Biometrically Enhanced Software-Defined Radios Joseph P. Campbell, William M. Campbell, Douglas A. Jones, Scott M. Lewandowski, Douglas A. Reynolds, Clifford J. Weinstein {jpc, wcampbell, daj, scl, dar, cjw}@ll.mit.edu MIT Lincoln Laboratory

slide-1
SLIDE 1

Biometrically Enhanced Software-Defined Radios

Joseph P. Campbell, William M. Campbell, Douglas A. Jones, Scott M. Lewandowski, Douglas A. Reynolds, Clifford J. Weinstein

{jpc, wcampbell, daj, scl, dar, cjw}@ll.mit.edu

MIT Lincoln Laboratory Lexington, MA Software Defined Radio Forum Technical Conference Orlando, FL 17-19 November 2003

This work was sponsored by the Defense Advanced Research Projects Agency under Air Force contract F19628-00-C-0002. Opinions, interpretations, conclusions, and recommendations are those of the authors and are not necessarily endorsed by the US Government.

slide-2
SLIDE 2

MIT Lincoln Laboratory

#2 Joe Campbell SDR‘03 Nov 2003

Outline

  • Introduction & Motivation
  • User Authentication
  • Architecture
  • Conclusions & Implications for Cognitive Radio
slide-3
SLIDE 3

MIT Lincoln Laboratory

#3 Joe Campbell SDR‘03 Nov 2003

Authenticating Radios & Users (1)

  • Motivation: need to authenticate users to their radios and

networks to…

– Ensure access and actions are authorized – Realize the full potential of software-defined radio and cognitive radio

  • Observations:

– Devices can be reliably authenticated (e.g., cryptographically) – Reliably authenticating users is a challenge

  • Our approach: exploit many forms of user authentication,

including biometrics and user behavior profiles (local actions and network interactions)

slide-4
SLIDE 4

MIT Lincoln Laboratory

#4 Joe Campbell SDR‘03 Nov 2003

Authenticating Radios & Users (2)

  • User recognition can be combined with situational

awareness to enhance the authentication process

– Strength of the user authentication can be adapted based upon the situation/environment/mission awareness and risk

  • f operation (e.g., benign versus sensitive operations)

– Multiple authentication factors (e.g., voice communication, mouse movement, dialogue structure, etc.) can be used to provide continuous authentication (e.g., to mitigate the impact of lost or captured radios) – Biometric-based authentication can be combined with tokens/knowledge for emergency transfer of operations

  • Our approach enhances user convenience in addition to

enhancing security

– Automatic recall of user preferences – Biometric logins and screen unlocking – Application-specific predictive behaviors

slide-5
SLIDE 5

MIT Lincoln Laboratory

#5 Joe Campbell SDR‘03 Nov 2003

Outline

  • Introduction & Motivation
  • User Authentication
  • Architecture
  • Conclusions & Implications for Cognitive Radio
slide-6
SLIDE 6

MIT Lincoln Laboratory

#6 Joe Campbell SDR‘03 Nov 2003

Are

  • Biometric: automatically recognizing a person using

distinguishing traits

– Voice, face, fingerprint, and iris are popular biometrics*

  • Biometrics can be combined with other forms of

authentication

  • The four pillars:

Strongest authentication

– Something you have - e.g., token – Something you know - e.g., password – Something you are - e.g., voice

User Authentication

Have Know – Something you do - e.g., use patterns Do

*See Biometric Consortium www.biometrics.org for others

slide-7
SLIDE 7

MIT Lincoln Laboratory

#7 Joe Campbell SDR‘03 Nov 2003

Why Not Use Just Knowledge and/or Tokens?

Have Know

  • Knowledge can be forgotten or compromised
  • Tokens can be lost or stolen
  • Ease of Use

– How many good passwords can you remember?

Work, Home, Bank, …

  • Cost Savings

– 20-50% of corporate help desk calls are password related – 24*7 help desk support costs about $150/yr. per user

  • Security

– Common hacker tools can typically guess 30% or more of the passwords on a network – Some hackers claim 90% success – Guessing improves with side information

At DEA, 30% passwords = ? (hint: see monitor bezel) Post-It Notes (hint: see under keyboard)

slide-8
SLIDE 8

MIT Lincoln Laboratory

#8 Joe Campbell SDR‘03 Nov 2003

Why Not Use Just Biometrics?

