slide-1
SLIDE 1

Cloud cover and Overlap 1 1

Cloud cover and overlap parameterizations

Adrian Tompkins, ICTP tompkins@ictp.it

slide-2
SLIDE 2

Cloud cover and Overlap 2 2

Clouds in General Circulation models=GCMs

GCMs describe the equations of motion on a discrete grid E.g. ECMWF global forecast model with T1280 spectral resolution (~9km equivalent) with 137 vertical levels Many processes occur

  • n scales smaller than

this

T,q,U,V,W …

slide-3
SLIDE 3

Cloud cover and Overlap 3 3

Clouds in GCMs - What are the problems ? Clouds are subgrid-scale (both horizontally and vertically)

GCM Grid cell 10-400km

slide-4
SLIDE 4

Cloud cover and Overlap 4 4

Clouds in GCMs: The aim

To represent the “important” characteristics of clouds with the smallest number of parameters possible ( = parametrization task)

Cloud/no cloud? Ice/liquid, amount, crystal size/shape…? Depends

  • n use!
slide-5
SLIDE 5

Cloud cover and Overlap 5 5

~1km ~100km

How can we describe clouds? Which characteristics?

VERTICAL COVERAGE Most models assume that this is 1

This can be a poor assumption with coarse vertical grids. Many climate models still use fewer than 30 vertical levels currently, some recent examples still use only 9 levels

x z

slide-6
SLIDE 6

Cloud cover and Overlap 6 6

~500m ~100km HORIZONTAL COVERAGE, C Spatial arrangement?

x z

How can we describe clouds? Which characteristics? C

slide-7
SLIDE 7

Cloud cover and Overlap 7 7

~500m ~100km VERTICAL OVERLAP OF CLOUD Important for Radiation and Microphysics Interaction

x z

How can we describe clouds? Which characteristics?

slide-8
SLIDE 8

Cloud cover and Overlap 8 8

Overlap approaches

Solar Zenith Effects

  • A. M. Tompkins and F. Di Giuseppe. Generalizing cloud overlap treatment to include solar zenith angle

effects on cloud geometry. J. Atmos. Sci., 64:2116-2125, 2007

  • A. M. Tompkins and F. Di Giuseppe. An interpretation of cloud overlap statistics. J. Atmos. Sci., 72:2877-

2889, 2015

  • F. Di Giuseppe and A. M. Tompkins. Generalizing cloud overlap treatment to include the effect of wind
  • shear. J. Atmos. Sci., 72:2865-2876, 2015
slide-9
SLIDE 9

Cloud cover and Overlap 9 9

~500m ~100km IN-CLOUD INHOMOGENEITY in terms of cloud particle size and number

x z

How can we describe clouds? Which characteristics?

slide-10
SLIDE 10

Cloud cover and Overlap 10 10

~500m ~100km

Macroscale Issues of Parameterization

Just these issues can become a little complex!!!

x z

slide-11
SLIDE 11

Cloud cover and Overlap 11 11

This talk will concentrate on how GCMs represent horizontal cloud cover, C

  • 1. Simple diagnostic schemes
  • 2. Statistical schemes
  • 3. The current ECMWF scheme
  • 4. Complications with ice

C

Talk Outline:

slide-12
SLIDE 12

Cloud cover and Overlap 12 12

First! Some assumptions: qv = water vapour mixing ratio qc = cloud water (liquid/ice) mixing ratio qs = saturation mixing ratio = F(T,p) qt = total water (vapour+cloud) mixing ratio RH = relative humidity = qv/qs (#1) Local criterion for formation of cloud: qt > qs This assumes that no supersaturation can exist (#2) Condensation process is fast (cf. GCM timestep) qv = qs, qc= qt – qs !!Both of these assumptions are suspect in ice clouds!!

slide-13
SLIDE 13

Cloud cover and Overlap 13 13

Partial coverage of a grid-box with clouds is only possible if there is a inhomogeneous distribution of temperature and/or humidity.

