C18 Computer Vision

Lecture 8

Recovering 3D from two images II: stereo correspondences, triangulation.

Computer Vision: This time…

• 5. Imaging geometry, camera calibration.
• 6. Salient feature detection and description.
• 7. Recovering 3D from two images I: epipolar

geometry. 8.

• 8. Recoveri

ring 3D fr from tw two im images II: II: stereo corr rrespondences, tria riangula latio ion, neural l nets.

1. The Correspondence Problem 2. Triangulation for Depth Recovery. 3. 1- views? 4. 2+ views?.

Reconstruction from two views

• We have seen that because the projection onto a

second camera of the back-projected ray from the first is a straight line, the search for potential matches lies (mostly) across epipolar lines.

• Search occurs (mostly ☺) in 1D, which must be less

demanding than 2D search throughout the image.

• We have seen how knowledge of the camera matrices

allows us to recover the fundamental matrix, which defines this epipolar geometry.

What next?

• The key tasks now are:
• 1. Determining which points in the images are from the

same scene location - the correspondence problem.

– We will discuss how to obtain sparse and dense correspondences.

• 2. Determining the 3D structure by back-projecting rays,
• r tria

triangulation.

– Although triangulation seems straightforward, it turns out to be a non-trivial estimation problem to which there are several approaches.

8.1 Establishing Correspondence

• With knowledge of the fundamental matrix, we

are able to reduce the search for correspondence down to a search along the epipolar line 𝐦′ = 𝑮𝐲.

• Correspondence algorithms can be either:

– Sparse: correspondence is sought for individual corner

• r edge features; or

– Dense: correspondences are sought for all the pixels in an image.

• We will use both methods.

Sparse Correspondences

• Aim to match the points we found in lecture 2

(corners and/or SIFTs).

• Outline:
• 1. Extract image points – same as in L2.
• 2. Obtain initial corner matches using local

descriptors.

• 3. Remove outliers and estimate the fundamental

matrix 𝑮 using RANSAC.

• 4. Obtain further corner matches using 𝑮.

Why salient points, especially?

• They make the algorithm faster, more efficient

and sometimes more robust.

• Salient points are:

– relatively sparse; – reasonably cheap to compute; – well-localized; – appear quite robustly from frame to frame.

Initial Matching

• Extract salient points (SIFT, Harris, etc.) in both

images (feature detection).

• For each corner 𝐲 in C, make a list of potential

matches 𝐲′ in a region in C′ around 𝐲 (heuristic).

• Rank the matches by comparing the regions

around the corners using e.g. the L2 norm of the SIFT descriptor or cross-correlation (see later).

• Process them to reconcile forward-backward

inconsistencies.

• The idea here is to not to do too much work —

just enough to get some good matches.

Initial Matching (example using Harris Corners)

Initial Matching

Matches — some good matches, some mismatches. Can still compute 𝑮 with around 50% mismatches. How?

RANSAC – RANdom SAmple Concensus

• Suppose you tried to fit a straight line to data containing out
• utli

liers — points which are not properly described by the assumed probability distribution.

• The usual methods of least squares are hopelessly corrupted.
• Need to detect outliers and exclude them.
• Use estimation based on robu
• bust statis

istic ics RANSAC was the first, devised by vision researchers, Fischler & Bolles (1981).

RANSAC algorithm for lines

• 1. For many repeated trials:

1. Select a random sample of tw two points. 2. Fit a line through them.

• 3. Count how many other points are within a threshold

distance of the line (in inliers).

• 2. Select the line with the largest number of inliers.
• 3. Refine the line by fitting it to all the inliers (using

least squares).

Remarks:

• Sample a min

inimal set t of f poin ints for your problem (2 for lines).

• Repeat such that there is a high chance that at least
• ne minimal set contains only inliers (see tutorial

sheet).

RANSAC algorithm for lines

RANSAC algorithm for lines

RANSAC algorithm for 𝑮

• 1. For many repeated trials:
• 1. Select a random sample of se

seven poin ints.

• 2. Compute 𝑮 using the 7 point method.
• 3. Count how many other correspondences are

within threshold distance of the epipolar lines (inlie inliers).

• 2. Select the 𝑮 with the largest number of

inliers.

• 3. Refine 𝑮 by fitting it to all the inliers (using

the SVD method).

