 ex:hasProfessor ex:S2 [V3]. ex:S1 ex:study ex:C1 [V1,V2,V3]. ex:S2 ex:study ex:C1 [V1]. ex:S3 ex:study ex:C1 [V2,V3].

a) Independent Copies/Snapshots (IC) b) Change-based approach (CB) c) Timestamp-based approach (TB)

RETRIEVAL MEDIATOR RETRIEVAL MEDIATOR

RETRIEVAL MEDIATOR

• Instantiation of archive queries in AnQL [1]
• Mat(Q,V1)
• version materialization
• Diff(Q,V1,V2)
• Ver(Q)
• join(Q1,vi,Q2,vj)
• Change(Q)

27

Benchmarking: Define the queries

SELECT * WHERE { Q :[v1] }

[1] Antoine Zimmermann, Nuno Lopes, Axel Polleres, and Umberto Straccia. A general framework for representing, reasoning and querying with annotated Semantic Web data. Journal of Web Semantics (JWS), 12:72--95, March 2012.

• Instantiation of archive queries in AnQL
• Mat(Q,V1)
• Diff(Q,V1,V2)
• delta materialization
• Ver(Q)
• join(Q1,vi,Q2,vj)
• Change(Q)

28

Benchmarking: Define the queries

SELECT * WHERE { { { {Q :[v1]} MINUS {Q :[v2]} } BIND (v1 AS ?V ) } UNION { { {Q :[v2] } MINUS {Q :[v1]}} BIND (v2 AS ?V ) }

• Instantiation of archive queries in AnQL
• Mat(Q,V1)
• Diff(Q,V1,V2)
• Ver(Q)
• results of Q annotated with the version
• join(Q1,vi,Q2,vj)
• Change(Q)

29

Benchmarking: Define the queries

SELECT * WHERE { Q :?V }

• Instantiation of archive queries in AnQL
• Mat(Q,V1)
• Diff(Q,V1,V2)
• Ver(Q)
• join(Q1,v1,Q2,v2)
• Change(Q)

30

Benchmarking: Define the queries

SELECT * WHERE { {Q :[v1]} {Q :[v2]} }

• Instantiation of archive queries in AnQL
• Mat(Q,V1)
• Diff(Q,V1,V2)
• Ver(Q)
• join(Q1,vi,Q2,vj)
• Change(Q)
• Returns consecutive versions in which Diff of a query is not null

31

Benchmarking: Define the queries

SELECT ?V1 ?V2 WHERE { {{Q :?V1 } MINUS {Q :?V2}} UNION {{Q :?V2 } MINUS {Q :?V1}} FILTER( abs(?V1-?V2) = 1 ) }

Open question remains: What is the right query syntax for archive queries?

32

Time-based access. Queries

Materialize (s,?,? ; version)

33

Time-based access. Queries

diff(?,?,o ; version0 ; version t)

• RDFCSA: Compressed Suffix Array
• v-RDFCSA[2] is designed as a lightweight TB approach
• Version information encoding
• Any triple can be identified by the position of its subject within SA
• Let be N the number of different versions and n the set of version-oblivious

triples

• Two encoding strategies
• tpv: N bitsequences 𝐂𝐰 𝐣 [𝟐, 𝐨] to encode what triple appears in version i
• vpt: n bitsequences 𝐂𝐮 i [1, N ] to encode versions where the kth triple occurs

34

Self-Indexing RDF Archives: v-RDFCSA

Bv

1

1 1 1 Bv

2

1 1 Bv

3

1 1 Triples 1 2 3 4 5

tpv

Versions 1 2 3 Bt

1

1 1 1 1 1 1 1 Triples 1 2 3 4 5

vpt

Version s 1 2 3 Bt

2 Bt 3 Bt 4 Bt 5

[2] Ana Cerdeira-Pena, Antonio Fariña, Javier D. Fernández, and Miguel A. Martínez-Prieto. Self- Indexing RDF Archives. Data Compression Conference (DCC), 2016.

Performs more than one order of magnitude faster than Jena-TDB for query resolution

Linked Open/Close Data (Linked Data markets)

Use case 3

G3b G1b

Linked Open Data Cloud Linked Closed Data Cloud

dbpedia G3a G4a G1a G2a G1c G2c G2b

So far so good but.. Linked Open/Close Data

“Deep Semantic Web”

Linked Open/Close Data

• A) Efficient Exchange: Compression + Encryption (hdtcrypt)

38

Linked Open/Close Data

• B) A secure LD Endpoint

39

Linked Open/Close Data

Self-Enforcing Access Control for Encrypted RDF Javier D. Fernández, Sabrina Kirrane, Axel Polleres and Simon Steyskal. In ESWC’17

Future work:

Hands on!

Find these slides in:

https://aic.ai.wu.ac.at/qadlod/presentations/ keystoneHandsOn2017.pdf https://aic.ai.wu.ac.at/qadlod/presentations/ codeKeystone2017

• 1) Desktop tool HDT-it!
• Thanks to Mario Arias

Consuming HDT

• 1) Desktop tool HDT-it!
• Download the tool for your OS:
• http://www.rdfhdt.org/downloads/
• Get an HDT dataset from the web
• http://www.rdfhdt.org/datasets/

OR

• http://lodlaundromat.org/wardrobe/

OR convert your RDF dataset with the tool.