Homogeneous Distribution of water vapour and temperature:

qs,2

q x

q

qs,1

One Grid-cell

Note in the second case the relative humidity=1 from our assumptions

slide-14
SLIDE 14

Cloud cover and Overlap 14 14

Heterogeneous distribution of T and q

q x

q

qs

Another implication of the above is that clouds must exist before the grid-mean relative humidity reaches 1.

cloudy= RH=1 RH<1

slide-15
SLIDE 15

Cloud cover and Overlap 15 15

qt x

qt

qs

The interpretation does not change much if we only consider humidity variability Throughout this talk I will neglect temperature variability In fact : Analysis of observations and model data indicates humidity fluctuations are more important

cloudy RH=1 RH<1

slide-16
SLIDE 16

Cloud cover and Overlap 16 16

#1 Simple Diagnostic Schemes

slide-17
SLIDE 17

Cloud cover and Overlap 17 17

qt x

qt

qs

#1 Simple diagnostic schemes: RH-based schemes Take a grid cell with a certain (fixed) distribution of total water. At low mean RH, the cloud cover is zero, since even the moistest part of the grid cell is subsaturated

RH=60%

RH 60 100 80 C 1

slide-18
SLIDE 18

Cloud cover and Overlap 18 18

qt x

qt

qs

#1 Simple diagnostic schemes: RH-based schemes Add water vapour to the gridcell, the moistest part of the cell become saturated and cloud

  • forms. The cloud cover is low.

RH=80%

RH 60 100 80 C 1

slide-19
SLIDE 19

Cloud cover and Overlap 19 19

qt x

qt

qs

#1 Simple diagnostic schemes: RH-based schemes Further increases in RH increase the cloud cover

RH=90%

60 100 80 C 1 RH

slide-20
SLIDE 20

Cloud cover and Overlap 20 20

qt x

qt

qs

#1 Simple diagnostic schemes: RH-based schemes The grid cell becomes

  • vercast when RH=100%,

due to lack of supersaturation

RH=100%

C 1 60 100 80 RH

slide-21
SLIDE 21

Cloud cover and Overlap 21 21

#1 Simple Diagnostic Schemes:

Relative Humidity Schemes

Many schemes, from the 1970s onwards, based cloud cover on the relative humidity (RH) e.g. Sundqvist et al. MWR 1989:

C=1−√

1−RH 1−RHcrit

RHcrit = critical relative humidity at which cloud assumed to form

(function of height, typical value is 60-80%) C 1 60 100 80 RH

slide-22
SLIDE 22

Cloud cover and Overlap 22 22

Diagnostic Relative Humidity Schemes

Since these schemes form cloud when RH<100%, they implicitly assume subgrid- scale variability for total water, qt, (and/or temperature, T) exists However, the actual PDF (the shape) for these quantities and their variance (width) are often not known “Given a RH of X% in nature, the mean distribution of qt is such that, on average, we expect a cloud cover of Y%”

slide-23
SLIDE 23

Cloud cover and Overlap 23 23

Diagnostic Relative Humidity Schemes

Advantages:

Better than homogeneous assumption, since clouds can form before grids reach saturation

Disadvantages:

Cloud cover not well coupled to other processes In reality, different cloud types with different coverage can exist with same relative humidity. This can not be represented

Can we do better?

slide-24
SLIDE 24

Cloud cover and Overlap 24 24

Diagnostic Relative Humidity Schemes

Could add further predictors E.g: Xu and Randall (1996) sampled cloud scenes from a 2D cloud resolving model to derive an empirical relationship with two predictors:

C=F(RH,qc)

More predictors, more degrees of freedom=flexible But still do not know the form of the PDF. (is model valid?) Can we do better?

slide-25
SLIDE 25

Cloud cover and Overlap 25 25

#2 Statistical Schemes

slide-26
SLIDE 26

Cloud cover and Overlap 26 26

#2: Statistical Schemes These explicitly specify the probability density function (PDF) for the total water qt (and sometimes also temperature)

qc=∫

qs

∞

(qt−qs)PDF(qt)dqt

qt x

q

qs

qt PDF(q t ) qs

Cloud cover is integral under supersaturated part of PDF

C=∫

qs

∞

PDF(qt)dqt

slide-27
SLIDE 27

Cloud cover and Overlap 27 27

#2: Statistical Schemes Knowing the PDF has advantages:

More accurate calculation of radiative fluxes Unbiased calculation

  • f microphysical

processes

However, location of clouds within gridcell unknown

qt PDF(q t ) qs

x y

C

e.g. microphysics bias

slide-28
SLIDE 28

Cloud cover and Overlap 28 28

Statistical schemes

Two tasks: Specification of the:

