Be a Binary Rockst r

An Introduction to Program Analysis with Binary Ninja

Agenda

• Motivation
• Current State of Program Analysis
• Design Goals of Binja Program

Analysis

• Building Tools

2

Motivation

3

• Tooling - Concrete -> Symbolic

○ Increase speed & effectiveness of RE / VR

• Make Program Analysis more accessible &

useful

4

Foundations

• Need to understand code semantics
• Could be done directly on the assembly
• An Intermediate Language (IL) is needed

5

Why IL?

• Architecture Abstraction
• Smaller number of instructions

6

Easy to lift

• Simple flags calculation
• As close to native instructions as possible
• Typeless - types inferred later

7

Easy to read

• Intuitive to read
• Tree-based infix notation
• No register abstraction
• Flags calculation only when necessary
• Avoid excessive temporaries

8

IL Instruction Set Size

Instruction Set Size

Easier to analyze Easier to lift

9

The Options

10

Existing Options for IL

• BAP
• VEX
• REIL
• LLVM
• IDA

11

BAP

• Tree-tree based :)
• Flags are explicit and inhibit readability :(
• Written in OCAML :(

12

add ebx, eax shl ebx, cl addr 0x0 @asm ”add %eax,%ebx” t:u32 = REBX:u32 REBX:u32 = REBX:u32 + REAX:u32 RCF:bool = REBX:u32 < t:u32 addr 0x2 @asm ”shl %cl,%ebx” t1:u32 = REBX:u32 >> 0x20:u32 − (RECX:u32 & 0x1f:u32) RCF:bool = ((RECX:u32 & 0x1f:u32) = 0:u32) & RCF:bool | ̃((RECX:u32 & 0x1f:u32) = 0:u32) & low:bool(t1:u32)

13

VEX

• Register names are abstracted :(
• Single assignment :(
• Over 1000 instructions! :(
• Yet they call it “RISC-like”
• Even Angr is planning a move away from it

14

t0 = GET:I32(16) t1 = 0x8:I32 t3 = Sub32(t0,t1) PUT(16) = t3 PUT(68) = 0x59FC8:I32 subs R2, R2, #8

15

REIL

• Tiny instruction set
• Horrible readability
• Makes abstractions nearly impossible
• Flags are explicit and inhibit readability :(

16

00000000.00 STR R_EAX:32, , V_00:32 00000000.01 STR 0:1, , R_CF:1 00000000.02 AND V_00:32, ff:8, V_01:8 00000000.03 SHR V_01:8, 7:8, V_02:8 00000000.04 SHR V_01:8, 6:8, V_03:8 00000000.05 XOR V_02:8, V_03:8, V_04:8 00000000.06 SHR V_01:8, 5:8, V_05:8 00000000.07 SHR V_01:8, 4:8, V_06:8 00000000.08 XOR V_05:8, V_06:8, V_07:8 00000000.09 XOR V_04:8, V_07:8, V_08:8 00000000.0a SHR V_01:8, 3:8, V_09:8 00000000.0b SHR V_01:8, 2:8, V_10:8 00000000.0c XOR V_09:8, V_10:8, V_11:8 00000000.0d SHR V_01:8, 1:8, V_12:8 00000000.0e XOR V_12:8, V_01:8, V_13:8 00000000.0f XOR V_11:8, V_13:8, V_14:8 00000000.10 XOR V_08:8, V_14:8, V_15:8 00000000.11 AND V_15:8, 1:1, V_16:1 00000000.12 NOT V_16:1, , R_PF:1 00000000.13 STR 0:1, , R_AF:1 00000000.14 EQ V_00:32, 0:32, R_ZF:1 00000000.15 SHR V_00:32, 1f:32, V_17:32 00000000.16 AND 1:32, V_17:32, V_18:32 00000000.17 EQ 1:32, V_18:32, R_SF:1 00000000.18 STR 0:1, , R_OF:1

test eax, eax

17

LLVM

• Easy to analyze and has great tools already

available

• It’s a compiler!

○ Reversers want a decompiler. ○ Cannot be the only goal

18

LLVM Challenges

• Hard to lift well from compiled binaries

○ Designed for compiler output

• Expects type information in the instructions
• SSA form - assembly is not
• Stack in assembly looks like a structure, but

structures lose many advantages of SSA

19

IDA

?

20

Binary Ninja’s Answer

• Binary Ninja Intermediate Language (BNIL)

21

IL Goals & Design

22

Why Another IL?

• Popular existing ILs for compiled binaries are not very

human readable. They are extremely low level and verbose.

• Existing ILs are single stage. Heavyweight analysis must

be performed to get anywhere close to decompiled output.

• Writing a lifter for a new architecture is usually very time

consuming.