Are

  • Unlike knowledge- and token-based authenticators,

biometrics cannot be transferred between users

– Can lead to difficulties (e.g., difficulty transferring operation in cases of emergency)

  • The four pillars can be used together to:

– Overcome these difficulties – Provide convenience to users – Provide strong user authentication

slide-9
SLIDE 9

MIT Lincoln Laboratory

#9 Joe Campbell SDR‘03 Nov 2003

Behavior-Based Authentication

Do

  • Goal: verify a user’s identify using a behavior profile that consists
  • f actions, interests, tendencies, preferences, and other patterns
  • Benefit: accurate authentication without adverse mission impact

– Authentication is inherent (no conscious user effort) – Low-cost in terms of resource utilization – High degree of user acceptance – Thorough user profiles are difficult to mimic – Continuous mode of authentication

  • Examples

– How a user does something: speed and pattern of typing, pen angle and intensity, use of menus vs keyboard shortcuts (user idiosyncrasies) – What a user does: pattern of application use, program features used, patterns of collaboration (user mission) – What a user causes to happen: sequences of system calls, patterns of resource access (low-level observables)

slide-10
SLIDE 10

MIT Lincoln Laboratory

#10 Joe Campbell SDR‘03 Nov 2003

Speaker Recognition Using Many Levels of Information

High-level cues (learned traits) Low-level cues (physical traits)

spectral prosodic phonetic

/S/ /oU/ /m/ /i:/ /D/ /&/ /m/ /Λ/ /n/ /i:/ …

idiolectal

<s>how shall i say this<e> <s> yeah i know …

dialogic

A: b b a b e c d d e B: A: b b a b e c d d e B: A: b b a b e c d d e c d d e B:

semantic

?

  • D. A. Reynolds, et al., “The SuperSID Project: Exploiting High-level

Information for High-accuracy Speaker Recognition,” Proc. ICASSP, 2003.

slide-11
SLIDE 11

MIT Lincoln Laboratory

#11 Joe Campbell SDR‘03 Nov 2003

Continuous Authentication via Behavior & Voice

Are Do

Trusted State

Required for sensitive operations

Provisional Trust

Continue interaction, gather behavioral & voice samples

time trust

Untrusted State

Interrupt interaction

  • T. J. Hazen, D. Jones, A. Park, L. Kukolich, D. Reynolds, “Integration of

Speaker Recognition into Conversational Spoken Dialogue Systems,” Eurospeech, 2003.

slide-12
SLIDE 12

MIT Lincoln Laboratory

#12 Joe Campbell SDR‘03 Nov 2003

User Authentication Issues

  • Remote/distributed/network enrollment and verification

– Where are user models created and stored? – How are models maintained/updated? – How is enrollment conducted? – How are models bound to users? – Total verification time?

  • New users

– Are models transferred and how so? – Model integrity?

  • Authentication

– Policy? – Architecture?

slide-13
SLIDE 13

MIT Lincoln Laboratory

#13 Joe Campbell SDR‘03 Nov 2003

Outline

  • Introduction & Motivation
  • User Authentication
  • Architecture
  • Conclusions & Implications for Cognitive Radio
slide-14
SLIDE 14

MIT Lincoln Laboratory

#14 Scott M. Lewandowski SDR’03 Nov 2003

Authentication Requirements

+

Auth. Auth.

=

Auth. Services

Transitively authenticate users and services:

authenticate users and services using a two-step process

slide-15
SLIDE 15

MIT Lincoln Laboratory

#15 Scott M. Lewandowski SDR’03 Nov 2003

Who Is Responsible For Security? Security functionality is distributed among radios, networks, and users

slide-16
SLIDE 16

MIT Lincoln Laboratory

#16 Scott M. Lewandowski SDR’03 Nov 2003

Notional Radio Security Architecture

Encrypted Comm

Network Radio

Authen. Interface Biometric Sensors Biometric Processor Operating System Security Policy Security Manager Authen. API Security API Applications

slide-17
SLIDE 17

MIT Lincoln Laboratory

#17 Scott M. Lewandowski SDR’03 Nov 2003

Secure Communication Interface Review

  • Shared symmetric keys (closed, static environments)

– Network and devices share a common key – Senders encrypt all data sent; if receivers can decrypt received data, it was from a trusted actor – Pros: simple, efficient – Cons: no per-client confidentiality, rekeying requires OOB comm.

