BCGold Corp. Discovery Driven March, 2014 Engineer Mine Property Corporate Strategy Focused exclusively on copper and gold exploration in established mining districts in British Columbia and Yukon since 2006. BCGolds

slide-1
SLIDE 1

BCGold Corp.

“Discovery Driven”

March, 2014

Engineer Mine Property

slide-2
SLIDE 2

2

Corporate Strategy

  • Focused exclusively on copper and gold exploration in

established mining districts in British Columbia and Yukon since 2006.

  • BCGold’s primary gold asset is the 100% owned, historic

high-grade gold Engineer Mine property, where the Company has defined a compelling gold concentrate production opportunity through continued exploration, bulk sampling and on-site milling.

  • Exploration focussed for an economic epithermal gold

deposit and on-going efforts to secure a qualified partner to finance the gold concentrate production opportunity.

  • Seek joint venture partners to advance numerous 100%
  • wned copper and gold exploration projects in British

Columbia and Yukon.

slide-3
SLIDE 3

3

Why Invest in BCGold?

  • Board and management with >120 years of collective

exploration, mining and development experience.

  • Proven project generators and property vendors, with

27 early to development stage copper-gold properties in emerging and established mining districts.

  • Tight share structure – 26.5 million shares O/S. 10:1

share consolidation completed in Nov, 2012.

  • Kinross has been significant shareholder since 2008.
slide-4
SLIDE 4

4

Board of Directors & Advisors

  • Brian P. Fowler, P.Geo., President & CEO, Director
  • Chairman and Director – Laurentian Goldfields Ltd.
  • John Kowalchuk, P.Geo., Independent Director
  • Geological Consultant.
  • Peter Kendrick, MBA, Independent Director
  • President – Management & Efficiency Consultants.
  • Robert Kendrick, P.Eng. AMP, Advisor
  • Randy Smallwood, P.Eng., Advisor
  • Derek White, CA, Advisor
slide-5
SLIDE 5

5

Management Team

  • Brian P. Fowler, P.Geo., President & CEO, Director
  • Quadra Mining Ltd., Placer Dome Inc.
  • Larry M. Okada, CA, CPA (Wash.), CFO
  • PricewaterhouseCoopers LLP, Deloitte.
  • Darren O’Brien, P.Geo., Vice President Exploration
  • Terrane Metals Corp., Placer Dome Inc.
  • Jacqueline Collins – Corporate Secretary
  • Global Minerals Ltd., Midnight Sun Mining Corp.
slide-6
SLIDE 6

6

Share Structure

Shares es Issu sued ed 26.5 M Fully y Dilute ted 45.4 M Warran rants ts & Opti tion

  • ns

18.9 M Share e Distrib tributio ution Managemen gement t , Directors ctors & Inside ders rs 24% 24% Retail il 70% 70% Kinross

  • ss Gold

d Corp. 3% 3% Institutio titutions 3% 3%

slide-7
SLIDE 7

7 7

B.C. and Yukon Property Portfolio

slide-8
SLIDE 8

8

Historic Mill Engineer Mine Townsite c.1924

Engineer Mine – Yesterday and Today

Present Day Mill Level 5 Portal

slide-9
SLIDE 9

9

Engineer Exploration Model and Upside

  • The Engineer Mine Property has the earmarks of a large epithermal

gold system with a number of characteristics (gold and roscoelite) similar to world-class, alkalic epithermal gold systems such as the Porgera, Cripple Creek and Emperor gold deposits.

  • The Engineer Mine Property hosts a robust and open mineralizing
  • system. High-grade gold has been confirmed 21 metres below the

deepest mine level (8 level) on the Double Decker Vein and between 5 and 7 Levels on the Engineer Vein by BCGold drilling, mine de- watering and sampling .

  • The Engineer and adjoining Blind Creek and Gold Hill Properties
  • ccupy the heart of the Engineer Mine mineralizing system and offer

excellent bulk-tonnage gold potential, hosting >8 km of 2nd order shear structures with drill intercepts of hydrothermal breccias grading up to 0.45 g/t Au over 34 metres.

