Capacity of Wireless Networks Anil Kumar S. Vullikanti Network - - PowerPoint PPT Presentation

Capacity of Wireless Networks Anil Kumar S. Vullikanti Network Dynamics and Simulation Science Laboratory, Virginia Bioinformatics Institute and Department of Computer Science, Virginia Tech Anil Vullikanti (Virginia Tech) Capacity of Wireless


slide-1
SLIDE 1

Capacity of Wireless Networks

Anil Kumar S. Vullikanti Network Dynamics and Simulation Science Laboratory, Virginia Bioinformatics Institute and Department of Computer Science, Virginia Tech

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 1 / 100

slide-2
SLIDE 2

Acknowledgments

Joint work with Deepti Chafekar (Nokia Research) David Levin (University of Maryland, College Park) Madhav Marathe (Virginia Tech) Guanhong Pei (Virginia Tech) Aravind Srinivasan (University of Maryland, College Park) Srinivasan Parthasarathy (IBM T.J. Watson Research Center)

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 2 / 100

slide-3
SLIDE 3

Based on following papers

V.S. Anil Kumar, M. Marathe, S. Parthasarathy. Cross-layer Capacity Estimation and Throughput Maximization in Wireless Networks, Springer Handbook on Algorithms for Next Generation Networks, pp. 67-98, 2009. V.S. Anil Kumar, M. V. Marathe, S. Parthasarathy and A. Srinivasan. Algorithmic Aspects

  • f Capacity in Wireless Networks, ACM SIGMETRICS, pp. 133-144, 33(1), 2005.

V.S. Anil Kumar, M. Marathe, S. Parthasarathy and A. Srinivasan. End-to-end packet scheduling in ad hoc networks, ACM Symposium on Discrete Algorithms (SODA), pp. 1021-1030, 2004.

  • D. Chafekar, V.S. Anil Kumar, M. Marathe, S. Parthasarathy and A. Srinivasan.

Approximating the Capacity of Wireless Networks with SINR constraints, 27th IEEE International Conference on Computer Communications (INFOCOM), pp. 1166-1174, 2008.

  • D. Chafekar, D. Levin, S. Parthasarathy, V.S. Anil Kumar, M. Marathe and A. Srinivasan.

On the capacity of asynchronous random-access wireless networks. 27th IEEE International Conference on Computer Communications (INFOCOM), pp. 1148-1156, 2008.

  • D. Chafekar, V.S. Anil Kumar, M. Marathe, S. Parthasarathy and A. Srinivasan. Cross-Layer

Latency Minimization in Wireless Networks with SINR Constraints, The ACM International Symposium on Mobile Ad Hoc Networking and Computing (MobiHoc), pp. 110-119, 2007.

  • B. Han, V.S. Anil Kumar, M. Marathe, S. Parthasarathy and A. Srinivasan. Distributed

Strategies for Channel Allocation and Scheduling in Software-Defined Radio Networks,

  • Proc. of the 28th IEEE Conference on Computer Communications (INFOCOM), Phoenix,

April 21-24, pp. 1521-1529, 2009.

  • G. Pei, V.S. Anil Kumar, S. Parthasarathy and A. Srinivasan. Approximation algorithms for

throughput maximization in wireless networks with delay constraints, IEEE Conference on Computer Communications (INFOCOM), 2011 (9 pages).

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 3 / 100

slide-4
SLIDE 4

Formulating the capacity of wireless networks

Fundamental Question

Max total rate of communication possible between a set of pairs (si, ti), i = 1, . . . , k, in a given wireless network G(V , E)? Involves choosing: Route for each connection and rate

  • f arrivals

Schedule which determines the edges to transmit at each time, and channels and power level Objectives: maximize total throughput Additional constraints: average delay, total power, fairness

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 4 / 100

slide-5
SLIDE 5

Protocol stack basics

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 5 / 100

slide-6
SLIDE 6

Modeling Physical and MAC layers

Physical layer abstraction: model broadcast region of a node as a disk (omnidirectional)

  • r sector (directional)

Distance-2 Matching model [Balakrishnan et al., 2004] N(e) = {e′ : dist(e, e′) ≤ 1}: interfering edges Tx-model [Yi et al., 2007] Transmissions Tx1 and Tx2 are si- multaneously possible if and only if d(Tx1, Tx2) ≥ (1 + ∆)(r1 + r2) Other models based on node/edge independent sets

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 6 / 100

slide-7
SLIDE 7

Other interference models

SINR model: Pairs (vi, v ′

i ) communi-

cate using power level Pi, i = 1, 2, . . . if and only if:

Pi d(vi ,v′

i )α

N + P

j=i Pj d(vj ,v′

1)α

≥ β β: gain (depends on antenna) N: ambient noise Joint physical+ MAC abstraction

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 7 / 100

slide-8
SLIDE 8

Feasible Schedules and link rates

Assumption: synchronous time slots of uniform length τ Schedule S specifies the time slots when packets move on links: X(e, t) = 1 if packet moves on edge e in time slot t S is feasible if: ∀t, X(e, t) = X(e′, t) = 1 ⇒ e, e′ do not interfere Link utilization vector, ¯ x, corresponding to S is defined as ∀e : x(e) = lim

T→∞

P

t≤T X(e, t)

T Flow rate vector, ¯ f , corresponding to S is defined as ∀e : f (e) = x(e) · cap(e), where cap(e) is the capacity of edge e.

Definition

A rate vector ¯ f is feasible if it has a corresponding feasible/stable schedule S that achieves rate ¯ f and is able to schedule all the packets in bounded time.

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 8 / 100

slide-9
SLIDE 9

Capacity - a combinatorial formulation

Setting Set V of n nodes in the plane Radius vector r = (r(v)) Directed graph G(V , r) k source destination pairs: (s1, t1), . . . , (sk, tk) Objective: Find feasible flow vector ¯ f such that There is a feasible schedule S corresponding to ¯ f Pk

i=1 fi is maximized, where fi is the

total flow out of si Additional QoS constraints: delays/fairness/total power.

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 9 / 100

slide-10
SLIDE 10

Factors influencing capacity

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 10 / 100

slide-11
SLIDE 11

Outline for this tutorial

Part I: Capacity of random networks Part II: Arbitrary networks: LP framework Part III: Dynamic control for network stability Open questions

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 11 / 100

slide-12
SLIDE 12

Outline for Part I

Basic setting, problem formulation Summary of related work Upper bound result: O( 1

√n) scaling

Lower bound: Ω(

1 √n log n) scaling

Extensions:

Directional antennas Mobility and delays Multi-channel multi-radio networks Hybrid networks

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 12 / 100

slide-13
SLIDE 13

Outline for Part II

Summary of related work LP based cross-layer formulation of the end-to-end capacity of wireless networks

Deriving linear necessary and sufficient constraints in a variety of models: O(1) approximation Inductive ordering to deal with non-uniform power levels: O(1) approximation

O(log n) approximation for Physical interference model based on SINR constraints O(1) approximation for random access networks with uniform power levels O(1) approximation for networks with adaptive channel/power allocation Logarithmic bounds on average end-to-end delays PTAS for computing maximum throughput capacity

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 13 / 100

slide-14
SLIDE 14

Outline for Part III

Background: arrival processes, queuing Backpressure algorithm and its analysis Approximate version of backpressure algorithm Random access approach Summary of related research

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 14 / 100

slide-15
SLIDE 15

Part I: capacity of random networks

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 15 / 100

slide-16
SLIDE 16

Outline for Part I

Basic setting, problem formulation Summary of related work Upper bound result: O( 1

√n) scaling

Lower bound: Ω(

1 √n log n) scaling

Extensions:

Directional antennas Mobility and delays Multi-channel multi-radio networks Hybrid networks

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 16 / 100

slide-17
SLIDE 17

Basic setting

1 n nodes distributed uniformly at random in the unit square 2 Each node has transmission range r = Θ(

q

log n n ).