23

Binary Ninja IL

• Create a family of ILs with multiple stages of analysis
• Lowest level is close to assembly
• After analysis and transformations, higher levels are

closer to decompiled output and would be much easier to translate to good LLVM code

• Analysis involved in each transformation is easy to

understand, fast, and directly aids further analysis

24

IL Design Goals

• Human readable
• Computer understandable (SSA, 3AF, etc.)
• Plugin understandable
• Easy to lift native architectures
• Translation to other ILs such as LLVM

25

Human Readable

• Reads like pseudocode, even in lowest level

form

• Flags are resolved into readable expressions

26

Low Level IL Example

lea rax, [0x201047] lea rdi, [0x201040] push rbp sub rax, rdi mov rbp, rsp cmp rax, 0xe ja 0x68d rax = 0x201047 rdi = 0x201040 push(rbp) rax = rax - rdi rbp = rsp if (rax u> 0xe) then 6 @ 0x68d else 8 @ 0x68b

x86-64 Assembly Low Level IL

27

Low Level IL Example

addiu $sp, $sp, -0x18 sw $ra, 0x14($sp) lw $a0, ($a1) jal atoi nop sltiu $at, $v0, 0x20 beqz $at, 0x4002d8 nop $sp = $sp - 0x18 [$sp + 0x14].d = $ra $a0 = [$a1].d call(atoi) $at = $v0 u< 0x20 ? 1 : 0 if ($at == 0) then 7 @ 0x4002d8 else 12 @ 0x400290

MIPS Assembly Low Level IL

28

Computer Understandable

• Multiple IL forms
• Pick the right IL for the task at hand

29

IL Forms

Lifted IL

ASM -> IL

Low Level IL

Flags use resolved

Medium Level IL

Stack usage resolved Type propagation

SSA / 3AF SSA / 3AF

High Level IL

Calls in high level form Expression folding Like decompiled output

30

Plugin Understandable

• All IL forms directly accessible from API
• Analysis performed on IL also accessible by

API

31

Easy to Lift

• Expression tree
• Designed for quick, modular lifter

implementations

• Semantic flags eases the burden of describing

flag effects during lifting

32

Semantic Flags

• Architecture plugins define the set of flags and

their semantic roles

• Instructions can define a set of flags they write
• Data flow analysis is performed to link flag

uses to flag writes

33

Semantic Flags

• In most compiled code, flags are resolved to

simple comparison expressions with no effort from the architecture plugin

• Special cases fall back to emitting concrete

flag write expressions

34

Semantic Flags Example

sub.q{*}(rax, 0xe) if (u>) then … else … if (rax u> 0xe) then … else … “Writes to all ALU flags” “Flag state representing unsigned greater than” Folded expression describing use of flags

35

Translating Upwards

• Semantic flags analysis gives Low Level IL with flag

usage fully resolved

• Stack is represented as memory accesses, so data flow

can be difficult to compute on stack variables in Low Level IL

• Need to analyze and translate to Medium Level IL

36

Low Level IL to Medium Level IL

• Low Level IL is translated to SSA form
• Use implicit data flow from SSA to resolve stack layout
• Data flow based stack layout resolution avoids problems

with nonstandard frame pointer behavior

• Translate loads and stores on stack to stack variable uses

and assignments

37

Medium Level IL Example

push(ebp) ebp = esp esp = esp - 0x18 eax = [ebp + 8].d [esp].d = eax call(free) esp = ebp ebp = pop <return> jump(pop) var_4 = ebp eax = arg_4 var_1c = eax free(var_1c) ebp = var_4 return Medium Level IL

38

Medium Level IL

• Registers and stack usage are now both treated as

variables

• Stack variables no longer use explicit memory access
• Translate to SSA form to obtain implicit data flow on both

registers and stack variables

• Type propagation is performed on SSA form

39

Using Medium Level IL - Jump Tables

40

Using Medium Level IL - Jump Tables

• Jump table resolution based on path-sensitive data flow
• SSA conversion process also tracks control flow

dependence for every block

• Data flow computations allow disjoint sets of possible

values

• Reads from memory are simulated
• At jump site, possible values are the possible jump targets

41

Jump Table Example

x8#1 = zx.q(x0#2.d) if (x0#2.d u> 0x1f) then … else … … x8#2 = sx.q([table + (x8#1 << 2)].d) x8#3 = x8#2 + table jump(x8#3) Solve for this to get jump targets

Medium Level IL SSA Form

42

Jump Table Example

x8#1 = zx.q(x0#2.d) if (x0#2.d u> 0x1f) then … else … … x8#2 = sx.q([table + (x8#1 << 2)].d) x8#3 = x8#2 + table jump(x8#3) Track flow backwards with SSA to find definitions

43

Jump Table Example

x8#1 = zx.q(x0#2.d) if (x0#2.d u> 0x1f) then … else … … x8#2 = sx.q([table + (x8#1 << 2)].d) x8#3 = x8#2 + table jump(x8#3) Memory read depends on value of x8#1

44

Jump Table Example

x8#1 = zx.q(x0#2.d) if (x0#2.d u> 0x1f) then … else … … x8#2 = sx.q([table + (x8#1 << 2)].d) x8#3 = x8#2 + table jump(x8#3) Value used in branch comparison

45

Jump Table Example

x8#1 = zx.q(x0#2.d) if (x0#2.d u> 0x1f) then … else … … x8#2 = sx.q([table + (x8#1 << 2)].d) x8#3 = x8#2 + table jump(x8#3) Branch condition must be false to reach jump site