  • Exploration results indicates excellent upside to resource expansion

and gold grade increase. The company is evaluating the premise of partially funding exploration through continued bulk sampling and on- site milling of high-grade material from Engineer Vein.

slide-10
SLIDE 10

10

Recent Corporate and Exploration Activity

  • Test-mined and milled a 246 tonne bulk sample from remnant pillars
  • f the Engineer Vein in 2011, producing 826 kg of gold gravity

concentrate (containing 68 oz gold) which was monetized for US$107,000 (Net).

  • 5th Level bulk sampling in 2011 defined the tops of 2 high-grade gold

shoots in Engineer Vein, estimated to contain up to 17,000 oz. gold grading between 30 – 60 g/t gold.

  • Successfully dewatered 6 and 7 Levels of underground workings in

2012, confirming gold grade and depth extent of 3 high-grade gold shoots on Engineer Vein.

  • 2012 test MMI soil surveys along mineralized segments of the 8km+

Shear Zone ‘A’,‘B’ and Happy Sullivan bulk tonnage gold structures confirmed as an effective means to define drill targets.

  • Consolidated land holdings over entire Engineer Mine Camp through

acquisition of Blind Creek claims. (3,537 ha). Aug.19, 2013

  • Amended Gold Hill Property option agreement – deferring $160,000

in exploration and option payments costs to 2014. Aug.27, 2013

slide-11
SLIDE 11

11

Engineer Mine Property, B.C.

  • Historic high-grade gold-silver mine.
  • Past production 18,000 oz Au and 8,950 oz Ag in 1920’s.
  • Average historic grade of 39 g/t Au and 20 g/t Ag.
  • Barge and ice road accessible, 32 km west of Atlin, B.C.
slide-12
SLIDE 12

12

Engineer Mine Property, B.C.

  • >$4M expenditures to

date (BCGold).

  • Excellent high-grade,

near-term production and resource expansion potential.

  • >8 km of untested,

2nd order shear structures known to host hydrothermal breccias and low- grade gold.

  • 3,537 ha property
  • ccupies entire

Engineer Mine Camp.

3,460 ha Mineral Claims 77 ha Crown Grants

slide-13
SLIDE 13

13

Tenure

Engineer Mine Property

  • 100% owned crown grants; site of historic mine workings.
  • No underlying royalties except for 30% NPI to EMC on small mineralized

shoot on the Double Decker Vein between 5 and 8 Levels.

  • Option to purchase surface rights for fair market value ($0.5M max) by

2017.

Gold Hill Option

  • 50% owned (Guardsmen Resources Inc.) with option to acquire remaining

50% for option payments of $50,000 and work commitment of $163,000 by 2014.

  • 2.5% NSR to Guardsman, reduced to 0.5% for $1.5M

Blind Creek Option

  • Option to earn 100% interest over 4 years through issuance of 1.25M

shares, $225,000 in cash payments and $400,000 in work commitments.

  • $10,000 cash payment and $100,000 work commitment for 2014.
  • 2% NSR to Blind Creek, reduced to 0.5% for $1.5M
slide-14
SLIDE 14

14

Engineer Mine – Property Geology

Hub A Hub B

  • Adjacent to Llewellyn Fault;

major domain boundary between Stikine and Nisling Terrains.

  • Black sediments intruded by

quartz monzonite to diorite dykes and stocks

  • Property cut by Llewellyn-

related shear zones up to 150 metres wide hosting hydrothermal breccia and low- grade gold.

  • > 25 narrow, dilational veins

discovered to date with high- grade gold mineralization.

slide-15
SLIDE 15

15

43-101 Engineer Mine Resource Estimate

Cut-Off Category Vein Tonnes Au (g/t) Contained Au (oz) 5 g/t Au Inferred Engineer 30,800 20.6 20,400 Inferred Double Decker 10,100 13.1 4,400 Total(3) 41,000 19.0 25,000 25 g/t Au Inferred Engineer 10,400 60 20,100 Inferred Double Decker 3,600 30 3,500 Total(3) 14,000 52.5 23,600

ENGINEER MINE INFERRED MINERAL RESOURCE ESTIMATE *

Note: Mineral Resources which are not Mineral Reserves do not have demonstrated economic viability. * April 18th, 2011 Snowden NI 43-101 estimate

slide-16
SLIDE 16

16

Engineer Mine Property – Shear Zones, Veins, & Underground Development (Level 5)

  • 5,500 m of underground

development on 8 levels.

