Automated Reasoning Model Checking with SPIN (II) Alan Bundy Automated Reasoning SPIN (II) page 1 Verifying Global Properties Assertions can be used to verify a property locally locally For example, place assert(MemReturned) at the

slide-1
SLIDE 1

Automated Reasoning page 1 SPIN (II)

Automated Reasoning Model Checking with SPIN (II)

Alan Bundy

slide-2
SLIDE 2

Automated Reasoning page 2 SPIN (II)

Verifying Global Properties

  • Assertions can be used to verify a property locally

locally

– For example, place assert(MemReturned) at the end of

the process to verify that the requested memory has been returned before the process ends

  • Some properties depend on non-local behaviour

non-local behaviour of the model

– For example, that the system never enters illegal states – or that it eventually enters the desired state

  • Assertions alone are not

not sufficient for verifying these properties

  • A more powerful method is to use “never claims”
slide-3
SLIDE 3

Automated Reasoning page 3 SPIN (II)

Never Claims

  • Roughly, never claims are used to specify system behaviour

which should never occur

  • In Promela, a never claim can be declared by

never { ... <Promela code> ... }

  • When generating a verifier, Spin creates one (active)

process for the never claim declared

  • Verifier executes the never-claim process between every

execution of other processes

  • Verifier reports error if the never-claim process ends
slide-4
SLIDE 4

Automated Reasoning page 4 SPIN (II)

Promela's goto Statement

  • We might need to write loops in never claims. The simplest way is

to use goto statement

  • Labels mark locations in

the code (Note: a location can have more than one label)

  • skip means “do nothing”

(usually needed because code cannot end with a label)

  • goto statements redirect program execution to a labelled location

in the code.

  • So this code loops through label_1 as long as p is false

– Where p is the property that is never meant to become true.

label_1: if :: p -> goto label_2 :: else -> goto label_1 fi; label_2: skip

slide-5
SLIDE 5

Automated Reasoning page 5 SPIN (II)

do :: guard -> statement; :: guard -> statement;

  • d;

Promela's do Loop

The do command is another way to write loops in Promela:

  • The guards function as in an if statement:
  • ne statement whose guard is true will be executed
  • But unlike if statements, the do body repeats
  • The do loop ends only if a break statement is reached

(or if a goto statement is used) do :: p -> break; :: else -> skip;

  • d;
slide-6
SLIDE 6

Automated Reasoning page 6 SPIN (II)

Fred's Drinks Revisited

mtype = { milk, lemonade, water }; bool bought_milk = false, bought_lemonade = false, bought_water = false; int num_drinks = 0; inline buy_item(a_drink, bought_a_drink) { (item==a_drink) -> bought_a_drink = true; } proctype perhaps_buy(mtype item) { atomic { bool bought_something = true; if :: buy_item(milk, bought_milk); :: buy_item(lemonade, bought_lemonade); :: buy_item(water, bought_water); :: true -> bought_something = false; fi; if /* output what Fred bought, if anything */ :: bought_something -> printf("FRED BOUGHT "); num_drinks++; :: else -> printf("FRED DID NOT BUY "); fi; printm(item);printf("\n"); } }

Note: num_drinks is now only incremented when Fred buys something. (This differs from previously)

slide-7
SLIDE 7

Automated Reasoning page 7 SPIN (II)

Fred's Drinks Revisited II

  • As an example, in Fred's Drinks model, never claims can

be used to verify that Fred can never buy more than two kinds of drinks

  • Desired behaviour: in all runs, num_drinks≤2 at all

times, i.e. in all runs □(num_drinks≤2)

  • Forbidden behaviour: in some run, num_drinks>2 at

some time, i.e. in some run

(num_drinks>2)

slide-8
SLIDE 8

Automated Reasoning page 8 SPIN (II)

Fred's Drinks Revisited III

  • Never claim for this property can be declared as follows:
  • do-loop exits and error is flagged whenever num_drinks

becomes greater than 2

never { /* <>(num_drinks>2) */ do :: ((num_drinks>2)) -> break; :: else -> skip

  • d

}

FredsNeverClaim

slide-9
SLIDE 9

Automated Reasoning page 9 SPIN (II)

% spin -a -N FredsNeverClaim FredsDrinks # build a verifier % cc -o pan pan.c # compile the verifier % ./pan -e # run, looking for errors pan: claim violated! (at depth 20) pan: wrote FredsDrinks1.trail % ./pan -r1 # examine the error ... FRED BOUGHT milk ... ... FRED BOUGHT lemonade ... ... FRED BOUGHT water ... 20: proc 0 (:never:) line 71 (state 8)

  • end- ...