3 n connections, with each node being a source for a connection, destination chosen

randomly (let si, ti denote source and destination for connection i).

4 Each connection has to support rate λ(n) 5 Each link has capacity W 6 Transport rate of connection i: connection throughput × distance between si and ti

(bit-meters/sec)

Basic Question

How does the expected per-connection throughput which can be supported by a random network evolve as n → ∞?

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 17 / 100

slide-18
SLIDE 18

Related work: capacity of random geometric networks

Initial results: Capacity scaling of Θ( p n/ log n) bit-meters/sec in protocol model of interference [Gupta-Kumar, 2001], simplifications by [Kulkarni-Vishwanatan, 2004], ... Extensions to other interference models: Capacity of Θ(√n) in SINR/Physical model of interference [Agarwal-Kumar, 2004] Extensions for different physical layer technologies: improvements using Directional antennas [Peraki, Servetto, 2003], [Yi, et al., 2003], multi-channel and multi-radio (MCMR)/cognitive networks [Kyanasur et al., 2006], [Bhandari et al., 2007] Hybrid networks: some intermediate nodes with higher bandwidth: improved capacity of Ω(√n) hybrid nodes are added [Liu, Liu, Towsley, 2003], [Negi, Rajeswaran] Impact of mobility [Grossglauser, Tse], [Bansal, Liu] Impact of delays: [El Gamal et al., 2004]

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 18 / 100

slide-19
SLIDE 19

Upper bound

[Gupta, Kumar]: tighter upper bound of λ(n) = O(

1 √n log n) (discussed in Part II)

Theorem (Yi et al., 2003)

Expected per-connection throughput is O( 1

√n).

Proof sketch Let L denote the average distance between the source and destination of a connection Each connection has rate of λ ⇒ transport capacity of nλL per second. Consider the bth bit, where 1 ≤ b ≤ λnT. Suppose it moves from its source to its destination in a sequence of h(b) hops, where the hth hop covers a distance of r h

b

  • units. We have:

λnT

X

b=1 h(b)

X

h=1

r h

b = λnTL

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 19 / 100

slide-20
SLIDE 20

Proof of upper bound (continued)

Let indicator Γ(h, b, s) be 1 if the hth hop of bit b occurs during slot s. We have

λnT

X

b=1 h(b)

X

h=1

Γ(h, b, s) ≤ Wn 2 Summing over all slots over the T- second period: H . =

λnT

X

b=1

h(b) ≤ WTn 2 Because of Tx-model of interference, disks of radius (1 + ∆) times the lengths of hops centered at the trans- mitters are disjoint.

λnT

X

b=1 h(b)

X

h=1

Γ(h, b, s)π(1+∆)2(r h

b )2 ≤ W

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 20 / 100

slide-21
SLIDE 21

Proof of upper bound (continued)

λnT

X

b=1 h(b)

X

h=1

π(1 + ∆)2(r h

b )2

≤ WT ⇒

λnT

X

b=1 h(b)

X

h=1

1 H (r h

b )2

≤ WT π(1 + ∆)2H @

λnT

X

b=1 h(b)

X

h=1

1 H (r h

b )

1 A

2

λnT

X

b=1 h(b)

X

h=1

1 H (r h

b )2( convexity)

λnT

X

b=1 h(b)

X

h=1

1 H (r h

b )

≤ s WT π(1 + ∆)2 · H

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 21 / 100

slide-22
SLIDE 22

Proof of upper bound (continued)

λnTL ≤ s WTH π(1 + ∆)2 ⇒ λnL ≤ 1 √ 2π 1 (1 + ∆)W √n bit-meters / second ⇒ λ = O( 1 √n ) Tighter upper bound using cuts and flows (discussed later)

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 22 / 100

slide-23
SLIDE 23

Lower bound

Theorem (Kulkarni et al., 2004)

Expected per-connection throughput is Ω(

1 √n log n).

Proof strategy: reduction to permutation routing.

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 23 / 100

slide-24
SLIDE 24

Step 1: partition into grid

1 Grid formed by horizontal and vertical lines uniformly spaced sn apart:

1 s2

n squarelets

  • f area s2

n.

2 Crowding factor: maximum number of nodes in any squarelet Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 24 / 100

slide-25
SLIDE 25

Reduction to permutation routing

1 ℓ × ℓ lattice of processors 2 Each processor can communicate with its adjacent vertical and horizontal neighbors

in a single slot simultaneously (with one packet being a unit of communication with any neighbor during a slot).

3 Each processor is the source and destination of exactly k packets. 4 The k × k permutation routing problem: routing all the kℓ2 packets to their

destinations.

Lemma (Kauffman et al., 1994, Kunde, 1993)

k × k permutation routing in a ℓ × ℓ mesh can be performed deterministically in

kℓ 2 + o(kℓ) steps with maximum queue size at each processor equal to k.

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 25 / 100

slide-26
SLIDE 26

Step II: Reduction to permutation routing

1 Map nodes in each specific squarelet onto a particular

processor (ℓ =

1 sn ).

2 Each node has m packets and set k = mcn. Map to

permutation routing on lattice.

3 Equivalence class for each squarelet s: squarelets

whose vertical and horizontal separation from s is an integral multiple of K squarelets:

1

K depends on ∆.

2

Transmissions only within squarelet, or to neighboring squarelets ⇒ for any transmission on e = (u, v), d(u, v) ≤ √ 5sn.

3

Minimum distance between two transmitters in the same equivalence class is (K − 2)sn.

4

By interference condition: (K − 2)sn > 2(1 + ∆) √ 5sn, or K > 4 + 2 √ 5∆. Thus, we could set K = 5 + ⌈2 √ 5∆⌉.

5

Number of equivalence classes = K 2 (a fixed constant dependent only on ∆).

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 26 / 100

slide-27
SLIDE 27

Step II: Reduction to permutation routing (contd.)

1 Construct schedule for packets on mesh. Each processor in the mesh can transmit

and receive up to four packets in the same slot.

2 Serialize transmissions of the processors not in the same equivalence class: 1

Expands the total number of steps in the mesh routing algorithm by a factor of K 2 (#

  • f equivalence classes).

2

Serialize the transmissions of a single processor: increases the total number of steps in the mesh routing by a further factor of 4.