  • 5th Level portal with rail.
  • 2 styles of epithermal gold

mineralization.

  • Narrow high grade veins (0.3

– 3.0 m, >35 g/t Au).

  • Broad, low grade shear

structures with hydrothermal breccias (0.45 g/t over 35 m).

  • Unexplored below 200 m from

surface.

  • BCGold conducted 1,850 m

drill program in 2008 (Shear Zone A), 1,100 m UG drill programs in 2010 (Engineer & Double Decker Veins) & mined and milled 6 bulk samples (246.1 tonnes) as part of a 2011, $1.1 million exploration program.

slide-17
SLIDE 17

17

High-Grade Gold Exploration Upside and Near-Term Production Potential

  • High-grade gold has been confirmed to extend laterally along veins

for >1km and from surface to at least 21 metres below deepest mine level (8 level), 180 metres below surface, by BCGold Corp. drilling in 2010, trenching and bulk sampling in 2011 and mine- dewatering and sampling in 2012.

  • High-grade mineral resource (tonnes and grade) is understated,

primarily due to a high gold “Nugget Effect”, with excellent upside

  • potential. Current resource is confined to remnant portions of 2

veins out of 25 known veins on the property.

  • 2011 bulk sampling program defined 2 accessible high-grade gold

shoots on Engineer Vein between 5 and 7 Levels, estimated to grade between 30-60 g/t gold and containing up to 17,000 oz gold.

  • Production drifts in place for Engineer Vein between 5-8 Levels

and Double Decker Vein on 5 and 8 Levels.

  • Production drifts in place on 5 Level for Boulder, Governor, Shaft

and Jersey Lilly Veins.

slide-18
SLIDE 18

18

Near-Term Production Potential

  • Fully permitted, operational 30 tpd gravity separation mill on site.

2011 metallurgical results provide basis for mill optimization and increase in gold recoveries.

  • De-watered 6 and 7 Levels in 2012. Air and water services

restored, Engineer Vein mapped and panel sampled; 3 gold shoots confirmed to 7 Level.

  • BCGold plans to mine and mill high-grade bulk-samples at

Engineer Mine in 2013, generating revenue while advancing and exploring the property.

  • Company is actively seeking a project partner to finance mine and

mill development to mine and mill up to 8,000 tonnes of bulk sample material and produce up to 8,000 oz of gold by 2014.

  • Net revenue to be applied to future exploration and development of

a sustainable 7,500 – 10,000 oz  year mining operation.

slide-19
SLIDE 19

19

Engineer Mine – High Grade Vein Mineralogy

Vein mineralogy

  • Quartz-carbonate-

muscovite

  • roscoelite
  • arsenopyrite
  • arsenic
  • antimony
  • allemontite (native

arsenic+stibarsen)

  • stibnite
  • pyrrhotite

Ore minerals: Au, Ag (electrum)

  • Occurs free in quartz,

and bonanza grades with roscoelite

3 cm Engineer Vein Gold Boulder Vein Sheet Gold

slide-20
SLIDE 20

20

Roscoelite & Electrum

slide-21
SLIDE 21

21

Engineer Mine Property VulcanTM Model & 2010 Underground Drilling

slide-22
SLIDE 22

22

Engineer Mine Resource, Bulk Sample and Underground Exploration Targets

slide-23
SLIDE 23

23

Engineer Vein, Bulk Sample Gold / Roscoelite and Gold Stream on Finishing Table Gold

3 6 9 12 15 cm

slide-24
SLIDE 24

24

Engineer Vein Resource, 2011 Bulk Sample Mining Grades and New Mining Targets

slide-25
SLIDE 25

25

Double Decker Vein Resource & 2011 Bulk Sample Location

slide-26
SLIDE 26

26

2011 Exploration Program & Results

  • Six bulk samples totalling 246.1 tonnes returned an average mining

grade of 16.9 g/t Au, including one 68.9 tonne bulk sample returning 44.6 g/t Au.