• As a suggestion of small datasets:
• SWDF (242K triples) or the bigger DBLP (55M triples)

Consuming HDT

• 2) Command line Tools (C++ and Java)

Consuming HDT

rdfhdt.org HDT-C++ HDT-Java Command Line tools X X TP search X X Full SPARQL

• with Jena

Parametrizable Compression

X

• Full text support

X

• Practical Uses

LDF

Jena, Fuseki

• 2) Command line Tools (c++ and Java)
• For simplicity, in this lecture we will use Java
• Download hdt-java library from https://github.com/rdfhdt/hdt-java/
• git clone https://github.com/rdfhdt/hdt-java.git
• r download https://github.com/rdfhdt/hdt-java/archive/master.zip
• Install the library with maven:
• mvn install
• Query an HDT file:
• Go to HDT-cli and execute:
• ./bin/hdhSearch.sh /path/to/your/hdt
• This will open a simple console where you can query triple patterns
• Export/Import
• $> rdf2hdt file.nt output.hdt
• $> hdt2rdf file.hdt output.nt

Consuming HDT

• 3) Set up a SPARQL Endpoint with HDT and Fuseki
• Go to hdt-fuseki and compile adding the dependencies:
• mvn package dependency:copy-dependencies
• Run fuseki
• ./bin/hdtEndpoint.sh --hdt path/to/dataset.hdt /mydataset
• Open your Web Browser and go to: http://localhost:3030
• Select Control Panel / Dataset / myDataset and click Select
• Type your SPARQL Query and see the results.
• Be careful with the number of results, here there is no limitation in the number
• f results such as in e.g. virtuoso:
• select * WHERE{ ?s ?p ?o} LIMIT 400

Consuming HDT

• 4) Set up a Linked Data Fragments Endpoint with HDT
• Download LDF Server (Node.js is the best one but we will use java for

simplicity in the installation).

• git clone https://github.com/LinkedDataFragments/Server.Java.git
• r download https://github.com/LinkedDataFragments/Server.Java/archive/master.zip
• Install the server, avoid the test (it fails :)
• mvn install -Dmaven.test.skip=true
• Open the file config-example.json and modify the settings to point to your

hdt, e.g.

• "settings": { "file": "/home/user/myfile.hdt" }
• Run the server
• java -jar target/ldf-server.jar
• Access http://localhost:8080

Consuming HDT

• 5) Access with the HDT C++/Java libraries (again, we restrict here to

Java)

• JAVADOC:
• http://purl.org/HDT/javadoc/api
• http://purl.org/HDT/javadoc/core
• I will refer to Eclipse and Maven but you can use your preferred environment

Consuming HDT

• Setting up the environment…
• Create a new maven project

Consuming HDT / HDT-java library

• Setting up the environment…
• Create a new maven project
• Select to create a simple project (skip archetype selection)

Consuming HDT / HDT-java library

• Setting up the environment…
• Create a new maven project
• With a simple archetype
• And any metadata

Consuming HDT / HDT-java library

• Setting up the environment…
• Include the maven dependency of hdt-java-core in the pom.xml

Consuming HDT / HDT-java library

• Setting up the environment…
• Include the maven dependency of hdt-java-core in the pom.xml
• Finally, let’s create a new Class and query our HDT

Consuming HDT / HDT-java library

• Test other queries
• get the S, P, O of the solution

• Let’s access the dictionary of terms in HDT

Consuming HDT / HDT-java library

• Open two HDT files
• Use the dictionaries to get the common predicates used in both

• Let’s access the terms as IDs

Consuming HDT / HDT-java library

• Use the estimation of results to count the cardinality of all

subjects

• We can build an histogram and see the distribution

• 6) Query full SPARQL with Jena and HDT
• First, include the hdt-jena dependency in pom.xml

Consuming HDT

• 6) Query full SPARQL with Jena and HDT
• First, include the hdt-jena dependency in pom.xml
• Import HDT into a model and query!

Consuming HDT

• Test other queries over your data

• +) Query LOD-a-lot
• First, get the correct hdt-java branch to deal with really long IDs
• git clone -b long-dict-id https://github.com/rdfhdt/hdt-java/
• Install, avoid the test
• mvn install -Dmaven.test.skip=true
• Change java head space
• export MAVEN_OPTS="-Xmx25G"
• In hdt-java-cli
• ./bin/hdtSearch.sh /media/javi/data/lod-a-lot/LOD_a_lot_v1.hdt

Consuming HDT

Let’s the lecture… end

• We are currently facing Big Linked Data challenges
• Generation, publication and consumption
• Thanks to compression, the Big Linked Data today

will be the “pocket” data tomorrow

• Compression is not just about space
• Fast exchange
• Fast processing/management
• Fast querying
• Compression democratizes the access to Big

Linked Data

= Cheap, scalable consumers

PAGE 59

Take-home messages

Thank you!

Let’s the lecture… end
