Closed-Form Expression for the Collision Probability in the IEEE EPON Registration Scheme Swapnil Bhatia (with Dr. Radim Barto s) CN Computer Networks Research Group G R Department of Computer Science University of New Hampshire This

slide-1
SLIDE 1

Closed-Form Expression for the Collision Probability in the IEEE EPON Registration Scheme

Swapnil Bhatia (with Dr. Radim Bartoˇ s) Computer Networks Research Group Department of Computer Science

CN

R

G

University of New Hampshire

This work was supported in part by the Cisco University Research Program.

slide-2
SLIDE 2

✬ ✫ ✩ ✪

Outline

◮ Introduction to Ethernet Passive Optical Networks (EPONs) ◮ IEEE EPON Registration Scheme ⋄ Description and model ◮ Efficiency of the Registration Scheme ⋄ Two devices ⋄ n devices ◮ Summary and discussion

2 of 29 IEEE GLOBECOM 2005

slide-3
SLIDE 3

✬ ✫ ✩ ✪

IEEE 802.3ah Ethernet Passive Optical Network

◮ Shared, passive, optical, access network ◮ Directed tree topology ◮ Central arbitrator: OLT (Optical Line Terminator) ◮ Subscriber Device: ONU (Optical Network Unit) ◮ Data rate of 1 Gbps (bidirectionally) ◮ 20 km reach = ⇒ RTT ≤ 200 µs

OLT ONU ONU ONU ONU ONU ONU ONU ONU ONU ONU ONU ONU ONU Backbone User data Passive Optical OLT: Optical Line Terminator ONU: Optical Network Unit 2 k m Fiber Optical Splitter

◮ Recently standardized by the IEEE 802.3ah group

3 of 29 IEEE GLOBECOM 2005

slide-4
SLIDE 4

✬ ✫ ✩ ✪

IEEE EPON Discovery and Registration Scheme

◮ Allow new ONUs to join the network ⋄ Synchronization ◮ Provide new ONUs with transmission parameters ⋄ Logical link identifiers, security (?) and QoS (?) ⋄ Enable RTT calculation by new ONUs ◮ RTT to new ONUs unavailable to the OLT, initially ⋄ = ⇒ a contention-based scheme

4 of 29 IEEE GLOBECOM 2005

slide-5
SLIDE 5

✬ ✫ ✩ ✪

IEEE EPON Discovery Protocol

◮ OLT reserves a sufficiently large window of time ◮ Broadcasts a “Discovery start” message to all ONUs ⋄ Contains length of window ◮ New ONUs follow Random Wait rule:

Discovery window Random delay REGISTER_REQ GATE GATE REGISTER_ACK REGISTER OLT ONU

⋄ Wait for a random period after receiving message ⋄ Transmit request to join network ⋄ Expect a Register reply before next Discovery cycle ⋄ Finish with an Ack, or retry

5 of 29 IEEE GLOBECOM 2005

slide-6
SLIDE 6

✬ ✫ ✩ ✪

IEEE EPON Discovery Protocol

◮ Discovery window required periodically ⋄ Every few minutes ◮ No subscriber traffic during Discovery window ⋄ Including voice, video etc. ◮ = ⇒ Important to choose window size wisely

Discovery window Random delay REGISTER_REQ GATE GATE REGISTER_ACK REGISTER OLT ONU

◮ Questions: ⋄ How do we choose the most efficient window size? ⋄ What do we mean by the efficiency of the Random Wait scheme?

