Chapter 12 COOKIES AND SESSIONS INTRO Unlike the unified single - - PowerPoint PPT Presentation

Chapter 12

COOKIES AND SESSIONS

INTRO

Unlike the unified single process that is the typical desktop application, a web application consists of a series of disconnected HTTP requests to a web server where each request for a server page is essentially a request to run a separate program. The web server sees only requests. The HTTP protocol does not, without programming intervention, distinguish two requests by one source as different than two requests from two different sources.

INTRO

INTRO

• HTTP is a stateless technology
• Each page rendered by a browser is unrelated to other pages

– even if they are from the same website

• There is no way with just HTTP to track users, create

shopping carts, or personalize web pages

• Maintaining state requires data to be sent from one page to

another

• Tools to maintain state:
• Query strings
• Form fields
• Cookies
• Sessions

THE OPTIONS

1) QUERY STRINGS

Example: <input type="hidden" name="image" value="$image"> Use $_GET or $_POST Storage is also temporary This will be discussed later

2) HIDDEN FORM FIELDS

Example: <a href="http:// …gallery.php?image=monk.jpg"> Creates $_GET variables that the next page can use Storage is temporary

THE OPTIONS

3) COOKIES

• Store data in the user's

browser

• May be disabled or

deleted by the user

• Can be made to last

longer

4) SESSIONS

• Store data on the server

itself

• More secure
• More robust (can store

more data)

COOKIES

Cookies are name/value pairs sent by a server to store information on the client's machine. Examples of cookies

• user_id=87
• email=jsmith@hotmail.com
• userName=jsmith
• passwordCookie=opensesame
• PHPSESSID=D1F15245171203E8670487F020544490

Cookies must be sent from the server to the client before any other HTML is sent.

COOKIES

Cookies aren’t harmful by themselves:

• Cookies don’t transmit viruses or steal passwords
• Contain plain text – not able to directly modify a user’s computer,

generate spam, steal files, etc.

• Misuse is generally from advertisers who want to track sites users

have visited

Typical uses:

• To allow users to skip login and registration forms
• To customize pages
• To focus advertising (banner-ads)

HOW COOKIES WORK

• On the server, a web application creates a cookie and sends

it to the browser.

• On the client, the browser saves the cookie locally and sends

it back to the server every time it accesses a page from that server.

• By default, cookies only last until the user closes his or her

web browser. However, cookies can be set to persist in the user’s browser for up to three years.

• Some users disable cookies in their browsers.
• Browsers generally accept only 20 cookies from each site

and 300 cookies total.

• Browsers can also limit each cookie to 4 kilobytes.

HOW COOKIES ARE HANDLED

THE SETCOOKIE() FUNCTION

Cookies are sent via the setcookie() function: setcookie(name, value); setcookie('name', 'Nicole');

The cookie as seen in Chrome's Developer Tools

SETCOOKIE() OPTIONAL PARAMETERS

setcookie($name, [$value, $expire, $path, $domain, $secure, $httponly]) The setcookie parameter $expire :

• default = 0; lasts until user closes browser window;

a per-session cookie.

• other timestamp values are called persistent cookies.
• time in seconds since 1/1/70 (Unix epoch)
• or relative to the present using time()

setcookie (name, value, time()+1800);

SETCOOKIE() OPTIONAL PARAMETERS

setcookie($name, [$value, $expire, $path, $domain, $secure, $httponly]) The setcookie parameter $path:

• the path on the server the cookie is available to
• if set to '/', the cookie is available to all directories
• n the current server
• default is the current directory (that set the cookie)

SETCOOKIE() OPTIONAL PARAMETERS

setcookie($name, [$value, $expire, $path, $domain, $secure, $httponly])

The setcookie parameter $domain:

• the specific domain the cookie is available to
• '.example.com' makes the cookie visible within

www.example.com

• default is the name of the server that is setting

the cookie

SETCOOKIE() OPTIONAL PARAMETERS

setcookie($name, [$value, $expire, $path, $domain, $secure, $httponly])

Other optional parameters: $secure:

• 1 means the cookie is available only if being sent using

HTTPS

• default is 0

$httponly:

• 1 means the cookie is only available through HTTP/HTTPS

and not through client-side scripts

• default is 0

SETCOOKIE() EXAMPLE

setcookie($name, [$value, $expire, $path, $domain, $secure, $httponly])

Setting a cookie in the browser:

$name = 'userid'; $value = 'bsmith'; $expire = time()+60*60*24*30; //in seconds $path = '/'; setcookie($name, $value, $expire, $path);

ACCESSING COOKIES

To retrieve a value from a cookie that has been sent, use the suberglobal variable $_COOKIE[ ]

setcookie ('userName', 'Smitherman'); can be referred to with:

$_COOKIE['userName']

but only from another page!

