Ben Greenman Matthias Felleisen Christos Dimoulas at at at COMPLETE MONITORS FOR GRADUAL TYPES Ben Greenman Matthias Felleisen Christos Dimoulas at at at COMPLETE MONITORS FOR GRADUAL TYPES a careful analysis of the mixed-typed

slide-1
SLIDE 1

COMPLETE MONITORS FOR GRADUAL TYPES

Ben Greenman Matthias Felleisen Christos Dimoulas

at at at

slide-2
SLIDE 2

COMPLETE MONITORS FOR GRADUAL TYPES

Ben Greenman Matthias Felleisen Christos Dimoulas

at at at

a careful analysis

  • f the mixed-typed

design space

slide-3
SLIDE 3

Type soundness is not enough Complete monitoring is crucial for meaningful gradual types "Incomplete" monitoring provides a way to measure the quality of blame errors *from ESOP 2012 *

slide-4
SLIDE 4

Mixed-Typed Language

slide-5
SLIDE 5

Mixed-Typed Language

U T U U T

Untyped/Typed mix

U

= untyped code

T

= simply-typed (no 'Dynamic' type) code

slide-6
SLIDE 6

A Few Motivations

U T U U T

slide-7
SLIDE 7

A Few Motivations

U T U U T

Prototyping

slide-8
SLIDE 8

A Few Motivations

U T U U T

Prototyping write untyped code, rely on types

slide-9
SLIDE 9

A Few Motivations

U T U U T

Prototyping write untyped code, rely on types Re-Use

slide-10
SLIDE 10

A Few Motivations

U T U U T

Prototyping write untyped code, rely on types Re-Use write typed code, use old libraries

slide-11
SLIDE 11

Many Implementations ...

JavaScript Flow + Racket Typed Racket + Python Reticulated + Python Mypy + PHP Hack + JavaScript TypeScript +

slide-12
SLIDE 12

Many Implementations ...

JavaScript Flow + Racket Typed Racket + Python Reticulated + Python Mypy + PHP Hack + JavaScript TypeScript +

... diffcult to compare

UTU U T

slide-13
SLIDE 13

Many Models, too

GTLC AGT λH λ*

→

UTU U T

slide-14
SLIDE 14

Goal: Characterize the Landscape

slide-15
SLIDE 15

Non-Goal: Restrict Landscape

slide-16
SLIDE 16
slide-17
SLIDE 17

Warmup: Optional Typing / Erasure

slide-18
SLIDE 18

Example: Optional Typing

function f (x : [N,N]) { ... fst x ... }

T

slide-19
SLIDE 19

Example: Optional Typing

function f (x : [N,N]) { ... fst x ... }

T

f(9)

U

slide-20
SLIDE 20

Example: Optional Typing

function f (x : [N,N]) { ... fst x ... }

T

f(9)

U

Error: 9 is not a pair

slide-21
SLIDE 21

Example: Optional Typing

function f (x : [N,N]) { ... fst x ... }

T

f(9)

U

Error: 9 is not a pair types are meaningless at run-time cannot help debug a faulty program

slide-22
SLIDE 22

= Does Not Preserve Types

Uni sound

slide-23
SLIDE 23

= Does Not Preserve Types

Uni sound

"type" sound

slide-24
SLIDE 24

ICFP '18

slide-25
SLIDE 25

ICFP '18 : Three Semantics, Soundnesses

slide-26
SLIDE 26

ICFP '18 : Three Semantics, Soundnesses

Erasure semantics

  • types predict nothing
slide-27
SLIDE 27

ICFP '18 : Three Semantics, Soundnesses

Erasure semantics

  • types predict nothing

Transient semantics

  • types predict the top-level shape of values
  • enforced by tag checks
slide-28
SLIDE 28

ICFP '18 : Three Semantics, Soundnesses

Erasure semantics

  • types predict nothing

Transient semantics

  • types predict the top-level shape of values
  • enforced by tag checks

Natural semantics

  • types predict the full behavior of values
  • enforced by higher-order wrappers
slide-29
SLIDE 29

ICFP '18 : Three Semantics, Soundnesses

Erasure semantics

  • types predict nothing

Transient semantics

  • types predict the top-level shape of values
  • enforced by tag checks

Natural semantics

  • types predict the full behavior of values
  • enforced by higher-order wrappers

Uni sound ⌊T⌋ sound T sound

Erasure semantics

  • types predict nothing

Transient semantics

  • types predict the top-level shape of values
  • enforced by tag checks

Natural semantics

  • types predict the full behavior of values
  • enforced by higher-order wrappers
slide-30
SLIDE 30