6 of 29 IEEE GLOBECOM 2005

slide-7
SLIDE 7

✬ ✫ ✩ ✪

Efficiency of the IEEE EPON Discovery Protocol

◮ Observation: Larger the discovery window size (say w), ⋄ larger the number of successful registrations ⋄ but larger the bandwidth wasted ◮ ∴ High efficiency means: ⋄ Maximal number of successful registrations, with ⋄ Minimal window size ◮ ∴ Efficiency of Discovery Window ⋄ Could be defined as: ρ = Number of successful registrations Size of Discovery window ◮ “Number of successful registrations” is a random variable

7 of 29 IEEE GLOBECOM 2005

slide-8
SLIDE 8

✬ ✫ ✩ ✪

Efficiency of the IEEE EPON Discovery Protocol

◮ Suppose: ⋄ there are n ONUs ⋄ Ps(n) is the probability of a successful registration for an ONU, in the presence of n − 1 other ONUs ⋄ T is the duration of the discovery window reserved by the OLT ◮ Efficiency of Discovery Window ρ = n · Ps(n) T

8 of 29 IEEE GLOBECOM 2005

slide-9
SLIDE 9

✬ ✫ ✩ ✪

Probability of a Successful Registration: Ps(n)

◮ For ONU-i, let random variable: Xi

  • its random RTT,

Yi

  • the random wait, and

Zi

  • the time of arrival of the message at the OLT.

Random delay GATE OLT ONU REGISTER_REQ window Reserved

Zi Yi X′

i

X′

i

T = 2p + w

= ⇒ Zi = Xi + Yi where : Xi = 2X′

i

9 of 29 IEEE GLOBECOM 2005

slide-10
SLIDE 10

✬ ✫ ✩ ✪

Efficiency of the IEEE EPON Discovery Protocol

◮ Efficiency of Discovery Window ρ = n · Ps(n) 2p + w where: n is the total number of ONUs in the EPON, Ps(n) is the probability of a successful registration for an ONU, in the presence of n−1 other ONUs, p is the maximum propagation delay to any new ONU, and w is the size of the discovery window ◮ Rule: Choose a window size w that maximizes ρ, given n and p. ◮ Question: How do we find Ps(n)?

10 of 29 IEEE GLOBECOM 2005

slide-11
SLIDE 11

✬ ✫ ✩ ✪

Probability of a Successful Registration: Ps(n)

◮ Suppose OLT chooses window size to be w µs ⋄ = ⇒ Wait Yi is ∈ [0, w] ⋄ distributed uniformly (IEEE standard) ◮ Suppose ONUs are located at a maximum propagation delay p ⋄ = ⇒ RTT Xi ∈ [0, 2p] ⋄ distributed uniformly (reasonable) ◮ Then, density of Zi = Xi + Yi:

fZi(z)

1 M

Zi m M M + m

z m M m + M − z m M

m = min(2p, w), M = max(2p, w)

11 of 29 IEEE GLOBECOM 2005

slide-12
SLIDE 12

✬ ✫ ✩ ✪

Probability of a message collision: 1 − Ps(n)

◮ Consider 1 − Ps(2): the probability of a message collision for an ONU, in the presence of 1 other ONU ◮ Consider arrival times Z1 and Z2 ( = ⇒ independent) ◮ The joint density of Z1, Z2:

14 12 10 14 8 0.002 12 z1 6 10 0.004 8 4 6 0.006 z2 4 2 0.008 2 0.01 M k M M + m Z

1

− Z

2

= k Z

1

− Z

2

= − k Z1 f1(z1) f2(z1) f3(z1) f1(z2) f2(z2) f3(z2) Z2 m k M + m

◮ The collision event: |Z1 − Z2| ≤ k where k message length

12 of 29 IEEE GLOBECOM 2005

slide-13
SLIDE 13

✬ ✫ ✩ ✪

Probability of a message collision: 1 − Ps(2)

k k M m M m M + m m + k m + k m − k M + k M − k M + k m − k M − k M + m Z

1

− Z

2

= − k Z

1

− Z

2

= k M + m − k M + m − k R1 R3 R5 R6 R4 R7 R8 R9 R12 R2 R10 R11 R13 Z1 Z2 f1(z1) f2(z1) f3(z1) f1(z2) f2(z2) f3(z2) m M k k m M M + m m + k M + m − k M + m − k Z

