B factory Peter Krian University of Ljubljana and J. Stefan - PowerPoint PPT Presentation

Requirements on detectors: example 1 B factory Peter Krian University of Ljubljana and J. Stefan Institute Peter Krian, Ljubljana Contents Physics case for B factories / Super B factories Accellerator Detector Peter Krian,


  1. Experimental considerations Choice of boost  : Maximize the ratio between the  c/  (z) average flight path  c and the vertex resolution  (z)  (z)  r 0 /sin 5/2  with  =atan(1/  )  c/  (z)  (1  r 0 )  c sin 5/2  = = (1  r 0 )  c sin 5/2 (atan(1/  ))  Boost around  =0.8 seems optimal Not the whole story.... Peter Križan, Ljubljana

  2. Experimental considerations Detector form: symmetric for symmetric energy beams; extended in the boost direction for an asymmetric collider. cms lab Exaggerated plot: in p* reality  =0.5  p* CLEO BELLE Peter Križan, Ljubljana

  3. Experimental considerations Which boost... Arguments for a smaller boost: Snowmass 1988 • Larger boost -> smaller acceptance (particles escape detection in the boosted direction in the region around the beam pipe)  • Larger boost -> it becomes hard to damp the betatron oscillations of Belle BaBar the low energy beam: less synchrotron radiation at fixed ring radius (same as the high energy  beam) • More Touschek (intra-beam) scattering for a lower energy beam Peter Križan, Ljubljana

  4. Requirements: Geometric Acceptance  max  min Peter Križan, Ljubljana

  5. Requirements: momentum acceptance Peter Križan, Ljubljana

  6. How to understand what happened in a collision? Illustration on an example: B 0  K 0 S J/  S   -  + K 0 J/    -  + Peter Križan, Ljubljana

  7. Belle II Detector KL and muon detector: Resistive Plate Counter (barrel outer layers) Scintillator + WLSF + MPPC (end-caps , inner 2 barrel layers) EM Calorimeter: CsI(Tl), waveform sampling (barrel) Pure CsI + waveform sampling (end-caps) Particle Identification Time-of-Propagation counter (barrel) electrons (7GeV) Prox. focusing Aerogel RICH (fwd) Beryllium beam pipe 2cm diameter Vertex Detector 2 layers DEPFET + 4 layers DSSD positrons (4GeV) Central Drift Chamber He(50%):C 2 H 6 (50%), small cells, long lever arm, fast electronics Peter Križan, Ljubljana

  8. Tracking and vertex systems in Belle II KL and muon detector: Resistive Plate Counter (barrel outer layers) Scintillator + WLSF + MPPC (end-caps , inner 2 barrel layers) EM Calorimeter: CsI(Tl), waveform sampling (barrel) Pure CsI + waveform sampling (end-caps) Particle Identification Time-of-Propagation counter (barrel) electrons (7GeV) Prox. focusing Aerogel RICH (fwd) Beryllium beam pipe 2cm diameter Vertex Detector 2 layers DEPFET + 4 layers DSSD positrons (4GeV) Central Drift Chamber He(50%):C 2 H 6 (50%), small cells, long lever arm, fast electronics Peter Križan, Ljubljana

  9. Vertexing, example: B 0  K 0 S J/  S   -  + K 0 J/    -  + _ B 0  K - X Peter Križan, Ljubljana

  10. Vertexing Measure very accurately points on the track close to the interaction point 10 cm e + e - z Use a beam pipe with very thin walls (and light material – long X 0 ) to reduce multiple scattering  Be Peter Križan, Ljubljana

  11. Peter Križan, Ljubljana

  12. Peter Križan, Ljubljana

  13. Belle II Detector – vertex region Beryllium beam pipe 2cm diameter Vertex Detector 2 layers DEPFET + 4 layers DSSD Peter Križan, Ljubljana

  14. Silicon vertex detector (SVD) pitch 20 cm 50 cm Two coordinates measured at the same time; strip pitch: 50  m (75  m); resolution 15  m (20  m). e + e - z Peter Križan, Ljubljana