ICFP '18: A Spectrum of Type Soundness

Uni sound

slide-31
SLIDE 31

ICFP '18: A Spectrum of Type Soundness

Uni sound ⌊T⌋ sound Uni sound T sound Erasure Natural Transient

slide-32
SLIDE 32

⌊T⌋ sound T sound Natural Transient

slide-33
SLIDE 33

⌊T⌋ sound T sound Natural Transient

Transient semantics

  • types predict the top-level shape of values
  • enforced by tag checks

Natural semantics

  • types predict the full behavior of values
  • enforced by higher-order wrappers

⌊T⌋ sound T sound

Transient semantics

  • types predict the top-level shape of values
  • enforced by tag checks

Natural semantics

  • types predict the full behavior of values
  • enforced by higher-order wrappers
slide-34
SLIDE 34

⌊T⌋ sound T sound Natural Transient

slide-35
SLIDE 35

⌊T⌋ sound T sound Natural Transient Amnesic

Amnesic semantics

  • enforce tag checks ⌊T⌋

with higher-order wrappers

  • same behavior as Transient
  • same type soundness as Natural

OOPSLA '19

Greenberg POPL '15 Castagna, Lanvin ICFP '17

slide-36
SLIDE 36

Type Soundness is NOT ENOUGH

⌊T⌋ sound Uni sound T sound ??? Erasure Natural Transient Amnesic

slide-37
SLIDE 37

Example: Transient/Amnesic vs. Natural

slide-38
SLIDE 38

Example: Transient/Amnesic vs. Natural

Prototyping

slide-39
SLIDE 39

Example: Transient/Amnesic vs. Natural

Prototyping Library Re-Use

slide-40
SLIDE 40

Example: Transient/Amnesic vs. Natural

Prototyping Library Re-Use Combine: untyped script + typed API + untyped library via a higher-order value

slide-41
SLIDE 41

Example: Transient/Amnesic vs. Natural

  • 1. plot data
  • 2. listen for a click
  • 3. draw an image

Clickable Plot

1

slide-42
SLIDE 42

Example: Transient/Amnesic vs. Natural

  • 1. plot data
  • 2. listen for a click
  • 3. draw an image

Clickable Plot

2

slide-43
SLIDE 43

Example: Transient/Amnesic vs. Natural

  • 1. plot data
  • 2. listen for a click
  • 3. draw an image

Clickable Plot

3

slide-44
SLIDE 44

Example: interactive plot

Client

U

Library

U

API

T

slide-45
SLIDE 45

Example: interactive plot

function h(x) { if (0 < fst x): pumpkin else: fish } p = ClickPlot(h) p.show() // click Client

U

Library

U

API

T

slide-46
SLIDE 46

Example: interactive plot

function h(x) { if (0 < fst x): pumpkin else: fish } p = ClickPlot(h) p.show() // click Client

U

class ClickPlot { constructor(

  • nClick){...}

mouseHandler(evt){ i = onClick(evt) // draw i } show(){...} } Library

U

API

T

slide-47
SLIDE 47

Example: interactive plot

class ClickPlot { constructor(

  • nClick){...}

mouseHandler(evt){ i = onClick(evt) // draw i } show(){...} } Library

U

type ClickPlot { constructor( ([N,N]) => Image) mouseHandler : (MouseEvt) => Void show : () => Void } API

T

function h(x) { if (0 < fst x): pumpkin else: fish } p = ClickPlot(h) p.show() // click Client

U

slide-48
SLIDE 48

Example: interactive plot

class ClickPlot { constructor(

  • nClick){...}

mouseHandler(evt){ i = onClick(evt) // draw i } show(){...} } Library

U

type ClickPlot { constructor( ([N,N]) => Image) mouseHandler : (MouseEvt) => Void show : () => Void } API

T

function h(x) { if (0 < fst x): pumpkin else: fish } p = ClickPlot(h) p.show() // click Client

U

slide-49
SLIDE 49

Example: interactive plot

class ClickPlot { constructor(

  • nClick){...}

mouseHandler(evt){ i = onClick(evt) // draw i } show(){...} } Library

U

type ClickPlot { constructor( ([N,N]) => Image) mouseHandler : (MouseEvt) => Void show : () => Void } API

T

function h(x) { if (0 < fst x): pumpkin else: fish } p = ClickPlot(h) p.show() // click Client

U

Promises a pair of numbers

slide-50
SLIDE 50

Example: interactive plot

class ClickPlot { constructor(

  • nClick){...}

mouseHandler(evt){ i = onClick(evt) // draw i } show(){...} } Library

U

type ClickPlot { constructor( ([N,N]) => Image) mouseHandler : (MouseEvt) => Void show : () => Void } API

T

function h(x) { if (0 < fst x): pumpkin else: fish } p = ClickPlot(h) p.show() // click Client

