29 th ICTCT Workshop in Lund, Sweden on 20 th 21 st October 2016 Can the Delphi method complement or replace time-based measuring of conflicts between vulnerable road users? Masters thesis Roads & Traffic Department of Civil

slide-1
SLIDE 1

1

Can the Delphi method complement or replace time-based measuring of conflicts between vulnerable road users?

Master’s thesis Roads & Traffic Department of Civil Engineering Aalborg University

Morten Lind Jensen Via Trafik Rådgivning mlj@viatrafik.dk

29th ICTCT Workshop in Lund, Sweden on 20th – 21st October 2016

slide-2
SLIDE 2

2

  • Conflicts between vulnerable road users
  • How to define a serious conflict?
  • A need for an alternative method?
  • Visual assessment of conflict severity
  • The Delphi method
  • Results obtained
  • Method development

Agenda

2

slide-3
SLIDE 3

3

Conflicts between vulnerable road users

A case study

  • Vulnerable road users:
  • Pedestrians
  • Cyclists (mopeds included)
  • Video based before and after study
  • Case study
  • Four T-junctions in Aalborg
slide-4
SLIDE 4

4

Conflicts between vulnerable road users

A case study

Before After

slide-5
SLIDE 5

5

Conflicts between vulnerable road users

A case study

Conflict between a cyclist (2) from left and a straight going cyclist (1) before entering the T-junction. Conflict between a pedestrian (2) from right or left and a straight going cyclist (1) before entering the T- junction. Conflict between a pedestrian (2) from right or left and a straight going cyclist (1) when leaving the T- junction.

slide-6
SLIDE 6

6

Simultanious arrival:

Two or more road users arrive at the same conflict zone within 3.00 seconds. A potential for a serious conflict.

Measure of risk:

Conflict zone

Conflict risk = Serious conflicts Simultanious arrivals t2 – t1 ≤ 3.00 sec

How to define a serious conflict?

slide-7
SLIDE 7

7

How to define a serious conflict?

7

  • Traditional time-based conflict technique
  • Distance parameter?

– TA – TTC – TET – TIT – PET – TAdv – T2 –

….

slide-8
SLIDE 8

8

How to define a serious conflict?

8

  • Traditional time-based conflict technique
  • Distance parameter?

– TA – TTC – TET – TIT – PET – TAdv – T2 –

….

Collision course: TTCmin ≤ 1.00 sec Crossing course: T2,min ≤ 0.55 sec

slide-9
SLIDE 9

9

How to define a serious conflict?

9

TTCmin = 0.66 sec T2,min = 0.12 sec Serious conflict

slide-10
SLIDE 10

10

How to define a serious conflict?

10

T2,min = 1.20 sec No conflict

slide-11
SLIDE 11

11

How to define a serious conflict?

11

TTCmin = 0.06 sec T2,min = 1.18 sec Serious conflict

slide-12
SLIDE 12

12

How to define a serious conflict?

12

1 2 3 4 5 1 2 3 4 Time-to-Collision [sec] Time [sec] TTC T2

Collision course: TTCmin ≤ 1.00 sec Crossing course: T2,min ≤ 0.55 sec

slide-13
SLIDE 13

13

  • Cyclists and pedestrians are often seen in close interaction
  • Can easily adapt to changes in speed and direction
  • Expresses efficient traffic flow

A need for an alternative method?

13

Is time span a usefull factor when assessing severity of conflicts between vulnerable road users?

slide-14
SLIDE 14

14

  • Definition of a serious conflict by visual assessment:

A simultanious arrival where at least one of the road users make a hazardous reaction just prior to the conflict zone.

  • How to assess conflict severity?