  15. Belle II Vertex detector SVD+PXD • Sensors of the innermost layers: Normal double sided Si detector (DSSD) → DEPFET Pixel sensors • Configuration: 4 layers → 6 layers (outer radius = 8cm→14cm) – More robust tracking – Higher Ks vertex reconstruction efficiency • Inner radius: 1.5cm → 1.3cm Slant layer to keep the – Better vertex resolution acceptance 2 pixel layers Peter Križan, Ljubljana

  16. Pixel vertex detector PXD principle: DEPFET p-channel FET on a completely depleted bulk Depleted p-channel FET A deep n-implant creates a potential minimum for electrons under the gate (“internal gate”) Signal electrons accumulate in the internal gate and modulate the transistor current (g q ~ 400 pA/e - ) Accumulated charge can be removed by a clear contact (“reset”) Invented in MPI Munich Fully depleted: Transistor on only during readout: → large signal, fast signal collection low power Low capacitance, internal Complete clear no reset noise amplification → low noise Peter Križan, Ljubljana

  17. Vertex Detector DEPFET: http://aldebaran.hll.mpg.de/twiki/bin/view/DEPFET/WebHome Beam Pipe r = 10mm DEPFET Layer 1 r = 14mm Layer 2 r = 22mm DSSD Layer 3 r = 38mm Layer 4 r = 80mm Layer 5 r = 115mm Layer 6 r = 140mm Mechanical mockup of pixel detector DEPFET pixel sensor DEPFET sensor: very good S/N  Peter Križan, Ljubljana

  18. Expected performance b    a    sin p  [  m ] Pixel detector close to the beam pipe Belle Belle II’ Belle II Less Coulomb scattering 0 1.0 2.0 p  sin(  ) 5/2 [GeV/c]   K s   Peter Križan, Ljubljana 37

  19. Main tracking device: small cell drift chamber Central Drift Chamber He(50%):C 2 H 6 (50%), small cells, long lever arm, fast electronics Peter Križan, Ljubljana

  20. Search for unstable particles which decayed close to the production point How do we reconstruct final states that decayed to two stable particles? From the measured tracks calculate the invariant mass of the system (i= 1,2):      2 2 2 2 ( ) ( ) Mc E p c i i The candidates for the X  12 decay show up as a peak in the distribution on (mostly combinatorial) background. Peter Križan, Ljubljana

  21. How do we know it was precisely this reaction?     S J/  B 0  K 0     K 0 S  detect J/       For     in     pairs we calculate the invariant mass: M 2 c 4 =(E 1 + E 2 ) 2 - (p 1 + p 2 ) 2     Mc 2 must be for K 0 S close to 0.5 GeV, for J/  close to 3.1 GeV. e  e  2.5 GeV 3.0 3.5 Rest in the histrogram: random coincidences (‘combinatorial background’)  Peter Križan, Ljubljana  

  22. Invariant mass resolution – momentum resolution The name of the game: have as little background under the peak as possible without loosing the events in the peak (=reduce background and have a narrow peak).      2 2 2 2 ( ) ( ) Mc E p c i i To understand the impact of momentum resolution, simplify the expression for the case where final state particles have a small mass compared to their momenta. Example J/       M 2 c 4 = (E 1 + E 2 ) 2 - (p 1 + p 2 ) 2  M 2 c 4 = 2 p 1 p 2 (1 - cos  12 ) Peter Križan, Ljubljana

  23. Resolution in invariant mass S      , J/       S J/  K 0 B 0  K 0 M 2 c 4 = (E 1 + E 2 ) 2 - (p 1 + p 2 ) 2 c 2  M 2 c 4 = 2 p 1 p 2 c 2 (1 - cos  12 ) The J/  peak should be narrow to minimize the contribution of random coincidences (‘combinatorial background’) The required resolution in Mc 2 : about 10 MeV. What is the corresponding momentum resolution?     For simplicity assume J/  is at rest   12 =180 0 , p 1 =p 2 =p=1.5 GeV/c, Mc 2 =2pc   (Mc 2 ) = 2  (pc) at p=1.5 GeV/c e  e  2.5 GeV 3.0 3.5   (p)/p = 10 MeV/2/1.5GeV = 0.3% Peter Križan, Ljubljana

  24. Requirements: momentum spectrum Peter Križan, Ljubljana

  25.   720 p  p T x T  2 4 p eBL N T http://www-f9.ijs.si/~krizan/sola/nddop/slides/anpod_1213.pdf Peter Križan, Ljubljana