Verifying a Never Claim

  • Run spin -a -N <NeverClaimFile> <ModelFile> to generate

a verifier

  • As expected, there's an error trail!
  • If the condition is changed to num_drinks>3, the verifier will

produce no errors

slide-10
SLIDE 10

Automated Reasoning page 10 SPIN (II)

Using LTL with Spin

  • Spin can generate a never claim from the given LTL formula

automatically

  • Run spin -f '<LTLFormula>'.
  • Spin's LTL syntax
  • Can use Promela variables or #defined symbols as propositions

[] always (□) <> eventually () X next (X) ! logical negation (¬) U strong until (U) && logical and (∧) || logical or (∨)

  • >

logical implication (⇒) <->logical equivalence (⇔)

slide-11
SLIDE 11

Automated Reasoning page 11 SPIN (II)

Using LTL with Spin (cont)

  • Example:

% spin -f '<>p' never { /* <>p */ T0_init: if :: ((p)) -> goto accept_all :: (1) -> goto T0_init fi; accept_all: skip }

#define p (num_drinks>2)

  • Need to add definition for p separately, e.g.
slide-12
SLIDE 12

Automated Reasoning page 12 SPIN (II)

The Bank Machine Revisited

Model checking is often used to model dynamic systems, such as the bank machine from lecture 9: We will represent this in Promela, using labels and goto, and then we will explore more complicated LTL claims.

Welcome card inserted Thanks, Goodbye cancel - card out Sorry wrong correct problem - card out sufficient funds - cash and card out Enter PIN Try again ack Amount?

slide-13
SLIDE 13

Automated Reasoning page 13 SPIN (II)

Bank Machine Promela Model

mtype = {S_Welcome, S_Enter_Pin, S_Try_Again, S_Amount, S_Thanks_Goodbye, S_Sorry} mtype state inline setState(x) { atomic { state = x; ... } } active proctype BankMachineModel() { s_welcome: setState(S_Welcome); printf("BANK [card inserted]\n"); s_enter_pin: setState(S_Enter_Pin); if :: true -> { printf("BANK [wrong pin]\n"); goto s_try_again; } :: true -> { printf("BANK [correct pin]\n"); goto s_amount; } :: true -> { printf("BANK [cancel]\n"); goto s_thanks_goodbye; } fi; s_try_again: setState(S_Try_Again); goto s_enter_pin; s_amount: .... end: skip; }

Labels correspond to states in our Bank Machine automaton. The description of current state is recorded in a global variable state (for display). Notice the non- deterministic choices in if-block

BankMachine

slide-14
SLIDE 14

Automated Reasoning page 14 SPIN (II)

Bank Machine Runs

Welcome card inserted Thanks, Goodbye cancel - card out Sorry wrong correct problem - card out sufficient funds - cash and card out Enter PIN Try again ack Amount?

BankMachine promela code

% spin BankMachine BANK state is: S_Welcome BANK [card inserted] BANK state is: S_Enter_Pin BANK [wrong pin] BANK state is: S_Try_Again BANK state is: S_Enter_Pin BANK [correct pin] BANK state is: S_Amount BANK [sufficient funds] BANK state is: S_Thanks_Goodbye % spin BankMachine BANK state is: S_Welcome BANK [card inserted] BANK state is: S_Enter_Pin BANK [cancel] BANK state is: S_Thanks_Goodbye % spin BankMachine BANK state is: S_Welcome BANK [card inserted] BANK state is: S_Enter_Pin BANK [correct pin] BANK state is: S_Amount BANK [problem] BANK state is: S_Sorry

slide-15
SLIDE 15

Automated Reasoning page 15 SPIN (II)

Verifying Bank Machine

  • Desired behaviour: all runs eventually reach

S_Thanks_Goodbye or S_Sorry, i.e. all runs satisfies (state==S_Thanks_Goodbye ∨ state==S_Sorry)

  • Forbidden behaviour: some run remains in other states,

i.e. some run satisfies □( state!=S_Thanks_Goodbye ∧ state!=S_Sorry)

  • We cannot tell that a run is forbidden from any (initial) finite
  • portion. (Something unexpected might happen after that!)

Welcome, EP, TA, EP, TA,..., EP, Thanks_Goodbye n

slide-16
SLIDE 16

Automated Reasoning page 16 SPIN (II)

Accept Cycles

  • Can we write a never claim for this behaviour? Yes, but

needs new error detection technique: accept cycles

  • Accept labels: labels that begin with accept.

e.g. accept, accept1, accept_all, accepting , ...

  • Verifier flags errors if there is a run containing a cycle

which goes through a location with an accept label

  • Such a run goes through an accept label infinitely often
  • Accept labels are normally used in never-claim blocks
slide-17
SLIDE 17

Automated Reasoning page 17 SPIN (II)

Verifying Bank Machine (II)

  • Define p and q and run

spin -f '[] ((!p) && (!q))' to generate never claim

  • Run verifier using pan -e -a to

detect accept cycles

  • Verifier finds a problematic infinite run where

the wrong pin is entered over and over again!

