Tom Wilkie Founder & VP Engineering

Castle: Reinventing Storage for Big Data

Before the Flood

Old hardware

1990

BTree File systems RAID Small databases BTree indexes

Two Revolutions

BTree file systems

2010

New hardware RAID

Write-optimised indexes

Distributed, shared-nothing databases BTree file systems New hardware RAID

Write-optimised indexes

...

Bridging the Gap

Castle

2011

Distributed, shared-nothing databases New hardware Castle New hardware

...

With Big Data, how do I...

S N A P S H O T S

With Big Data, how do I...

What’s in the Castle?

Acunu Kernel Userspace Linux Kernel Doubling Arrays

userspace interface kernelspace interface doubling array mapping layer modlist btree mapping layer block mapping & cacheing layer linux's block & MM layers Memory manager "Extent" layer

Streaming interface

Cache

In-kernel workloads Block layer

Shared memory interface

Arrays

• Opensource (GPLv2, MIT

for user libraries)

• http://bitbucket.org/acunu
• Loadable Kernel Module,

targeting CentOS’s 2.6.18

• http://www.acunu.com/

blogs/andy-twigg/why- acunu-kernel/

Castle

Acunu Kernel Userspace Doubling Arrays

arrays range queries key insert queues Bloom filters

x

userspace interface kernelspace interface doubling array mapping layer Streaming interface

key insert key get buffered value get buffered value insert range queries

In-kernel workloads

shared buffers async, shared memory ring

Shared memory interface

keys

values key get arrays management

The Interface

castle_{back,objects}.c

Acunu Kernel Doubling Arrays

arrays range queries key insert insert queues Bloom filters

x

userspace interface kernelspace interface doubling array mapping layer modlist btree mapping layer

btree range queries key get key insert Version tree

Streaming interface

key insert key get buffered value get buffered value insert range queries

In-kernel workloads

shared buffers async, shared memory ring values

Arrays

value arrays btree key get arrays management merges

Doubling Array

castle_{da,bloom}.c

Update Range Query (Size Z) B-Tree

O(logB N) random IOs O(Z/B) random IOs

B = “block size”, say 8KB at 100 bytes/entry ~= 100 entries

Doubling Array

2 9 2 9

Inserts Buffer arrays in memory until we have > B of them

Doubling Array

11 8 8 11 2 9 2 8 9 11

Inserts etc...

Similar to log-structured merge trees (LSM), cache-

• blivious lookahead array (COLA), ...

https://acunu-videos.s3.amazonaws.com/dajs.html

Demo

Update Range Query (Size Z) B-Tree

O(logB N) random IOs O(Z/B) random IOs

Doubling Array

O((log N)/B) sequential IOs

B = “block size”, say 8KB at 100 bytes/entry ~= 100 entries

Doubling Array

Queries

• Add an index to each array to do lookups
• query(k) searches each array independently

query(k)

Doubling Array

• Bloom Filters can help exclude arrays from

search

• ... but don’t help with range queries

Queries query(k)

B = “block size”, say 8KB at 100 bytes/entry ~= 100 entries

Update Range Query (Size Z) B-Tree

O(logB N) random IOs O(Z/B) random IOs

Doubling Array

O((log N)/B) sequential IOs O(Z/B) sequential IOs

~ log (2^30)/log 100 = 5 IOs/update ~ log (2^30)/100 = 0.2 IOs/update 8KB @ 100MB/s = 13k IOs/s 8KB @ 100MB/s, w/ 8ms seek = 100 IOs/s 13k / 0.2 = 65k updates/s 100 / 5 = 20 updates/s

Acunu Kernel Doubling Arrays

arrays range queries key insert insert queues Bloom filters

x

userspace interface kernelspace interface doubling array mapping layer modlist btree mapping layer

btree range queries key get key insert Version tree

Streaming interface

key insert key get buffered value get buffered value insert range queries

In-kernel workloads

shared buffers async, shared memory ring values

Arrays

value arrays btree key get arrays management merges

Doubling Array

castle_{da,bloom}.c

Linux Kernel Doubling Arrays

arrays range queries key insert insert queues Bloom filters

x

ke doubling array mapping layer modlist btree mapping layer block mapping & cacheing layer ck & rs "Extent" layer

extent allocator & mapper freespace manager btree range queries key get key insert Version tree

Cache

flusher extent block cache page cache prefetcher

Arrays

value arrays btree key get arrays management merges

“Mod-list” B-Tree

castle_{btree,versions}.c

Copy-on-Write BTree

Idea:

• Apply path-copying [DSST] to

the B-tree Problems:

• Space blowup: Each update may

rewrite an entire path

• Slow updates: as above

A log file system makes updates sequential, but relies on random access and garbage collection (achilles heel!)

