Code Modification Forum Ashling Hotel, Dublin Wednesday, 16 January 2019 Agenda (1 of 2) 1. Review of minutes from last meeting 2. Review of Action Items from last meeting 3. GNI Scheduled Maintenance Update Transporter review of

slide-1
SLIDE 1

Code Modification Forum

Ashling Hotel, Dublin Wednesday, 16 January 2019

slide-2
SLIDE 2

Agenda (1 of 2)

1. Review of minutes from last meeting 2. Review of Action Items from last meeting 3. GNI Scheduled Maintenance Update – Transporter review of operational procedures when system repair result in issue of Restricted Capacity Day Notices

  • 4. Intra-day Nomination Patterns and Profiles / Cod Mod Proposal A086-Incentives for Intra-day Balancing
  • 5. Biomethane update including update of 1) Cush Project, 2) Code Modification Proposal A091- Modification of
  • xygen content levels for Renewable Natural Gas (RNG) injected from RNG Entry Points and, 3) Code

Modification Proposal A093-RNG Outline Code Modification

  • 6. Code Modification A095 – Adjustment of Daily Imbalance Charges / Code Modification Proposal A094- Changes

to Shipper Portfolio Tolerances –Update

2

slide-3
SLIDE 3

Agenda (2 of 3)

  • 7. Code Modification Proposal A097- Amendment of Final Allocation Date for LDM Offtake(s), DM Offtake(s), NDM

Supply Point(s) and Sub-Sea Offtake from D+5 to M+5

  • 8. Brexit and ROI Gas Market
  • 9. Data Sharing Agreement
  • 10. Shrinkage Gas Update
  • 11. Gas and Electricity Interaction
  • 12. AOB

Meeting Schedule for 2019

3

slide-4
SLIDE 4

1. Review of minutes from last meeting

4

slide-5
SLIDE 5

2. Review of Action Items from last meeting

5

slide-6
SLIDE 6

ID Action Responsibility Status Priority C538 Transporter to continue consultation process surrounding intra-day nomination patterns and profiles Transporter Open High C567 Transporter to carry out development work on its Website to make it more user friendly for Shipper Transporter Open Medium C568 Transporter to carry out a review of its operational procedures in the event of system repair resulting in the issue of Restricted Capacity Day Notices to minimise Shipper supply restriction consequences Transporter Open High C569 Transporter to carry out analysis of extent of Eirgrid Dispatches during Trading Platform dead band and formulate scheme to process imbalance charge exemptions Transporter Open High C571 Transporter to issue letters to Shippers indicating each respective credit position, issue Report to CRU, and settle each credit position through the Disbursement Account Transporter Open High

Code Modification Forum – Open Actions

6

slide-7
SLIDE 7

3. GNI Scheduled Maintenance Update

Code Modification Forum

7

slide-8
SLIDE 8

Network Maintenance Update

8

Location Nature of Works Planned Timings (Subject to change) Duration (days) Entry/Exit Points Affected Impact on flows at entry/exit points affected

NOTHING TO REPORT

  • 1. Upstream Operator Maintenance

GNI have been advised of the following scheduled Maintenance Upstream of Entry Points:

slide-9
SLIDE 9

2018/ 2019 Maintenance Days

Maintenance Programme Gas Year 2018/2019

Date Duration Entry Points Commentary 7th March 2019 1 Bellanaboy Station testing, valve check and validations at Cappagh South. 9th May 2019 1 Inch Odourant injection system planned maintenance 4th Jul 2019 1 Moffat Station testing, valve checks and validations at Beattock and Brighouse Bay compressor station 12th Sep 2019 1 Bellanaboy ESD testing at the Corrib Terminal

9

slide-10
SLIDE 10

IT Maintenance Update

10

Nature of Works Planned Timings (Subject to change) Duration (days) Systems Affected Nothing to report