  • Public key approach (open, dynamic environments)

– Network and devices have unique public/private key pairs – Senders encrypt data using receiver’s public key; if receivers can decrypt data using their private key, it was from a trusted actor – All messages sent to the network: network routes messages – Pros: easy to add/remove clients, no trust required among clients – Cons: key management can be complex, inefficient (e.g., systems that support broadcast are costly)

Authenticates users and radios and provides confidentiality and integrity

slide-18
SLIDE 18

MIT Lincoln Laboratory

#18 Scott M. Lewandowski SDR’03 Nov 2003

Biometric Subsystems

Inputs Sensors Processors Models, Profiles, Logs, etc.

Need high-performance, secure communication Output is a confidence measure for each biometric

slide-19
SLIDE 19

MIT Lincoln Laboratory

#19 Scott M. Lewandowski SDR’03 Nov 2003

Authentication API: Discrete vs Continuous Authentication

  • Current approach: authenticate user once; assigned security

token is used for the remainder of the session

  • Our approach: authenticate user periodically and refresh all

in-use security tokens (update grey tokens with blue ones)

  • Benefits: protects against lost or captured terminals,

impersonation attacks, etc.

Application Application Application Biometric Processors

slide-20
SLIDE 20

MIT Lincoln Laboratory

#20 Scott M. Lewandowski SDR’03 Nov 2003

Authentication API: Binary vs Confidence-Based Authentication

  • Current approach:

authenticated users receive full privileges and unauthenticated users receive no privileges

  • Our approach: assign varying

degrees of privilege based on the confidence in the authentication

  • Benefits: access to

applications and functionality can be mediated based on their sensitivity

Application Security Manager Can This User Use Bob’s Privileges? Yes Application Security Manager Which of Bob’s Privileges Can This User Use? Policy

slide-21
SLIDE 21

MIT Lincoln Laboratory

#21 Scott M. Lewandowski SDR’03 Nov 2003

Security Manager: Enhancements to Current Systems

  • Need to maintain confidence information

– Current systems: {object, principal, privileges} – Our system: {object, principal, confidence, privileges}

  • How to handle “insufficient privilege” failures?

– Not a new problem – but now it is more likely to occur – Need to consider the impact on the user experience – One proposed approach:

  • 1. Attempt to “silently” acquire the necessary permissions
  • 2. Ask user to help acquire the necessary permissions
  • 3. Return insufficient privilege error to the application
  • Implementation via replacement or software wrappers

– Retain support for legacy applications

slide-22
SLIDE 22

MIT Lincoln Laboratory

#22 Scott M. Lewandowski SDR’03 Nov 2003

Security API

  • Minimize resource utilization while ensuring the user can

perform his mission by providing the minimum required level

  • f authentication

Application Security Manager Minimum Required Authentication Confidence Sensors On/Off Cmds

slide-23
SLIDE 23

MIT Lincoln Laboratory

#23 Joe Campbell SDR‘03 Nov 2003

Outline

  • Introduction & Motivation
  • User Authentication
  • Architecture
  • Conclusions & Implications for Cognitive Radio
slide-24
SLIDE 24

MIT Lincoln Laboratory

#24 Joe Campbell SDR‘03 Nov 2003

Conclusions and Implications for Cognitive Radio

  • We presented an integrated approach to user authentication

and architecture to enhance trusted radio communication networks

  • User authentication, via generalized biometrics, can be

combined with other authenticators to provide continuous, flexible, and strong user authentication

  • A biometrically enhanced authentication system approach

can be extended to become part of a cognitive radio system which learns about users, situations, and surroundings and takes appropriate proactive or reactive actions

  • Generalized biometric authentication is enhanced by

machine learning, where a user’s distinctive behaviors and traits are learned and later recognized

  • An advanced cognitive radio will also learn about and take

action based upon user preferences, availability of network resources, and other elements of the situation and surroundings
