SLIDE 1
Backpropagation
Slides credits: Barak Oshri, Vincent Chen, Nish Khandwala, Yi Wen
TA: Yi Wen
April 17, 2020 CS231n Discussion Section
Agenda
- Motivation
- Backprop Tips & Tricks
- Matrix calculus primer
Backpropagation TA: Yi Wen April 17, 2020 CS231n Discussion - - PowerPoint PPT Presentation
Backpropagation TA: Yi Wen April 17, 2020 CS231n Discussion - - PowerPoint PPT Presentation
Backpropagation TA: Yi Wen April 17, 2020 CS231n Discussion Section Slides credits: Barak Oshri, Vincent Chen, Nish Khandwala, Yi Wen Agenda Motivation Backprop Tips & Tricks Matrix calculus primer Agenda Motivation
SLIDE 2
SLIDE 3
Agenda
- Motivation
- Backprop Tips & Tricks
- Matrix calculus primer
SLIDE 4
Motivation
Recall: Optimization objective is minimize loss
SLIDE 5
Motivation
Recall: Optimization objective is minimize loss Goal: how should we tweak the parameters to decrease the loss?
SLIDE 6
Agenda
- Motivation
- Backprop Tips & Tricks
- Matrix calculus primer
SLIDE 7
A Simple Example
Loss Goal: Tweak the parameters to minimize loss => minimize a multivariable function in parameter space
SLIDE 8
A Simple Example
=> minimize a multivariable function
Plotted on WolframAlpha
SLIDE 9
Approach #1: Random Search
Intuition: the step we take in the domain of function
SLIDE 10
Approach #2: Numerical Gradient
Intuition: rate of change of a function with respect to a variable surrounding a small region
SLIDE 11
Approach #2: Numerical Gradient
Intuition: rate of change of a function with respect to a variable surrounding a small region Finite Differences:
SLIDE 12
Approach #3: Analytical Gradient
Recall: partial derivative by limit definition
SLIDE 13
Approach #3: Analytical Gradient
Recall: chain rule
SLIDE 14
Approach #3: Analytical Gradient
Recall: chain rule E.g.
SLIDE 15
Approach #3: Analytical Gradient
Recall: chain rule E.g.
SLIDE 16
Approach #3: Analytical Gradient
Recall: chain rule Intuition: upstream gradient values propagate backwards -- we can reuse them!
SLIDE 17
Gradient
“direction and rate of fastest increase” Numerical Gradient vs Analytical Gradient
SLIDE 18
What about Autograd?
- Deep learning frameworks can automatically perform backprop!
- Problems might surface related to underlying gradients when debugging your
models “Yes You Should Understand Backprop”
https://medium.com/@karpathy/yes-you-should-understand-backprop-e2f06eab496b
SLIDE 19
Problem Statement: Backpropagation
Given a function f with respect to inputs x, labels y, and parameters 𝜄 compute the gradient of Loss with respect to 𝜄
SLIDE 20
Problem Statement: Backpropagation
An algorithm for computing the gradient of a compound function as a series of local, intermediate gradients:
- 1. Identify intermediate functions (forward prop)
- 2. Compute local gradients (chain rule)
- 3. Combine with upstream error signal to get full gradient
Input x y
- utput
local(x,W,b) => y dx,dW,db <= grad_local(dy,x,W,b)
dx dy
W,b dW,db
SLIDE 21
Modularity: Previous Example
Compound function Intermediate Variables
(forward propagation)
SLIDE 22
Modularity: 2-Layer Neural Network
Compound function Intermediate Variables
(forward propagation)
=> Squared Euclidean Distance
between and
SLIDE 23
? f(x;W,b) = Wx + b ?
Intermediate Variables
(forward propagation)
(↑ lecture note) Input one feature vector (← here) Input a batch of data (matrix)
SLIDE 24
Intermediate Variables
(forward propagation)
Intermediate Gradients
(backward propagation)
- 1. intermediate functions
- 2. local gradients
- 3. full gradients
？？？ ？？？ ？？？
SLIDE 25
Agenda
- Motivation
- Backprop Tips & Tricks
- Matrix calculus primer
SLIDE 26
Derivative w.r.t. Vector
Scalar-by-Vector Vector-by-Vector
SLIDE 27
Derivative w.r.t. Vector: Chain Rule
- 1. intermediate functions
- 2. local gradients
- 3. full gradients
?
SLIDE 28
Derivative w.r.t. Vector: Takeaway
SLIDE 29
Derivative w.r.t. Matrix
Vector-by-Matrix ? Scalar-by-Matrix
SLIDE 30
Derivative w.r.t. Matrix: Dimension Balancing
When you take scalar-by-matrix gradients The gradient has shape of denominator
- Dimension balancing is the “cheap” but efficient approach to
gradient calculations in most practical settings
SLIDE 31
Derivative w.r.t. Matrix: Takeaway
SLIDE 32
Intermediate Variables
(forward propagation)
Intermediate Gradients
(backward propagation)
- 1. intermediate functions
- 2. local gradients
- 3. full gradients
SLIDE 33
Backprop Menu for Success
1. Write down variable graph 2. Keep track of error signals 3. Compute derivative of loss function 4. Enforce shape rule on error signals, especially when deriving
- ver a linear transformation
SLIDE 34
Vector-by-vector
?
SLIDE 35
Vector-by-vector
?
SLIDE 36
Vector-by-vector
?
SLIDE 37
Vector-by-vector
?
SLIDE 38
Matrix multiplication [Backprop]
? ?
SLIDE 39
Elementwise function [Backprop]
?