  26. http://www-f9.ijs.si/~krizan/sola/nddop/slides/anpod_1213.pdf eB = 0.3 (B/T) (1/m) GeV/c Peter Križan, Ljubljana

  27. Momentum resolution  Tracking system  720 eB = 0.3 (B/T) (1/m) GeV/c p  p T uncertainty x T  2 4 p eBL N T    3  0 . 1 10 720 0 . 0008 m p   p T T p   2 T 0 . 3 ( / ) 1 . 5 1 54 p GeV m m GeV T For B=1.5T, L = 1m,  x = 0.1 mm For p T = 1 GeV:  pT /p T = 0.08% For p T = 2 GeV:  pT /p T = 0.16% Uncertainty from multiple scattering  13 . 6 p T  MeV 2 2        p T eB LX       p p / p / 0 T T T         p p p  T T T 13 . 6 tracking msc MeV   p T 0 . 003   0 . 3 ( / ) 1 . 5 1 100 p T GeV m m m Peter Križan, Ljubljana

  28. Tracking: Belle central drift chamber •50 layers of wires (8400 cells) in 1.5 Tesla magnetic field •Helium:Ethane 50:50 gas, W anode wires, Al field wires, CF inner wall with cathodes, and preamp only on endplates •Particle identification from ionization loss (5.6-7% resolution) Peter Križan, Ljubljana

  29. Drift chamber with small cells One big gas volume, small cells defined by the anode and field shaping (potential) wires Peter Križan, Ljubljana

  30. Belle II CDC Wire stringing in a clean room • thousands of wires, • 1 year of work... Peter Križan, Ljubljana

  31. Particle identification systems in Belle II KL and muon detector: Resistive Plate Counter (barrel outer layers) Scintillator + WLSF + MPPC (end-caps , inner 2 barrel layers) EM Calorimeter: CsI(Tl), waveform sampling (barrel) Pure CsI + waveform sampling (end-caps) Particle Identification Time-of-Propagation counter (barrel) electrons (7GeV) Prox. focusing Aerogel RICH (fwd) Beryllium beam pipe 2cm diameter Vertex Detector 2 layers DEPFET + 4 layers DSSD positrons (4GeV) Central Drift Chamber He(50%):C 2 H 6 (50%), small cells, long lever arm, fast electronics Peter Križan, Ljubljana

  32. Identification of charged particles Particles are identified by their mass or by the way they interact. Determination of mass: from the relation between momentum and velocity, p=  mv. Momentum known (radius of curvature in magnetic field)  Measure velocity: time of flight ionisation losses dE/dx Cherenkov angle transition radiation Mainly used for the identification of hadrons. Identification through interaction: electrons and muons Peter Križan, Ljubljana

  33. Reminder: where do we need identification?  + Fully reconstruct decay Fully reconstruct decay  - B 0 or B or B 0 J/  J/ to CP eigenstate to CP eigenstate  - B CP CP Υ (4s) (4s) Tag flavor Tag flavor  + K s l - of other B of other B K - from from B tag tag  t= t=  z/ z/  c charges charges determined determined of typical of typical B 0 (B (B 0 ) decay decay Determine time between decays Determine time between decays products products Peter Križan, Ljubljana

  34. Requirements: Particle Identification Peter Križan, Ljubljana

  35. PID coverage of kaon/pion spectra Peter Križan, Ljubljana

  36. PID coverage of kaon/pion spectra Peter Križan, Ljubljana

  37. Identification with the dE/dx measurement dE/dx is a function of velocity  For particles with different mass the Bethe-Bloch curve gets displaced if plotted as a function of p For good separation: resolution should be ~5% Peter Križan, Ljubljana

  38. Identification with dE/dx measurement Problem: long tails (Landau distribution, not Gaussian) of a single measurement (one drift chamber cell) Measure in each of the 50 drift chamber layers – use truncated mean (discard 30% largest values – from the tail). Peter Križan, Ljubljana

  39. Identification with dE/dx measurement Optimisation of the counter: length L, number of samples N, resolution (FWHM) If the distribution of individual measurements were Gaussian, only the total detector length L would be relevant. Tails: eliminate the largest 30% values  the optimum depends also on the number of samples. At about 1m path length: optimal number of samples: 50 FWHM: full width at half maximum = 2.35 sigma for a Gaussian distribution Peter Križan, Ljubljana