3 m packets from all nodes reach in time 4K 2 kℓ

2 = Θ( K 2mcn sn

)

Lemma

Assuming each squarelet has at least one node, the per-connection throughput for a network with squarelet size sn and crowding factor cn is Ω( sn

cn ).

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 27 / 100

slide-28
SLIDE 28

Step II: Reduction to permutation routing (contd.)

1 Set sn =

q

3 log n n

2 With high probability, no squarelet is empty (union bound) 3 cn ≤ 3e log n (Chernoff bound). Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 28 / 100

slide-29
SLIDE 29

Extensions: directional antennas

α β Transmission beamwidth: α Reception beamwidth: β

Lemma (Yi et al., 2007)

The expected per-connection throughput in random networks with directed antennas with transmission and reception beamwidth α and β, respectively is:

λ(n) = 8 > > > > < > > > > :

cW (1+∆)2√n log n ,

Omni Tx, Omni Rv

2π α cW (1+∆)2√n log n ,

Dir Tx, Omni Rv

2π β cW (1+∆)2√n log n ,

Omni Tx, Dir Rv

4π2 αβ cW (1+∆)2√n log n ,

Dir Tx, Dir Rv

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 29 / 100

slide-30
SLIDE 30

Extensions: delays and mobility

End-to-end delay D(n): average delay between packet arrival at source and delivery at destination v(n): speed of a node T(n): expected per-node throughput

Delay-throughput tradeoffs

How does T(n) vary with D(n) and v(n)?

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 30 / 100

slide-31
SLIDE 31

Delay-throughput tradeoffs in mobile networks

Theorem (El Gamal et al., 2004)

In a mobile network with average delay D(n) and per-connection throughput T(n), we have D(n) = Θ(nT(n)) for T(n) = O(1/√n log n) D(n) = O(√n/v(n)) when T(n) = Θ(1) Several unrealistic assumptions, e.g., arbitrarily large packets and buffering

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 31 / 100

slide-32
SLIDE 32

Extensions: hybrid networks

n nodes distributed randomly, each choosing a random destination m hybrid base stations distributed randomly hybrid nodes are all connected by high capacity wired links

Theorem (Liu et al., 2003)

In a hybrid network with n nodes and m base stations, the per-connection throughput λ(m, n) satisfies: λ(m, n) = 8 < : Θ( q

1 n log nW )

if m = O( q

n log n)

Θ( mW

n )

if m = ω( q

n log n)

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 32 / 100

slide-33
SLIDE 33

Part II: approximating the capacity of arbitrary networks

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 33 / 100

slide-34
SLIDE 34

Related work: algorithms for computing capacity

Small sample of results... Formulation of rate region using LPs and conflict graphs: [Hajek, Sasaki, 1988], [Jain et al., 2003], [Kodialam and Nandagopal, 2003],... Constant factor approximation of the capacity under primary interference [Kodialam and Nandagopal, 2003] Constant factor approximation of the capacity for uniform power levels in disk graph models: [Lin, Schroff, 2005], [Kumar et al, 2005], [Kar, Sarkar, Chaporkar, 2005] Local multi-commodity flow algorithms [Awerbuch-Leighton, 1993] Stability based on Max-weight matching policy [Tassiulas-Ephrimedes, 1993] Convex programming methods for capacity [Low et al.]

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 34 / 100

slide-35
SLIDE 35

Feasible Schedules and link rates (recap)

Assumption: synchronous time slots of uniform length τ Schedule S specifies the time slots when packets move on links: X(e, t) = 1 if packet moves on edge e in time slot t S is feasible if: ∀t, X(e, t) = X(e′, t) = 1 ⇒ e, e′ do not interfere Link utilization vector, ¯ x, corresponding to S is defined as ∀e : x(e) = lim

T→∞

P

t≤T X(e, t)

T Flow rate vector, ¯ f , corresponding to S is defined as ∀e : f (e) = x(e) · cap(e), where cap(e) is the capacity of edge e.

Definition

A rate vector ¯ f is feasible if it has a corresponding feasible/stable schedule S that achieves rate ¯ f and is able to schedule all the packets in bounded time.

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 35 / 100

slide-36
SLIDE 36

Example

The flow vector f with f1 = 2/8, f2 = 1/8 corresponds to periodic schedule S, and is feasible

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 36 / 100

slide-37
SLIDE 37

Example

f1 = f2 = 1/5 for this schedule Goal: Given a network, and source-destination pairs, find a feasible flow vector f with high total throughput

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 37 / 100

slide-38
SLIDE 38

General strategy

Define suitable interference set ˆ N(e) for each link e Construct LP P(λ) with flow constraints, and congestion constraints of the form x(e) + X

e′∈ ˆ N(e)

x(e′) ≤ λ, for each e Prove that P(c1) gives necessary conditions – any feasible solution f , x satisfies the constraints of P(c1) Prove that P(c2) gives sufficient conditions – corresponding to any feasible solution

  • f ,

x of P(c2), we can construct a schedule S that corresponds to f , x

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 38 / 100

slide-39
SLIDE 39

Summary: techniques used

1 Linearization of joint physical and MAC constraints: upper bounds on the rate

region expressed by weaker linear constraints

2 Scheduling based on inductive ordering: packets on edge e scheduled after those on

edges in N≥(e) - lower bounds on the optimum

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 39 / 100

slide-40
SLIDE 40

Characterizing the Rate Region

e1 e2 e3

For any edge e: x(e) = limT→∞ P

t≤T X(e, t)/T

Capacity Constraint: One packet per edge ⇒ X(ei, t) ≤ 1 ⇒ x(ei) ≤ 1 Primary Interference: For any node, at most

  • ne incident edge is used at a time

⇒ ∀t : X(e1, t) + X(e2, t) + X(e3, t) ≤ 1 ⇒ x(e1) + x(e2) + x(e3) ≤ 1

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 40 / 100

slide-41
SLIDE 41

Throughput capacity under Primary Interference

Objective: max P

i fi Subject to:

∀i, fi = X

e=(si ,v)

f (e) (P(λ)) − X

e=(v,si )

f (e) ∀e, x(e) = f (e)/cap(e) ∀v, X

e∈N(v)

x(e) ≤ λ (C) ∀e, f (e) ≥ Observation Any feasible link utilization vector ¯ x is a feasible solution to P(1).

Lemma (Kodialam and Nandagopal, 2003)

Any solution to the program P(2/3) can be scheduled feasibly.

Theorem (Kodialam and Nandagopal, 2003)

The optimum solution to the program P(2/3) gives a 2/3-approximation to the total throughput capacity, under primary interference constraints.

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 41 / 100

slide-42
SLIDE 42

Effects of Secondary Interference

e1 e e2 e3 e4 e5 e6

X(e, t) = 1 ⇒ X(ei, t) = 0, ∀ei X(e, t) = 0 ⇒ all edges ei can simultaneously transmit ⇒ non-linear constraints Linearization X(e, t) + P6

i=1 X(ei, t) ≤ 6

⇒ x(e) + P6

i=1 x(ei) ≤ 6

Lemma

Any feasible utilization vector ¯ x satisfies the congestion constraints: ∀e = (u, v), x(e) + P

e′∈N(e) x(e′) ≤ λ.

