Compiler Construction Chapter 2: CFGs & Parsing

Slides modified from Louden Book and Dr. Scherger

Parsing

February, 2010 Chapter 3: Context Free Grammars and Parsers 2

 The parser takes the compact representation (tokens)

from the scanner and checks the structure

 It determines if it is syntactically valid

 That is, is the structure correct  Also called syntax analysis

 Syntax given by a set of grammar rules of a context-

free-grammar

 Context-free grammars are much more powerful than REs,

they are recursive.

 Since not linear as the scanner, we need a parse stack or a tree

to represent

 Parse tree or syntax tree

What Are We Going To Do?

February, 2010 Chapter 3: Context Free Grammars and Parsers 3

 Actually parsing is only discussed in the abstract in this

chapter

 Chapters 4 and 5 are the (real) parsing chapters.  This chapter title could renamed “Context-free Grammars and

Syntax”

 Here we introduce a number of basic compiling ideas and

illustrate their usage with the development of a simple example compiler.

Syntax Definition

February, 2010 Chapter 3: Context Free Grammars and Parsers 4

 A context-free grammar is a common notation for

specifying the syntax of a language:

 Backus-Naur Form or BNF are synonyms for a context-free

• grammar. The grammar naturally describes the hierarchical

structure of many programming languages. For example, an if- else statement in C has the form:

if ( expression ) statement else statement

 In other words, an if-else statement in C is the

concatenation of: the keyword if; an opening parenthesis; an expression; a closing parenthesis; a statement; the keyword else; and another statement.

Syntax Definition

February, 2010 Chapter 3: Context Free Grammars and Parsers 5

 If one uses the variable expr to denote an expression and the

variable stmt to denote a statement then one can specify the syntax of an if-else statement with the following production in the context-free grammar for C: stmt --> if ( expr ) stmt else stmt

 The arrow is read as "can have the form". This particular

production says that "a statement can have the form of the keyword if followed by an opening parenthesis followed by an expression followed by a closing parenthesis followed by a statement followed by the keyword else followed by another statement."

Context Free Grammars

February, 2010 Chapter 3: Context Free Grammars and Parsers 6

 A context-free grammar has four components:

 A finite terminal vocabulary Vt



The tokens from the scanner, also called the terminal symbols;

 A finite nonterminal vocabulary Vn



Intermediate symbols, also called nonterminals ;

 A start symbol S Vn.



All Derivations start here

 A finite set of productions (rewriting rules) of the form:

A  X1...Xm where A Vn, Xi  Vn  Vt,



The vocabulary V is Vn  Vt

Context-Free Grammars

February, 2010 Chapter 3: Context Free Grammars and Parsers 7

 Starting with S, nonterminals are rewritten using

productions (P) until only terminals remain

 The set of strings derivable from S comprises the

context-free-language of grammar G

CFG Productions

February, 2010 Chapter 3: Context Free Grammars and Parsers 8

 The left hand side (LHS) is a single nonterminal symbol

(from Vn)

 The right hand side (RHS) is a string of zero or more

symbols (from V)

 A symbol can be the RHS for > 1 rule  Notation

My Symbol Book Symbol What a,b,c a,b,c symbols in Vt A,B,C a,b,c symbols in Vn a,b,g strings in V* l e special symbol for an empty production

CFG Productions

February, 2010 Chapter 3: Context Free Grammars and Parsers 9

 A  X1 ... Xm  A  a  A  a|b|....|z

 Abbreviation for

A  a A  b .... A  z

CFG Example

February, 2010 Chapter 3: Context Free Grammars and Parsers 10

 S  aSb // rule1  S  l// rule2  An example Parse  Start with S, then use rule1, rule1, rule1, then rule 2.

The result is:

 S  aSb  aaSbb  aaaSbbb  aaabbb  The context free language is anbn

CFG Example

February, 2010 Chapter 3: Context Free Grammars and Parsers 11

 S  AB  S  ASB  A  a  B  b  What is the language of this CFG?

CFG Example

February, 2010 Chapter 3: Context Free Grammars and Parsers 12

 S  A | S+A | S-A  A  B | A*B | A/B  B  C | (S)  C  D | CD   D  0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9  What is the language of this CFG?

CFG Productions

February, 2010 Chapter 3: Context Free Grammars and Parsers 13

 S  A | B  A  a  B  B b  C  c

 C useless, can't be reached via derivation  B useless, derives no terminal string  Grammars with useless nonterminals are

“nonreduced”

 A “reduced” grammar has no useless NT  If we reduce a grammar do we change its

language?

CFG Productions

February, 2010 Chapter 3: Context Free Grammars and Parsers 14

 S  A  A  a

 This grammar has the same language as the

previous grammar

 It is reduced

Ambiguous CFG

February, 2010 Chapter 3: Context Free Grammars and Parsers 15

 <expr>  <expr> - <expr>  <expr>  Id

 This grammar is ambiguous since it allows more

than one derivation tree, and therefore a non-unique structure

 Ambiguous grammars should be avoided

 It is impossible to guarantee detection of ambiguity in

any given CFG.

Ambiguous CFG

February, 2010 Chapter 3: Context Free Grammars and Parsers 16

<expr> <expr> <expr> - <expr> <expr> - <expr> <expr> - <expr> Id Id <expr> - <expr> id id Id Id Possible derivation trees for Id – Id – Id

Grammars Can’t

February, 2010 Chapter 3: Context Free Grammars and Parsers 17

 Check if a variable is declared before use  Check operands are of the correct type  Check correct number of parameters  Do semantic checking  Underlined words

 lettersn backspacen underscoresn  But can do (letters backspaces underscore)n

Context Free Grammars: Simple Integer Arithmetic Expressions

February, 2010 Chapter 3: Context Free Grammars and Parsers 18

In what way does such a CFG differ from a regular expression?

digit = 0|1|…|9 number = digit digit*

Recursion!

exp  exp op exp | ( exp ) | number

• p  + | - | *

2 non-terminals 6 terminals 6 productions (3 on each line)

Recursive rules “Base” rule

Context Free Grammars

February, 2010 Chapter 3: Context Free Grammars and Parsers 19

 Multiple productions with the same nonterminal on the

left usually have their right sides grouped together separated by vertical bars.