RANSAC algorithm for 𝑰

• 1. For many repeated trials:

1. Select a random sample of four points. 2. Compute 𝑰 as in B14.

• 3. Count how many other correspondences are within

threshold distance of the epipolar lines (in inliers).

• 2. Select the 𝑰 with the largest number of inliers.
• 3. Refine 𝑰 by fitting it to all the inliers, optimizing

the reprojection error:

min

𝑰

෍

𝐲,𝐲′ ∈inliers

𝑒2 𝐲′, 𝑰𝐲 + 𝑒2(𝑰−1𝐲′, 𝐲)

RANSAC Song

Correspondences consistent with epipolar geometry

A Virtual Compass

Fyuse

Dense Correspondences

• Aim to match all

ll poin ints between the two vie iews.

• Useful for e.g. 3D reconstruction, augmented

reality, etc.

• First we will explore how to adjust the epipolar

geometry for convenience a process called image rectification.

Adjusting epipolar geometry: Rectification

New optical axes are chosen to be coplanar and perpendicular to the base line, and the new image planes set with the same intrinsic matrix 𝑳rect.

Rectification

• The actual and rectified frames

differ by a rotation 𝑺 only. Obviously this must be rotation about the optic centre.

• The scene point 𝐘 is projected

to 𝐲 in the actual image, and 𝐲rect in the rectified image.

• What is the relationship

between them?

Rectification

• Allow 𝐘 to be defined in the actual camera frame. The projections

are: 𝐲 = 𝑳 𝑱 𝟏 𝐘 = 𝑳𝐘3×1 and 𝐲rect = 𝑳rect 𝑺 𝟏 𝐘 = 𝑳rect𝑺𝐘3×1

• Eliminate 𝐘3×1 using 𝐘3×1 = 𝑳−1𝐲 (so 𝐘’s is actually irrelevant)

𝐲rect = 𝑳rect𝑺𝑳−1𝐲.

• The 3 × 3 transformation is a homography 𝑰 = 𝑳rect𝑺𝑳−1 - a

plane to plane mapping through the projection center.

A correlation-based approach

• The basic assumption here is

that the image bands around two corresponding epipolar lines are similar.

• The example, for || cameras,

shows that this is ~ the case, though there are regions of noise, ambiguity, and occlusion.

• In Lecture 2, we saw that auto-

correlation provides a method

• f quantifying the self-similarity
• f image patches. Here we use

cr cross ss-correlati tion.

Zero-Normalized cross-correlation

• Images are from different cameras with potentially different

global gains and offsets.

• Model by 𝐽′ = 𝛽𝐽 + 𝛾 and use zero-normalized cross-

correlation.

• Step 1: Set source patch 𝐵 around 𝐲.
• Step 2: Subtract the patch mean 𝐵𝑗𝑘 ← 𝐵𝑗𝑘 − 𝜈𝐵.
• Step 3: For each 𝐲′ on the epipolar line:

– Generate patch 𝐶 and 𝐶𝑗𝑘 ← 𝐶𝑗𝑘 − 𝜈𝐶 – Compute NCC 𝐲, 𝐲′ =

σ𝑗 σ𝑘 𝐵𝑗𝑘𝐶𝑗𝑘 σ𝑗 σ𝑘 𝐵𝑗𝑘

2

σ𝑗 σ𝑘 𝐶𝑗𝑘

2

• Useful analogy: Imagine the regions as vectors 𝐵 → 𝐛 and

𝐶 → 𝐜. . NCC ≡

𝐛⋅𝐜 𝐛 𝐜 , a scale product of two unit vectors, so

− 1 ≤ NCC ≤ 1.

Examples

Examples

Why is cross-correlation a poor measure in Example 2?

• The neighbourhood region does not have a distinctive spatial
• intensity. Weak aut

auto-correlatio ion → am ambig iguous cr cross-corr rrela latio ion.

• Foreshortening effects perspective distortion. Correlation assumes

minim inimal ap appearance ch change which favours fronto-parallel surfaces.

Outline of a dense correspondence algorithm

Algorit ithm 1. Rectify images in C and C’. 2. For each pixel 𝐲 in image C:

• Compute NCC for each pixel

𝐲′ along epipolar line 𝐦′ in image C′.

• Choose the match 𝐲′ with the

highest NCC. Par arameters to

• adju

adjust

• size of neighbourhood patches
• limit on maximum disparity

(𝐲′ − 𝐲) Con

• nstraints to
• ap

apply

• uniqueness of match.
• match ordering.
• smoothness of disparity field

(disparity gradient limit).