DELETING A COOKIE

Cookies will automatically expire:

• when the user closes the browser
• when the expiration date/time is met

A script can manually delete cookies by:

• resetting the value parameter to ' '
• setting an expiration date in the past

MORE ABOUT COOKIES

• After a cookie is set, it isn't available until either

the page is reloaded or another page is accessed.

• After a cookie is deleted, it exists until either the

page is reloaded or another page has been accessed.

VIEWING COOKIES ON YOUR MACHINE

In Firefox: Options -> Privacy & Security -> Cookies & Site Data -> Manage Data In Chrome: Settings -> Privacy & Security -> Site Data -> Cookies and site data -> See all cookies and site data

SESSIONS

Data generated by the server and stored on the server To start a session or resume a previous session: session_start(); This must be called before any HTML is sent back to the browser! The function will try to send a cookie called PHPSESSID and a value to the browser

SESSIONS

Once the session starts, the superglobal $_SESSION[ ] array can be used to store data on the server: $_SESSION['user'] = $userID; Or to retrieve data from the server: $first_name = $_SESSION['first_name'];

SESSIONS

• Any pages that attempt to use the $_SESSION[ ]

superglobal, must have sessions enabled with session_start();

• session_start(); will try to retrieve the PHPSESSID

value from the stored cookie, or it will create a new session

• If a new session is started, any previous session

data is no longer available.

SESSIONS…UNLIKE COOKIES

• Session variables are available as soon as they

are enabled

• A session variable can be assigned a value and

then referred to from within the same script (without reloading the page.)

SESSIONS

Three kinds of information are stored:

• 1. The session identifier, PHPSESSID, is stored

as a cookie by default

• 2. The session data which is stored as a text file
• n the server
• 3. The $_SESSION array, which is how the script

accesses the data in the text file

CONTROLLING THE SESSION COOKIE

To control the session cookie, use the function: session_set_cookie_params($lifetime[, $path, $domain, $secure, $httponly]) $lifetime: of the cookie in seconds; required parameter $path: the sever path that the cookie is available to; default is current directory of the script setting the cookie. The other three parameters don’t usually need to be changed.

CONTROLLING THE SESSION COOKIE

Start a session with custom cookie parameters:

$lifetime = 60 * 60 * 24 * 365; // 1 year in seconds session_set_cookie_params($lifetime, '/'); session_start(); Note: this must occur before any HTML code is returned and session_set_cookie_params() must precede

session_start();

DELETING SESSION VARIABLES

• 1. Access the existing session using session_start();
• 2. Reset the $_SESSION array to be empty:

$_SESSION=array();

• 3. Use session_destroy(); to remove session data from

server

• 4. Specify that the session cookie expires.

**NOTE: Although there is an unset() function, don’t use it on the entire $_SESSION array, as it causes unpredictable results.

A LOGIN PAGE

• 1. A form submits the login data
• 2. A script validates and confirms that the necessary

information was submitted

• 3. A database query compares the submitted

information against the stored information

• 4. Cookies or sessions store data that reflect a

successful login

• 5. The cookie or session will check the login status so

the user won't have to login on each new page

THE LOGIN PROCESS

Login Form Validate Form Input Query Database Set Cookies and/or Start Session

OK Valid Login Incomplete Invalid login

THEN WHAT?

• Once the Login is successful, go to a default

page for logged in users: logged_in.php

• What if a user gets to logged_in.php by typing

the URL?

• Check to see if there is an existing session

with session data.

if (….) { // Login successful // Set the cookies: setcookie ('user_id', $user_id); setcookie ('first_name', $first_name); // Redirect: to logged_in.php page } In general, don't store a primary key in a cookie, because cookies can be changed.

SETTING COOKIES FOLLOWING SUCCESSFUL LOGIN

You select what cookies

• r session data you

want to store

REDIRECTING THE BROWSER

We have seen how the action attribute of a form "redirects" the browser to another page. (HTML hyperlinks do this too.) What if you don't have a form or don't want the user to click a hyperlink, and want to direct the browser to another page?