  • Preliminary test milling averaged 51.3% gold recovery from the

gravity recovery circuit. Recoveries >71% indicated by Gekko metallurgical studies.

  • Bulk samples consistently returned much higher gold grades

(average of 861% increase) than indicated by smaller volume channel samples collected in previous programs.

  • Bulk sample results clearly indicate that test mining and test milling

is the only reliable method to define “ore-grade” gold mineralization at Engineer Mine.

  • Bulk sample results indicate conventional sampling techniques can

grossly underestimate gold grades and the current resource estimate is likely conservative and open to significant expansion.

slide-27
SLIDE 27

27

2011 Exploration Program & Results

  • Completed a 600 line km SkyTEM deep penetrating Time-Domain

Electromagnetic / Magnetic airborne survey over the Engineer and Gold Hill properties. Numerous exploration targets defined for follow-up.

  • > 600 metres of trench excavation completed on the Boulder, Shaft,

Double Decker and Shear “B” zones, all of which were either exposed or partially developed 120 metres vertically below on 5 Level in the 1920’s. The exposed veins have been geologically mapped and channel sampled.

  • Gekko Systems bench-scale gravity and leach amenability tests on

mill feed and table concentrate validated BCGold’s bulk sampling results, returning a 54.9 g/t Au and 40.6 g/t Ag ROM head grade and gold and silver recoveries up to 71.4% and 67.8%, respectively, using only gravity concentration methods.

  • Gold and silver recoveries from concentrate of up to 98% and 90%,

respectively, by intensive leaching after 24 hours.

slide-28
SLIDE 28

28

2012 Exploration Program & Results

In 2012 BCGold conducted a $550,000 exploration program at the Engineer Mine and Gold Hill Properties. Work included:

  • Geological mapping, prospecting and test MMI soil surveys
  • ver the Shear A and B bulk tonnage gold exploration targets.

MMI confirmed as an effective means to delineate bulk- tonnage gold drill targets within shear zones.

  • Dewatered 6 and 7 Levels of the underground mine workings

to access the down-plunge extension of the high-grade 505-3 and the 505-5 Shoots.

  • Installed air and water services to Levels 6 and 7, geological

mapping and panel sampling completed.

  • Confirmed the presence of 3 high-grade gold shoots between

5 and 7 Levels.

  • Underground hoist and service installation, mill upgrade and

bulk sample mining and milling of 505-3 & 505-5 exploration targets will commence in 2013 if a concentrate forward sale agreement is secured.

slide-29
SLIDE 29

29

UBC / Mitacs Postdoctoral Research Thesis

  • Dr. Leo Millonig (Postdoc Fellow)

– Supervisors: Dr. Lee Groat, UBC / Dr. Robert Linnen, UWO

  • 1 year / $85,000 postdoc thesis studying:

– Gold deportment / Vein mineralogy / Geochemistry / Chronology – SEM / Microprobe / XRD / LA ICP-MS / Isotope analysis – Triggers to gold deposition / Consequences for exploration

  • Preliminary results include:

– Auriferous aspy grading 6 ppm to 683 ppm Au – Strong Au / As / Cu correlation – Age dates: Ar/Ar 49 Ma; 54 Ma U/Pb

  • Final report due this fall. Publication next year.
slide-30
SLIDE 30

30

6 Level Geology and Panel Sampling (Engineer Vein)

  • 505-2 Shoot partially cut off by feldspar

porphyry dike

  • 505-5 Shoot requires 30m of drift

development; confirmed with drill hole BCG10-11 (129 g/t Au over 1.0m)

  • Elevated silver assays indicate south

end of drift near 505-3 Shoot

Geological Mapping

Panel Samples Gold Assays

12,720 g/t Au!