Please note the above works/timings/duration are subject to change

slide-11
SLIDE 11
  • 4. Intra-day Nomination Patterns and Profiles /Code

Mod Proposal A086 –Incentives for intra-day Balancing

Code Modification Forum

11

slide-12
SLIDE 12

Outline of proposed GNI Modification A086

  • Modification Raised by GNI to address concerns that the aggregate system imbalance intra-day is creating
  • perational difficulties.
  • At times, there are large deviations between the prevailing exit nominations on the system and the prevailing

entry nominations. GNI wish to introduce an incentive to encourage more alignment of entry and exit

  • PROPOSAL: At check points during the gas day (11:00, 17:00, 23:00) a shippers portfolio Nomination Imbalance

position will be recorded.

  • A tolerance will be applied at each point
  • Worked Example:

A shipper has 24 units of Aggregate Exit Nomination at 11:00. ‒ Deemed flow at Exit = (24 units * 6hrs/24hrs) = 6 units ‒ Total Entry Nomination = 4 units ‒ Apply a [10%] tolerance: Adjusted Nomination Imbalance Position

  • Nomination Imbalance Position = (6 * 90 %) – 4 = 1.4 units

‒ The Adjusted Nomination Imbalance Position at the 3 time checks will be added ‒ The total for the day will be multiplied by [SAP] * [x%] ‒ The amounts for each day in a month will be invoiced at month end.

12

slide-13
SLIDE 13

Impact if Code Mod was applied in November 2017 –December 2018

  • There was a marked improvement in Shipper Nominations following discussions of the proposed modification at

recent code mod forums

  • However, during Mid February to June late day nominations (attributable to 3 Shippers) has resulted in almost

hourly batches late in the gas day, causing operational difficulties once again for both GNI and National Grid

  • Since July 2018 there has been continued improvement in intraday behaviour

13

slide-14
SLIDE 14

Impact if Code Mod was applied in November 2017 – December 2018

14

  • 50,000

100,000 150,000 200,000 250,000 300,000 350,000 400,000 450,000 500,000

  • 100,000,000

200,000,000 300,000,000 400,000,000 500,000,000 600,000,000

Euro kWh

Intraday Imbalance Nov 2017 - December 2018

Sum of MONTHLY TOTAL (kWh) Sum of TOTAL MONTHLY PRICE

slide-15
SLIDE 15

5.Biomethane Code Modifications/ Biomethane Project

  • Code Modification Proposal A091-Modification of
  • xygen content limits for Renewable Natural Gas

(RNG) – Legal Drafting Approved

  • Code Modification Proposal A093 –RNG Outline Code

Modification –Legal Drafting Approved

15

Code Modification Forum

slide-16
SLIDE 16

Code Modification Forum

CUSH PROJECT

Commissioning of the Cush Biomethane Network Entry Facility will be completed

  • nce GNI receives confirmation of acceptance of Safety Case from CRU

16

slide-17
SLIDE 17

6.Code Modification Proposal A095- Adjustment of Daily Imbalance Charges/Code Modification Proposal A094- Changes to Shipper Portfolio Tolerances UPDATE

Code Modification Forum

17

slide-18
SLIDE 18

Code Modification Forum

Code Modification Proposal A097 – Amendment of Final Allocation Date for LDM Offtake(s), DM Offtake(s), NDM Supply Point(s) and Sub-Sea Offtake from D+5 to M+5

18

slide-19
SLIDE 19

Code Modification Proposal A097

  • AMENDMENT OF FINAL EXIT ALLOCATION DATE
  • MODIFICATION PROPOSER : GAS NETWORKS IRELAND
  • PURPOSE : TO AMEND THE FINAL ALLOCATION DATE IN RESPECT OF LDM OFFTAKE(S), DM

OFFTAKES, NDM SUPPLY POINT(S) AND SUB-SEA OFFTAKES FROM D+5 TO M+5 (i.e. 5 CALENDAR DAYS AFTER MONTH END)