 For example, the three productions:

 list --> list + digit  list --> list - digit  list --> digit

 may be grouped together as:

 list --> list + digit | list - digit | digit

Context Free Grammars

February, 2010 Chapter 3: Context Free Grammars and Parsers 20

 Productions with the start symbol on the left side are

always listed first in the set of productions.

 Here is an example: list --> list + digit | list - digit | digit digit --> 0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9

 From this set of productions it is easy to see that the

grammar has two nonterminals: list and digit (with list being the start symbol) and 12 terminals:

+ - 0 1 2 3 4 5 6 7 8 9

CFGs Are Designed To Represent Recursive (i.e. Nested) Structures

February, 2010 Chapter 3: Context Free Grammars and Parsers 21

 …But consequences are huge:

 The structure of a matched string is no longer given by just a

sequence of symbols (lexeme), but by a tree (parse tree)

 Recognizers are no longer finite, but may have arbitrary data

size, and must have some notion of stack.

Recognition Process Is Much More Complex:

February, 2010 Chapter 3: Context Free Grammars and Parsers 22

 Algorithms can use stacks in many different ways.  Nondeterminism is much harder to eliminate.  Even the number of states can vary with the algorithm

(only 2 states necessary if stack is used for “state”structure.

Major Consequence: Many Parsing Algorithms, Not Just One

February, 2010 Chapter 3: Context Free Grammars and Parsers 23

 Top down

 Recursive descent (hand choice)  “Predictive” table-driven, “LL” (outdated)

 Bottom up

 “LR” and its cousin “LALR” (machine-generated choice

[Yacc/Bison])

 Operator-precedence (outdated)

Productions

February, 2010 Chapter 3: Context Free Grammars and Parsers 24

 A production is for a nonterminal if that nonterminal appears

• n the left-side of the production.

 A grammar derives a string of tokens by starting with the start

symbol and repeatedly replacing nonterminals with right-sides

• f productions for those nonterminals.

 A parse tree is a convenient method of showing that a given

token string can be derived from the start symbol of a grammar:

 the root of the tree must be the starting symbol, the leaves must be

the tokens in the token string, and the children of each parent node must be the right-side of some production for that parent node.

 For example, draw the parse tree for the token string

9 - 5 + 2

Productions

February, 2010 Chapter 3: Context Free Grammars and Parsers 25

 The language defined by a grammar is the set of all token

strings that can be derived from its start symbol.

 The language defined by the example grammar contains

all lists of digits separated by plus and minus signs.

Productions

February, 2010 Chapter 3: Context Free Grammars and Parsers 26

 Epsilon, e , on the right-side of a production denotes the

empty string.

 Consider the grammar for Pascal begin-end blocks

 a block does not need to contain any statements

block --> begin opt_stmts end

• pt_stmts --> stmt_list | e

stmt_list --> stmt_list ; stmt | stmt

Ambiguity

February, 2010 Chapter 3: Context Free Grammars and Parsers 27

 A grammar is ambiguous if two or more different parse

trees can derive the same token string.

 Grammars for compilers should be unambiguous since

different parse trees will give a token string different meanings.

Ambiguity (cont.)

February, 2010 Chapter 3: Context Free Grammars and Parsers 28

 Here is another example of a grammar for strings of digits separated by

plus and minus signs:

string --> string + string | string - string | 0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9

 However this grammar is ambiguous. Why?

 Draw two different parse trees for the token string 9 - 5 + 2 that correspond to

two different ways of parenthesizing the expression:

( 9 - 5 ) + 2 or 9 - ( 5 + 2 )

 The first parenthesization evaluates to 6 while the second parenthesization

evaluates to 2.

Sources Of Ambiguity:

February, 2010 Chapter 3: Context Free Grammars and Parsers 29

 Associativity and precedence of operators  Sequencing  Extent of a substructure (dangling else)  “Obscure” recursion (unusual)

 exp  exp exp

Dealing With Ambiguity

February, 2010 Chapter 3: Context Free Grammars and Parsers 30

 Disambiguating rules  Change the grammar (but not the language!)  Can all ambiguity be removed?

 Backtracking can handle it, but the expense is great

Associativity of Operators

February, 2010 Chapter 3: Context Free Grammars and Parsers 31

 By convention, when an operand like 5 in the expression 9 - 5

+ 2 has operators on both sides, it should be associated with the operator on the left:

 In most programming languages arithmetic operators like addition,

subtraction, multiplication, and division are left-associative .

 In the C language the assignment operator, =, is right-

associative:

 The string a = b = c should be treated as though it were

parenthesized a = ( b = c ).

 A grammar for a right-associative operator like = looks like:

right --> letter = right | letter letter --> a | b | ... | z

Precedence of Operators

February, 2010 Chapter 3: Context Free Grammars and Parsers 32

 Should the expression 9 + 5 * 2 be interpreted like (9 +

5) * 2 or 9 + (5 * 2)?

 The convention is to give multiplication and division

higher precedence than addition and subtraction.

 When evaluating an arithmetic expression we perform

• perations of higher precedence before operations of

lower precedence:

 Only when we have operations of equal precedence (like

addition and subtraction) do we apply the rules of associativity.

Syntax of Expressions

February, 2010 Chapter 3: Context Free Grammars and Parsers 33

 An arithmetic expression is a string of terms separated by left-

associative addition and subtraction operators.

 A term is a string of factors separated by left-associative

multiplication and division operators.

 A factor is a single operand (like an id or num token) or an

expression wrapped inside of parentheses.

 Therefore, a grammar of arithmetic expressions looks like:

expr --> expr + term | expr - term | term term --> term * factor | term / factor | factor factor --> id | num | ( expr )

Syntax Directed Translation

February, 2010 Chapter 3: Context Free Grammars and Parsers 34

 As mentioned in earlier, modern compilers use syntax-

directed translation to interleave the actions of the compiler phases.

 The syntax analyzer directs the whole process:

 calling the lexical analyzer whenever it wants another token

and performing the actions of the semantic analyzer and the intermediate code generator as it parses the source code.

Syntax Directed Translation (cont.)

February, 2010 Chapter 3: Context Free Grammars and Parsers 35

 The actions of the semantic analyzer and the

intermediate code generator usually require the passage of information up and/or down the parse tree.

 We think of this information as attributes attached to

the nodes of the parse tree and the parser moving this information between parent nodes and children nodes as it performs the productions of the grammar.

Postfix Notation

February, 2010 Chapter 3: Context Free Grammars and Parsers 36

 As an example of syntax-directed translation a simple

infix-to-postfix translator is developed here.