1

− Z

2

= k Z

1

− Z

2

= − k m + k R1 R2 R3 R4 R5 R6 R7 R8 R9 Z1 f1(z1) f2(z1) f3(z1) f1(z2) f2(z2) f3(z2) Z2 M − k M − k M + m

m ≥ k m < k M − m ≥ k

13 of 29 IEEE GLOBECOM 2005

slide-14
SLIDE 14

✬ ✫ ✩ ✪

Probability of a message collision: 1 − Ps(2)

k k m m M M M + m M + m m − k M − k m + k M + m − k M + m − k Z1 Z2 R1 R2 R3 R4 R5 R7 R9 R10 R12 M + k m − k R11 R13 M + k

8 6

M − k m + k f1(z1) f2(z1) f3(z1) f1(z2) f2(z2) f3(z2)

Z

1

− Z

2

= − k Z

1

− Z

2

= k

m m k M M k M − k M − k m + k m + k M + m − k M + m − k M + m Z1 Z2

Z1 − Z2 = −k Z1 − Z2 = k

f3(z1) f2(z1) f1(z1) f1(z2) f2(z2) f3(z2) R2 R4 R6 R8 R9 R5 R7 R1 R3 M + m

m ≥ k m < k M − m < k

14 of 29 IEEE GLOBECOM 2005

slide-15
SLIDE 15

✬ ✫ ✩ ✪

Probability of a message collision: 1 − Ps(2)

m m M M M + m Z1 Z2 f3(z1) f2(z1) f1(z1) f1(z2) f2(z2) f3(z2) R2 M + m M + m − k M + m − k k k

Z1 − Z2 = −k Z1 − Z2 = k

R3 R1 k k

Z1 − Z2 = −k Z1 − Z2 = k

Z2 Z1 M M + m M M + m f3(z2) f2(z2) f1(z2) f1(z1) f2(z1) f3(z1) m m

M + m > k M + m ≤ k m < M < k

15 of 29 IEEE GLOBECOM 2005

slide-16
SLIDE 16

✬ ✫ ✩ ✪

Probability of a message collision: 1 − Ps(2)

M Z1 Z2 R2 M + m M − k k k

Z1 − Z2 = −k Z1 − Z2 = k

R3 R1 m m M M + m M + m − k fX(z1) fX(z2) M − k M + m − k

m = 0, M > k

16 of 29 IEEE GLOBECOM 2005

slide-17
SLIDE 17

✬ ✫ ✩ ✪

Probability of a message collision: 1 − Ps(2)

m = 0 M < k M + m ≤ k m < k m < k M > k k > 0, M > 0 M − m < k

true false true false true true true false false true true false false false true false

P7 P6 P6 P6 P4 P5 P3P2 P1

17 of 29 IEEE GLOBECOM 2005

slide-18
SLIDE 18

✬ ✫ ✩ ✪

Probability of a message collision: 1 − Ps(2)

400 300 200 p 100 0.2 100 200 0.4 300 0.6 w 400 0.8 1

k = 2.528 µs m = min(2p, w), M = max(2p, w)

18 of 29 IEEE GLOBECOM 2005

slide-19
SLIDE 19

✬ ✫ ✩ ✪

How about Ps(n)?

◮ A successful transmission by Z1 can be expressed as:

n

  • i=2
  • |Z1 − Zi| > k
  • ◮ ∴ Ps(n):

P n

  • i=2
  • |Z1 − Zi| > k
  • =

∞

  • −∞

P n

  • i=2
  • |Z1 − Zi| > k|Z1 = t
  • · P(Z1 = t) · dt

=

∞

  • −∞

[1 − FZ2(t + k) + FZ2(t − k)](n−1) · fZ2(t) · dt

19 of 29 IEEE GLOBECOM 2005

slide-20
SLIDE 20

✬ ✫ ✩ ✪

How about Ps(n)?

fZi(z)

1 M

Zi m M M + m t − k t M + m − k t + k M − k M + k m + k m − k

z m M m + M − z m M

P n

  • i=2
  • |Z1 − Zi| > k
  • =

∞

  • −∞

[1 − FZ2(t + k) + FZ2(t − k)](n−1) · fZ2(t) · dt ◮ Must consider relative magnitude of t in addition to m, M, k as before ⋄ Many cases, quite tedious

20 of 29 IEEE GLOBECOM 2005

slide-21
SLIDE 21

✬ ✫ ✩ ✪

How about Ps(n)?

