Canto Highlights Developed on the updated N & W electronic - - PowerPoint PPT Presentation

Canto

Highlights

• Developed on the updated N & W electronic platform
• Patented FB Sigma brewing system for tea, Z4000 espresso

unit for bean coffee and FREEMIX technology for instant drinks

• New design of the Z4000 espresso unit makes it much

easier to remove

• Large colour display for improved visibility (16 different

colours available

• Colour coded internal parts for ease of maintenance and
• peration
• Available with an optional still or still and carbonated

chiller unit for cold drinks

• New pre and post selection software available
• Full range available including 7oz, 9oz and 12oz

Design and User Interface

• New Necta design, elegant, clean, simple and can be

banked with other new machines in the Necta range; Festival, Samba and Diesis

• LED light path at coin entry, product delivery and coin

return, guides the user through the vend process

• Compatible with all major payment/ cashless systems
• Available with an optional video screen with or without

sound, to display video or advertising messages

• Wide selection of drinks, thanks to an increased number
• f 22 direct selection buttons
• New transparent cup columns allow for a quick visual

check of the cup levels

• Different branding options available
• Also available in numeric version

Branding – 7/9oz Canto

Branding – 12oz Canto

UK Specifications – Instant

CANISTER CAPACITIES INGREDIENT LITRES KILOS Sugar 4.5 4.5 Whitener 4.5 1.4 Chocolate 6.0 3.6 Topping 6.0 1.9 Decaff Coffee 2.5 0.6 Coffee 4.5 1.3 Tea 4.5 2.7 Soup 4.5 3.3

Instant – Standard Drinks Menu

Coffee / Tea Strength -  Coffee / Tea Strength +  Sugar  Extra Sugar  Coffee Black  Tea Black  Coffee White  Tea White  Espresso  Soup  Coffee Black Decaff  Chocomilk  Coffee White Decaff  Espresso Decaff  Cappuccino  Cappuccino Decaff  Café Latte  Café Latte Decaff  Espressochoc  Espressochoc Decaff  Chocolate  Hot Water 

UK Specifications - SFB

CANISTER CAPACITIES INGREDIENT LITRES KILOS FB Tea 10.5 4.5 Sugar 4.5 4.5 Milk 6 1.9 Decaff Coffee (INS) 2.5 0.6 Coffee (INS) 4.5 1.3 Soup 2.5 1.9 Chocolate 6 3.6

SFB – Standard Drinks Menu

Coffee / Tea Strength -  Coffee / Tea Strength +  Sugar  Extra Sugar  Coffee Black  Fresh brew Tea Black  Coffee White  Fresh brew Tea White  Coffee Black Decaff  Chocolate  Coffee White Decaff  Chocomilk  Cappuccino  Cappuccino Decaff  Café Latte  Café Latte Decaff  Espressochoc  Espressochoc Decaff  Espresso  Espresso Decaff  Soup  Hot Water 

UK Specifications - ESFB

CANISTER CAPACITIES INGREDIENT LITRES KILOS Beans 15 5.3 Coffee (INS) 4.5 1.3 Chocolate 4.5 2.7 Sugar 4.5 4.5 Milk 4.5 1.4 FB Tea 10 4.0

ESFB – Standard Drinks Menu

Coffee / Tea Strength -  Coffee / Tea Strength +  Sugar  Extra Sugar  Bean Coffee Black  Fresh brew Tea Black  Bean Coffee White  Fresh brew Tea White  Instant Coffee Black  Chocolate  Instant Coffee White  Chocomilk  Bean Cappuccino  Instant Cappuccino  Bean Café Latte  Instant Café Latte  Bean Espressochoc  Instant Espressochoc  Bean Espresso  Instant Espresso   Hot Water 

Dimensions

Height 1830 mm Width 650 mm Depth 760mm Weight 170 Kg Depth with door

• pen 1320mm

Instant FREEMIX Technology

• Newly designed mixers and adjustable

ingredient motors whose speed can be customized according to individual needs (quality vs speed): powders flow, speed mixing

• More drink creation flexibility
• 5 parts to creating your drink – choose to

dispense the coffee, milk, chocolate and water in whatever order you choose

• Easier to remove and clean

Energy Consumption

Canto is an environmental friendly and low consumption vending machine thanks to:

• New low consumption LED lighting

behind the panels replacing the fluorescent tubes

• Overall energy consumption has been

reduced by 30% in comparison with Astro
