Compositional Software Model Checking Dan R. Ghica Oxford University Computing Laboratory October 18, 2002 Outline of talk program verification issues the semantic challenge programming languages the logical challenge

slide-1
SLIDE 1

Compositional Software Model Checking

Dan R. Ghica Oxford University Computing Laboratory October 18, 2002

slide-2
SLIDE 2

Outline of talk

  • program verification issues
  • the semantic challenge — programming languages
  • the logical challenge — specification logics
  • specialised quantifiers — a model-checking friendly logic

Dan R. Ghica, Compositional software model checking 1

slide-3
SLIDE 3

Program verification I — inferential

  • programming logics:

– Hoare logic; specification logic (Reynolds); dynamic logic (Harel)

  • common features:

– ‘exogenous’; compositional; sound; excruciating; – (partially) automated with proof checkers/assistants – can prove (partial) correctness; cannot find bugs

Dan R. Ghica, Compositional software model checking 2

slide-4
SLIDE 4

Program verification II — semantic

  • temporal logics (many)
  • common features:

– ‘endogenous’; non-compositional; unsound (‘semantic gap’); fun – algorithmic semantics – fully automated with model checkers (Slam, Bandera) – cannot prove correctness; can find bugs

Dan R. Ghica, Compositional software model checking 3

slide-5
SLIDE 5

Program verification desiderata

  • unify the two approaches: ‘compositional model checking’
  • inference rules

– correctness, compositionality

  • algorithmic semantics of program and logic

– automated model-checking, find counterexamples

  • fewer inferential steps

Dan R. Ghica, Compositional software model checking 4

slide-6
SLIDE 6

The semantic challenge

  • an algorithmic semantics of programming languages with

procedures

  • program (fragment) code ⇒ finite model
  • difficult problem

Dan R. Ghica, Compositional software model checking 5

slide-7
SLIDE 7

Games semantics

  • Hyland & Ong and (independently) Abramsky, Jagadeesan

& Malacaria and (independently) Nickau (93–94): Full abstraction for PCF

  • Abramsky & McCusker (96–97):

Full abstraction of Idealised Algol

  • many more important results followed

A complex combinatorial account of programming language se- mantics.

Dan R. Ghica, Compositional software model checking 6

slide-8
SLIDE 8

Regular-language semantics

Observation: for certain languages, if higher-order functions and recursion are omitted then much of the game-theoretic formal apparatus can be also omitted

  • second-order Idealised Algol can be modeled using regular

languages (Ghica & McCusker 2000)

  • second-order reduced ML can be modeled using regular lan-

guages (Ghica 01)

  • third-order Idealised Algol can be modeled using deterministic

context-free languages (Ong 02) A practicable algorithmic model.

Dan R. Ghica, Compositional software model checking 7

slide-9
SLIDE 9

The programming language IA

Data sets: booleans, bounded integers Ground types: variables, expressions, commands; Imperative features: assignment, branching, iteration, local variables; Functional features: first-order functions (uniformly on all types), call-by-name;

Dan R. Ghica, Compositional software model checking 8

slide-10
SLIDE 10

Semantic valuations

Γ ⊢ M:θ : Term → Regular Language

Helpful notation

Γ ⊢ E:int =

nq · Γ ⊢ E:intn · n

Γ ⊢ C:com = run · Γ ⊢ C:com · done Γ ⊢ V :var =

nread · Γ ⊢ V :varread n

· n +

nwrite(n) · Γ ⊢ V :varwrite n

· ok

Dan R. Ghica, Compositional software model checking 9

slide-11
SLIDE 11

RL interpretation

Language constants:

skip:com = run · done n:int = q · n loop:com = ∅

Imperative features:

C; C′ = C · C′ if B then C else C′ = B:booltt · C + B:boolff · C′ while B do C =

  • Btt · C

∗ · Bff

Dan R. Ghica, Compositional software model checking 10

slide-12
SLIDE 12

A simple example

Γ ⊢ while true do C ≡ loop

while true do C =

  • truett · C

∗ · trueff

=

  • ǫ · C

∗ · ∅

= ∅ = loop Because: truett = ǫ, trueff = ∅.