(1) PDF shape (2) PDF moments

Shape: Unimodal? bimodal? How many parameters? Moments: How do we set those parameters?

slide-29
SLIDE 29

Cloud cover and Overlap 29 29

TASK 1: Specification of the PDF Lack of observations to determine qt PDF

Aircraft data

 limited coverage

Tethered balloon

 boundary layer

Satellite

 difficulties resolving in vertical  no qt observations  poor horizontal resolution

Raman Lidar

 only PDF of water vapour

Cloud Resolving models have also been used

 realism of microphysical parameterisation?

modis image from NASA website

slide-30
SLIDE 30

Cloud cover and Overlap 30 30

qt PDF(qt) Height

Aircraft Observed PDFs

Wood and field JAS 2000 Aircraft

  • bservations low

clouds < 2km Heymsfield and McFarquhar JAS 96 Aircraft IWC obs during CEPEX

slide-31
SLIDE 31

Cloud cover and Overlap 31 31

Conclusion: PDFs are mostly approximated by uni or bi- modal distributions, describable by a few parameters More examples from Larson et al. JAS 01/02 Note significant error that can

  • ccur if PDF is

unimodal

PDF Data

slide-32
SLIDE 32

Cloud cover and Overlap 32 32

TASK 1: Specification of PDF Many function forms have been used symmetrical distributions:

Triangular:

Smith QJRMS (90)

qt qt

Gaussian:

Mellor JAS (77)

qt PDF( q t )

Uniform:

Letreut and Li (91)

qt

s4 polynomial:

Lohmann et al. J. Clim (99)

slide-33
SLIDE 33

Cloud cover and Overlap 33 33

TASK 1: Specification of PDF skewed distributions:

qt PDF( q t )

Exponential:

Sommeria and Deardorff JAS (77)

Lognormal:

Bony & Emanuel JAS (01)

qt qt

Gamma:

Barker et al. JAS (96)

qt

Beta:

Tompkins JAS (02)

qt

Double Normal/Gaussian:

Lewellen and Yoh JAS (93), Golaz et al. JAS 2002

slide-34
SLIDE 34

Cloud cover and Overlap 34 34

TASK 2: Specification of PDF moments

Need also to determine the moments of the distribution: Variance (Symmetrical PDFs) Skewness (Higher

  • rder PDFs)

Kurtosis (4-parameter PDFs)

qt PDF(q t ) e.g. HOW WIDE? saturation cloud forms? Moment 1=MEAN Moment 2=VARIANCE Moment 3=SKEWNESS Moment 4=KURTOSIS Skewness Kurtosis positive negative negative positive

slide-35
SLIDE 35

Cloud cover and Overlap 35 35

TASK 2: Specification of PDF moments

Some schemes fix the moments (e.g. Smith 1990) based on critical RH at which clouds assumed to form If moments (variance, skewness) are fixed, then statistical schemes are identically equivalent to a RH formulation e.g. uniform qt distribution = Sundqvist form

¯ qv=Cqs+(1−C)¯ qe

C

qs

1-C

¯ qt

(1-RHcrit)qs

qt G(q t )

¯ qe

RH=¯ qv qs =1−(1−RH crit)(1−C)2

∴ C=1−√

1−RH 1−RH crit

Sundqvist formulation!!!

¯ qe=qs(1−(1−RHcrit)(1−C))

where

slide-36
SLIDE 36

Cloud cover and Overlap 36 36

Clouds in GCMs Processes that can affect distribution moments convection turbulence dynamics microphysics

slide-37
SLIDE 37

Cloud cover and Overlap 37 37

Example: Turbulence dry air moist air In presence of vertical gradient of total water, turbulent mixing can increase horizontal variability

slide-38
SLIDE 38

Cloud cover and Overlap 38 38

Example: Turbulence dry air moist air In presence of vertical gradient of total water, turbulent mixing can increase horizontal variability while mixing in the horizontal plane naturally reduces the horizontal variability

slide-39
SLIDE 39

Cloud cover and Overlap 39 39

Specification of PDF moments

q

t2

' =−τ 2w ' qt ' d qt

dz

Example: Ricard and Royer, Ann Geophy, (93), Lohmann et al. J. Clim (99)