 Postfix notation (also called Reverse Polish Notation or

RPN) places each binary arithmetic operator after its two source operands instead of between them:

 The infix expression (9 - 5) + 2 becomes 9 5 - 2 + in postfix

notation

 The infix expression 9 - (5 + 2) becomes 9 5 2 + - in postfix

(postfix expressions do not need parentheses.)

Principle of Syntax-directed Semantics

February, 2010 Chapter 3: Context Free Grammars and Parsers 37

 The parse tree will be used as the basic model;

 semantic content will be attached to the tree;  thus the tree should reflect the structure of the eventual

semantics (semantics-based syntax would be a better term)

Syntax Directed Defintions

February, 2010 Chapter 3: Context Free Grammars and Parsers 38

 A syntax-directed definition uses a context-free grammar to

specify the syntactic structure of the input, associates a set of attributes with each grammar symbol, and associates a set of semantic rules with each production of the grammar.

 As an example, suppose the grammar contains the

production: X --> Y Z so node X in a parse tree has nodes Y and Z as children and further suppose that nodes X , Y , and Z have associated attributes X.a , Y.a , and Z.a , respectively.

Syntax Directed Definitions

February, 2010 Chapter 3: Context Free Grammars and Parsers 39  As an example, suppose the grammar

contains the production:



X --> Y Z so node X in a parse tree has nodes Y and Z as children and further suppose that nodes X , Y , and Z have associated attributes X.a , Y.a , and Z.a , respectively.



An annotated parse tree looks like this 

 If the semantic rule



{X.a := Y.a + Z.a } is associated with the X --> Y Z production then the parser should add the a attributes of nodes Y and Z together and set the a attribute

• f node X to their sum.

X (X.a) Z (Z.a) Y (Y.a)

Synthesized Attributes

February, 2010 Chapter 3: Context Free Grammars and Parsers 40

 An attribute is synthesized if its value at a parent node can

be determined from attributes at its children.

 Attribute a in the previous example is a synthesized

attribute.

 Synthesized attributes can be evaluated by a single

bottom-up traversal of the parse tree.

Example: Infix to Postfix Translation

February, 2010 Chapter 3: Context Free Grammars and Parsers 41



The following table shows the syntax-directed definition of an infix-to-postfix translator.



Attribute t associated with each node is a character string and the || operator denotes concatenation.



Since the grammar symbol expr appears more than once in some productions, subscripts are used to differentiate between the tree nodes in the production and in the associated semantic rule.



The figure shows how the input infix expression 9 - 5 + 2 is translated to the postfix expression 9 5 - 2 + at the root of the parse tree.

Production Semantic Rule expr -> expr1 + term expr1.t := expr1.t || term.t || ‘+’ expr -> expr1 – term expr1.t := expr1.t || term.t || ‘-’ expr -> term expr1.t := term.t term -> 0 term.t := ‘0’ term -> 0 term.t := ‘1’ … … term -> 9 term.t := ‘9’

Example: Infix to Postfix Translation

February, 2010 Chapter 3: Context Free Grammars and Parsers 42



The following table shows the syntax-directed definition of an infix-to-postfix translator.



Attribute t associated with each node is a character string and the || operator denotes concatenation.



Since the grammar symbol expr appears more than once in some productions, subscripts are used to differentiate between the tree nodes in the production and in the associated semantic rule.



The figure shows how the input infix expression 9 - 5 + 2 is translated to the postfix expression 9 5 - 2 + at the root of the parse tree.

expr.t = 95-2+ expr.t = 95- expr.t = 9 term.t = 5 term.t = 9

• 5

+ 2 9 term.t = 2

Example: Robot Navigation

February, 2010 Chapter 3: Context Free Grammars and Parsers 43  Suppose a robot can be instructed to

move one step east, north, west, or south from its current position.

 A sequence of such instructions is

generated by the following grammar.

 seq -> seq instr | begin  instr -> east | north |

west | south

 Changes in the position of the robot

• n input



begin west south east east east north north begin (0,0) west (-1,0) south (-1,-1) east east east (2,-1) north (2,1) north

Example: Robot Navigation

February, 2010 Chapter 3: Context Free Grammars and Parsers 44

seq.x = -1 seq.y = -1 seq.x = -1 seq.y = 0 instr.dx = 0 instr.dy = -1 seq.x = 0 seq.y = 0 instr.dx = -1 instr.dy = 0 begin west south seq.x = seq1.x + instr.dx seq.y = seq1.y + instr.dy

Example: Robot Navigation

February, 2010 Chapter 3: Context Free Grammars and Parsers 45

Production Semantic Rules seq -> begin seq.x := 0 seq.y := 0 seq -> seq1 instr seq.x := seq1.x + instr.dx seq.y := seq1.y + instr.dy instr -> east instr.dx = 1 instr.dy = 0 instr -> north instr.dx = 0 instr.dy = 1 instr ->west instr.dx = -1 instr.dy = 0 instr -> south instr.dx = 0 instr.dy = -1

Depth First Traversals

February, 2010 Chapter 3: Context Free Grammars and Parsers 46



A depth-first traversal of the parse tree is a convenient way of evaluating attributes.



The traversal starts at the root, visits every child, returns to a parent after visiting each

• f its children, and eventually returns to

the root



Synthesized attributes can be evaluated whenever the traversal goes from a node to its parent.



Other attributes (like inherited attributes) can be evaluated whenever the traversal goes from a parent to its children. . procedure visit(n: node) begin

for each child m of n, from left to right do visit( m ); evaluate semantic rules at node n



end

Translation Schemes

February, 2010 Chapter 3: Context Free Grammars and Parsers 47

 A translation scheme is another way of specifying a syntax-

directed translation:

 semantic actions (enclosed in braces) are embedded within the

right-sides of the productions of a context-free grammar.

 For example,

rest --> + term { print ('+') } rest1

 This indicates that a plus sign should be printed between the

depth-first traversal of the term node and the depth-first traversal of the rest1 node of the parse tree.

