Case Presentation Maha Akkawi, MD, Fatima Obeidat, MD, Tariq Aladily, MD Department of Pathology Jordan University Hospital Amman, Jordan The 25th Annual Congress of the ADIAP The 8/11/2013 1 5th International Conference of JSP Clinical

slide-1
SLIDE 1

Case Presentation

Maha Akkawi, MD, Fatima Obeidat, MD, Tariq Aladily, MD Department of Pathology Jordan University Hospital Amman, Jordan

The 25th Annual Congress of the ADIAP The 5th International Conference of JSP 8/11/2013 1

slide-2
SLIDE 2

Clinical Background

  • 39 year old smoker lady, presented with

a 6 month history of toothache and headache

  • Medical history: hypertension

The 25th Annual Congress of the ADIAP The 5th International Conference of JSP 8/11/2013 2

slide-3
SLIDE 3

Clinical Background

  • Multiple visits to dental clinics, received

pain killers but without relief

  • Visited an ENT clinic, physical exam

revealed a nasal cavity mass

  • CT scan was performed

The 25th Annual Congress of the ADIAP The 5th International Conference of JSP 8/11/2013 3

slide-4
SLIDE 4

CT scan

slide-5
SLIDE 5

Radiologic findings

  • Large, lobulated, destructive solid tumor

measuring 5 cm in maximum dimension, involving the roof of the mouth, the right nasal cavity, maxillary sinus, orbit

  • The tumor also extends to the right

infratemporal fossa, ptregopalatine fossa and parapharyngeal space, sparing the oropharynx

  • The patient underwent endoscopic biopsy

from the nasal mass

The 25th Annual Congress of the ADIAP The 5th International Conference of JSP 8/11/2013 5

slide-6
SLIDE 6

6

slide-7
SLIDE 7

7

slide-8
SLIDE 8

8

slide-9
SLIDE 9

9

slide-10
SLIDE 10

10

slide-11
SLIDE 11

11

slide-12
SLIDE 12

12

slide-13
SLIDE 13

Differential Diagnosis

  • Sarcoamtoid carcinoma(CK??)
  • Extracranial meningeoma (EMA, vimentin??)
  • Leiomyosarcoma ( Desmin, SMA??)
  • Solitary fibrous tumor (Bcl2, EMA??)
  • Anaplastic large cell lymphoma(CD30,CD45??)
  • Melanoma (HMB45??)

The 25th Annual Congress of the ADIAP The 5th International Conference of JSP 8/11/2013 13

slide-14
SLIDE 14

cytokeratin

14

slide-15
SLIDE 15

vimentin

15

slide-16
SLIDE 16

CD45

16

slide-17
SLIDE 17

SMA

17

slide-18
SLIDE 18

Desmin

18

slide-19
SLIDE 19

S100

19

slide-20
SLIDE 20

EMA

20

slide-21
SLIDE 21

Bcl2

21

slide-22
SLIDE 22

CD30

22

slide-23
SLIDE 23

CD21

23

slide-24
SLIDE 24

CD23

24

slide-25
SLIDE 25

CD68

25

slide-26
SLIDE 26

Immunoprofile

Positive

  • vimentin
  • CD21
  • CD23
  • CD68 (focal)

Negative

  • S100
  • CD45
  • CK
  • EMA
  • SMA
  • Desmin
  • HMB45
  • CD99
  • Bcl2
  • CD20
  • CD30
  • ALK
  • CD1a

The 25th Annual Congress of the ADIAP The 5th International Conference of JSP 8/11/2013 26

slide-27
SLIDE 27

Diagnosis

Extranodal follicular dendritic cell sarcoma

The 25th Annual Congress of the ADIAP The 5th International Conference of JSP 8/11/2013 27

slide-28
SLIDE 28

FDC sarcoma

  • A rare neoplastic proliferation of FDCs

(antigen-presenting immune accessory cells that are widely distributed in tissues)

  • First reported by Monda et al, in 1986
  • Almost all patients are adults, with a median

age of 40 years and with no sex predilection

  • Some association with Castleman disease

(hyaline vascular variant)

The 25th Annual Congress of the ADIAP The 5th International Conference of JSP 8/11/2013 28

slide-29
SLIDE 29

Etiology

  • Most cases: unknown
  • Hyaline-vascular Castleman disease (10-20%) of

cases

  • A pathway for tumor evolution: FDC hyperplasia,

dysplasia then transformation

  • Overexpression of p53 protein is noted in FDC

sarcoma, and is weakly positive in spindle cells in Castleman disease

  • Epidermal growth factor receptor expression

The 25th Annual Congress of the ADIAP The 5th International Conference of JSP 8/11/2013 29

slide-30
SLIDE 30

Clinical symptoms

  • Patients often present with a slow-growing,

painless mass

  • Constitutional symptoms and paraneoplastic

syndromes are rare, unless associated with Castleman disease, or in inflammatory pseudotumor variant of FDC sarcoma