Nv = #keys live (accessible) at version v

Update Range Query Space CoW B- Tree

O(logB Nv) random IOs O(Z/B) random IOs O(N B logB Nv)

1 a 1 b

• Inserts produce arrays

v1

“BigTable” snapshots

1 a 1 b

“BigTable” snapshots

• Inserts produce arrays
• Snapshots increment ref

counts on arrays

• Merges product more

arrays, decrement ref count on old arrays

2 a 2 b

v1 v2

1 c

• Inserts produce arrays
• Snapshots increment ref

counts on arrays

• Merges product more

arrays, decrement ref count on old arrays

1 1

v1 v2

1 1 a 1 b 1 a b c

“BigTable” snapshots

“BigTable” snapshots

• Inserts produce arrays
• Snapshots increment ref

counts on arrays

• Merges product more

arrays, decrement ref count on old arrays

• Space blowup

1 1

v1 v2

1 1 a 1 b 1 a b c

Nv = #keys live (accessible) at version v

Update Range Query Space CoW B- Tree

O(logB Nv) random IOs O(Z/B) random IOs O(N B logB Nv)

“BigTable” style DA

O((log N)/B) sequential IOs O(Z/B) sequential IOs O(VN)

“Mod-list” BTree

Idea:

• Apply fat-nodes [DSST] to the

B-tree

• ie insert (key, version, value)

tuples, with special operations Problems:

• Similar performance to a BTree

If you limit the #versions, can be constructed sequentially, and embedded into a DA

Nv = #keys live (accessible) at version v

Update Range Query Space CoW B- Tree

O(logB Nv) random IOs O(Z/B) random IOs O(N B logB Nv)

“BigTable” style DA

O((log N)/B) sequential IOs O(Z/B) sequential IOs O(VN)

“Mod-list” in a DA

O((log N)/B) sequential IOs O(Z/B) sequential IOs O(N)

CASTLE

LevelDB

Stratified BTree

Problem: Embedded “Mod- list” #versions limit Solution: Version-split arrays during merges

v0 v1 v2

v-split

v2 v2 v2 v0 v0

k1 k4 k5 k3 k2

{v2} {v1,v0}

v1 v1 v1 v0 v1 v0 v0

k1 k4 k5 k2

v0 entries here are duplicates

v1 v2 v2 v1 v2 v1 v0 v1 v0 v1 v0 v1

newer

• lder

merge

v1 v2 v2 v1 v2 v1 v0 v1 v0 v0

k1 k4 k5 k3 k2

(duplicates removed)

Linux Kernel Doubling Arrays

arrays range queries key insert insert queues Bloom filters

x

ke doubling array mapping layer modlist btree mapping layer block mapping & cacheing layer ck & rs "Extent" layer

extent allocator & mapper freespace manager btree range queries key get key insert Version tree

Cache

flusher extent block cache page cache prefetcher

Arrays

value arrays btree key get arrays management merges

“Mod-list” B-Tree

castle_{btree,versions}.c

Linux Kernel modlist btree mapping layer block mapping & cacheing layer linux's block & MM layers Memory manager "Extent" layer

extent allocator & mapper freespace manager btree range queries key get key insert Version tree

Cache

flusher extent block cache page cache prefetcher

Block layer Arrays

value arrays btree

Disk Layout: RDA

castle_{cache,extent,freespace,rebuild}.c

13 8 9 5 14 2 1 2 3 4 6 7 8 1 3 4 5 6 7 10 11 12 13 15 16 9 10 11 14 5 2 8 9 14 13 12 15 16

Disk Layout: RDA

random duplicate allocation

Performance Comparison

Small random inserts Inserting 3 billion rows

Acunu powered Cassandra - ‘standard’ Cassandra -

Insert latency

While inserting 3 billion rows

Acunu powered Cassandra x ‘standard’ Cassandra +

Small random range queries

Performed immediately after inserts

Acunu powered Cassandra - ‘standard’ Cassandra -

Standard Acunu Benefits inserts rate 95% latency ~32k/s ~32s ~45k/s ~0.3s >1.4x >100x gets rate 95% latency ~100/s ~2s ~350/s ~0.5s >3.5x >4x range queries 95% latency ~0.4/s ~15s ~40/s ~2s >100x >7.5x

Performance summary

• Castle: like BDB, but for Big Data
• DA: transforms random IO into

sequential IO

• Snapshots & Clones: addressing

real problems with new workloads

• 2 orders of magnitude better

performance and predictability

Questions?

Tom Wilkie @tom_wilkie tom@acunu.com http://bitbucket.org/acunu http://www.acunu.com/download http://www.acunu.com/insights

References

[LSM] The Log-Structured Merge-Tree (LSM-Tree) Patrick O'Neil, Edward Cheng, Dieter Gawlick, Elizabeth O'Neil http://staff.ustc.edu.cn/~jpq/paper/flash/1996-The %20Log-Structured%20Merge-Tree%20%28LSM- Tree%29.pdf [COLA] Cache-Oblivious Streaming B-trees, Michael A. Bender et al http://www.cs.sunysb.edu/~bender/newpub/ BenderFaFi07.pdf [DSST] Making Data Structures Persistent - J. R. Driscoll, N. Sarnak, D. D. Sleator, R. E. Tarjan, Making Data Structures Persistent, Journal of Computer and System Sciences,

• Vol. 38, No. 1, 1989

http://www.cs.cmu.edu/~sleator/papers/making- data-structures-persistent.pdf Stratified B-trees and versioned dictionaries, - Andy Twigg, Andrew Byde, Grzegorz Miłoś, Tim Moreton, John Wilkes, Tom Wilkie, HotStorage’11 http://www.usenix.org/event/hotstorage11/tech/ final_files/Twigg.pdf [RDA] Random duplicate storage strategies for load balancing in multimedia servers, 2000, Joep Aerts and Jan Korst and Sebastian Egner http://www.win.tue.nl/~joep/IPL.ps Apache, Apache Cassandra, Cassandra, Hadoop, and the eye and elephant logos are trademarks of the Apache Software Foundation.