◮ A simple approximation ⋄ An ONU’s transmission was successful in the presence of n − 1

  • ther ONUs (Ps(n))

⋄ = ⇒ it was successful in the presence of each of the n − 1 ONUs, taken one at a time (Ps(2)) Ps(n) ≈ Ps(2)n−1 ⋄ Done!

21 of 29 IEEE GLOBECOM 2005

slide-22
SLIDE 22

✬ ✫ ✩ ✪

Probability of a Successful Registration: Ps(n)

0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 50 100 150 200 250 300 350 400 Probability of successes in first attempt (99% confidence) Window size (micro sec)

  • No. nodes

2 8 16 30 50 65 90 100 Closed-form

p > 0

22 of 29 IEEE GLOBECOM 2005

slide-23
SLIDE 23

✬ ✫ ✩ ✪

Probability of a Successful Registration: Ps(n)

◮ For ONU-i, let random variable: Xi

  • its random RTT,

Yi

  • the random wait, and

Zi

  • the time of arrival of the message at the OLT.

Random delay GATE OLT ONUs window Reserved

T = 2p + w p p

= ⇒ Zi = Xi + Yi where : Xi = 2X′

i

23 of 29 IEEE GLOBECOM 2005

slide-24
SLIDE 24

✬ ✫ ✩ ✪

Probability of a Successful Registration: Ps(n)

0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 50 100 150 200 250 300 350 400 Probability of successes in first attempt (99% confidence) Window size (micro sec)

  • No. nodes

2 4 8 16 35 65 100 Closed-form

p = 0

24 of 29 IEEE GLOBECOM 2005

slide-25
SLIDE 25

✬ ✫ ✩ ✪

Probability of a Successful Registration: Ps(n)

200 150 0.2 0.4 0.6 0.8 100 1 100 n w 200 50 300 400 200 0.2 0.4 150 0.6 100 0.8 1 100 200 n w 50 300 400 0

p > 0 (Random RTT) p = 0 (Identical RTT)

25 of 29 IEEE GLOBECOM 2005

slide-26
SLIDE 26

✬ ✫ ✩ ✪

Efficiency of the IEEE Discovery Scheme

400 300 200 0.01 0.02 0.03 150 200 0.04 w 0.05 0.06 100 0.07 100 n 50 400 300 200 0.01 150 0.02 200 0.03 w 100 0.04 100 n 50

p > 0 (Random RTT) p = 0 (Identical RTT) ρ = n · Ps(n) 2p + w

26 of 29 IEEE GLOBECOM 2005

slide-27
SLIDE 27

✬ ✫ ✩ ✪

Choosing an efficient window size

p > 0 (Random RTT) p = 0 (Identical RTT)

50 100 150 200 250 300 350 200 400 600 800 1000 1200 1400 1600 Number of nodes Window size (micro seconds) uniform identical

# devices Most efficient (M = 0) window size (µs) 2 35.82 4 64.63 8 105.20 10 122.39 16 168.43 32 273.77 50 380.49 64 459.65

27 of 29 IEEE GLOBECOM 2005

slide-28
SLIDE 28

✬ ✫ ✩ ✪

Summary

◮ Characterized efficiency of the IEEE Registration scheme ◮ Exact closed-form expression for two ONUs ◮ Approximate closed-form expression for n > 2 ONUs ◮ Performance for variable message lengths ◮ Analysis of multi-step performance of registration scheme possible ◮ Work may be applicable to similar schemes in other technologies

28 of 29 IEEE GLOBECOM 2005

slide-29
SLIDE 29

✬ ✫ ✩ ✪

Discussion and Questions

29 of 29 IEEE GLOBECOM 2005