Translation Schemes

February, 2010 Chapter 3: Context Free Grammars and Parsers 48

 This figure shows the translation scheme for an infix-to-

postfix translator: expr -> expr + term { print(‘+’) } expr -> expr - term { print(‘-’) } expr -> term term -> 0 { print(‘0’) } term -> 1 { print(‘1’) } … term -> 9 { print(‘9’) }

Translation Schemes

February, 2010 Chapter 3: Context Free Grammars and Parsers 49

 The postfix expression is printed out as the parse tree is

traversed as shown in this figure

 Note that it is not necessary to actually construct the

parse tree.

expr.t = 95-2+ expr.t = 95- term.t = 2 expr.t = 9 term.t = 5 term.t = 9

• 5

+ 2 9

{print(‘9’)} {print(‘5’)} {print(‘-’)} {print(‘+’)} {print(‘2’)}

Parsing

February, 2010 Chapter 3: Context Free Grammars and Parsers 50

 For a given input string of tokens we can ask, “Is this input

syntactically valid?”

 That is, can it be generated by our grammar  An algorithm that answers this question is a recognizer  If we also get the structure (derivation tree) we have a parser

 For any language that can be described by a context-free

grammar a parser that parses a string of n tokens in O (n3) time can be constructed.

 However, most every programming language is so simple that a

parser requires just O (n ) time with a single left-to-right scan

• ver the input.

Parsing

February, 2010 Chapter 3: Context Free Grammars and Parsers 51

 Most parsers are either top-down or bottom-up.

 A top-down parser “discovers” a parse tree by starting at the root

(start symbol) and expanding (predict) downward depth-first.

 Predict the derivation before the matching is done

 A bottom-up parser builds a parse tree by starting at the leaves

(terminals) and determining the rule to generate them, and continues working up toward the root.

 Top-down parsers are usually easier to code by hand but compiler-

generating software tools usually generate bottom-up parsers because they can handle a wider class of context-free grammars.

 This course covers both top-down and bottom-up parsers and

the coding projects may give you the experience of coding both kinds:

Parsing Example

Consider the following Grammar <program> begin <stmts> end $ <stmts> SimpleStmt ; <stmts> <stmts> begin <stmts> end ; <stmts> <stmts> l 

 Input:

begin SimpleStmt; SimpleStmt; end $

Top-down Parsing Example

Input: begin SimpleStmt; SimpleStmt; end $ <program>

<program> begin <stmts> end $ <stmts> SimpleStmt ; <stmts> <stmts> begin <stmts> end ; <stmts> <stmts> l

Top-down Parsing Example

Input: begin SimpleStmt; SimpleStmt; end $ <program> begin <stmts> end $

<program> begin <stmts> end $ <stmts> SimpleStmt ; <stmts> <stmts> begin <stmts> end ; <stmts> <stmts> l

Top-down Parsing Example

Input: begin SimpleStmt; SimpleStmt; end $ <program> begin <stmts> end $ SimpleStmt ; <stmts>

<program> begin <stmts> end $ <stmts> SimpleStmt ; <stmts> <stmts> begin <stmts> end ; <stmts> <stmts> l

Top-down Parsing Example

Input: begin SimpleStmt; SimpleStmt; end $ <program> begin <stmts> end $ SimpleStmt ; <stmts> SimpleStmts ; <stmts>

<program> begin <stmts> end $ <stmts> SimpleStmt ; <stmts> <stmts> begin <stmts> end ; <stmts> <stmts> l

Top-down Parsing Example

Input: begin SimpleStmt; SimpleStmt; end $ <program> begin <stmts> end $ SimpleStmt ; <stmts> SimpleStmts ; <stmts> l

<program> begin <stmts> end $ <stmts> SimpleStmt ; <stmts> <stmts> begin <stmts> end ; <stmts> <stmts> l

Bottom-up Parsing Example

 Scan the input looking for any substrings that appear

• n the RHS of a rule!

 We can do this left-to-right or right-to-left

 Let's use left-to-right  Replace that RHS with the LHS  Repeat until left with Start symbol or error

Bottom-up Parsing Example

Input: begin SimpleStmt; SimpleStmt; end $ <stmts> l 

<program> begin <stmts> end $ <stmts> SimpleStmt ; <stmts> <stmts> begin <stmts> end ; <stmts> <stmts> l

Bottom-up Parsing Example

Input: begin SimpleStmt; SimpleStmt; end $ <stmts> SimpleStmts ; <stmts>  l

<program> begin <stmts> end $ <stmts> SimpleStmt ; <stmts> <stmts> begin <stmts> end ; <stmts> <stmts> l

Bottom-up Parsing Example

Input: begin SimpleStmt; SimpleStmt; end $ <stmts> SimpleStmt ; <stmts> SimpleStmts ; <stmts> l 

<program> begin <stmts> end $ <stmts> SimpleStmt ; <stmts> <stmts> begin <stmts> end ; <stmts> <stmts> l

Bottom-up Parsing Example

Input: begin SimpleStmt; SimpleStmt; end $ <program> begin <stmts> end $ SimpleStmt ; <stmts> SimpleStmts ; <stmts> l 

<program> begin <stmts> end $ <stmts> SimpleStmt ; <stmts> <stmts> begin <stmts> end ; <stmts> <stmts> l

Top Down Parsing

February, 2010 Chapter 3: Context Free Grammars and Parsers 63

 To introduce top-down parsing we consider the following

context-free grammar: expr --> term rest

rest --> + term rest | - term rest | e term --> 0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9  and show the construction of the parse tree for the input

string: 9 - 5 + 2.

Top Down Parsing

February, 2010 Chapter 3: Context Free Grammars and Parsers 64

 Initialization: The root of the parse tree must be the

starting symbol of the grammar, expr .

expr

expr --> term rest rest --> + term rest | - term rest | e term --> 0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9

Top Down Parsing

February, 2010 Chapter 3: Context Free Grammars and Parsers 65

 Step 1: The only production for expr is expr --> term

rest so the root node must have a term node and a rest node as children.

expr term rest

expr --> term rest rest --> + term rest | - term rest | e term --> 0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9

Top Down Parsing

February, 2010 Chapter 3: Context Free Grammars and Parsers 66

 Step 2: The first token in the input is 9 and the only

production in the grammar containing a 9 is:

 term --> 9 so 9 must be a leaf with the term node as a parent.

expr term rest 9

expr --> term rest rest --> + term rest | - term rest | e term --> 0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9

Top Down Parsing

February, 2010 Chapter 3: Context Free Grammars and Parsers 67

 Step 3: The next token in the input is the minus-sign and

the only production in the grammar containing a minus- sign is:

 rest --> - term rest . The rest node must have a minus-sign leaf, a term

node and a rest node as children. expr term rest term rest

• 9

expr --> term rest rest --> + term rest | - term rest | e term --> 0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9