Drill Hole BCG10-11 1.0m @ 129.0 g/t Au

Panel Samples Silver Assays

?

slide-31
SLIDE 31

31

7 Level Geology and Panel Sampling (Engineer Vein)

Panel Samples Silver Assays Geological Mapping

  • Bonanza grade shoots identified by

geologic mapping

  • Vein / dike intersections
  • Quartz (silica) content
  • Also identified by non-gold metals not

as susceptible to nugget effect

  • Ag, As, Sb, Mo

Panel Samples Gold Assays

3,180 g/t Au!

slide-32
SLIDE 32

32

Shear Zone ‘A’ – Bulk Tonnage Gold Exploration Drill Targets

slide-33
SLIDE 33

33

Shear Zone ‘B’ – Bulk Tonnage Gold Exploration Drill Targets

slide-34
SLIDE 34

34

>24 km2 Airborne Geophysics with Major Structures and Vein Workings

EM Resistivity (100m Depth Slice)

1 km 1 km Engineer Mountain Volcanic Complex

slide-35
SLIDE 35

35

2012 MMI Test Soil Surveys and Results

  • Historic (1980’s) conventional soil

sampling (upper B Horizon) failed to identify shear zones and alteration halos.

  • In 2012 test MMI lines were completed
  • ver known mineralized segments of the

Shear “A”, Shear “B”, Engineer Vein, Hub “A” and Hub “B” structures.

  • Results showed that MMI positively

identified discrete, moderate to strong, coincidental Au, Ag, As, Sb and Mo anomalies.

  • New zones identified:

– Hub “B” – Shear “B” 2 km north of Hub “B” – Happy Sullivan

  • MMI appears to be a proven means to

identify bulk tonnage gold drill targets in shear zone structures!

MMI Soils (Au) Over Magnetics

500 m

slide-36
SLIDE 36

36

2014 Engineer Mine Exploration Plans

  • Continue efforts to secure a joint venture partner to advance

exploration and development of Engineer Mine Property.

  • Refine economic model for small-scale production.
  • Broaden MMI soil surveys along remaining segments of the 8km+

Shear Zone ‘A’,‘B’ and Happy Sullivan bulk tonnage gold structures to define drill targets.

  • Conduct I.P. surveys over MMI gold anomalies.
  • Conduct surface diamond drill program targeting near-mine

magnetic high/ resistivity high / Au/As MMI anomaly, believed to represent shallow intrusive source to gold mineralization.

  • Trenching on the Happy Sullivan vein system.
  • Continue efforts to option all other exploration properties to

suitable exploration partners and to establish an exploration alliance with a major company to explore for copper-gold porphyry systems in BC and Yukon.

slide-37
SLIDE 37

37

Engineer Mine Property Summary

  • BCGold’s Engineer Mine project has the earmarks of a large

epithermal gold system with a number of characteristics (gold and roscoelite) similar to world-class, alkalic epithermal gold systems such as the Porgera, Cripple Creek and Emperor gold deposits.

  • The Engineer Mine Property hosts a large, poorly explored, robust

and open mineralizing system. High-grade gold has been confirmed 21 metres below deepest mine level (8 level) on the Double Decker Vein and on 7 level on the Engineer Vein by drilling and sampling in 2010 and 2012.

  • BCGold’s property covers the entire Engineer Mine mineralizing

system, and offers excellent, demonstrable bulk-tonnage gold potential, hosting >8 km of untested 2nd order shear structures with near-surface drill intercepts up to 0.45 g/t Au over 34 metres.

  • 2011 bulk sampling results indicates excellent upside to high-grade

resource expansion and gold grade increase. The company believes a continued, larger-scale bulk sampling and on-site milling program can provide the necessary capital to fund exploration and development.

slide-38
SLIDE 38

38

BCGold Corp – Reviving the Engineer Mine

slide-39
SLIDE 39

BCGold Corp.

“Discovery Driven”

March, 2014

Engineer Mine Property