U

Promises a pair of numbers

slide-51
SLIDE 51

Example: interactive plot

class ClickPlot { constructor(

  • nClick){...}

mouseHandler(evt){ i = onClick(evt) // draw i } show(){...} } Library

U

type ClickPlot { constructor( ([N,N]) => Image) mouseHandler : (MouseEvt) => Void show : () => Void } API

T

function h(x) { if (0 < fst x): pumpkin else: fish } p = ClickPlot(h) p.show() // click Client

U

Promises a pair of numbers Expects a pair of numbers

slide-52
SLIDE 52

Example: interactive plot

class ClickPlot { constructor(

  • nClick){...}

mouseHandler(evt){ i = onClick(evt) // draw i } show(){...} } Library

U

type ClickPlot { constructor( ([N,N]) => Image) mouseHandler : (MouseEvt) => Void show : () => Void } API

T

function h(x) { if (0 < fst x): pumpkin else: fish } p = ClickPlot(h) p.show() // click Client

U

slide-53
SLIDE 53

Example: interactive plot

class ClickPlot { constructor(

  • nClick){...}

mouseHandler(evt){ i = onClick(evt) // draw i } show(){...} } Library

U

type ClickPlot { constructor( ([N,N]) => Image) mouseHandler : (MouseEvt) => Void show : () => Void } API

T

function h(x) { if (0 < fst x): pumpkin else: fish } p = ClickPlot(h) p.show() // click Client

U

slide-54
SLIDE 54

Example: interactive plot

class ClickPlot { constructor(

  • nClick){...}

mouseHandler(evt){ i = onClick(evt) // draw i } show(){...} } Library

U

type ClickPlot { constructor( ([N,N]) => Image) mouseHandler : (MouseEvt) => Void show : () => Void } API

T

function h(x) { if (0 < fst x): pumpkin else: fish } p = ClickPlot(h) p.show() // click Client

U

Sends MouseEvt value

slide-55
SLIDE 55

Example: interactive plot

class ClickPlot { constructor(

  • nClick){...}

mouseHandler(evt){ i = onClick(evt) // draw i } show(){...} } Library

U

type ClickPlot { constructor( ([N,N]) => Image) mouseHandler : (MouseEvt) => Void show : () => Void } API

T

function h(x) { if (0 < fst x): pumpkin else: fish } p = ClickPlot(h) p.show() // click Client

U

Sends MouseEvt value

[N,N] != MouseEvt

slide-56
SLIDE 56

Example: interactive plot

class ClickPlot { constructor(

  • nClick){...}

mouseHandler(evt){ i = onClick(evt) // draw i } show(){...} } Library

U

type ClickPlot { constructor( ([N,N]) => Image) mouseHandler : (MouseEvt) => Void show : () => Void } API

T

function h(x) { if (0 < fst x): pumpkin else: fish } p = ClickPlot(h) p.show() // click Client

U

Sends MouseEvt value

[N,N] != MouseEvt

  • Q. Does h receive

bad input?

slide-57
SLIDE 57

Example: interactive plot

class ClickPlot { constructor(

  • nClick){...}

mouseHandler(evt){ i = onClick(evt) // draw i } show(){...} } Library

U

type ClickPlot { constructor( ([N,N]) => Image) mouseHandler : (MouseEvt) => Void show : () => Void } API

T

function h(x) { if (0 < fst x): pumpkin else: fish } p = ClickPlot(h) p.show() // click Client

U

  • Q. Does h receive

bad input?

slide-58
SLIDE 58

Example: interactive plot

class ClickPlot { constructor(

  • nClick){...}

mouseHandler(evt){ i = onClick(evt) // draw i } show(){...} } Library

U

type ClickPlot { constructor( ([N,N]) => Image) mouseHandler : (MouseEvt) => Void show : () => Void } API

T

function h(x) { if (0 < fst x): pumpkin else: fish } p = ClickPlot(h) p.show() // click Client

U

  • Q. Does h receive

bad input?

  • A. Yes, Trans/Amns
  • A. No, Natural
slide-59
SLIDE 59

U T U

slide-60
SLIDE 60

U T U

h

slide-61
SLIDE 61

U T U

h

slide-62
SLIDE 62

U T U

h(evt)

  • Q. Do types guard the callback channel?
slide-63
SLIDE 63

U T U

h(evt)

  • Q. Do types guard the callback channel?

Transient/Amnesic: no, because the channel is between two untyped components Natural: yes, because the channel was created via typed code

slide-64
SLIDE 64

U T U

h(evt)

  • Q. Do types guard the callback channel?