Disadvantage:

Can give good estimate in boundary layer, but above, other processes will determine variability, that evolve on slower timescales

turbulence

d q

t2

'

dt =−2w

' qt ' d qt

dz − q

t2

'

τ

Source dissipation local equilibrium

If a process is fast compared to a GCM timestep, an equilibrium can be assumed, e.g. Turbulence

slide-40
SLIDE 40

Cloud cover and Overlap 40 40

Prognostic Statistical Scheme Tompkins (2002) introduced a prognostic statistical scheme into ECHAM5 climate GCM Prognostic equations are introduced for the variance and skewness of the total water PDF Some of the sources and sinks are rather ad-hoc in their derivation!

convective detrainment precipitation generation mixing

qs

slide-41
SLIDE 41

Cloud cover and Overlap 41 41

Scheme in action

Minimum Maximum qsat

slide-42
SLIDE 42

Cloud cover and Overlap 42 42

Scheme in action

Minimum Maximum qsat Turbulence breaks up cloud

slide-43
SLIDE 43

Cloud cover and Overlap 43 43

Scheme in action

Minimum Maximum qsat Turbulence breaks up cloud Turbulence creates cloud

slide-44
SLIDE 44

Cloud cover and Overlap 44 44

Summary of statistical schemes Advantages

Information concerning subgrid fluctuations of humidity and cloud water is available It is possible to link the sources and sinks explicitly to physical processes Use of underlying PDF means cloud variables are always self-consistent

Disadvantages

Deriving these sources and sinks rigorously is hard, especially for higher order moments needed for more complex PDFs! If variance and skewness are used instead of cloud water and humidity, conservation of the latter is not ensured

slide-45
SLIDE 45

Cloud cover and Overlap 45 45

#3 The ECMWF scheme

slide-46
SLIDE 46

Cloud cover and Overlap 46 46

ECMWF Scheme

Tiedtke MWR 1993 The ECMWF cloud scheme introduces two prognostic equations for cloud water and cloud cover As for the prognostic statistical scheme, each process of convection, turbulence, microphysics and dynamics provides sources and sinks of these variables These terms are often derived assuming a subgrid-scale distribution of total water Effectively a “variable transformation”

slide-47
SLIDE 47

Cloud cover and Overlap 47 47

Example: (a)diabatic heating/cooling

1-C qt PDF(q t ) C

Δqs

ECMWF PDF is (mostly) Uniform: in clear sky part Delta: in cloudy part cooling Red-hashed area is the change in cloud fraction due to cooling, this is added to the cloud cover budget

slide-48
SLIDE 48

Cloud cover and Overlap 48 48

Advantages Some terms are easier to handle with a simple cloud cover variable e.g. Convective detrainment:

k k+1/2 k-1/2 (MuC)k-1/2 (MuC)k+1/2 Du

S(C)CV= Du ρ

(1−C )+

Mu ρ ∂C ∂ z

slide-49
SLIDE 49

Cloud cover and Overlap 49 49

Disadvantages Not all terms are derived using PDF assumptions, therefore easy for scheme to render unreasonable states.

Cloud water qc = 0, Cloud cover C > 0 or vice versa Cloud variables are like a celebrities…

slide-50
SLIDE 50

Cloud cover and Overlap 50 50

Disadvantages Not all terms are derived using PDF assumptions, therefore easy for scheme to render unreasonable states.

Cloud water qc = 0, Cloud cover C > 0 or vice versa Cloud variables are like a celebrities…

…they don’t stay together very long!!!

slide-51
SLIDE 51

Cloud cover and Overlap 51 51

Disadvantages Loss of “memory” in clear sky or overcast conditions; scheme is not “reversible”.

e.g: RH=80%, C=0, qc=0

qt qs PDF( q t ) PDF( q t )

wide distribution? narrow distribution? (clear long time?) Cloud would form with small cooling! …but not in this case!

qt qs

slide-52
SLIDE 52

Cloud cover and Overlap 52 52

#4 Ice complications

Cirrus and permanent contrail cloud over my back garden, Reading, UK. Summer 2005.

slide-53
SLIDE 53

Cloud cover and Overlap 53 53

Ice complications

Due to relative lack of ice nuclei in the atmosphere, supersaturation with respect to ice is common!