46

Jump Table Example

x8#1 = zx.q(x0#2.d) if (x0#2.d u> 0x1f) then … else … … x8#2 = sx.q([table + (x8#1 << 2)].d) x8#3 = x8#2 + table jump(x8#3) When false, we know that x0#2.d is between 0 and 0x1f inclusive

47

Jump Table Example

x8#1 = zx.q(x0#2.d) if (x0#2.d u> 0x1f) then … else … … x8#2 = sx.q([table + (x8#1 << 2)].d) x8#3 = x8#2 + table jump(x8#3) Resolve forward to obtain possible jump targets Set of possible values here are the jump targets

48

Using Medium Level IL - Jump Tables

• More complex idioms need to combine multiple sources of

information

• Value through SSA ϕ-functions is the set union of the

inputs

• Value of a specific SSA variable is the set intersection of

the information found in the definition and all uses of the variable

49

Leveraging the Jump Table Algorithm

• Single jump table algorithm works on all architectures with

no additional effort from architecture plugin

• Control flow dependence information accessible from API
• Queries for set of possible values accessible from API

50

The Final Forms

• Medium Level IL has the type information, stack

knowledge, and SSA form to translate easily into LLVM IR

• Further analysis can be performed to translate to High

Level IL, the Binary Ninja IL that will be used to create its decompiler

• All aspects of every IL form are plugin accessible, so

translating to other representations is straightforward

51

Binary Ninja for Profit

52

Binja API

• Python, C and C++ API’s

(headless)

• Branches: Basic block/ Function edges

(incoming & outgoing)

• Get the register states, some naive range

analysis

• api.binary.ninja/search.html

53

binja_memcpy.py: IL /bin/bash

54

binja_memcpy.py: IL /bin/bash

55

binja_memcpy.py: API

56

binja_memcpy.py: API

57

binja_memcpy.py: API

58

binja_memcpy.py: API

59

binja_memcpy.py: Output

60

SSA: Uninitialized variable

for func in bv.functions: for block in func.medium_level_il.ssa_form: for instr in block: visit_instr(instr)

61

SSA: Uninitialized variable

def visit_instr(inst): # Read of variable if inst.operation == MLIL_VAR_SSA: # Not written if inst.index == 0: if inst.src.type == StackVariableSourceType: # Local variables if inst.src.identifier < 0: print ("Uninitialized stack variable reference at " + hex(inst.address))

62

SSA: Uninitialized variable

else: for op in instr.operands: if isinstance(op, MediumLevelILInstruction): visit_instr(op)

63

Symbolic Execution

• Very accurate
• Takes time, data, and memory, often not feasible
• IDEA! Reasoning only about what we care about.
• Apply complex data to abstract domains !
• Domains: type, sign, range, color etc….

64

Abstract Interpretation

• Sets of

concrete values are abstracted imprecisely

• Galois

Connection formalizes Concrete <-> Abstract

65

• X ‘s value is imprecise
• Compilers perform imprecise

abstraction

int x; int[] a = new int[10]; a[2 * x] = 3;

• 1. Add precision - i.e. declare

abstract value [0, 9] 1.

• 2. Symbolically execute with

abstract domain/ values

• Requires control-flow analysis

Abstract Interpretation

66

Abstract Domains & Sign Analysis

int a,b,c; a = 42; b = 87; if (input) { c = a + b; } else { c = a - b; }

• Map variables to an

abstract value

67

Abstract Domains & Sign Analysis

• Binary Ninja plugin
• Path sensitive - construct lattices of

abstract values

• Under approximate
• One abstract state per CFG node
• Avoid loss in precision for fractions.

68

Demo!

• Analyze

example program

• PHP

CVE-2016-6289

69

UAF Analysis: PointsTo for Binja IL

blog.trailofbits.com/2016/03/09/the-problem-with-dynamic-program-analysis/

• Before: Allocation -> Write
• UAF Analysis: Allocation -> Free -> Use
• Key Idea: Data flow graph, assignments, copies, dereferences,

and frees of pointers

• Context and path sensitive (path API == soon!).

70

Devirtualizing C++

• VTable Function Call
• Example: mov eax, [ecx]; call [eax + 4]

https://blog.trailofbits.com/2017/02/13/devirtualizing-c-with-binary-ninja/

71

Devirtualizing C++

72

Devirtualizing C++

73

Playing with Scripts!

• memcpy, headless python

API script

• Depth-first-search, path

sensitive CFG template

• Sign analysis, abstract domain

plugin, CFG traversal script

https://github.com/ trailofbits/binjascripts

• And much much more ….

74

Conclusion: Resources

• binary.ninja/
• Abstract Interpretation talk:

santos.cs.ksu.edu/schmidt/Escuela03/WSSA/talk1p.pdf

• Static Program Analysis Book!

cs.au.dk/~amoeller/spa/spa.pdf

75

Conclusion: Binary Ninja

76

Contact Us

Sophia d’Antoine

• IRC/Slack: @quend
• sophia@trailofbits.com

Peter LaFosse Rusty Wagner

• https://binaryninjaslack.herokuapp.com
• binaryninja@vector35.com