• Use PHP's header() function
• Not to be confused with:
• HTML5 <header> element
• HTML <head> element
• HTML heading elements: <h1>, <h2>, etc.

REDIRECTING

• Depending on whether or not a user has successfully

logged in, the code should redirect to the appropriate page.

• Redirection uses the header() function with the

'Location: ' string: header('Location: logged_in.php');

• This line will send to the browser a different page to

display.

• It is a server-initiated response

HEADER('LOCATION: URL')

However, to maximize browser compatibility, this is one time you want to use an absolute URL: header('Location: http://satoshi.cis.uncw.edu/~…/…logged_in.php');

DEFINING A URL DYNAMICALLY

Better yet, instead of hard-coding it, determine it dynamically. The $_SERVER superglobal array contains several values set by the web server. The relevant ones here are: $_SERVER['HTTP_HOST'] which gives the host name $_SERVER['PHP_SELF'] which refers to the current script including its directory name

EXAMPLES

The URL:

https://satoshi.cis.uncw.edu/~mferner/CSC465/buildURL.php

$_SERVER['HTTP_HOST'] is: satoshi.cis.uncw.edu $_SERVER['PHP_SELF'] could be: /~mferner/CSC465/buildURL.php dirname($_SERVER['PHP_SELF']) /~mferner/CSC465 The dirname() function returns the directory path of the parent.

EXAMPLES

The dirname() function may return a string with ending characters such as / . \ (Windows) In case of an ending character, apply the rtrim() function

Statement Returns

echo dirname("/etc/passwd") /etc echo dirname("/etc/") / or \ on Windows echo dirname(".") . echo dirname("C:\\") C:\ echo dirname("/usr/local/lib", 2); (PHP 7.0+) /usr

EXAMPLES

The URL:

https://satoshi.cis.uncw.edu/~mferner/CSC465/buildURL.php

$_SERVER['HTTP_HOST'] satoshi.cis.uncw.edu $_SERVER['PHP_SELF'] /~mferner/CSC465/buildURL.php dirname($_SERVER['PHP_SELF']) /~mferner/CSC465

$url = 'http://' . $_SERVER['HTTP_HOST'] . dirname($_SERVER['PHP_SELF']); $url = rtrim($url, '/\\.'); http://satoshi.cis.uncw.edu/~mferner/CSC465 $url .= '/logged_in.php'; // Add the page name to get:

http://satoshi.cis.uncw.edu/~mferner/CSC465/logged_in.php

Remember the concatenating assignment

• perator?

FUNCTION WITH DEFAULT VALUE

function redirect_user ($page = 'index.php') {

// URL is http:// plus the host name plus the current directory:

$url = 'http://' . $_SERVER['HTTP_HOST'] . dirname($_SERVER['PHP_SELF']);

//Remove any trailing slashes (/ or \ or dot but escape \ )

$url = rtrim($url, '/\\.'); $url .= '/' . $page; // Add the page name or index.php as default header("Location: $url"); // Redirect the user: exit(); // Quit the script. } // End of redirect_user() function.

SESSION SECURITY

Never store sensitive data in a cookie Prevent session vulnerabilities: Session hijacking Session fixation Use a secure connection (https) when dealing with sensitive data. This will be covered in the next chapter.

SESSION SECURITY

Session Hijacking

• Occurs when the session ID is discovered
• If the session ID is not stored in a cookie, it

must be transmitted another way making it vulnerable

• It can then be used to access another user's

data

SESSION SECURITY

Preventing Session Hijacking

• Require the use of cookies
• Store an additional user-identifier for each user e.g.

$_SERVER['HTTP_USER_AGENT'] could be assigned to $_SESSION['agent']

• $_SERVER['HTTP_USER_AGENT'] is a string

containing browser and operating system data

• A hijack could only occur if the hijacker has the

exact same OS and browser version

SESSION SECURITY

Session Fixation

• An attacker explicitly sets the session identifier of a

session for a user

• The victim then uses the attackers session

unknowingly and inadvertently exposes sensitive data

• It can be done via URL by sending:

http://www.example.com/index...?session_name=sessionid

• Or with a redirect:

header('Location: http://host/index.php?PHPSESSID=1234');

SESSION SECURITY

Preventing Session Fixation

• Change the session ID after a user logs in

using: session_regenerate_id();

• Learn more online