Threshold for ice nucleation is not qs Liquid clouds do not glaciate at 0oC

Nucleation and sublimation timescales are not necessarily fast compared to a GCM timestep (depends on Ni)

RH ice

100% 150% RHcrit

slide-54
SLIDE 54

Cloud cover and Overlap 54 54

Ice complications

Typical GCM No supersaturation ECMWF current operations

RH ice

100% 150% RHcrit

Due to relative lack of ice nuclei in the atmosphere, supersaturation with respect to ice is common!

Threshold for ice nucleation is not qs Liquid clouds do not glaciate at 0oC

Nucleation and sublimation timescales are not necessarily fast compared to a GCM timestep (depends on Ni)

slide-55
SLIDE 55

Cloud cover and Overlap 55 55

Ice complications

Threshold allowed but no nucleation timescale

RH ice

100% 150% RHcrit ECMWF 2006!!!

Due to relative lack of ice nuclei in the atmosphere, supersaturation with respect to ice is common!

Threshold for ice nucleation is not qs Liquid clouds do not glaciate at 0oC

Nucleation and sublimation timescales are not necessarily fast compared to a GCM timestep (depends on Ni)

slide-56
SLIDE 56

Cloud cover and Overlap 56 56

Simple ECMWF scheme: comparison to Mozaic aircraft data

Region Lat:30./70., Lon:0./360.

0.8 1.0 1.2 1.4 1.6 1.8 RH 0.001 0.010 0.100 1.000 10.000 Freq

default clipping t

  • Koop

new param et erizat ion Moziac

New scheme 2006 Aircraft data Default

slide-57
SLIDE 57

Cloud cover and Overlap 57 57

Ice complications RH ice

100% 150% RHcrit full scheme, nice but requires…

Due to relative lack of ice nuclei in the atmosphere, supersaturation with respect to ice is common!

Threshold for ice nucleation is not qs Liquid clouds do not glaciate at 0oC

Nucleation and sublimation timescales are not necessarily fast compared to a GCM timestep (depends on Ni)

slide-58
SLIDE 58

Cloud cover and Overlap 58 58

requires... more prognostic parameters!!! qv needed separately in and out of cloud since nucleation only affects cloudy area, while supersaturation in both regions is allowed Calculation of C requires knowledge of process!

x y

cloudy area: Ni, qv, qi clear area: qv plus cloud fraction, C

slide-59
SLIDE 59

Cloud cover and Overlap 59 59

Statistical scheme framework, identical considerations!

qt PDF(q t ) qs

x y

qcrit cloudy “activated” region supersaturated clear region subsaturated region qcloud

slide-60
SLIDE 60

Cloud cover and Overlap 60 60

qs qcrit qt PDF(q t ) qs qcrit qt PDF(q t ) qs qcrit

qi= ???

qi≠∫

qs

∞

(qt−qs)PDF(qt)dqt

qcloud qt PDF(q t )

qi= ∫

qcloud

∞

(qt−qs)PDF(qt)dqt

Also, equation for cloud ice no longer holds If assume fast adjustment, derivation is straightforward Much more difficult if want to integrate nucleation equation explicitly throughout cloud

slide-61
SLIDE 61

Cloud cover and Overlap 61 61

The Future? Future development at ECMWF is likely to take the form of a hybrid scheme Prognostic equations for qv, qi/ql, qt, variance of qt, but also C There is no redundancy between these variables if supersaturation is allowed However, writing sources terms self-consistently for these variables will be difficult

qt PDF(q t ) qs qcrit

slide-62
SLIDE 62

Cloud cover and Overlap 62 62

And what about mixed phase clouds? Rotstayn MWR (2000) – How would this be represented in a PDF framework?

slide-63
SLIDE 63

Cloud cover and Overlap 63 63

Conclusions Partial cloud fraction is a result of thermodynamic variability on the subgrid-scale Any scheme that gives partial cloud cover makes implicit or explicit assumptions about fluctuations Explicit: Statistical schemes, with full “memory” of subgrid qt state; useful info for other schemes But, assumption of no supersaturation is not good in ice phase Future schemes could be hybrid, combining cloud cover C with statistical approach to model ice