  • Abdominal tumors present with pain and

compression symptoms

The 25th Annual Congress of the ADIAP The 5th International Conference of JSP 8/11/2013 30

slide-31
SLIDE 31

Nodal vs Extranodal sites

  • Nodal FDC sarcoma accounts for more than

two thirds of cases, with cervical lymph nodes being the most commonly affected

  • Extranodal FDC sarcoma is very rare (37 cases

by 2010)*

  • Most of the prototype: oropharynx
  • IPT-variant: spleen or liver
  • Other reported sites: GIT, soft tissue, skin, lung

and breast

* Duan GJ, Wu F, Zhu J, Guo DY, Zhang R, Shen LL, Wang SH, Li Q, Xiao HL, Mou JH, Yan XC, Extranodal follicular dendritic cell sarcoma of the pharyngeal region: a potential diagnostic pitfall, with literature review, Am j clin pathol, 2010 jan. 8/11/2013 31

slide-32
SLIDE 32

Gross features

  • Size range from 1 to 20 cm maximum

diameter, with a median size of 6 cm

  • Round to ovoid, well-circumscribed, fleshy

masses that on cut section are solid and tan

  • Interspersed areas of hemorrhage and

yellowish necrotic areas might be present particularly in larger tumors

The 25th Annual Congress of the ADIAP The 5th International Conference of JSP 8/11/2013 32

slide-33
SLIDE 33

Microscopic features

  • The tumor is characterized by a proliferation of

spindle to ovoid cells that form fascicles, storiform patterns and whorls (360o)

  • Cells tend to be plump, with slightly eosinophilic,

fibrillary cytoplasm and indistinct cell borders

  • The nuclei are elongated, unevenly spaced, small

distinct nucleoli

  • Occasional nuclear pseudoinclusions

The 25th Annual Congress of the ADIAP The 5th International Conference of JSP 8/11/2013 33

slide-34
SLIDE 34

Microscopic features

  • Small lymphocytes are scattered throughout

the tumor and perivascular cuffing

  • Occasional binucleated and multinucleated

tumor cells may be present

  • Although highly cellular, atypia is only mild to

moderate

  • Mitotic figures: 0-10/ 10HPF
  • Necrosis can be seen in higher grade tumors

The 25th Annual Congress of the ADIAP The 5th International Conference of JSP 8/11/2013 34

slide-35
SLIDE 35

IPT variant

  • Spleen or liver
  • Prominent lymphoplasmacytic infiltrate,

masking neoplastic cells

  • Atypia is more variable within the tumor
  • Necrosis and hemorrhage are more common
  • EBV positive (EBER-ISH)
  • More aggressive

The 25th Annual Congress of the ADIAP The 5th International Conference of JSP 8/11/2013 35

slide-36
SLIDE 36

Immunophenotype

  • Normal FDC antigens: CD21, CD35, CD23, D2-40,

CXCL-13

  • Common positivity: vimentin, fascin,

desmoplakin, HLA-DR, EGFR, CD4

  • Variable positivity: CD68, S100, EMA, CD15
  • Negative: CD45, CD20, CD1a, lysozyme, MPO,

CD34, CD3, CD79a, CD30, HMB-45, CK

  • Clusterin: sensitive and specific
  • Ki-67 index: 1-25%

The 25th Annual Congress of the ADIAP The 5th International Conference of JSP 8/11/2013 36

slide-37
SLIDE 37

Treatment

  • The current approach is to apply therapeutic

guidelines similar to those used for soft tissue sarcomas of high grade

  • Complete surgical resection is the therapy of

choice

  • Adjuvant radiation or chemotherapy

decreases the rate of recurrence

The 25th Annual Congress of the ADIAP The 5th International Conference of JSP 8/11/2013 37

slide-38
SLIDE 38

Biologic behavior and Prognosis

  • The behavior of these tumors is more akin to that of a

low-grade soft tissue sarcoma than a malignant lymphoma

  • Local recurrences rate: 36%, metastasis: 28%, mostly

to LN and liver Poor prognostic factors:

  • intra-abdominal location
  • size ≥ 6 cm
  • mitotic count ≥ 5 /10 HPFs
  • coagulative necrosis
  • significant nuclear pleomorphism

The 25th Annual Congress of the ADIAP The 5th International Conference of JSP 8/11/2013 38

slide-39
SLIDE 39

Message?

  • As spindle cell tumors within lymph nodes are

rare, the diagnosis of FDCS within a node is not that difficult. However, extranodal FDCS cases are much more challenging in diagnosis because sarcomatoid carcinoma and sarcoma are by far much more common

  • Clue: morphologic features

The 25th Annual Congress of the ADIAP The 5th International Conference of JSP 8/11/2013 39

slide-40
SLIDE 40

Our patient

  • Patient still alive with disease
  • Receiving radiotherapy...
  • No surgery yet….

The 25th Annual Congress of the ADIAP The 5th International Conference of JSP 8/11/2013 40