  40. Cherenkov detectors Endcap PID: Aerogel RICH (ARICH) 200mm Barrel PID: Time of Propagation Counter (TOP) Quartz radiator Aerogel radiator Focusing mirror Small expansion block n~1.05 Hamamatsu HAPD Hamamatsu MCP-PMT (measure t, x and y) + new ASIC Aerogel radiator Hamamatsu HAPD + readout 200 Peter Križan, Ljubljana

  41. Cherenkov radiation A charged track with velocity v=  c exceeding the speed of light c/n in a medium with refractive index n emits polarized light at a characteristic (Cherenkov) angle, cos  = c/nv = 1  n Two cases:   <  t = 1/n: below threshold no Cherenkov light is emitted.   >  t : the number of Cherenkov photons emitted over unit photon energy E=h  in a radiator of length L :  dN        2 1 1 2 sin 370 ( ) ( ) sin L cm eV L dE c  Few detected photons Peter Križan, Ljubljana

  42. Measuring the Cherenkov angle Idea: transform the direction into a coordinate  ring on the detection plane  Ring Imaging Cherenkov (RICH) counter Proximity focusing RICH RICH with a focusing mirror Peter Križan, Ljubljana

  43. Measuring Cherenkov angle Radiator: aerogel, n=1.06  K p  K p thresholds Peter Križan, Ljubljana

  44. Measuring Cherenkov angle Radiator:  quartz, n=1.46  K p K p  K p thresholds Peter Križan, Ljubljana

  45. Efficiency and purity in particle identification Efficiency and purity are tightly coupled! Two examples: particle type 1 type 2 eff. vs fake probability any discriminating variable, e.g. Cherenkov angle Peter Križan, Ljubljana

  46. Measuring Cherenkov angle Radiator:  quartz, n=1.06  K p K/  overlap K p P max for K/  separation P min for K/  separation Peter Križan, Ljubljana

  47. Aerogel RICH (endcap PID): larger particle momenta Test Beam setup Aerogel Clear Cherenkov image observed Cherenkov angle distribution Hamamatsu HAPD RICH with a novel “focusing” radiator – a two layer radiator Employ multiple layers with different refractive indices  6.6 σ  /K at 4GeV/c ! Cherenkov images from individual layers overlap on the Peter Križan, Ljubljana photon detector.

  48. Radiator with multiple refractive indices How to increase the number of photons without degrading the resolution?  stack two tiles with different refractive indices: normal “focusing” configuration n 1 = n 2 n 1 < n 2  focusing radiator Such a configuration is only possible with aerogel (a form of Si x O y ) Peter Križan, Ljubljana – material with a tunable refractive index between 1.01 and 1.13.

  49. Focusing configuration – data Increases the number of photons without degrading the resolution 4cm aerogel single index 2+2cm aerogel  NIM A548 (2005) 383 Peter Križan, Ljubljana

  50. Cherenkov detectors Endcap PID: Aerogel RICH (ARICH) 200mm Barrel PID: Time of Propagation Counter (TOP) Quartz radiator Aerogel radiator Focusing mirror Small expansion block n~1.05 Hamamatsu HAPD Hamamatsu MCP-PMT (measure t, x and y) + new ASIC Aerogel radiator Hamamatsu HAPD + readout 200 Peter Križan, Ljubljana

  51. DIRC (@BaBar) - detector of internally reflected Cherenkov light e + Support tube (Al) e - Quartz Barbox Compensating coil Assembly flange Standoff box Peter Križan, Ljubljana

  52. Belle II Barrel PID: Time of propagation (TOP) counter y ~400mm Quartz radiator Linear-array type z x photon detector 20mm L X • Cherenkov ring imaging with precise time measurement. • Device uses internal reflection of Cerenkov ring images from quartz like the BaBar DIRC. • Reconstruct Cherenkov angle from two hit coordinates and the time of propagation of the photon – Quartz radiator (2cm) – Photon detector (MCP-PMT) • Excellent time resolution ~ 40 ps • Single photon sensitivity in 1.5 Peter Križan, Ljubljana