19

slide-20
SLIDE 20

Code Modification Proposal A097

  • Present Position
  • Sect.2.9.2 of Part D of Code provides that “ The Transporter shall make available to

Shippers the Final Allocation in respect of a Shipper’s LDM Offtake(s), DM Offtake(s), NDM Supply Point(s), and/or the Sub-Sea Offtake by 16:00 hours on D+5”

  • Meter cleansing takes place at the start of a calendar month for a preceding month which is

after D+5

  • Transporter cannot correct billing issues uncovered after D+5 other than as a cumulative

month end adjustment which is not date specific and hinders Shippers in detailing their customer invoices

20 |

slide-21
SLIDE 21

Code Modification Proposal A097

  • Effect of Proposal Implementation
  • GNI will be able correct metering issues as they arise, adjust the metered quantity for the

day, reallocate and issue more accurate monthly allocation statements/invoices to Shippers

  • Shippers will be able to issue accurate statement/invoices to customers and will not have to
  • btain subsequent account adjustments.

21

slide-22
SLIDE 22

Code Modification Proposal A097

  • Three Industry queries received and two have been responded to by GNI.
  • Third query will by discussed by GNI with Industry querist before end January
  • Note of queries and responses will be furnished by GNI to CRU before next CMF Meeting

22

slide-23
SLIDE 23

Code Modifications - Live

Number Title of Proposal Proposer Status A085 Profiling of Gas Flows at Entry Points IOOA Live/Parked A086 Intra-day Nomination Incentive Proposal GNI Not yet issued A087 New Framework for Suppliers in PPM Market GNI Live/Legal Drafting A090 Proposed new Invoice Dispute Resolution Procedure BGES Live/ Parked A091 Modification of oxygen content limits for Renewable Natural Gas (RNG) injected from RNG Entry Points GNI Live A092 GNI Trading Platform participation GNI Live/Legal Drafting A093 RNG Outline Code Modification GNI Live/ Legal Drafting A094 Changes to Shipper Portfolio Tolerances GNI Live/Consultation A095 Adjustment of Daily Imbalance Charges GNI Live/ Consultation A096 Data Sharing Procedures GNI Not yet issued A097 Amendment of Final Allocation Date from D+5 to M+5 GNI Live

23

slide-24
SLIDE 24

24

Code Modification Forum

8. Brexit and ROI Gas Market

slide-25
SLIDE 25

Code Modification Forum

  • 9. Data Sharing Agreement Update

25

slide-26
SLIDE 26
  • GNI has consulted its external legal advisors.
  • GNI intends to mitigate the “Double Jeopardy” issue by proposing modifications to Part B –

General Principles which addresses priority between licences, Code etc.

  • GNI is working to develop drafting, within the Code, to implement the agreed provisions

from Draft DPA.

  • GNI will prepare potential drafting and circulate.

26

Data Sharing Agreement

slide-27
SLIDE 27

Code Modification Forum

  • 10. Shrinkage Gas Update

27

slide-28
SLIDE 28

Code Modification Forum

  • 11. Gas / Electricity Interaction

28

slide-29
SLIDE 29

Code Modification Forum

  • 12. AOB

29

slide-30
SLIDE 30

AOB Item No. 1- Trading Platform: Overview of activity on EBI platform, December 2018

30

  • Trading volumes were on average 220 kTherms per day in December with an average of 3.9 trades each day.
  • The maximum volume traded on a day was 605 kTherms on the 18th of December with 7 trades on this day.
  • The maximum number of trades on a day was 10 trades on the 17th of December which coincided with an

unplanned reduction in production from the Corrib field.