N(e) = {e′ = (u′, v ′) : u′ ∈ N(u) ∪ N(v)}.

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 42 / 100

slide-43
SLIDE 43

Formulation Puniform(λ): uniform disks

Objective: max P

i fi Subject to:

∀i, fi = X

e=(si ,v)

f (e) − X

e=(v,si )

f (e) ∀e, x(e) = f (e)/cap(e) ∀e, x(e) + X

e′∈N(e)

x(e′) ≤ λ (Congestion Constraints) ∀e, f (e) ≥

Lemma

The constraints of program Puniform(λ) are necessary for some constant λ: every feasible utilization vector ¯ x is a feasible solution to the program Puniform(λ).

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 43 / 100

slide-44
SLIDE 44

Capacity under Uniform Power Levels

Lemma

The optimum solution to the program Puniform(1) can be scheduled feasibly. The solution ¯ x to Puniform(1) can be scheduled using a periodic greedy schedule.

Theorem

Program Puniform(1) gives an O(1)-approximation to the total throughput capacity of a wireless network with uniform power levels.

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 44 / 100

slide-45
SLIDE 45

Non-uniform power levels: problem with Puniform(1)

Large number of edges ei can transmit simultaneously X(e, t) + P

i X(ei, t) could be large

⇒ x(e) + P

e′∈N(e) x(e′) ≤ 1 could be highly

suboptimal

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 45 / 100

slide-46
SLIDE 46

Non-uniform power levels

Idea: Inductive ordering - ignore “small” edges in the constraint For e = (u, v), define r(e) = max{r(u), r(v)} N≥(e) = {e′ ∈ N(e) : r(e′) ≥ r(e)}

Lemma

∀e, t, X(e, t) + P

e′∈N≥(e) X(e′, t) ≤ λ, for a constant λ.

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 46 / 100

slide-47
SLIDE 47

Non-uniform power levels: Formulation Pnon−uniform(λ)

Objective: max P

i fi

Subject to: ∀i, fi = X

e=(si ,v)

f (e) − X

e=(v,si )

f (e) ∀e, x(e) = f (e)/cap(e) ∀e, x(e) + X

e′∈N≥(e)

x(e′) ≤ λ (Congestion Constraints) ∀e, f (e) ≥

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 47 / 100

slide-48
SLIDE 48

Non-uniform power levels: Formulation Pnon−uniform(λ)

Lemma

There is a constant λ such that the constraints ∀e, x(e) + P

e′∈N≥(e) x(e′) ≤ λ are

necessary: every feasible vector ¯ x is a feasible solution to program Pnon−uniform(λ).

Lemma

The constraints ∀e, x(e) + P

e′∈N≥(e) x(e′) ≤ 1 are sufficient: the solution to

Pnon−uniform(1) can be scheduled feasibly.

Theorem

The program Pnon−uniform(1) gives an O(1)-approximation to the total throughput capacity under non-uniform power levels.

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 48 / 100

slide-49
SLIDE 49

Necessary condition

Lemma

For any edge e and any D-2 matching E ′, |E ′ ∩ N≥(e)| ≤ λ

1 e ∈ E ′ ⇒ |E ′ ∩ N≥(e)| = 1 2 Let e ∈ E ′

Suppose e1 = (u1, v1), e2 = (u2, v2) ∈ E ′ ∩ N≥(e) u1, v1 ∈ D(u2) ∪ D(v2) D(u) ∪ D(v) can be partitioned into disjoint regions of area πr(e)2/λ

3 Let n(e) =# packets sent on e in time T 4 ∀e, n(e) + P

e′∈N≥(e) n(e′) ≤ λT

5 Set x(e) = n(e)/T Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 49 / 100

slide-50
SLIDE 50

Sufficient condition

Lemma

The constraints ∀e, x(e) + P

e′∈N≥(e) x(e′) ≤ 1 are sufficient: the solution to

Pnon−uniform(1) can be scheduled feasibly. Objective: Need to show existence of stable schedule that can send all packets Different approaches:

1 Periodic scheduling: stable, not necessarily polynomial time, in general 2 Randomized scheme: stable, centralized 3 Random access scheduling: completely local 1

Lose a factor of 1

e for synchronous random access

2

Lose a factor of O( 1

γ ), where γ is the ratio of the maximum transmission duration to

the minimum transmission duration

4 Distributed collision free scheduling: based on access hash functions Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 50 / 100

slide-51
SLIDE 51

Periodic Scheduling

Step I: Choosing time slots

1 Choose W s.t. S(e) = Wx(e) integral for each e 2 Order edges so that r(e1) ≥ . . . ≥ r(em) 3 (Inductive Scheduling) Choose time slots S(e) for edges in this order:

  • For edge ei choose any Wx(ei) slots from the set

{1, . . . , W } \ (∪j≤i−1, ej∈N≥(ei )S(ej)) Step II: Periodic scheduling For each packet, move one edge in W steps

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 51 / 100

slide-52
SLIDE 52

Example

W = 7 Need Wx(e) = 1 slot for all links other than (3, 5); Wx(3, 5) = 2 Assign slots: S(1, 2) = {1}, S(2, 3) = {2}, S(3, 4) = {3}, S(3, 5) = {4, 5},...

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 52 / 100

slide-53
SLIDE 53

When does greedy fail?

Consider the utilization vector: W = 8. Assign slots {1, . . . , 8} Consider an ordering with link (3, 5) in the end Suppose greedy assigns: S(1, 2) = {1, 2}, S(2, 3) = {3, 4}, S(3, 4) = {5}, S(5, 6) = {1, 2}, S(6, 7) = {3, 4} Not enough free slots for (3, 5)

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 53 / 100

slide-54
SLIDE 54

Periodic scheduling: proof

Lemma

For each edge ei, |{1, . . . , W } \ (∪j≤i−1,ej∈N≥(ei )S(ej))| ≥ Wx(ei)

Proof.