• figural continuity.

Limit itatio ions

• scene must be textured, and
• largely fronto-parallel (related

to d.g. limit).

Example: Left and Right Images

Results: Left Image and 3D Range Map

Example: Full Sequence

The “Other Constraints” on correspondence

• Un

Uniq iqueness s of

• f match: Promote 1-to-1 matches, but there can be 0-to-1 and 1-to-0

because of occlusion.

• Or

Ordering: From a continuous opaque surface it is not possible to change the match

• rder.
• Di

Disparity sm smoo

• othness

ss: This is stronger than the previous constraint and favours smooth surfaces with no sudden changes in depth.

• Fi

Figural continuit ity: The disparity field along an epipolar line should not be much different from that along a neighbouring epipolar line.

• There are lots of ways to impose these, by e.g. discrete optimisation or dynamic

programming.

8.2 Triangulation: bursting into 3D

We have:

• Exact projection matrices

𝑸 and 𝑸′

• Potentially noisy 𝐲 ↔ 𝐲′

We want the 3D point 𝐘

Many ways, we explore only two here

Approach 1: Linear Triangulation

• We use the equations 𝐲 = 𝑸𝐘 and 𝐲’ = 𝑸’𝐘 to solve for X.

X.

• We first write:

𝑸 = 𝑞11 𝑞12 𝑞13 𝑞14 𝑞21 𝑞22 𝑞23 𝑞24 𝑞31 𝑞32 𝑞33 𝑞34 = 𝐪1T 𝐪2T 𝐪3T

• Eliminate unknown scale 𝜇𝐲 = 𝑸𝐘, by forming a cross product 𝐲 × 𝑸𝐘 =
• 0. The three components are:

𝑦 𝐪3T𝐘 − 𝐪1T𝐘 = 0 𝑧 𝐪3T𝐘 − 𝐪2T𝐘 = 0 𝑦 𝐪2T𝐘 − 𝑧 𝐪1T𝐘 = 0

• Rearrange just the first two as:

𝑦𝐪3T − 𝐪1T 𝑧𝐪3T − 𝐪2T 𝑌4×1 = 𝟏2×1

Linear Triangulation

• For the second camera we can write the same:

𝑦′𝐪′3T − 𝐪′1T 𝑧′𝐪′3T − 𝐪′2T 𝑌4×1 = 𝟏2×1

• Put all in joint system to obtain 𝑩4×4𝐘4×1 = 𝟏4×1, where:

𝑩4×4𝐘4×1 = 𝑦𝐪3T − 𝐪1T 𝑧𝐪3T − 𝐪2T 𝑦′𝐪′3T − 𝐪′1T 𝑧′𝐪′3T − 𝐪′2T 𝑌4×1 = 𝟏4×1

• Solve as null space problem or least squares if we have more

than two views – sa same math th as s in in th the 𝑮 matr trix case se.

Approach 2: Minimizing a geometrical/statistical error

• Project estimated scene position: ො

𝐲 = 𝑸෡ 𝐘 and ො 𝐲′ = 𝑸′෡ 𝐘.

• Measure Euclidean displacements: 𝑒(𝐲, ො

𝐲) and 𝑒(𝐲′, ො 𝐲′).

• Compute the cost 𝐷 ෡

𝐘 = 𝑒2 𝐲, ො 𝐲 + 𝑒2(𝐲′, ො 𝐲′).

• Adjust ෡

𝐘 to minimise the cost.

• If the measurement noise is a zero-mean Gaussian

𝑂(0, 𝜏2), then this is the Maxim imum Lik ikelihood Estim timator of 𝒀.

8.3 1- views? Depth from Neural Net

Predicting Dep Depth, , Surf Surfac ace Norm

• rmal

als and and Sem Semantic Lab Labels with ith a a Common Mul ulti-Scale Con

• nvolutional

al Ar Architecture David Eigen, Rob Fergus, ICCV 2015

8.4 2+ views?: Structure-from-Motion

Semantic Large Scale Dense SLAM

Summary of Lecture 8

The Correspondence Problem:

• Sparse Correspondences.
• RANSAC.
• Rectification.
• Zero Normalized cross correlation.
• Outline of a dense stereo algorithm.

Triangulation for Depth Recovery. Others: Depth from Neural Nets, Structure-from- Motion