  53. TOP image Pattern in the coordinate-time space (‘ring’) of a pion hitting a quartz bar with ~80 MAPMT channels Time distribution of signals recorded by one of the PMT channels: different for  and K (~shifted in time) Peter Križan, Ljubljana

  54. Muon (and K L ) detector Separate muons from hadrons (pions and kaons): exploit the fact that muons interact only e.m., while hadrons interact strongly  need a few interaction lengths (about 10x radiation length in iron, 20x in CsI) Detect K L interaction (cluster): again need a few interaction lengths.  Put the detector outside the magnet coil, and integrate into the return yoke Some numbers: 3.9 interaction lengths (iron) + 0.8 interaction length (CsI) Interaction length: iron 132 g/cm 2 , CsI 167 g/cm 2 (dE/dx) min : iron 1.45 MeV/(g/cm 2 ), CsI 1.24 MeV/(g/cm 2 )   E min = (0.36+0.11) GeV = 0.47 GeV  identification of muons above ~600 MeV Peter Križan, Ljubljana

  55. Muon and K L detector Example: event with • two muons and a • K L and a pion that partly penetrated Peter Križan, Ljubljana

  56. Muon and K L detector performance Muon identification >800 MeV/c efficiency fake probability   Peter Križan, Ljubljana

  57. Muon and K L detector performance K L detection: resolution in direction  K L detection: also with possible with electromagnetic calorimeter (0.8 interactin lengths) Peter Križan, Ljubljana

  58. Belle II, detection of muons and K L s: Parts of the present RPC system have to be replaced to handle higher backgrounds Belle II Detector (mainly from neutrons). K L and muon detector: Resistive Plate Counter (barrel) Scintillator + WLSF + MPPC (end-caps + barrel 2 inner layers) hv  Depletion Region 2  m Substrate U bias Peter Križan, Ljubljana

  59. Muon detection system upgrade in the endcaps Scintillator-based KLM (endcap and two layers in the barrel part) • Two independent (x and y) layers in one superlayer made of orthogonal strips with WLS read out • Photo-detector = avalanche photodiode in Geiger mode (SiPM) • ~120 strips in one 90º sector (max L=280cm, w=25mm) y-strip plane • ~30000 read out channels • Geometrical acceptance > 99% Iron plate x-strip plane Mirror 3M (above groove & at fiber end) Optical glue increases the Aluminium frame light yield by ~ 1.2-1.4) WLS: Kurarai Y11  1.2 mm GAPD Strips: polystyrene with 1.5% PTP & 0.01% POPOP Diffusion reflector (TiO 2 )  Peter Križan, Ljubljana 2008/2/28 Toru Iijima, INSTR08 @ BINP, Novosibirsk 78

  60. Calorimetry in Belle II KL and muon detector: Resistive Plate Counter (barrel outer layers) Scintillator + WLSF + MPPC (end-caps , inner 2 barrel layers) EM Calorimeter: CsI(Tl), waveform sampling (barrel) Pure CsI + waveform sampling (end-caps) Particle Identification Time-of-Propagation counter (barrel) electrons (7GeV) Prox. focusing Aerogel RICH (fwd) Beryllium beam pipe 2cm diameter Vertex Detector 2 layers DEPFET + 4 layers DSSD positrons (4GeV) Central Drift Chamber He(50%):C 2 H 6 (50%), small cells, long lever arm, fast electronics Peter Križan, Ljubljana

  61. Requirements: Photons   Peter Križan, Ljubljana

  62. Requirements: Photons     Need to reconstruct neutral pions from gamma pairs Also gammas (photons) with low energy • Excellent energy resolution • Detection of photons: scintillator crystal + photosensor scintillation photons are detected in the photo sensor shower, electrons gamma ray and positrons produce scintillation light Peter Križan, Ljubljana

  63.  Calorimeter size depends only logarithmically on E 0 Peter Križan, Ljubljana

  64. Detailed model: ˝Rossi aproximaton B˝ Determined mainly by multiple scattering of shower particles Peter Križan, Ljubljana