If not, Wx(ei) + X

j≤i−1,ej∈N≥(ei )

Wx(ej) > W which violates the congestion constraint in Pnon−uniform(1). ⇒ S(e) = W · x(e) slots can be allocated for each edge e

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 54 / 100

slide-55
SLIDE 55

Sufficient condition: proof (continued)

Schedule is valid since N() is symmetric:

Suppose e ∈ N(e′), e′ ∈ N(e), r(e′) ≥ r(e) ⇒ e′ ∈ N≥(e) Suppose e′ is scheduled at time t. Then, t ∈ S(e′). Since e′ ∈ N≥(e), slot t is not assigned to edge e

Schedule is stable (constant bit rate): in a frame of length W , number of packets required to flow through e is x(e)W , and exactly this many slots are assigned for this edge. Lyapunov technique for proving stability for stochastic arrivals

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 55 / 100

slide-56
SLIDE 56

Adding additional constraints: fairness

Objective: max P

i fi

Subject to: ∀i, fi = X

e=(si ,v)

f (e) − X

e=(v,si )

f (e) ∀e, x(e) = f (e)/cap(e) ∀v, x(e) + X

e′∈N≥(e)

x(e′) ≤ 1 ∀e, f (e) ≥ ∀i, j, fi ≤ fj/γ Fairness constraints Fairness: γ = 1 ⇒ completely fair γ = 0 ⇒ throughput maximization

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 56 / 100

slide-57
SLIDE 57

Adding additional constraints: fairness

Same approximation ratio holds Can quantify the relationship between fairness and capacity

0.5 1 1.5 2 2.5 3 3.5 4 4.5 5 5 10 15 20 25 30 35 40 Maximum throughput Number of flows Maximum throughput vs Number of flows single run averaged 1 1.2 1.4 1.6 1.8 2 2.2 2.4 2.6 2.8 3 0.001 0.01 0.1 1 Throughput Fairness index Throuput vs. Fairness k=2 k=5 k=7 k=9 k=11

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 57 / 100

slide-58
SLIDE 58

Extensions: SINR model

SINR model: If pairs (v1, v ′

1), (v2, v ′ 2), . . . communicate P1 d(v1,v′

1)α

N + P

i>1 Pi d(vi ,v′

1)α

≥ β ∀e : N(e) = E ∀e = (u, v) : N≥(e) = {e′ = (u′, v ′) : ℓ(e′) ≥ max{ℓ(e), a · d(u, u′)} Assumptions: Power levels for all links are fixed, For each edge e, cap(e) is fixed under an additive white Gaussian noise assumption

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 58 / 100

slide-59
SLIDE 59

Extensions: SINR model

∆ = maxe{ℓ(e)}/ mine′{ℓ(e′)}

Lemma

The program Pnon−uniform(λ) gives necessary conditions for a constant λ, while the program Pnon−uniform(1/ log ∆) gives sufficient conditions.

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 59 / 100

slide-60
SLIDE 60

Extensions: power constraints

Setting: S has to determine which edges e to use at time t, and what power level to use Capacity of link e at power level p cap(e, p) = W log2(1 + p d(u, v)αN0W )

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 60 / 100

slide-61
SLIDE 61

Extensions: power constraints

Setting: S has to determine which edges e to use at time t, and what power level to use Capacity of link e at power level p cap(e, p) = W log2(1 + p d(u, v)αN0W ) J= set of possible choices of power levels; need not be finite Define T (J) = {(e, p) ∈ E × J} Define N(e, p) = {(e′ = (u′, v ′), p′) : e′ ∈ V 2, p′ ∈ J, d(u, u′) ≤ (1 + ∆)(range(p) + range(p′))} Define N≥(e, p) = {(e′ = (u′, v ′), p′) ∈ N(e, p) : p′ ≥ p}

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 60 / 100

slide-62
SLIDE 62

Program Ppctm(λ)

max X

i

fi s.t.: ∀i, fi = X

(e=(si ,v),p)∈T

f (e, p) − X

(e=(v,si ),p)∈T

f (e, p) ∀(e, p) ∈ T , x(e, p) = f (e, p)/cap(e, p) ∀(e, p) ∈ T , x(e, p) + X

(e′,p′)∈N≥(e,p)

x(e, p) ≤ λ ∀i, ∀u = si, ti X

e∈Nout(u)

f (e, p) = X

e∈Nin(u)

f (e, p) X

(e,p)∈T

x(e, p) · p ≤ B B= total bound on power usage

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 61 / 100

slide-63
SLIDE 63

Joint power and throughput capacity optimization: special case

Lemma

Any feasible rate vector and power assignment must satisfy the constraints of P(c) for a constant c. Further, any solution to P(1) is feasible.

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 62 / 100

slide-64
SLIDE 64

Joint power and throughput capacity optimization: special case

Lemma

Any feasible rate vector and power assignment must satisfy the constraints of P(c) for a constant c. Further, any solution to P(1) is feasible. Assumption: |J| ≤ poly(n) ⇒ |Ppctm| is polynomial sized.

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 62 / 100

slide-65
SLIDE 65

Joint power and throughput capacity optimization: general case

Let pmax = max{p ∈ J} and pmin = min{p′ ∈ J} Assumption: pmax/pmin ≤ poly(n) J′ = {pmin, (1 + ǫ)pmin, . . . , pmax}

Lemma

The program Ppctm(1) defined using set J′ (instead of set J) gives a constant factor approximation to throughput capacity under a given bound on total power consumption.

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 63 / 100

slide-66
SLIDE 66

Extension: capacity with random access scheduling

Node v attempts to transmit on link e = (v, w) only if no neighbor of v is currently transmitting If channel free, v transmits on e with probability τ(e) Tid: idle slot length Txmit(ℓ): length of transmission on link ℓ Npri(ℓ): links within primary interference of ℓ Nsec(ℓ) = N(ℓ) \ Npri(ℓ) Probability of accessing the link ℓ: τ(ℓ) = 1 − e−x(ℓ)

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 64 / 100

slide-67
SLIDE 67

Synchronous Random Access Networks

Lemma

Let ¯ x be a feasible solution to the program P(1). Then, 1

e ¯

x can be achieved by synchronous random access scheduling. Proof: Choose τ(ℓ) = 1 − e−x(ℓ)/λ, for each ℓ. Probability of collision free transmission on edge ℓ: η(ℓ) = Πℓ′∈I(ℓ)(1 − τ(ℓ′)) = e

P

ℓ′∈I(ℓ) −x(ℓ′)

≥ ex(ℓ)−1

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 65 / 100

slide-68
SLIDE 68

Synchronous Random Access Networks

Successful flow through ℓ = cap(ℓ) · τ(ℓ) · η(ℓ) ≥ cap(ℓ) · (1 − e−x(ℓ)) · ex(ℓ)−1 = cap(ℓ) · (ex(ℓ)−1 − e−1) ≥ cap(ℓ) · „1 + x(ℓ) e − 1 e « = f (ℓ) e ⇒

1 e ¯

f is stable

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 66 / 100

slide-69
SLIDE 69

Random Access Scheduling in an Asynchronous Network

Tid: idle slot length Txmit(ℓ): transmission duration on ℓ γ =

maxℓ Txmit(ℓ) minℓ′ Txmit(ℓ′)

∆: max #simultaneous transmissions possible in N(ℓ) (interference degree)

Theorem

Let x be a feasible solution to P(1). The random access protocol with channel access probability τ(ℓ) = 1 − e

− x(ℓ)

∆(ℓ) · Tid Txmit (ℓ)(1+γ) ,

achieves a link utilization of h ≥

1 e(γ+1)∆

x.