Visual assessment of conflict severity

14

slide-15
SLIDE 15

15 The Delphi method in general:

  • Experts are consulted
  • Uncertainty regarding a given topic
  • Consensus building
  • Multible rounds of questioning
  • Distribution of responses are presented before next round

The Delphi method

15

slide-16
SLIDE 16

16 This Delphi study:

  • 30 experts (professionals with sound knowledge of traffic safety)
  • Assess conflict severity
  • Two rounds of questioning
  • 50 potential conflicts are categorized in four levels of interaction:
  • 0. No interaction
  • 1. Early interaction
  • 2. Late interaction / Slight conflict
  • 3. Breakdown / Serious conflict
  • Measuring consensus: IQR (Inter Quartile Range)

The Delphi method

16

slide-17
SLIDE 17

17

The Delphi method

17

0% 15% 54% 31% 0% 0% 77% 23% 0% 20% 40% 60% 80% 100% Runde 1 Runde 2

Round 1 Round 2 No interaction Early interaction Slight conflict Serious conflict

slide-18
SLIDE 18

18

The Delphi method

18

0% 15% 54% 31% 0% 0% 77% 23% 0% 20% 40% 60% 80% 100% Runde 1 Runde 2

Round 1 Round 2 No interaction Early interaction Slight conflict Serious conflict

slide-19
SLIDE 19

19

The Delphi method

19

0% 15% 54% 31% 0% 0% 77% 23% 0% 20% 40% 60% 80% 100% Runde 1 Runde 2

Round 1 Round 2 No interaction Early interaction Slight conflict Serious conflict

slide-20
SLIDE 20

20

The Delphi method

20

0% 15% 54% 31% 0% 0% 77% 23% 0% 20% 40% 60% 80% 100% Runde 1 Runde 2

Round 1 Round 2 No interaction Early interaction Slight conflict Serious conflict

Consensus = Slight conflict

slide-21
SLIDE 21

21

  • 227 hours of video
  • 43,000 vulnerable road users:

– 24,000 cyclists – 19,000 pedestrians

  • 846 simultanious arrivals:

– Before: 372 – After: 474

Results obtained

21

Period Number of serious conflicts Time-based Delphi Before 12 4 After 9

Time-based Both methods Delphi

18 3 1

slide-22
SLIDE 22

22

  • 227 hours of video
  • 43,000 vulnerable road users:

– 24,000 cyclists – 19,000 pedestrians

  • 846 simultanious arrivals:

– Before: 372 – After: 474

Results obtained

22

Period Conflict risk* Time-based Delphi Before 3.2 1.1 After 1.9 0.0

*Pr. 100 simultanious arrivals

Time-based Both methods Delphi

18 3 1

slide-23
SLIDE 23

23 Consensus building:

  • Round 1: Consensus in 47 of 50 potential conflicts
  • Round 2: Consensus in all 50 potential conflicts

Assessment of severity:

  • Based on visible reactions
  • No reaction  No conflict

Results obtained

23

slide-24
SLIDE 24

24 Include other interaction parameters?

Reactions: Additional behaviour: Personal characteristics:

  • Accelerations
  • Gestures
  • Sex
  • Braking
  • Orientation
  • Age
  • Changing course
  • Body language
  • Disability
  • (Auditive contact)
  • Injury risk

Method development

24

This project

slide-25
SLIDE 25

25

Method development

Full length of the conflict It went well… Trimmed conflict What happens next? 25

slide-26
SLIDE 26

26 Fixed group of 8-10 respondents:

– Familiar with the method – Reduce instructions and time usage

Conflict risk <=> Accident risk How are these measures related?

Method development

26

slide-27
SLIDE 27

27

Can the Delphi method complement or replace time-based measuring of conflicts between vulnerable road users?

27

slide-28
SLIDE 28

28

Can the Delphi method complement or replace time-based measuring of conflicts between vulnerable road users?

28

slide-29
SLIDE 29

29

THANK YOU!

Morten L. Jensen Traffic Planner Via Trafik Rådgivning mlj@viatrafik.dk Harry Lahrmann Associate Professor Aalborg University hsl@civil.aau.dk Tanja K.O. Madsen PhD Fellow Aalborg University tkom@civil.aau.dk