Top Down Parsing

February, 2010 Chapter 3: Context Free Grammars and Parsers 68

 Step 4: The next token in the input is 5 and the only

production in the grammar containing a 5 is:

 term --> 5 so 5 must be a leaf with a term node as a parent.

expr term rest term rest 5

• 9

expr --> term rest rest --> + term rest | - term rest | e term --> 0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9

Top Down Parsing

February, 2010 Chapter 3: Context Free Grammars and Parsers 69

 Step 5: The next token in the input is the plus-sign and the only

production in the grammar containing a plus-sign is:

 rest --> + term rest .  A rest node must have a plus-sign leaf, a term node and a rest node as

children. expr term rest term rest term rest + 5

• 9

expr --> term rest rest --> + term rest | - term rest | e term --> 0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9

Top Down Parsing

February, 2010 Chapter 3: Context Free Grammars and Parsers 70

 Step 6: The next token in the input is 2 and the only

production in the grammar containing a 2 is: term --> 2 so 2 must be a leaf with a term node as a parent.

expr term rest term rest term rest 2 + 5

• 9

expr --> term rest rest --> + term rest | - term rest | e term --> 0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9

Top Down Parsing

February, 2010 Chapter 3: Context Free Grammars and Parsers 71

 Step 7: The whole input has been absorbed but the parse

tree still has a rest node with no children.

 The rest --> e production must now be used to give the rest

node the empty string as a child.

expr term rest term rest term rest e 2 + 5

• 9

expr --> term rest rest --> + term rest | - term rest | e term --> 0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9

Parsing

 Only one possible derivation tree if grammar

unambiguous

 Top-down use leftmost derivations

 Leftmost nonterminal expanded first

 Bottom-up use right most derivations

 Rightmost nonterminal expanded first

 Two most common types of parsers are LL and

LR parsers

 1st letter for left-to-right token parsing  2nd for derivation (leftmost, rightmost)

 LL(n) – n is # of lookahead symbols

LL(1) Parsing

 How do we predict which NT to expand?

 We can use the lookahead

 However, if more than 1 rule expands given

that lookahead the grammar cannot be parsed by our LL(1) parser

 This means the “prediction” for top-down is

easy, just use the lookahead

Building an LL(1) Parser

 We need to determine some sets  First(n) – Terminals that can start valid strings

that are generated by n: n V*

 Follow(A) – Set of terminals that can follow A in

some legal derivation. A is nonterminal

 Predict(prod) – Any token that can be the 1st

symbol produced by the RHS of prod

 Predict(AX1 ...Xm) = (First(X1 ...Xm)-l)UFollow(A) if l  First(X1 ...Xm) First(X1 ...Xm) otherwise

 These sets used to create a parse table

Parse Table

 A row for each nonterminal  A column for each terminal  Entries contain rule (production) #s

 For a lookahead T, the production to predict

given that terminal as the lookahead and that non terminal to be matched.

Example Micro

On handout

 Predict(AX1 ...Xm) =

if l  First(X1 ...Xm) (First(X1 ...Xm)-l) U Follow(A) else First(X1 ...Xm)

The parse table is filled in using: T(A,a) = AX1 ...Xm if a  Predict(AX1 ...Xm) T(A,a) = Error otherwise

Making LL(1) Grammars

 This is not always an easy task  Must have a unique prediction for each

(nonterminal, lookahead)

 Conflicts are usually either

 Left-recursion  Common prefixes

 Often we can remove these conflicts  Not all conflicts can be removed

 Dangling else (Pascal) is one of them

LL(1) Grammars

February, 2010 Chapter 3: Context Free Grammars and Parsers 78

 A grammar is LL(1) iff whenever A a|b are two

distinct productions the following conditions hold

 The is no terminal a, such that both α and β derive strings

beginning with a.

 At most one of aandb can derive the empty string  If β derives the empty string, then α does not derive any string

beginning with a terminal in FOLLOW(A). Likewise, if α derives the empty string, then β does not derive any string beginning with a terminal in FOLLOW(A).

 LL(1) means we scan the input from left to right (first L)

and a leftmost derivation is produced (leftmost non terminal expanded) by using 1 lookahead symbol to decide the rule to expand.

Making LL(1) Grammars Left-recursion

 Consider A  Ab  Assume some lookahead symbol t causes the

prediction of the above rule

 This prediction causes A to be put on the parse

stack

 We have the same lookahead and the same

symbol on the stack, so this rule will be predicted again, and again.......

Eliminating Left Recursion

February, 2010 Chapter 3: Context Free Grammars and Parsers 80

 Replace

expr → expr + term | term

 by

expr → term expr' expr' → + term expr' | ε

Making LL(1) Grammars Factoring

 Consider

<stmt>  if <expr> then <stmts> end if; <stmt>  if <expr> then <stmts> else <stmts> end if;

 The productions share a common prefix  The First sets of each RHS are not disjoint  We can factor out the common prefix

<stmt>  if <expr> then <stmts> <ifsfx> <ifsfx>  end if; <ifsfx>  else <stmts> end if;

Properties of LL(1) Parsers

 A correct leftmost parse is guaranteed  All LL(1) grammars are unambiguous  O(n) in time and space

Top Down Parsing

February, 2010 Chapter 3: Context Free Grammars and Parsers 83

 In the previous example, the grammar made it easy for

the parser to pick the correct production in each step of the parse.

 This is not true in general: consider the following grammar:

statement --> if expression then statement else statement statement --> if expression then statement

 When the input token is an if token should a top-down

parser use the first or second production?

 The parser would have to guess which one to use,

continue parsing, and later on, if the guess is wrong, go back to the if token and try the other production.

Top Down Parsing

February, 2010 Chapter 3: Context Free Grammars and Parsers 84

 Usually one can modify the grammar so a predictive top-

down parser can be used:

 The parser always picks the correct production in each step of

the parse so it never has to back-track.

 T

• allow the use of a predictive parser, one replaces the two

productions above with:

statement --> if expression then statement optional_else

• ptional_else --> else statement | e

Predictive Parsing

February, 2010 Chapter 3: Context Free Grammars and Parsers 85

 A recursive-descent parser is a top-down parser that executes a

set of recursive procedures to process the input:

 there is a procedure for each nonterminal in the grammar.