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 67 / 100

slide-70
SLIDE 70

Asynchronous Random Access: effect of packet sizing policies

Random access is more competitive when the packet sizes on links are non-uniform, and are proportional to the link capacity

2 4 6 8 10 12 14 0.5 1 1.5 2 2.5 Flow 2’s rate (Mbps) Flow 1’s rate (Mbps) Flow 1 = 6Mbps, Flow 2 = 24Mbps 500B 750B 1000B 1250B 1500B 1750B 2000B

ℓ1 and ℓ2: hidden interfering links c(ℓ1)= 6Mbps, c(ℓ2)=24Mbps packet size on ℓ1: 500 Bytes packet size on ℓ2 varied from 500 Bytes to 2000 Bytes

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 68 / 100

slide-71
SLIDE 71

Limits on the competitive ratio of asynchronous random access scheduling

ℓ0 ℓ1 ℓ2 ℓ∆ ∀i ≥ 1, ℓi ∈ hidden(ℓ0) ∀i ≥ 1, ℓ0 ∈ hidden(ℓi) Assume Txmit(ℓi) = Txmit = a1Tid and Txmit(ℓ0) = γTxmit

  • f = 1/2, . . . , 1/2 is feasible for greedy

scheduling

Lemma

λ f is feasible for random access scheduling

  • nly if λ ≤ c log ∆γ

∆γ

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 69 / 100

slide-72
SLIDE 72

Characterizing the capacity region for random access protocols

New formulation to approximate the throughput capacity of an asynchronous random access network within an O(∆)-factor:

Theorem (Necessary Conditions)

  • x is feasible for asynchronous random access protocol only if:

∀ℓ : x(ℓ) + X

ℓ′∈exposed(ℓ)

x(ℓ′) + X

ℓ′∈hidden(ℓ)

x(ℓ′) · (1 + Txmit(ℓ) − Tid Txmit(ℓ′) ) ≤ ∆

Theorem (Sufficient Conditions)

  • x is feasible for asynchronous random access protocol if:

∀ℓ : x(ℓ) + X

ℓ′∈exposed(ℓ)

x(ℓ′) + X

ℓ′∈hidden(ℓ)

x(ℓ′) · (1 + Txmit(ℓ) − Tid Txmit(ℓ′) ) ≤ 1 e

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 70 / 100

slide-73
SLIDE 73

Extension: multi-channel multi-radio networks

Graph G = (V , E) For each node u ∈ V , Radios(u): set

  • f wireless interfaces associated with it.

Set Ψ of channels available Schedule + channel assignment: at each time t, choose links e = (u, v) which will transmit, which radio interfaces to use at u, v and which channel to use Induced Radio Network G = (V, L): V is the set ∪uRadios(u) and L = ∪e=(u,v)∈ERadios(u) × Radios(v) For link ℓ = (ρ, ρ′), parent(ℓ) = (u, v) if ρ ∈ Radios(u) and ρ′ ∈ Radios(v) Consider set T = {(ℓ, ψ) : ℓ ∈ L, ψ ∈ Ψ}

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 71 / 100

slide-74
SLIDE 74

Necessary conditions for scheduling

For link ℓ = (ρ, ρ′) in induced radio network G = (V, L): Pri(ℓ) = {ℓ′ sharing a radio with ℓ} Pri≻(ℓ) = {ℓ′ ∈ Pri(ℓ) : parent(ℓ′) ≻ parent(ℓ)} Sec(ℓ) = {ℓ′ : parent(ℓ′) ∈ Pri(parent(ℓ))} ∪ {ℓ′ : parent(ℓ′) ∈ Sec(parent(ℓ))} Sec≻(ℓ) = {ℓ′ ∈ Succ(ℓ) : parent(ℓ′) ≻ parent(ℓ)}

Theorem

Flow constraints with the following congestion constraints are necessary for any feasible flow+utilization vector: x(ℓ, ψ) + X

ρ∈Ψ\{ψ}

x(ℓ, ρ) + X

χ∈Ψ

X

f ∈Pri≻(ℓ)

x(f , χ) + X

g∈Sec≻(ℓ)

x(g, ψ) ≤ λ + 2

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 72 / 100

slide-75
SLIDE 75

Sufficient conditions

Theorem

The rate vector satisfying the following conditions can be scheduled feasibly: ∀(ℓ, ψ), x(ℓ, ψ) + X

ρ∈Ψ\{ψ}

x(ℓ, ρ) + X

χ∈Ψ

X

f ∈Pri(ℓ)

x(f , χ) + X

g∈Sec(ℓ)

x(g, ψ) ≤ 1 e − ǫ

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 73 / 100

slide-76
SLIDE 76

Random Access Hash Functions

Need access-hash function H(ℓ, ψ, t) such that: H(ℓ, ψ, t) =  1 with probability 1 − e−e·x(ℓ,ψ) with probability e−e·x(ℓ,ψ) Key Property: Value of H(., ., ) fixed no matter who invokes it with the same arguments Also known as random oracles in Cryptography SHA-1 works well in practice

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 74 / 100

slide-77
SLIDE 77

Algorithm PLDS

Executed by each radio ρ:

1 ∀ℓ incident on ρ: compute H(ℓ, ψ, t), for each ψ, t. 2 Randomly pick a pair (ℓ, ψ) s.t. H(ℓ, ψ, t) = 1

  • if no such pair exists, sleep during time t

3 If selected link ℓ ∈ Lout(ρ), then schedule an outgoing transmission across ℓ on

channel ψ at time t

4 if selected link ℓ ∈ Lin(ρ), then tune to channel ψ and await an incoming

transmission across ℓ on channel ψ at time t

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 75 / 100

slide-78
SLIDE 78

Extensions: Bounding Delays

Goal: choose flow vector f so that: P

i fi is maximized

For each session i such that fi > 0, average delay for each packet is at most D

Our Result

Careful choice of paths plus random access scheduling to get joint bounds on throughput and delays.

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 76 / 100

slide-79
SLIDE 79

Choosing routes and flows

Choose flow f that maximizes P

i fi subject to:

∀i, X

p∈P(i)

f (p)cost(p) ≤ Dfi ∀(e, i), x(e, i) = X

p∈P(i): e∈p

f (p)/cap(e) ∀e, X

i

x(e, i) + X

e′∈N(e)

X

i

x(e′, i) ≤ 1 (Filter) Drop flows on paths longer than 2D for each i (Round) Choose a subset S of sessions and a path pi for each i ∈ S by iterative rounding (Choose flows) Choose flow f (pi) = K log log D/ log D

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 77 / 100

slide-80
SLIDE 80

Joint Delay-Throughput Tradeoffs

Theorem

The flow vector f along with random access scheduling ensures that P

i fi = Ω(OPT · log log D/ log D), and at least (1 − 1/n)-fraction of the packets for each

session i are delivered within a delay of O(D · (log D/ log log D) · log n). Adaptive channel switching delays can be incorporated into the framework in terms

  • f cost(p) to quantify the throughput gains of adaptive channel switching

Similar tradeoffs for adaptive power switching

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 78 / 100

slide-81
SLIDE 81

Summary: General strategy

Define suitable interference set ˆ N(e) for each link e Construct LP P(λ) with flow constraints, and congestion constraints of the form x(e) + X

e′∈ ˆ N(e)

x(e′) ≤ λ, for each e Prove that P(c1) gives necessary conditions – any feasible solution f , x satisfies the constraints of P(c1) Prove that P(c2) gives sufficient conditions – corresponding to any feasible solution

