Aureus Mining New Liberty Project Geology February 2014

Contents

2

• Location and Regional context
• Deposit geology
• Resources and Reserves
• Grade Control
• Underground potential
• Near-mine exploration potential

New Liberty: Established Infrastructure

3

Tarmac Road from Monrovia to Sierra Leone

• Daily European flights
• Three operating deep water ports
• New Liberty is 100km from the deep-water

commercial port at the capital, Monrovia

• Tarmac road from port of Monrovia to within

20km of site, laterite road the final 20km to site

4

Location Map and License Areas

New Liberty

5

Exploration Opportunities: 1,470km2 Licence Portfolio

New Liberty

6

New Liberty: Project History

7

New Liberty: Infrastructure Layout

8

New Liberty Exploration Camp and Pit Outline

Simplified Geology Showing Mineralisation

9

Section 17 Section 25

10

New Liberty: Sections Showing Mineralisation Zones and Grades

16m @ 4.43g/t

K342 K343 K347 K433 K492

9m @ 7.29g/t 28m @ 3.32g/t 21m @ 3.86g/t 4m @ 1.28g/t

11

New Liberty: Relationship Between Alteration & Gold Mineralisation

Mineralised zone (red) Magnetic depletion (grey) Pit outline

Host rock and Alteration Margin Signatures

Gold associated with low:

• Magnetic

susceptibility

• Sodium
• Potassium
• Rubidium

and high:

• silicification
• Sulphur
• Arsenic
• Tungsten

12

Margins of Phlogopite mica, Magnesium, Potassium, Sodium, Rubidium

Mineralogy

• Lower amphibolite grade (Tremolite-actinolite-hornblende-chlorite-

phlogopite) assemblages

• Pyrrhotite-arsenopyrite-gersdorffite
• Gold associated with silicates and sulphides
• Two gold populations: Coarse >10µm & Fine <10µm

Gold with pyrrhotite (PO), chalcopyrite (CP) and non-opaque minerals (NOP) Interstitial fine gold between silicate minerals 13

14

Evidence of Shearing

Above left: Breccias are common in the ultramafic unit, representing zones of shortening Left: Sheared clasts & mylonite in ultramafics Below: Highly sheared magnetite blebs in the ultramafic unit

14

New Liberty: Oblique View Showing Mineralisation and Pit Outline

Exploration camp West East

15

East West

16

New Liberty: Sections Showing Mineralisation Zones and Grades

Section 17 Section 25

0 – 0.8 0.8 – 2.0 2.0 – 4.0 > 4.0 Au g/t

Underground Potential

• Resource increased to:

– Measured: 651,000t at 4.8 g/t (for 100,000 ounces)1 – Indicated: 9,145,000t at 3.6 g/t (for 1,043,000 ounces)1 – Inferred: 5,730,000t at 3.2 g/t (for 593,000 ounces)1 – Total M & I: 1,143koz at 3.63g/t;

New Liberty: Resource and Reserves

17

1 Cut off grade = 1.0 g/t 2 Cut off grade = 0.8 g/t

Footwall Zone

2km 500m

Larjor Latiff Kinjor Marvoe

Reserve Classification Tonnes Gold (g/t) Gold (koz) Proven 700,000 4.4 99 Probable 7,800,000 3.3 825 Total Reserve2 8,500,000 3.4 924

Note 1: Reserve reported at a cut-off grade of 0.8g/t Au and ore grading between 0.8 & 1.0 g/t cut-off is stockpiled for processing towards the end of the mine life Note 2: A dilution skin of 0.5m added and minimum mining width of 2.5m applied Note 3: A gold price of US$ 1,300 was used for pit optimisation

West East

Aim

• Define mineralisation boundaries and minimise

dilution

• Define mining blocks

Prior to mining

• RC drill programme on 15x15m grid planned
• Drill 1 year’s production in advance, ~ 8,000m/ year
• Reconcile with orebody block model (based on a

30x30m grid)

• Establish detailed distribution of gold and incorporate

into mine planning

18

Grade Control

Production

• RC drilling in dry season advance of mining
• Sample blastholes (10m benches)
• In pit geological mapping – structures, bleaching, silicification, sulphides, mag sus.
• Reconciliation of grade control work with both orebody model and plant figures
• Marking out of grade blocks (minimum mining width of 2.5m)
• Blast design to separate waste from ore
• Selective mining - 2.5m flitches on 10m benches
• Blending on ROM pad near crusher to ensure steady feed to plant
• High, Medium & Low grade stockpiles and Mineralised waste

19

Grade Control

Exploration - Additional potential below the pit

20

Upside from upgrading Inferred resources and underground potential

• Potential to add to current reserve, with minimal infill drilling
• Hanging wall Inferred resource within pit
• Additional Inferred resources just below base of current
• ptimised pit
• Ore body is open at depth, with underground potential

2km E W

New Liberty Underground Potential (West – East)

21

22

Geophysics – New Liberty Exploration Targets

Reduced to Pole Aeromagnetics

Ground IP TMI

New Liberty near mine exploration

23

¹

• Regolith and fact geology mapping to produce near mine map
• Re-interpretation of soil geochemistry and geophysics anomalies
• Prospect scale mapping and data integration
• West Mafa target mapping and pitting

5 km New Liberty W Mafa Jikando (A) Jawaje (C) Diversion (B)

BEA Mountain ML

Western Extension

New Liberty near mine exploration

Regolith understanding key for geochem interpretation

• Concealed orebodies
• Upper saprolite leaching

Regime change W of Mafa River Mapping currently ongoing New Liberty

Relict regime with extensive depositional material

West Mafa gold anomaly

25

1.3 km 450m New Liberty 6km

Artisanal workings

West Mafa

• New find, 6km west of New Liberty
• 1.3km long, 450m wide gold in soil anomaly
• Mineralisation associated with veins and

shearing in gneisses and amphibolites

• Minor artisanal workings
• Bulk of area is soil covered – outcrop is
• poor. Geological mapping is in progress

Near Mine exploration

26

Summary

• Clearly defined orebody with >2km continuous

mineralisation

• High grade deposit with both coarse and fine free

gold

• Strong association of gold mineralisation with

geological alteration features and clear geophysical and geochemical signatures

• Robust mineralisation model consistent with geology
• Grade improves with depth - good underground

potential

• Considerable potential for additional resources below

and around the pit as well as in nearby prospects.

27

Panned gold from weathered Fe rich soils at New Liberty Close up of gold nugget from New Liberty

Thank you
