Causal Discovery Richard Scheines Peter Spirtes, Clark Glymour, and many others Dept. of Philosophy & CALD Carnegie Mellon Graphical Models --11/30/05 1 Outline 1. Motivation 2. Representation 3. Connecting Causation to Probability

slide-1
SLIDE 1

Graphical Models --11/30/05 1

Causal Discovery

Richard Scheines Peter Spirtes, Clark Glymour, and many others

  • Dept. of Philosophy & CALD

Carnegie Mellon

slide-2
SLIDE 2

Graphical Models --11/30/05 2

Outline

1. Motivation 2. Representation 3. Connecting Causation to Probability (Independence) 4. Searching for Causal Models 5. Improving on Regression for Causal Inference

slide-3
SLIDE 3

Graphical Models --11/30/05 3

  • 1. Motivation

Non-experimental Evidence

Typical Predictive Questions

  • Can we predict aggressiveness from the amount of violent TV watched
  • Can we predict crime rates from abortion rates 20 years ago

Causal Questions:

  • Does watching violent TV cause Aggression?
  • I.e., if we change TV watching, will the level of Aggression change?

Day Care Aggressivenes John Mary A lot None A lot A little

slide-4
SLIDE 4

Graphical Models --11/30/05 4

Bayes Netw orks

Disease

[Heart Disease, Reflux Disease, other]

Shortness of Breath

[Yes, No]

Chest Pain

[Yes, No]

Qualitative Part:

Directed Graph

P(Disease = Heart Disease) = .2 P(Disease = Reflux Disease) = .5 P(Disease = other) = .3 P(Chest Pain = yes | D = Heart D.) = .7 P(Shortness of B = yes | D= Hear D. ) = .8 P(Chest Pain = yes | D = Reflux) = .9 P(Shortness of B = yes | D= Reflux ) = .2 P(Chest Pain = yes | D = other) = .1 P(Shortness of B = yes | D= other ) = .2

Quantitative Part:

Conditional Probability Tables

slide-5
SLIDE 5

Graphical Models --11/30/05 5

Bayes Netw orks: Updating

Given: Data on Symptoms

Chest Pain = yes

Wanted:

P(Disease | Chest Pain = yes )

Disease

[Heart Disease, Reflux Disease, other]

Shortness of Breath

[Yes, No]

Chest Pain

[Yes, No]

Updating

P(D = Heart Disease) = .2 P(D = Reflux Disease) = .5 P(D = other) = .3 P(Chest Pain = yes | D = Heart D.) = .7 P(Shortness of B = yes | D= Hear D. ) = .8 P(Chest Pain = yes | D = Reflux) = .9 P(Shortness of B = yes | D= Reflux ) = .2 P(Chest Pain = yes | D = other) = .1 P(Shortness of B = yes | D= other ) = .2

slide-6
SLIDE 6

Graphical Models --11/30/05 6

Causal Inference

Given: Data on Symptoms

Chest Pain = yes

P(Disease | Chest Pain = yes )

Updating

P(Disease | Chest Pain set= yes )

Causal Inference

slide-7
SLIDE 7

Graphical Models --11/30/05 7

Causal Inference

When and how can we use non-experimental data to tell us about the effect of an intervention? Manipulated Probability P(Y | X set= x, Z= z) from Unmanipulated Probability P(Y | X = x, Z= z)

slide-8
SLIDE 8

Graphical Models --11/30/05 8

  • 2. Representation

1. Association & causal structure - qualitatively 2. Interventions 3. Statistical Causal Models

1. Bayes Networks 2. Structural Equation Models

slide-9
SLIDE 9

Graphical Models --11/30/05 9

Causation & Association

X and Y are associated (X _||_ Y) iff

∃x1 ≠ x2 P(Y | X = x1) ≠ P(Y | X = x2)

Association is symmetric: X _||_ Y ⇔ Y _||_ X X is a cause of Y iff

∃x1 ≠ x2 P(Y | X set= x1) ≠ P(Y | X set= x2)

Causation is asymmetric: X Y ⇔ X Y

slide-10
SLIDE 10

Graphical Models --11/30/05 10

Direct Causation

X is a direct cause of Y relative to S, iff

∃z,x1 ≠ x2 P(Y | X set= x1 , Z set= z) ≠ P(Y | X set= x2 , Z set= z)

where Z = S - { X,Y}

X Y

slide-11
SLIDE 11

Graphical Models --11/30/05 11

Causal Graphs

Causal Graph G = { V,E} Each edge X → Y represents a direct causal claim: X is a direct cause of Y relative to V