  • f ,

x of P(c2), we can construct a schedule S that corresponds to f , x

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 79 / 100

slide-82
SLIDE 82

Summary

Two techniques for cross-layer formulation of the end-to-end capacity of wireless networks

Linearization of interference constraints Inductive ordering to deal with non-uniform power levels

Framework extends to a number of models, constraints and objective functions

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 80 / 100

slide-83
SLIDE 83

Part III: Dynamic control for network stability

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 81 / 100

slide-84
SLIDE 84

Outline for Part III

Background: arrival processes, queuing Backpressure algorithm and its analysis Approximate version of backpressure algorithm Random access approach Summary of related research

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 82 / 100

slide-85
SLIDE 85

Background

“Arrivals at all sources are well-behaved”

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 83 / 100

slide-86
SLIDE 86

Background

“Arrivals at all sources are well-behaved”

1 Let Ai(t) be the exogenous arrival process for connection i with rate λi 2 An arrival process Ai(t) is admissible with rate λi if 1

The time averaged expected arrival rate satisfies: lim

t→∞

1 t

t−1

X

τ=0

E[Ai(τ)] = λ

2

Let H(t) represent the history until time t There exists Amax such that E[(Ai(t))2 | H(t)] ≤ A2

max for t.

3

For any δ > 0, there exists an interval size T, possibly dependent on δ, such that for any initial time t0: E " 1 T

T−1

X

k=0

Ai(t0 + k)|H(t0) # ≤ λ + δ

Other models: adversarial arrivals

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 83 / 100

slide-87
SLIDE 87

Background (continued)

Each node v maintains queues for each link (v, w) and each connection i Assume unbounded buffer sizes – no packet drops because of buffer overflows Let Ui

v(t) denote the queue at node v for connection i at time t; let U(t) = Ui v(t)

µi

(u,v)(t) ≤ c(u, v): data rate allocated to commodity i during slot t across the link

(u, v) by the network controller.

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 84 / 100

slide-88
SLIDE 88

Capacity region revisited

I ⊂ E is a conflict free subset if for every e, e′ ∈ I, e and e′ are conflict-free. Let I denote the set of all possible conflict-free subsets I ⊂ E Let µ(I) denote the vector of transmission rates for each e ∈ I. Let Γ . = Conv({ µ(I) | I ∈ I}) denote the convex hull of all transmission-rate matrices Let inflowi

v,µ(t) = P (w,v)∈E µi (w,v)(t) denote the flow of commodity i into node v

for policy µ at time t Let outflowi

v,µ(t) = P (v,w)∈E µi (v,w)(t) denote the flow of commodity i out of node

v for policy µ at time t Let netflowi

v,µ(t) = outflowi v,µ(t) − inflowi v,µ(t) denote the total flow of commodity

i out of node v for policy µ at time t

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 85 / 100

slide-89
SLIDE 89

Example

Assume primary interference: edges with common end-point conflict Two connections (s1, t1) and (s2, t2) Γ = {αI1 + βI2 : α + β ≤ 1} Traffic matrix corresponding to µ = 2

3I1 + 1 3I2

inflow1

2,µ(t) = µ1 (1,2) = 2/3

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 86 / 100

slide-90
SLIDE 90

Capacity region

Theorem (Grigoriadis et al., 2006)

The connection rate vector λi is within the network-layer capacity region Λ if and only if there exists a randomized network control algorithm that makes valid µi

(u,v)(t)

decisions, and yields: ∀i, E[netflowi

si ,µ(t)] = λi

∀i, ∀w / ∈ {si, ti}, E[netflowi

w,µ(t)] = 0

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 87 / 100

slide-91
SLIDE 91

Backpressure algorithm

At each time t For each link (v, w): let i = i∗ be the commodity with maximum differential backlog ∆Ui

v − Ui w

For each link (v, w), define weight(v, w) to be the maximum differential backlog Choose independent set I with maximum weight wt(I) = P

e∈I wt(e)

Schedule all links in I simultaneously, and send as much as possible

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 88 / 100

slide-92
SLIDE 92

Example

Assume primary interference: edges with common end-point conflict Two connections (s1, t1) and (s2, t2) Γ = {αI1 + βI2 : α + β ≤ 1} ∆U1

(1,2) = 5, ∆U2 (1,2) = −35

⇒ i∗

(1,2) = 1, W ∗ (1,2) = 5

∆U1

(2,3) = 15, ∆U2 (2,3) = 5

⇒ i∗

(2,3) = 1, W ∗ (2,3) = 15

∆U1

(3,4) = 0, ∆U2 (3,4) = 30

⇒ i∗

(3,4) = 2, W ∗ (3,4) = 30

wt(I1) = 5 + 30 = 35, wt(I2) = 15

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 89 / 100

slide-93
SLIDE 93

Backpressure algorithm

At each time t For each link (v, w): let i∗

(v,w)(t) denote the connection which

maximizes the differential backlog W ∗

(v,w)(t) = U i∗

(v,w)(t)

v

(t) − U

i∗

(v,w)(t)

w

(t). Choose conflict-free link set I ∗ ∈ I which maximizes P

(u,v)∈I ∗ W ∗ (u,v)(t) · c(u, v)

The network controlled chooses links e = (u, v) ∈ I ∗ and connection i∗

(u,v)(t) if W ∗ (u,v)(t) > 0 (if there is not enough backlogged data, i.e.,

U

i∗

(u,v)(t)

(u,v)

(t) < c(u, v) use dummy bits)

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 90 / 100

slide-94
SLIDE 94

Analysis

Consider any valid resource allocation policy that assigns a rate of ˜ µi

(u,v)(t) to

commodity i across link (u, v) at time t. Let µi

(u,v)(t) denote the corresponding values for the dynamic backpressure

algorithm. By construction: X

(u,v)

X

i

˜ µi

(u,v)(t)[Ui u(t) − Ui v(t)]

≤ X

(u,v)

X

i

˜ µi

(u,v)(t)W ∗ (u,v)(t)

≤ X

(u,v)

W ∗

(u,v)(t) · µ(u, v)

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 91 / 100

slide-95
SLIDE 95

Analysis (continued)

Rearranging the terms: “P

v of queue-size at v· netflow(v) = P e flow(e)·backlog(e)”

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 92 / 100

slide-96
SLIDE 96

Analysis (continued)

Rearranging the terms: “P

v of queue-size at v· netflow(v) = P e flow(e)·backlog(e)”

X

i

X

v

Ui

v(t) · [

X

w

µi

(v,w)(t)

− X

u

µi

(u,v)(t)]

= X

(u,v)

X

i

µi

(u,v)(t)[Ui u(t) − Ui v(t)]

Lemma (Property)

If ˜ µi

(u,v)(t) denotes any resource allocation policy, and µi (u,v)(t) denotes the resource

allocation for the Backpressure scheme, we have: X

v

X

i

Ui

v(t)[

X

w

˜ µi

(v,w)(t)

− X

u

˜ µi

(u,v)(t)]

≤ X

v

X

i

Ui

v(t)

"X

w

µi

(v,w)(t) −

X

u

µi

(u,v)(t)

#

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 92 / 100

slide-97
SLIDE 97

Lyapunov functions

Define: L(U(t)) = X

i

X

v

(Ui

v(t))2

Theorem (Grigoriadis et al., 2006)

If there exist constants B > 0 and ǫ > 0 such that for all slots t: E[L(U(t + 1)) − L(U(t)) | U(t)] ≤ B − ǫ X

v

X

i

Ui

v(t)

(1) then, the network is strongly stable.