Dan R. Ghica, Compositional software model checking 11

slide-13
SLIDE 13

Free identifiers

c:com ⊢ c:com = run · runc · donec · done f:com → com ⊢ f:com → com

= run · runf · (runf1 · run1 · done1 · donef1)∗ · donef · done E.g.

f(skip) = run · runf · (runf1 · donef1)∗ · donef · done

Dan R. Ghica, Compositional software model checking 12

slide-14
SLIDE 14

Variables

Assignment:

V := E =

nEn · V write n

Dereferencing (reading):

!V : intn = V : varread

n

Obs: no causal relation between read and write actions:

let v be y :=!y + 1; y in · · ·

Dan R. Ghica, Compositional software model checking 13

slide-15
SLIDE 15

Local (block) variables

Only local variables are guaranteed to be well behaved: · · · writex(n) · okx · · · readx · nx · · · readx · nx · · · Interpretation of block variables:

Γ ⊢ int x in C =

  • Γ, x:var ⊢ C ∩

γx

  • ↾ Ax

Where γx =

  • n writex(n) · okx · (readx · nx)∗∗
  • Ax the alphabet of moves not tagged by x,

γx = γx ∐ (Ax)∗ (shuffle)

  • ↾ is restriction.

Dan R. Ghica, Compositional software model checking 14

slide-16
SLIDE 16

An example

c:com ⊢ int x in c ≡ c First proved using possible-worlds-style functor categories.

c:com ⊢ int x in c =

  • c:com, x:var ⊢ c ∩

γx

  • ↾ Ax

=

  • runc · donec ∩

γx

  • ↾ Ax

= runc · donec = c:com ⊢ c

Dan R. Ghica, Compositional software model checking 15

slide-17
SLIDE 17

The semantic gap is bridged.

  • algorithmic regular-language based model
  • sound and complete (fully abstract)
  • decidable (for most properties)

Dan R. Ghica, Compositional software model checking 16

slide-18
SLIDE 18

And now for something completely different... ...specification logic.

Dan R. Ghica, Compositional software model checking 17

slide-19
SLIDE 19

Common specification idiom

In Hoare-logic {P} C {Q} In (Reynolds) spec. logic, with non-local procedures ∀p : σ • Sproc(p) → Sprog(p) E.g. ∀c : comm • {v = v0} c {v = v0 + 1} → {v = z} c; c {v = z + 2}

Dan R. Ghica, Compositional software model checking 18

slide-20
SLIDE 20

A problem

Specification logic is undecidable

  • boolean, recursion-free, first-order fragment

Questionable suitability for model checking

Dan R. Ghica, Compositional software model checking 19

slide-21
SLIDE 21

Equational theory of IA is undecidable

φ ::= ∀x : σ.φ | ∃x : σ.φ | φ ∧ φ | φ ∨ φ | φ → φ | ¬φ | M ≡ N We can encode polynomials: − : N[X] → IA.

X = x : comm → comm 0 = λc.skip succ(n) = λc.(n)c; c m + n = λc.(n)c; (m)c m × n = λc.(n)((m)c)

Dan R. Ghica, Compositional software model checking 20

slide-22
SLIDE 22

Equational theory of IA is undecidable (cont’d)

Hilbert’s 10th problem corresponds to proving ∃ x : comm → comm.P1 ≡ P2, Pi ∈ N[X].

  • Spec. logic of IA is also undecidable
  • ∀p:assert.{true} c1 {p} ↔ {true} c2 {p}
  • ↔ c1 ≡ c2.

Dan R. Ghica, Compositional software model checking 21

slide-23
SLIDE 23

A solution

Common idiom: ∀p : σ • Sproc(p) → Sprog(p) Relativised quantifiers (syntactic): ∀p : Sproc • Sprog(p) Specialised quantifiers (semantic): Ψp : Sproc • Sprog(p)

Dan R. Ghica, Compositional software model checking 22

slide-24
SLIDE 24

Example: “effects quantifier”

Ψc : {v = v0} c {v = v0 + 1}

  • Sproc
  • {v = z} c; c {v = z + 2}
  • Sprog

All the variables above are global, distinct.

Dan R. Ghica, Compositional software model checking 23

slide-25
SLIDE 25

Another useful quantifier: “stability quantifier”

CBN+computational side-effects breaks arithmetic: x = x Context: let x be v := !v + 1; !v in · · · Obs: this is in general a difficult problem (Boehm 82) ∇x : σ.S E.g. ∇x : exp.x = x is always true. Semantics: similar to block variables (· · · ∩ γx

σ) ↾ Ax

Dan R. Ghica, Compositional software model checking 24

slide-26
SLIDE 26

A more generalised stability quantifier

∇x/ y : σ.S Interpretation: x is stable but the actions of identifiers in y may change its value. E.g. ∇y.∇x/y • x + x = 2 × x is true ∇y.∇x/y • x + y = y + x is not necessarily true