Exposure

Rash

Chicken Pox

Exposure

Infection Rash

slide-12
SLIDE 12

Graphical Models --11/30/05 12

Causal Graphs

Do Not need to be Cause Complete

Omitted Causes 2 Omitted Causes 1

Exposure

Infection Symptoms

Do need to be Common Cause Complete

Exposure

Infection Symptoms Omitted Common Causes

slide-13
SLIDE 13

Graphical Models --11/30/05 13

Modeling Ideal Interventions

Ideal Interventions (on a variable X): (on a variable X):

  • Completely determine the value or

distribution of a variable X

  • Directly Target only X

(no “fat hand”)

E.g., Variables: Confidence, Athletic Performance Intervention 1: hypnosis for confidence Intervention 2: anti-anxiety drug (also muscle relaxer)

slide-14
SLIDE 14

Graphical Models --11/30/05 14

Modeling Ideal Interventions

Interventions on the Effect

Pre-experimental System Post

Sweaters On Room Temperature

slide-15
SLIDE 15

Graphical Models --11/30/05 15

Modeling Ideal Interventions

Interventions on the Cause

Pre-experimental System Post

Sweaters On Room Temperature

slide-16
SLIDE 16

Graphical Models --11/30/05 16

Interventions & Causal Graphs

  • Model an ideal intervention by adding an “intervention” variable
  • utside the original system
  • Erase all arrows pointing into the variable intervened upon

Intervene to change Inf Post-intervention graph? Pre-intervention graph

Exp Inf Rash I Exp Inf Rash

slide-17
SLIDE 17

Graphical Models --11/30/05 17

Conditioning vs. Intervening

P(Y | X = x 1) vs. P(Y | X set= x 1) Teeth Slides

slide-18
SLIDE 18

Graphical Models --11/30/05 18

Causal Bayes Netw orks

S m oking [0,1] L u ng C an cer [0,1] Y ellow F ingers [0,1]

The Joint Distribution Factors According to the Causal Graph, i.e., for all X in V P(V) = ΠP(X|Immediate Causes of(X))

P(S = 0) = .7 P(S = 1) = .3 P(YF = 0 | S = 0) = .99 P(LC = 0 | S = 0) = .95 P(YF = 1 | S = 0) = .01 P(LC = 1 | S = 0) = .05 P(YF = 0 | S = 1) = .20 P(LC = 0 | S = 1) = .80 P(YF = 1 | S = 1) = .80 P(LC = 1 | S = 1) = .20

P(S,YF, L) = P(S) P(YF | S) P(LC | S)

slide-19
SLIDE 19

Graphical Models --11/30/05 19

Structural Equation Models

Education Longevity Income

Causal Graph Statistical Model

  • 1. Structural Equations
  • 2. Statistical Constraints
slide-20
SLIDE 20

Graphical Models --11/30/05 20

Structural Equation Models

Education Longevity Income

Causal Graph z Structural Equations:

One Equation for each variable V in the graph: V = f(parents(V), errorV) for SEM (linear regression) f is a linear function

z Statistical Constraints:

Joint Distribution over the Error terms

slide-21
SLIDE 21

Graphical Models --11/30/05 21

Structural Equation Models

Equations: Education = εed Income = β1 Education + εincome Longevity = β2 Education + εLongevity Statistical Constraints: (εed, εIncome,εIncome ) ~ N(0,Σ2)

− Σ2 diagonal

  • no variance is zero

Education Longevity Income

Causal Graph

Education εIncome εLongevity β1 β2 Longevity Income

SEM Graph (path diagram)

slide-22
SLIDE 22

Graphical Models --11/30/05 22

  • 3. Connecting

Causation to Probability

slide-23
SLIDE 23

Graphical Models --11/30/05 23

Causal Structure

Statistical Predictions

The Markov Condition

Causal Markov Axiom

Independence X _||_ Z | Y

i.e.,

P(X | Y) = P(X | Y, Z) Causal Graphs

Z Y X

slide-24
SLIDE 24

Graphical Models --11/30/05 24

Causal Markov Axiom

If G is a causal graph, and P a probability distribution over the variables in G, then in P: every variable V is independent of its non-effects, conditional on its immediate causes.

slide-25
SLIDE 25

Graphical Models --11/30/05 25

Causal Markov Condition

Two Intuitions: 1) Immediate causes make effects independent of remote causes (Markov). 2) Common causes make their effects independent (Salmon).

slide-26
SLIDE 26

Graphical Models --11/30/05 26

Causal Markov Condition

1) Immediate causes make effects independent of remote causes (Markov).

E = Exposure to Chicken Pox I = Infected S = Symptoms

Markov Cond.

E || S | I S I E

slide-27
SLIDE 27

Graphical Models --11/30/05 27

Causal Markov Condition

2) Effects are independent conditional on their common causes.

Sm oking (S) Y ellow Fingers (Y F) Lung Cancer (LC)

Markov Cond.