  • The minimum volume traded on a day was zero therms on the 27th of December.
  • The average trade size in December was 57 kTherms.
  • GNI conducted 5 Balancing Sells (404 kTherm) and 1 Balancing Buy (100kTherms)
  • GNI also purchased Stock Gas for the IC2 Cluden to Brighouse Bay pipeline (1024 kTherms)
slide-31
SLIDE 31

Trading Platform: Overview of activity on EBI platform, December 2018

31

2 4 6 8 10 12 100 200 300 400 500 600 700

Number of Trades Volume Traded (kTherms)

Volume Traded and #Trades - December 2018

Volume Traded (Left Axis) # of Trades (Right Axis)

slide-32
SLIDE 32

56.0000 58.0000 60.0000 62.0000 64.0000 66.0000 68.0000 70.0000 72.0000 74.0000 01/12/2018 06/12/2018 11/12/2018 16/12/2018 21/12/2018 26/12/2018

Price (p/Therm)

UK NBP SAP Versus IBP SAP

IBP SAP UK SAP (p/Therm)

Trading Platform Activity – December 2018

32

  • IBP System Average Price (SAP) generally traded at, or at a premium to the NBP SAP during December.
  • The greatest premium of the IBP SAP over the NBP SAP was 6.0 p/therm on the 1st of December.
  • The greatest discount of the IBP SAP to the NBP SAP was 2.1 p/therm on the 30th of December.
slide-33
SLIDE 33

AOB – Item No.2- IBP 15 Trading Terms and Conditions Modification Rules

  • Modification Rules for IBP 15 Trading Terms and Conditions circulated to IBP Terms Mailing

List on 23 October

  • Submissions to be forwarded to GNI (Secretariat) by COB on 21 December 2018. One query

received.

  • IBP Mailing List Members have been notified that a Meeting of IBP Terms Mailing List to

consider Modification Rules has now been fixed for Wednesday 27 March and will start after the conclusion of the Code Modification Forum Meeting on that date.

33

slide-34
SLIDE 34

AOB Item No.3- Removal of Code Mod. Proposals from CMF

Code Modification Proposal A085 – Profiling of Gas Flows at Entry Points . Proposed by IOOA in 2017 Code Modification Proposal A090 – Proposal for new Invoice Dispute Resolution Procedure Proposed by Bord Gais Energy Limited on 14 February 2018

34

slide-35
SLIDE 35

AOB Item No.4 - Gas Quality – Wobbe Index Increase

  • GNI previously provided an update on Gas Quality to

the CMF on the 27th Nov 2017

  • Focus then was on IGEM continuing it’s review of

GS(M)R and combustion parameters, in particular increasing the Wobbe Index (WI) upper limit from 51.41 MJ/m³ to 53.25 MJ/m³

  • Principle drivers in increasing the WI allows a wider

range of gas supplies to enter the network

  • Currently, IGEM review is still in progress
  • GNI has carried out an impact assessment of potential

changes in the UK natural gas interchangeability requirements on the Republic of Ireland

35

slide-36
SLIDE 36

Impact assessment conclusions / recommendations

Conclusions

  • In principle, the ROI gas industry is relatively modern, and the domestic appliance population is estimated to be

newer and more tolerant of a wider Wobbe range

  • Further information on domestic, commercial and industrial appliances would benefit a more thorough

assessment of impacts on gas consumers Recommendations

  • It is likely that the studies currently being carried out for the IGEM GQWG, in conjunction with ROI appliance

population data, ought to allow an assessment to be made for the ROI This topic should be an Industry concern (shippers) and not merely one for the transporter

  • Information on commercial and industrial appliances in use in ROI is not available and further assessment of

these sectors is recommended

  • Similar customer surveys completed in UK should be completed in ROI

36

slide-37
SLIDE 37

Code Modification Forum Meetings in 2019

37

CMF Dates 2019 Location

16th January 2019 (Wednesday) Dublin 27th March 2019 (Wednesday) Dublin 12th June 2019 (Wednesday) Cork 14th August 2019 (Wednesday) Dublin 16th October 2019 (Wednesday) Cork 11th December 2019 (Wednesday Dublin Next Meeting

slide-38
SLIDE 38

Thank you for your participation