Dan R. Ghica, Compositional software model checking 25

slide-27
SLIDE 27

Our example, this time formally

∇v/c.Ψc : ∇v0.{v = v0} c {v = v0 + 1} • ∇z.{v = z} c; c {v = z + 2}

  • no need to restrict to global variables
  • more abstract formulations

∇e/c.Ψc : ∇e0.{e = e0} c {e = e0 + 1} • ∇z.{e = z} c; c {e = z + 2}

Dan R. Ghica, Compositional software model checking 26

slide-28
SLIDE 28

Why does it work? — a discussion

  • no true universal quantifier in the logic

– no quantification over languages – (no quantification over opponent behaviours)

  • specialised quantifiers are tamer

– regular-language interpretation – (encode a strategy for the opponent)

Dan R. Ghica, Compositional software model checking 27

slide-29
SLIDE 29

A bit of quantifier theory

introduced by Mostowski (57) and extended by Lindstroem (66); called “generalised” quantifiers; extend expressiveness without increasing order

  • “for uncountably many”
  • “for all connected graphs”

applications to descriptive complexity theory

Dan R. Ghica, Compositional software model checking 28

slide-30
SLIDE 30

What is a generalised quantifier?

any collection of structures closed under isomorphism type of a generalised quantifier (n1, n2, . . . , nk) ni identifiers are bound in the ith formula e.g. of type (1, 1) quantifier: Ψx, y : there are as many x with P(x) as there are y with Q(y) strict hierarchy (Hella et.al. 96) (1) < (1, 1) < · · · < (2) < (2, 1) < (2, 1, 1) · · · < (2, 2) < · · · < (3) · · ·

Dan R. Ghica, Compositional software model checking 29

slide-31
SLIDE 31

Proof theory of generalised quantifiers

substructural logics—substitution subject to extra conditions Ψ x1 : P1 . . . xk : Pk • S Pi( Mi) Mi # S, Mi # Mj, i = j S[ xi/ Mi] we call # non-interference work done by Alechina & Lambalgen (96)

Dan R. Ghica, Compositional software model checking 30

slide-32
SLIDE 32

Example

Ψc : {v = v0} c {v = v0 + 1} • {v = z} c; c {v = z + 2} {v = v0} v := v + 1 {v = v0 + 1} {v = z} v = v + 1; v = v + 1; {v = z + 2} Or Ψc : {v = v0} c {v = v0 + 1} • {v = z} c; c {v = z + 2} {v = v0} v := v + 1; k := k + 1 {v = v0 + 1} {v = z} v = v + 1; k := k + 1; v = v + 1; k := k + 1 {v = z + 2} But not Ψc : {v = v0} c {v = v0 + 1} • {v = z} c; c {v = z + 2} {v = v0} v := v + 1; z := z + 1 {v = v0 + 1} {v = z} v = v + 1; z := z + 1; v = v + 1; z := z + 1 {v = z + 2}

Dan R. Ghica, Compositional software model checking 31

slide-33
SLIDE 33

Non-interference

C # S C does not write to the ‘protected’ variables of S and vice versa.

Dan R. Ghica, Compositional software model checking 32

slide-34
SLIDE 34

Higher-type quantifiers and substitution

In the previous example we actually have a type (1,1) quantifier

  • ∇e/c

Ψc : ∇e0.{e = e0} c {e = e0 + 1}

  • ∇z.{e = z} c; c {e = z + 2}

Elimination must be simultaneous ∇v.∇(!v) ∇v.∇e0.{!v = e0} v := !v + 1 {!v = e0 + 1} ∇v.∇z.{!v = z} v := !v + 1; v := !v + 1 {!v = z + 2}

Dan R. Ghica, Compositional software model checking 33

slide-35
SLIDE 35

Highlights of the logical system

  • effects and stability quantifiers for ground and first order

types

  • quantifiers of type (1, 1, · · · , 1)
  • regular-language semantics, decidable
  • quantifiers discharged through substitution
  • also, Hoare axioms

Dan R. Ghica, Compositional software model checking 34

slide-36
SLIDE 36

Drawback

“algebraic” specifications involve quantifiers of higher type:

  

∇x/do, undo ∇y.{x = y} do; undo {x = y} ∇y.{x = y} undo; do {x = y}

   • · · · .

has type (1, 2), does not (?) have a RL semantics.

Dan R. Ghica, Compositional software model checking 35

slide-37
SLIDE 37

Conclusion

  • RL semantics, inference — compositional model checking
  • non-interference conditions — syntactic or semantic
  • challenging programming language — semantic and logic
  • not very complicated (?) — avoid “low level” axioms
  • some drawbacks
  • no verification tool yet

Dan R. Ghica, Compositional software model checking 36

slide-38
SLIDE 38

Related work

Interface automata, de Alfaro & Henzinger (2001)

  • emphasis on the automata model
  • the discharge of the interface — “refinement”

Dan R. Ghica, Compositional software model checking 37