% spin -a -N BankMachineNever1 BankMachine % cc -o pan pan.c % ./pan -e -a ... pan: acceptance cycle (at depth 4) pan: wrote BankMachine1.trail ... errors: 1 ... % ./pan -r1 ... BANK state is: S_Welcome ... BANK [card inserted] ... BANK state is: S_Enter_Pin ... <<<<<START OF CYCLE>>>>> ... BANK [wrong pin] ... BANK state is: S_Try_Again ... BANK state is: S_Enter_Pin ... #define p state==S_Thanks_Goodbye #define q state==S_Sorry never { /* [] (!p && !q) */ accept_init: T0_init: if :: (! ((p)) && ! ((q))) -> goto T0_init fi; }

BankMachineNever1

slide-18
SLIDE 18

Automated Reasoning page 18 SPIN (II)

Verifying Bank Machine (III)

  • At this stage, we can use the error trail(s) produced to

identify and correct bugs in the model

  • Let's consider a more complicated behaviour
  • Desired behaviour: If a run eventually never goes to

S_Try_Again, then it will either eventually always be in S_Thanks_Goodbye or it will eventually always be in S_Sorry. (□¬s_Try_Again) ⇒ (□s_Thanks_Goodbye) ∨(□s_Sorry)

Welcome card inserted Thanks, Goodbye cancel - card out Sorry wrong correct problem - card out sufficient funds - cash and card out Enter PIN Try again ack Amount?

slide-19
SLIDE 19

Automated Reasoning page 19 SPIN (II)

Verifying Bank Machine (IV)

  • Negate the LTL claim from the previous slide
  • Use spin -f to generate our never claim (above)
  • Create and run the

verifier (at right). No error trails found!

% spin -a -N BankMachineNever2 BankMachine % cc -o pan pan.c % ./pan -e -a ... errors: 0 ... #define s_Try_Again (state==S_Try_Again) ... never { /*!((<>[]!s_Try_Again)->(<>[]s_Thanks_Goodbye)|| (<>[]s_Sorry)) */ ... }

BankMachineNever2

slide-20
SLIDE 20

Automated Reasoning page 20 SPIN (II)

Spin accept-cycle detection

  • A few questions arise:
  • If a model does not have the desired property, is it always

the case that there will be an error trail which is either finite or eventually repeats in a cycle?

– Yes, provided that the desired property is specifiable in LTL

  • r using never claim (+ accept labels)

– Such an error trail is said to be regular (i.e. it is a path in a

finite graph)

– Examples:

  • Finite run:
  • Regular run:
  • Irregular run:

s0 s1 sn s2 ... s0 s1 s1 s2 ... s1 s2 s1 s2 s0 s1 s1 s2 ... s2 s1 s1 s1 s2 s1

slide-21
SLIDE 21

Automated Reasoning page 21 SPIN (II)

Spin accept-cycle detection II

  • Can Spin always find such an error trail? How?

– Yes. This is where automata theory comes in. Spin constructs a

Büchi automaton from the Promela model and the never

  • claim. Then determines if it has an accepting run.

– Use an algorithm that detects “accept cycles” (aka “bad

cycles”) in the automaton.

– Details in next lecture.

  • Follows from well-known results in automata theory:

1) If a Büchi automaton has an accepting run, then it must have a regular accepting run 2) There is an effective procedure to find such a regular accepting run

slide-22
SLIDE 22

Automated Reasoning page 22 SPIN (II)

Safety and Liveness Properties

Desired properties are often split into two categories:

  • Safety

– “Nothing bad ever happens” – Model checker searches for any possible execution that leads to a

violation of a safety property

– Example: system invariance (x never equals zero,

  • r Fred has never bought both milk and water)
  • Liveness

– “Something good eventually happens” – Model checker searches for any possible execution in which the “good

thing” can be postponed indefinitely

– Example: responsiveness (requests get responses),

closure (Fred eventually buys 3 drinks, or every bank machine session ends with Sorry or Thanks)

slide-23
SLIDE 23

Automated Reasoning page 23 SPIN (II)

Notes on Never Claims and LTL

  • Never claims (+ accept labels) are strictly more powerful

than LTL formulae

– Properties specifiable in LTL can be specified using never claims – but never claims can specify properties not specifiable in LTL

  • Code in never claims must be side-effect free; e.g. they are

not allowed to modify variables.

  • The LTL operator next (X) is confusing – it is usually better

to avoid it. (This is because if there are multiple processes, the next state will be a single step by any process, and X(p) means that p holds for all such immediately next states.)

slide-24
SLIDE 24

Automated Reasoning page 24 SPIN (II)

Correctness in Spin

We have seen several ways to specify correctness in Spin:

  • An assert statement specifies that a property holds at a

certain point in the execution of a process

  • Never claims describe behaviour that should never occur
  • Accept labels specify that certain cycles should never occur

Spin supports other techniques (see the Spin manual on-line):

  • End labels specify that all processes end in certain states
  • Progress labels specify that a model will never run forever

without passing through certain states infinitely often

  • Trace assertions specify that channels send or receive

certain types of data

slide-25
SLIDE 25

Automated Reasoning page 25 SPIN (II)

Summary

  • Loops in Promela (do and goto)
  • Verifying using never claims
  • Generating never claims from LTL formulae
  • Accept cycles
  • Safety and liveness properties