YF || LC | S

slide-28
SLIDE 28

Graphical Models --11/30/05 28

Causal Structure ⇒ Statistical Data

X

3 |X 2

X

1

X

2

X

3

X

1

Causal M arkov A xiom (D

  • separation)

Independence

A cyclic Causal G raph

slide-29
SLIDE 29

Graphical Models --11/30/05 29

Causal Markov Axiom

In SEMs, d-separation follows from assuming independence among error terms that have no connection in the path diagram - i.e., assuming that the model is common cause complete.

slide-30
SLIDE 30

Graphical Models --11/30/05 30

Causal Markov and D-Separation

  • In acyclic graphs: equivalent
  • Cyclic Linear SEMs with uncorrelated errors:
  • D-separation correct
  • Markov condition incorrect
  • Cyclic Discrete Variable Bayes Nets:
  • If equilibrium --> d-separation correct
  • Markov incorrect
slide-31
SLIDE 31

Graphical Models --11/30/05 31

D-separation: Conditioning vs. Intervening

X3 T X2 X1

P(X3 | X2) ≠ P(X3 | X2, X1) X3 _||_ X1 | X2

X3 T X2 X1 I

P(X3 | X2 set= ) = P(X3 | X2 set=, X1) X3 _||_ X1 | X2 set=

slide-32
SLIDE 32

Graphical Models --11/30/05 32

  • 4. Search

From Statistical Data to Probability to Causation

slide-33
SLIDE 33

Graphical Models --11/30/05 33

Causal Discovery Statistical Data ⇒ Causal Structure

Background Knowledge

  • X2 before X3
  • no unmeasured common causes

X

3 | X 2

X

1

Independence

Data

Statistical Inference

X

2

X

3

X

1

Equivalence Class of Causal Graphs

X

2

X

3

X

1

X

2

X

3

X

1

Discovery Algorithm Causal Markov Axiom (D-separation)

slide-34
SLIDE 34

Graphical Models --11/30/05 34

Representations of D-separation Equivalence Classes

We want the representations to:

  • Characterize the Independence Relations

Entailed by the Equivalence Class

  • Represent causal features that are shared

by every member of the equivalence class

slide-35
SLIDE 35

Graphical Models --11/30/05 35

Patterns & PAGs

  • Patterns (Verma and Pearl, 1990): graphical

representation of an acyclic d-separation equivalence - no latent variables.

  • PAGs: (Richardson 1994) graphical

representation of an equivalence class including latent variable models and sample selection bias that are d-separation equivalent over a set of measured variables X

slide-36
SLIDE 36

Graphical Models --11/30/05 36

Patterns

X2 X1 X2 X1 X2 X1 X4 X3 X2 X1

Possible Edges Example

slide-37
SLIDE 37

Graphical Models --11/30/05 37

Patterns: What the Edges Mean

X2 X1 X2 X1 X1 → X2 in some members of the equivalence class, and X2 → X1 in

  • thers.

X1 → X2 (X1 is a cause of X2) in every member of the equivalence class. X2 X1 X1 and X2 are not adjacent in any member of the equivalence class

slide-38
SLIDE 38

Graphical Models --11/30/05 38

Patterns

X2 X4 X3 X1 X2 X4 X3 Represents Pattern X1 X2 X4 X3 X1

slide-39
SLIDE 39

Graphical Models --11/30/05 39

PAGs: Partial Ancestral Graphs

What PAG edges mean.

X2 X1 X2 X1 X2 X1 X2 There is a latent common cause of X1 and X2 No set d-separates X2 and X1 X1 is a cause of X2 X2 is not an ancestor of X1 X1 X2 X1 X1 and X2 are not adjacent

slide-40
SLIDE 40

Graphical Models --11/30/05 40

PAGs: Partial Ancestral Graph

X 2 X 3 X 1 X 2 X 3 Represents PAG X 1 X 2 X 3 X 1 X 2 X 3 T 1 X 1 X 2 X 3 X 1 etc. T 1 T 1 T 2

slide-41
SLIDE 41

Graphical Models --11/30/05 41

Overview of Search Methods

  • Constraint Based Searches
  • TETRAD
  • Scoring Searches
  • Scores: BIC, AIC, etc.
  • Search: Hill Climb, Genetic Alg., Simulated Annealing
  • Very difficult to extend to latent variable models

Heckerman, Meek and Cooper (1999). “A Bayesian Approach to Causal Discovery” chp. 4 in Computation, Causation, and Discovery, ed. by Glymour and Cooper, MIT Press, pp. 141-166

slide-42
SLIDE 42

Graphical Models --11/30/05 42

Tetrad 4 Demo

www.phil.cmu.edu/projects/tetrad_download/

slide-43
SLIDE 43

Graphical Models --11/30/05 43

  • 5. Regession and

Causal Inference

slide-44
SLIDE 44

Graphical Models --11/30/05 44

Regression to estimate Causal Influence

  • Let V = { X,Y,T} , where
  • Y : measured outcome
  • measured regressors: X = { X1, X2, …, Xn}
  • latent common causes of pairs in X U Y: T = { T1, …, Tk}
  • Let the true causal model over V be a Structural Equation