 A predictive parser is a top-down parser where the current

input token unambiguously determines the production to be applied at each step.

 Here, we show the code of a predictive parser for the

following grammar:

expr --> term rest rest --> + term rest | - term rest | e term --> 0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9

Predictive Parsing

February, 2010 Chapter 3: Context Free Grammars and Parsers 86  We assume a global variable, lookahead

, holding the current input token and a procedure match( ExpectedToken ) that loads the next token into lookahead if the current token is what is expected, otherwise match reports an error and halts.

 Procedure match( t:token )  Begin



If lookahead = t then

 Lookahead := nexttoken 

Else

 error

 end

Predictive Parsing

February, 2010 Chapter 3: Context Free Grammars and Parsers 87



This is a recursive-descent parser so a procedure is written for each nonterminal of the grammar.



Since there is only one production for expr , procedure expr is very simple:



Since there are three productions for rest , procedure rest uses lookahead to select the correct production.



If lookahead is neither + nor - then rest selects the -production and simply returns without any actions:

expr() { term(); rest(); return; }

rest() { if (lookahead == '+') { match('+'); term(); rest(); return; } else if (lookahead == '-') { match('-'); term(); rest(); return; } else { return; } }

expr --> term rest rest --> + term rest | - term rest | e term --> 0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9

Predictive Parsing

February, 2010 Chapter 3: Context Free Grammars and Parsers 88  The procedure for term , called term,

checks to make sure that lookahead is a digit:

term() { if (isdigit(lookahead)) { match(lookahead); return; } else { ReportErrorAndHalt(); } }

expr --> term rest rest --> + term rest | - term rest | e term --> 0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9

Predictive Parsing

February, 2010 Chapter 3: Context Free Grammars and Parsers 89

 After loading lookahead with the first input token this parser is

started by calling expr (since expr is the starting symbol.)

 If there are no syntax errors in the input, the parser conducts

a depth-traversal of the parse tree and returns to the caller through expr, otherwise it reports an error and halts.

 If there is an e-production for a nonterminal then the

procedure for that nonterminal selects it whenever none of the other productions are suitable.

 If there is no e-production for a nonterminal and none of its

productions are suitable then the procedure should report a syntax error.

Left Recursion

February, 2010 Chapter 3: Context Free Grammars and Parsers 90

 A production like:

expr --> expr + term

 Where the first symbol on the right-side is the same as

the symbol on the left-side is said to be left-recursive .

 If one were to code this production in a recursive-

descent parser, the parser would go in an infinite loop calling the expr procedure repeatedly.

Left Recursion

February, 2010 Chapter 3: Context Free Grammars and Parsers 91

 Fortunately a left-recursive grammar can be easily modified to

eliminate the left-recursion.

 For example,

expr --> expr + term | expr - term | term

 defines an expr to be either a single term or a sequence of terms

separated by plus and minus signs.

 Another way of defining an expr (without left-recursion) is:

expr --> term rest rest --> + term rest | - term rest | e

A Translator for Simple Expressions

February, 2010 Chapter 3: Context Free Grammars and Parsers 92

 A translation-scheme for converting simple infix

expressions to postfix is: expr --> term rest rest --> + term { print('+') ; } rest rest --> - term { print('-') ; } rest rest --> e term --> 0 { print('0') ; } term --> 1 { print('1') ; } ... ... term --> 9 { print('9') ; }

A Translator for Simple Expressions

February, 2010 Chapter 3: Context Free Grammars and Parsers 93

expr() { term(); rest(); return; } rest() { if (lookahead == '+') {match('+'); term(); print('+'); rest(); return; } else if (lookahead == '-') {match('-'); term(); print('-'); rest(); return; } else { return; } } term() { if (isdigit(lookahead)) { print(lookahead); match(lookahead); return ; } else { ReportErrorAndHalt(); } }

Parse Trees

 Phrase – sequence of tokens descended from

a nonterminal

 Simple phrase – phrase that contains no

smaller phrase at the leaves

 Handle – the leftmost simple phrase

Parse Trees

E Prefix ( E ) F V Tail + E V Tail l

LR Parsing Shift Reduce

 Use a parse stack

 Initially empty, it contains symbols already

parsed (T & NT)

 Tokens are shifted onto stack until the top of

the stack contains the handle

 The handle is then reduced by replacing it on

the stack with the non terminal that is its parent in the derivation tree

 Success when no input left and goal symbol on

the stack

Shift Reduce Parser Useful Data Structures

 Action table – determines whether to shift,

reduce, terminate with success, or an error has

• ccurred

 Parse stack – contains parse states

 They encode the shifted symbol and the

handles that are being matched

 GoTo Table – defines successor states after a

token or LHS is matched and shifted.

Shift Reduce Parser

S – top parse stack state T – Current input token push(S0) // start state Loop forever case Action(S,T) error => ReportSyntaxError() accept => CleanUpAndFinish() shift => Push(GoTo(S,T)) Scanner(T) // yylex() reduce => Assume X -> Y1...Ym Pop(m) // S' is new stack top Push(GoTo(S',X))

Shift Reduce Parser Example

Consider the following grammar G0: <program>  begin <stmts> end $ <stmts>  SimpleStmt ; <stmts> <stmts>  begin <stmts> end ; <stmts> <stmts>  l  using the Action and GoTo tables for G0 what would the parse look like for the following input:? Begin SimpleStmt; SimpleStmt; end $

Shift Reduce Parser Example

Parse Stack Remaining Input Action 0 Begin SimpleStmt; SimpleStmt; end $ shift 0,1 SimpleStmt; SimpleStmt; end $ shift

LR(1) Parsers

 Very powerful and most languages can be

recognized by them

 But, the LR(1) machine contains so many

states the GoTo and Action tables are prohibitively large

LR(1) Parser Alternatives

 LR(0) parsers

 Very compact tables  With no lookahead not very powerful

 SLR(1) – Simple LR(1) parsers

 Add lookahead to LR(0) tables  Almost as powerful as LR(1) but much

smaller

 LALR(1) – look-ahead LR(1) parsers

 Start with LR(1) states and merge states

differing only in the look-ahead

 Smaller and slightly weaker than LR(1)

Properties of LR(1) Parsers

 A correct rightmost parse is guaranteed  Since LR-style parsers accept only viable

prefixes, syntax errors are detected as soon as the parser attempts to shift a token that isn't part of a viable prefix

 Prompt error reporting

 They are linear in operation  All LR(1) grammars are unambiguous

 Will yacc generate a parser for an

ambiguous grammar?