Type Soundness ⇒ yes Complete Monitoring ⇒ yes

slide-65
SLIDE 65

⌊T⌋ sound Uni sound T sound Complete monitoring Erasure Natural Transient Amnesic

slide-66
SLIDE 66

Natural Transient Amnesic type soundness

T ⌊T⌋ T

complete monitoring Natural Transient Amnesic type soundness

T ⌊T⌋ T

complete monitoring

slide-67
SLIDE 67

Natural Transient Amnesic type soundness

T ⌊T⌋ T

complete monitoring Natural Transient Amnesic type soundness

T ⌊T⌋ T

complete monitoring BLAME

slide-68
SLIDE 68

Natural, Blame

class ClickPlot { constructor(

  • nClick){...}

mouseHandler(evt){ i = onClick(evt) // draw i } show(){...} } Library

U

type ClickPlot { constructor( ([N,N]) => Image) mouseHandler : (MouseEvt) => Void show : () => Void } API

T

function h(x) { if (0 < fst x): pumpkin else: fish } p = ClickPlot(h) p.show() // click Client

U

slide-69
SLIDE 69

Natural, Blame

class ClickPlot { constructor(

  • nClick){...}

mouseHandler(evt){ i = onClick(evt) // draw i } show(){...} } Library

U

type ClickPlot { constructor( ([N,N]) => Image) mouseHandler : (MouseEvt) => Void show : () => Void } API

T

function h(x) { if (0 < fst x): pumpkin else: fish } p = ClickPlot(h) p.show() // click Client

U

Error: MouseEvt is not a pair

slide-70
SLIDE 70

Natural, Blame

class ClickPlot { constructor(

  • nClick){...}

mouseHandler(evt){ i = onClick(evt) // draw i } show(){...} } Library

U

type ClickPlot { constructor( ([N,N]) => Image) mouseHandler : (MouseEvt) => Void show : () => Void } API

T

function h(x) { if (0 < fst x): pumpkin else: fish } p = ClickPlot(h) p.show() // click Client

U

Error: expected [N,N] got MouseEvt blaming Library assuming the API types are correct

slide-71
SLIDE 71

Transient/Amnesic, Blame

class ClickPlot { constructor(

  • nClick){...}

mouseHandler(evt){ i = onClick(evt) // draw i } show(){...} } Library

U

type ClickPlot { constructor( ([N,N]) => Image) mouseHandler : (MouseEvt) => Void show : () => Void } API

T

function h(x) { if (0 < fst x): pumpkin else: fish } p = ClickPlot(h) p.show() // click Client

U

slide-72
SLIDE 72

Transient/Amnesic, Blame

class ClickPlot { constructor(

  • nClick){...}

mouseHandler(evt){ i = onClick(evt) // draw i } show(){...} } Library

U

type ClickPlot { constructor( ([N,N]) => Image) mouseHandler : (MouseEvt) => Void show : () => Void } API

T

function h(x) { if (0 < fst x): pumpkin else: fish } p = ClickPlot(h) p.show() // click Client

U

Error: <obj> is not a pair blaming: Client / API API / Library

slide-73
SLIDE 73

U T U U T

v

Blame Properties

  • 1. blame only

responsible edges

  • 2. blame all

responsible edges

  • 3. blame exactly the responsible edges
slide-74
SLIDE 74

U T U U T

v

Blame Properties

  • 1. blame only

responsible edges

  • 2. blame all

responsible edges

  • 3. blame exactly the responsible edges

Blame Soundness Blame Completeness

  • B. Soundness + B. Completeness
slide-75
SLIDE 75

Natural Transient Amnesic type soundness

T ⌊T⌋ T

complete monitoring blame soundness blame completeness Natural Transient Amnesic type soundness

T ⌊T⌋ T

complete monitoring blame soundness blame completeness

slide-76
SLIDE 76

Natural Transient Amnesic type soundness

T ⌊T⌋ T

complete monitoring blame soundness blame completeness Natural Transient Amnesic type soundness

T ⌊T⌋ T

complete monitoring blame soundness blame completeness

slide-77
SLIDE 77

Every Typed Language is Mixed-Typed

Many typed languages trust untyped code

slide-78
SLIDE 78

Every Typed Language is Mixed-Typed

Many typed languages trust untyped code Gradual typing makes these boundaries visible ...

U T

slide-79
SLIDE 79

Every Typed Language is Mixed-Typed

Many typed languages trust untyped code Gradual typing makes these boundaries visible ...

U T

... and challenges our notions of types and what types mean

slide-80
SLIDE 80

Complete monitoring strengthens type soundness for programs that compose typed and untyped and enables precise statements about the quality of blame

slide-81
SLIDE 81

github.com/nuprl/gfd-oopsla-2019

Code + Proofs:

slide-82
SLIDE 82

Natural Transient Amnesic type soundness

T ⌊T⌋ T

complete monitoring* blame soundness* blame completeness* Natural Transient Amnesic type soundness

T ⌊T⌋ T

complete monitoring* blame soundness* blame completeness*

slide-83
SLIDE 83

⌊T⌋ sound Uni sound T sound Complete monitoring Erasure Natural Transient Amnesic