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 93 / 100

slide-98
SLIDE 98

Analysis of backpressure

Theorem

Let λ denote the vector of arrival rates; if there exists an ǫ > 0 such that λ + ǫ ∈ Λ (where ǫ is the vector such that ǫi = 0 if λi = 0, and ǫi = ǫ otherwise), then the dynamic backpressure algorithm stably services the arrivals.

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 94 / 100

slide-99
SLIDE 99

Analysis of backpressure

If V , U, µ, A ≥ 0 and V ≤ max{U − µ, 0} + A, then, V 2 ≤ U2 + µ2 + A2 − 2U(µ − A) Since Ui

v(t + 1) ≤ max{Ui v(t) − P e=(v,w) µi e(t), 0} + P i Ai(t) + P e=(u,v) µi e(t), we

have: Ui

v(t + 1)2 ≤ Ui v(t)2 +

`P

w µi (v,w)(t)

´2 + ` Ai

v(t) + P u µi (u,v)(t)

´2 − 2Ui

v(t) ·

`P

w µi (v,w)(t) − Ai v(t) − P u µi (u,v)(t)

´

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 95 / 100

slide-100
SLIDE 100

Analysis (continued)

Summing over all indices (v, i) and since P

j z2 j ≤ (P j zj)2, if zj ≥ 0,

L(U(t + 1)) − L(U(t)) ≤ 2BN − 2 X

v

X

i

Ui

v(t) ·

X

w

µi

(v,w)(t) − Ai v(t) −

X

u

µi

(u,v)(t)

! ,

where B . =

1 2N · P v[(maxw µ(v, w))2 + (maxi Ai + maxu µ(u, v))2].

⇒ E[L(U(t + 1)) − L(U(t)) | U(t)] ≤ 2BN + 2 · X

i

Ui

si (t) · E[Ai si (t) | U(t)] −

2E[ X

v

X

i

Ui

v(t) ·

@X

w

µi

(v,w)(t) −

X

(u,v)

µ(u,v)(t) 1 A | U(t)]

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 96 / 100

slide-101
SLIDE 101

Analysis (continued)

Simple algebra: “expected change in potential ≤ constant +2 · P

i Ui si (t) expected-arrival at si − 2 P v E[Ui v(t) netflow(v)]”

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 97 / 100

slide-102
SLIDE 102

Analysis (continued)

Simple algebra: “expected change in potential ≤ constant +2 · P

i Ui si (t) expected-arrival at si − 2 P v E[Ui v(t) netflow(v)]”

⇒ E[L(U(t + 1)) − L(U(t)) | U(t)] ≤ 2BN + 2 · X

i

Ui

si (t) · E[Ai si (t) | U(t)] −

2E[ X

v

X

i

Ui

v(t) · (

X

w

µi

(v,w)(t) −

X

(u,v)

µ(u,v)(t)) | U(t)]

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 97 / 100

slide-103
SLIDE 103

Analysis (continued)

By definition of arrival process: E[Ai

si (t) | U(t)] = λi for all commodities i.

For optimal allocation vector ˜ µ:

∀i, E[total flow out of si for ˜ µ] = λi + ǫi ∀i, E[total flow out of v for ˜ µ] = 0, for all v = si, ti

Backpressure algorithm maximizes

E[P

v

P

i Ui v(t) ·

“P

w µi (v,w)(t) − P (u,v) µ(u,v)(t)

” | U(t)] at each step t ⇒ E[ X

v

X

i

Ui

v(t) · (

X

w

µi

(v,w)(t) −

X

(u,v)

µ(u,v)(t)) | U(t)] ≥ X

i

Ui

si (t)(λi + ǫi)

⇒ E[L(U(t + 1)) − L(U(t)) | U(t)] ≤ 2BN − 2 X

i

Ui

si (t)ǫi ,

which implies stability of backpressure algorithm with arrival rates λ if λ + ǫ is stable.

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 98 / 100

slide-104
SLIDE 104

Approximate max-weight independent set

Finding max-weight independent set is NP-complete in most interference models Approximating the max-weight independent set within a γ-factor implies γ-factor approximation of the rate region, γ > 1:

Suppose γ λ ∈ Γ, and λi is the arrival rate for connection i In earlier analysis: P

i Ui si (t) · E[Ai si (t) | U(t)] = P i λiUi si (t)

For any policy ˜ µ, approximate backpressure implies: X

(u,v)

X

i

˜ µi

(u,v)(t)[Ui u(t) − Ui v (t)]

≤ X

(u,v)

X

i

˜ µi

(u,v)(t)W ∗ (u,v)(t)

≤ γ X

(u,v)

W ∗

(u,v)(t) · µ(u, v)

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 99 / 100

slide-105
SLIDE 105

Approximate max-weight independent set

Finding max-weight independent set is NP-complete in most interference models Approximating the max-weight independent set within a γ-factor implies γ-factor approximation of the rate region, γ > 1:

Suppose γ λ ∈ Γ, and λi is the arrival rate for connection i In earlier analysis: P

i Ui si (t) · E[Ai si (t) | U(t)] = P i λiUi si (t)

For any policy ˜ µ, approximate backpressure implies: X

(u,v)

X

i

˜ µi

(u,v)(t)[Ui u(t) − Ui v (t)]

≤ X

(u,v)

X

i

˜ µi

(u,v)(t)W ∗ (u,v)(t)

≤ γ X

(u,v)

W ∗

(u,v)(t) · µ(u, v)

Rearranging terms: 1 γ X

v

X

i

Ui

v(t)[

X

w

˜ µi

(v,w)(t)

− X

u

˜ µi

(u,v)(t)]

≤ X

v

X

i

Ui

v(t)

"X

w

µi

(v,w)(t) −

X

u

µi

(u,v)(t)

#

Implies stability condition for approximate backpressure

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 99 / 100

slide-106
SLIDE 106

Summary

Approximation algorithm for one-hop weighted link scheduling problem ⇒ approximation algorithm for end-to-end throughput capacity in general interference models. Greedy scheduling gives O(1)-factor approximation to max-weight scheduling in many models Limitations:

Does not immediately give us a way to compute the approximate rate vector λ – need additional characterization Convergence time not necessarily polynomial time

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 100 / 100

slide-107
SLIDE 107

Open problems

SINR models Distributed algorithms Delay-throughput tradeoffs Incorporating specific protocols for different layers Power constraints Adaptive channel switching, cognitive networks New paradigms: Cooperative networking, Physical layer advances, information theoretic bounds

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 101 / 100

slide-108
SLIDE 108

Thank You

Anil Vullikanti (Virginia Tech) Capacity of Wireless Networks 102 / 100