LL(1) vs LALR(1)

 LL(1) and LALR(1) are dominant types

 Although variants are used (recursive

descent and SLR(1))

 LL(1) is simpler  LALR(1) is more general

 Most languages can be represented by an

LL(1) or LALR(1) grammar, but it is easier to write the LALR(1) grammar

 LL(1) can be easier to specify actions  Error repair is easier to do in LL(1)  LL(1) tables will be ~½ size of LALR(1)

Summary

 Fundamental concern of a top-down parser is

deciding which production to use to expand a non terminal

 Fundamental concern of a bottom-up parser is

to decide when a LHS replaces a RHS

 LL(1) and LALR(1) are dominant types

 LL(1) beats LALR(1) in all features except

generality, but very close comparison

Author’s Notes

February, 2010 Chapter 3: Context Free Grammars and Parsers 106

Structural Issues First!

February, 2010 Chapter 3: Context Free Grammars and Parsers 107

Express matching of a string [“(34-3)*42”] by a derivation:

(1) exp  exp op exp [exp  exp op exp] (2)  exp op number [exp  number] (3)  exp * number [op  * ] (4)  ( exp ) * number [exp  ( exp )] (5)  ( exp op exp ) * number [exp  exp op exp] (6)  (exp op number) * number [exp  number ] (7)  (exp - number) * number [op  - ] (8)  (number - number)*number [exp  number ]

exp  exp op exp exp  ( exp ) exp  number

• p  + | - | *

Abstract The Structure Of A Derivation To A Parse Tree:

February, 2010 Chapter 3: Context Free Grammars and Parsers 108

exp

• p

* 1 exp 4 3 exp number 2 exp exp

• p

exp number

• number

5 8 7 6 ( )

Derivations Can Vary, Even When The Parse Tree Doesn’t:

February, 2010 Chapter 3: Context Free Grammars and Parsers 109

A leftmost derivation (previous was a rightmost):

(1) exp  exp op exp [exp  exp op exp] (2)  (exp) op exp [exp  ( exp )] (3)  (exp op exp) op exp [exp  exp op exp] (4)  (number op exp) op exp [exp  number] (5)  (number - exp) op exp [op  -] (6)  (number - number) op exp [exp  number] (7)  (number - number) * exp [op  *] (8)  (number - number) * number [exp  number]

February, 2010 Chapter 3: Context Free Grammars and Parsers 110

A leftmost derivation corresponds to a (top-down) preorder traversal

• f the parse tree.

A rightmost derivation corresponds to a (bottom-up) postorder traversal, but in reverse. T

• p-down parsers construct leftmost derivations.

(LL = Left-to-right traversal of input, constructing a Leftmost derivation) Bottom-up parsers construct rightmost derivations in reverse order. (LR = Left-to-right traversal of input, constructing a Rightmost derivation)

But What If The Parse Tree Does Vary? [ exp op exp op exp ]

February, 2010 Chapter 3: Context Free Grammars and Parsers 111

The grammar is ambiguous, but why should we care? Semantics!

exp

• p

* exp number exp exp

• p

exp number

• number

exp

• p

* exp number exp exp

• p

exp number

• number

Correct one

Example: Integer Arithmetic

February, 2010 Chapter 3: Context Free Grammars and Parsers 112

exp  exp addop term | term addop  + | - term  term mulop factor | factor mulop  * factor  ( exp ) | number

Precedence “cascade”

Which operator(s) will appear closer to the root? Does closer to the root mean higher

• r lower precedence?

Repetition and Recursion

February, 2010 Chapter 3: Context Free Grammars and Parsers 113

 Left recursion: A  A x | y

 yxx:

A A x y x A  Right recursion: A  x A | y

– xxy:

A A x y x A

Repetition & Recursion, cont.

February, 2010 Chapter 3: Context Free Grammars and Parsers 114

 Sometimes we care which way recursion goes: operator

associativity

 Sometimes we don’t: statement and expression sequences  Parsing always has to pick a way!  The tree may remove this information (see next slide)

Abstract Syntax Trees

February, 2010 Chapter 3: Context Free Grammars and Parsers 115

 Express the essential structure of the parse tree only  Leave out parens, cascades, and “don’t-care” repetitive

associativity

 Corresponds to actual internal tree structure produced

by parser

 Use sibling lists for “don’t care” repetition: s1 --- s2 --- s3

Previous Example [ (34-3)*42 ]

February, 2010 Chapter 3: Context Free Grammars and Parsers 116

* 42 34 3

Data Structure

February, 2010 Chapter 3: Context Free Grammars and Parsers 117

typedef enum {Plus,Minus,Times} OpKind; typedef enum {OpK,ConstK} ExpKind; typedef struct streenode { ExpKind kind; OpKind op; struct streenode *lchild,*rchild; int val; } STreeNode; typedef STreeNode *SyntaxTree;

Or (Using A union):

February, 2010 Chapter 3: Context Free Grammars and Parsers 118

typedef enum {Plus,Minus,Times} OpKind; typedef enum {OpK,ConstK} ExpKind; typedef struct streenode { ExpKind kind; struct streenode *lchild,*rchild; union { OpKind op; int val; } attribute; } STreeNode; typedef STreeNode *SyntaxTree;

Or (C++ but not ISO 99 C):

February, 2010 Chapter 3: Context Free Grammars and Parsers 119

typedef enum {Plus,Minus,Times} OpKind; typedef enum {OpK,ConstK} ExpKind; typedef struct streenode { ExpKind kind; struct streenode *lchild,*rchild; union { OpKind op; int val; }; // anonymous union } STreeNode; typedef STreeNode *SyntaxTree;

Sequence Examples

February, 2010 Chapter 3: Context Free Grammars and Parsers 120

 stmt-seq  stmt ; stmt-seq | stmt

• ne or more stmts separated by a ;

 stmt-seq  stmt ; stmt-seq | e

zero or more stmts terminated by a ;

 stmt-seq  stmt-seq ; stmt | stmt

• ne or more stmts separated by a ;

 stmt-seq  stmt-seq ; stmt | e

zero or more stmts preceded by a ;

Sequence Exercises:

February, 2010 Chapter 3: Context Free Grammars and Parsers 121

 Write grammar rules for one or more statements

terminated by a semicolon.