  65. Peter Križan, Ljubljana

  66. Requirements: Photons     Need to reconstruct neutral pions from gamma pairs Also gammas (photons) with low energy • Excellent energy resolution • Detection of photons: scintillator crystal + photosensor scintillation photons are detected in the photo sensor shower, electrons gamma ray and positrons produce scintillation light Need: High light yield (many scintillation photons)   (E)/E  N -1/2 • photo-sensor with low noise (noise spoils resolution) • Peter Križan, Ljubljana

  67. Peter Križan, Ljubljana

  68. Calorimeter with CsI(Tl) crystals Doping with tallium improves the light yield Peter Križan, Ljubljana

  69. B factories main result: CP violation in the B system CP violation in B system: from the discovery (2001) to a precision measurement B 0 tag sin2  1 /sin2  from b  ccs _ B 0 tag _ 535 M BB pairs Constraints from measurements of angles and sides of the unitarity triangle  Remarkable agreement Peter Križan, Ljubljana

  70. Unitarity triangle – 2011 vs 2001 CP violation in the B system: from the discovery (2001) to a precision measurement (2011). Peter Križan, Ljubljana

  71. KM’s bold idea verified by experiment Relations between parameters as expected in the Standard model  Nobel prize 2008!  With essential experimental confirmations by BaBar and Belle! (explicitly noted in the Nobel Prize citation) Peter Križan, Ljubljana

  72. B factories: a success story • Measurements of CKM matrix elements and angles of the unitarity triangle • Observation of direct CP violation in B decays • Measurements of rare decay modes (e.g., B   , D  ) • b  s transitions: probe for new sources of CPV and constraints from the b  s  branching fraction • Forward-backward asymmetry (A FB ) in b  sl + l - has become a powerfull tool to search for physics beyond SM. • Observation of D mixing • Searches for rare  decays • Observation of new hadrons Peter Križan, Ljubljana

  73. More slides... Peter Križan, Ljubljana

  74. Additional literature Slides EFJOD (http://www-f9.ijs.si/~krizan/sola/efjod/slides/) • Calorimetry • Particle identification Peter Križan, Ljubljana

  75. Systematic studies of B mesons: at  (4s) Peter Križan, Ljubljana

  76. Systematic studies of B mesons at  (4s) 80s-90s: two very successful experiments: •ARGUS at DORIS (DESY) •CLEO at CESR (Cornell) Magnetic spectrometers at e + e - colliders (5.3GeV+5.3GeV beams) Large solid angle, excellent tracking and good particle identification (TOF, dE/dx, EM calorimeter, muon chambers). Peter Križan, Ljubljana

  77. Mixing in the B 0 system 1987: ARGUS discovers BB mixing: B 0 turns into anti-B 0 Reconstructed event cited >1000 times. Time-integrated mixing rate: 25 like sign, 270 opposite sign dilepton events Integrated Y(4S) luminosity 1983-87: 103 pb -1 ~110,000 B pairs Peter Križan, Ljubljana

  78. Mixing in the B 0 system Large mixing rate  high top mass (in the Standard Model) The top quark has only been discovered seven years later! Peter Križan, Ljubljana

  79. Time evolution in the B system An arbitrary linear combination of the neutral B-meson flavor eigenstates  0 0 a B b B is governed by a time-dependent Schroedinger equation       a a a d i           ( ) i H M       2       dt b b b M and  are 2x2 Hermitian matrices. CPT invariance  H 11 =H 22       M M 12 ,        12 M     diagonalize    * *     M M 12 12 Peter Križan, Ljubljana

  80. Time evolution in the B system The light B L and heavy B H mass eigenstates with   eigenvalues are given by , , , m m H H L L   0 0 B p B q B L   0 0 B p B q B H With the eigenvalue differences         , m m m B H L B H L They are determined from the M and  matrix elements 1 1 2 2       2 2 ( ) ( ) 4 ( ) m M 12 12 B B 4 4 *     4 Re( ) m M 12 12 B B Peter Križan, Ljubljana

  81. The ratio p/q is i i * *      2 ( ) m M 12 12 q B B 2 2     i i p      2 ( ) M m 12 12 B B 2 2 What do we know about  m B and  B ?  m B =(0.502+-0.007) ps -1 well measured   m B /  B = x d =0.771+-0.012  B /  B not measured, expected O(0.01), due to decays common to B and anti-B - O(0.001).   B <<  m B Peter Križan, Ljubljana