Model in which each V ∈ V is a linear combination of its direct causes and independent, Gaussian noise.

slide-45
SLIDE 45

Graphical Models --11/30/05 45

Regression and Causal Inference

  • Consider the regression equation:

Y = b0 + b1X1 + b2X2 + ..…bnXn

  • Let the OLS regression estimate bi be the estimated causal

influence of Xi on Y.

  • That is, holding X/Xi experimentally constant, bi is an estimate of

the change in E(Y) that results from an intervention that changes Xi by 1 unit.

  • Let the real Causal Influence Xi → Y = βi
  • When is the OLS estimate bi an unbiased estimate of βi ?
slide-46
SLIDE 46

Graphical Models --11/30/05 46

Linear Regression

Let the other regressors O = { X1, X2,....,Xi-1, Xi+ 1,...,Xn}

bi = 0 if and only if ρXi,Y.O = 0

In a multivariate normal distribuion,

ρXi,Y.O = 0 if and only if Xi _||_ Y | O

slide-47
SLIDE 47

Graphical Models --11/30/05 47

Linear Regression

So in regression:

bi = 0 ⇔

Xi _||_ Y | O

But provably :

βi = 0 ⇐ ∃S ⊆ O, Xi _||_ Y | S

So ∃S ⊆ O, Xi _||_ Y | S ⇒ βi = 0 ~ ∃S ⊆ O, Xi _||_ Y | S ⇒ don’t know (unless we’re

lucky)

slide-48
SLIDE 48

Graphical Models --11/30/05 48

Regression Example

b1≠ 0

X1 _||_ Y | X2

X2 Y X1 True Model

b2 = 0

X2 _||_ Y | X1

Don’t know

~ ∃S ⊆ { X2} X1 _||_ Y | S

β2 = 0

∃S ⊆ { X1} X2 _||_ Y | {X1}

slide-49
SLIDE 49

Graphical Models --11/30/05 49

Regression Example

b1≠ 0 X2 Y X3 X1 T1 True Model T2

~ ∃S ⊆ { X2,X3} , X1 _||_ Y | S X1 _||_ Y | { X2,X3} X2 _||_ Y | { X1,X3}

b2≠ 0 b3≠ 0

X3 _||_ Y | { X1,X2}

DK β2 = 0

∃S ⊆ { X1,X3} , X2 _||_ Y | { X1}

~ ∃S ⊆ { X1,X2} , X3 _||_ Y | S

DK

slide-50
SLIDE 50

Graphical Models --11/30/05 50

Regression Example

X2 Y X3 X1 T1 True Model T2

X2 Y X3 X1 PAG

slide-51
SLIDE 51

Graphical Models --11/30/05 51

Regression Bias

If

  • Xi is d-separated from Y conditional on X/Xi

in the true graph after removing Xi → Y, and

  • X contains no descendant of Y, then:

bi is an unbiased estimate of βi

See Using Path Diagrams as a Structural Equation Modeling Tool, (1998). Spirtes, P., Richardson, T., Meek, C., Scheines, R., and Glymour, C., Sociological Methods & Research, Vol. 27, N. 2, 182-225

slide-52
SLIDE 52

Graphical Models --11/30/05 52

Ongoing Projects

  • Finding Latent Variable Models (Ricardo Silva, Gatsby Neuroscience, former CALD PhD)
  • Ambiguous Manipulations (Grant Reaber, Philosophy)
  • Strong Faithfulness (Jiji Zhang, Philosophy)
  • Educational Data Mining (Benjamin Shih, CALD)
  • Sequential Experimentation (Active Discovery), (Frederick Eberhardt, CALD & Philosophy)
slide-53
SLIDE 53

Graphical Models --11/30/05 53

References

  • Causation, Prediction, and Search, 2nd Edition, (2000), by P. Spirtes, C. Glymour, and R.

Scheines ( MIT Press)

  • Causality: Models, Reasoning, and Inference, (2000), Judea Pearl, Cambridge Univ. Press
  • Computation, Causation, & Discovery (1999), edited by C. Glymour and G. Cooper, MIT Press
  • Causality in Crisis?, (1997) V. McKim and S. Turner (eds.), Univ. of Notre Dame Press.
  • TETRAD IV: www.phil.cmu.edu/projects/tetrad
  • Causality Lab: www.phil.cmu.edu/projects/causality-lab
  • Web Course: www.phil.cmu.edu/projects/csr/