 Write grammar rules for zero or more statements

separated by a semicolon.

“Obscure” Ambiguity Example

February, 2010 Chapter 3: Context Free Grammars and Parsers 122

Incorrect attempt to add unary minus: exp  exp addop term | term | - exp addop  + | - term  term mulop factor | factor mulop  * factor  ( exp ) | number

Ambiguity Example (cont.)

February, 2010 Chapter 3: Context Free Grammars and Parsers 123

 Better: (only one at beg. of an exp)

exp  exp addop term | term | - term

 Or maybe: (many at beg. of term)

term  - term | term1 term1  term1 mulop factor | factor

 Or maybe: (many anywhere)

factor  ( exp ) | number | - factor

Dangling Else Ambiguity

February, 2010 Chapter 3: Context Free Grammars and Parsers 124

statement  if-stmt | other if-stmt  if ( exp ) statement | if ( exp )statement else statement exp  0 | 1

The following string has two parse trees: if(0) if(1) other else other

Parse Trees for Dangling Else:

February, 2010 Chapter 3: Context Free Grammars and Parsers 125

statement if-stmt if ( ) else exp statement statement

• ther

if-stmt if ( ) exp statement 1

• ther

statement if-stmt if ( ) exp statement if-stmt if ( ) else exp statement statement 1

• ther
• ther

Correct one

Disambiguating Rule:

February, 2010 Chapter 3: Context Free Grammars and Parsers 126

An else part should always be associated with the nearest if- statement that does not yet have an associated else-part. (Most-closely nested rule: easy to state, but hard to put into the grammar itself.) Note that a “bracketing keyword” can remove the ambiguity: if-stmt  if ( exp ) stmt end | if ( exp )stmt else stmt end

Bracketing keyword

TINY Grammar:

February, 2010 Chapter 3: Context Free Grammars and Parsers 127

program  stmt-sequence stmt-sequence  stmt-sequence ; statement | statement statement  if-stmt | repeat-stmt | assign-stmt | read-stmt | write-stmt if-stmt  if exp then stmt-sequence end | if exp then stmt-sequence else stmt-sequence end repeat-stmt  repeat stmt-sequence until exp assign-stmt  identifier := exp read-stmt  read identifier write-stmt  write exp exp  simple-exp comparison-op simple-exp | simple-exp comparison-op  < | = simple-exp  simple-exp addop term | term addop  + | - term  term mulop factor | factor mulop  * | / factor  ( exp ) | number | identifier

TINY Syntax Tree (Part 1)

February, 2010 Chapter 3: Context Free Grammars and Parsers 128

typedef enum {StmtK,ExpK} NodeKind; typedef enum {IfK,RepeatK,AssignK,ReadK,WriteK} StmtKind; typedef enum {OpK,ConstK,IdK} ExpKind; /* ExpType is used for type checking */ typedef enum {Void,Integer,Boolean} ExpType; #define MAXCHILDREN 3

TINY Syntax Tree (Part 2)

February, 2010 Chapter 3: Context Free Grammars and Parsers 129

typedef struct treeNode { struct treeNode * child[MAXCHILDREN]; struct treeNode * sibling; int lineno; NodeKind nodekind; union { StmtKind stmt; ExpKind exp;} kind; union { TokenType op; int val; char * name; } attr; ExpType type; /* for type checking */ } TreeNode;

Syntax Tree of sample.tny

February, 2010 Chapter 3: Context Free Grammars and Parsers 130 read (x) if assign (fact)

• p

(<) const (0) id (x) const (1) repeat write assign (fact) assign (x)

• p

(=)

• p

(*)

• p

(-) id (fact) id (x) id (x) const (1) const (0) id (x) id (fact)

A Grammar for 1988 ANSI C

February, 2010 Chapter 3: Context Free Grammars and Parsers 131

http://www.lysator.liu.se/c/ANSI-C-grammar-y.html

Ambiguities in C

February, 2010 Chapter 3: Context Free Grammars and Parsers 132

• Dangling else
• One more:

cast_expression  unary_expression | ( type_name ) cast_expression unary_expression  postfix_expression | ... postfix_expression  primary_expression | ... primary_expression  IDENTIFIER | CONSTANT | STRING_LITERAL| ( expression ) type_name  … | TYPE_NAME Example:

typedef double x; printf("%d\n", (int)(x)-2); int x = 1; printf("%d\n", (int)(x)-2);

Removing The Cast Amiguity Of C

February, 2010 Chapter 3: Context Free Grammars and Parsers 133

 TYPE_IDs must be distinguished from other IDs in the

scanner.

 Parser must build the symbol table (at least partially) to

indicate whether an ID is a typedef or not.

 Scanner must consult the symbol table; if an ID is found

as a typedef, return TYPE_ID, if not return ID.

Extra Notation:

February, 2010 Chapter 3: Context Free Grammars and Parsers 134

 So far: Backus-Naur Form (BNF)

 Metasymbols are |  e

 Extended BNF (EBNF):

 New metasymbols […] and {…}  e largely eliminated by these

 Parens? Maybe yes, maybe no:

 exp  exp (+ | -) term | term  exp  exp + term | exp - term | term

EBNF Metasymbols:

February, 2010 Chapter 3: Context Free Grammars and Parsers 135

 Brackets […] mean “optional” (like ? in regular

expressions):

 exp  term ‘|’ exp | term becomes:

exp  term [ ‘|’ exp ]

 if-stmt  if ( exp ) stmt

| if ( exp )stmt else stmt becomes: if-stmt  if ( exp ) stmt [ else stmt ]

 Braces {…} mean “repetition” (like * in regexps - see

next slide)

Braces in EBNF

February, 2010 Chapter 3: Context Free Grammars and Parsers 136

 Replace only left-recursive repetition:

 exp  exp + term | term becomes:

exp  term { + term }

 Left associativity still implied  Watch out for choices:

 exp  exp + term | exp - term | term

is not the same as exp  term { + term } | term { - term }

Simple Expressions in EBNF

February, 2010 Chapter 3: Context Free Grammars and Parsers 137

exp  term { addop term } addop  + | - term  factor { mulop factor } mulop  * factor  ( exp ) | number

Final Notational Option: Syntax Diagrams (from EBNF):

February, 2010 Chapter 3: Context Free Grammars and Parsers 138

number ( ) exp > > > > > factor

term exp < > addop <
