Asynchronous Logging and Fast Recovery for a Large-Scale Distributed In-Memory Storage

Kevin Beineke, Florian Klein, Michael Schöttner Institut für Informatik, Heinrich-Heine-Universität Düsseldorf

Outline

• Motivation
• The In-Memory Storage DXRAM
• Asynchronous Logging
• Fast Recovery
• Reorganization
• Conclusion

Motivation

• Large-scale interactive applications and online graph

computations:

• Billions of small data objects
• Dynamically expanding
• Read accesses dominate over write accesses
• Short latency required
• Example: Facebook
• More than one billion users
• More than 150 TB of data (2011)
• 70% of all data objects are smaller than 64 byte (2011)

26.September 2014

1/13

Traditional databases are at their limits

Motivation

• Common approach to meet discussed requirements: RAM-Caches
• Must be synchronized with secondary storage
• Refilling after failure very time consuming (Facebook outage 2011 -> 2,5h)
• Cache misses are expensive
• Another approach: Keeping all object always in RAM
• RAMCloud:
• Table-based data model
• 64 bit global ID-mapping via Hashtable
• Log-structured memory design
• Optimized for large files

26.September 2014

2/13

The In-Memory Storage DXRAM

26.September 2014

The In-Memory Storage DXRAM Overview

• DXRAM is a distributed in-memory system:
• Optimized to handle billions of small
• bjects
• Key-value data model with name service
• Transparent backup to SSD(HDD)
• Core Services:
• For management, storage and transfer of

key-value tuples (chunks)

• Minimal interface
• Extended Data Services:
• General services and extended data models

26.September 2014

3/13

The In-Memory Storage DXRAM

Chunks

26.September 2014

4/13

• Variable sizes
• Every chunk is initially stored on the creator, but can be migrated (hot spots)
• Every chunk has a 64 bit globally unique chunk ID (CID)
• First 16 bit: NodeID of the creator node
• Last 48 bit: Locally unique sequential ID
• Impact:
• Locality: Chunks that are created at the same location adjacent in time have similar CIDs
• Initial location is stored in CID:
• No lookup needed if chunks was not migrated
• After migration: New location must be stored elsewhere
• Applications cannot specify own IDs

LocalID NID CID

• Migrated CIDs are stored in ranges in a b-tree on dedicated nodes
• No entry -> chunk is still stored on creator
• Support for user-defined keys:
• Name service with a patricia-trie structure

26.September 2014

5/13

• Fast node lookup with a custom Chord-like super-

peer overlay

• 8 to 10% of all nodes are super-peers
• Super-peers do not store data but meta-data
• Meta-data is replicated on successors
• Every super-peer knows every other super-peer ->

Lookup with constant time complexity O(1)

• Every peer is assigned to one super-peer
• Fast node recovery
• Super-peers also store backup locations
• Distributed failure detection
• Super-peer coordinated recovery with multiple peers

The In-Memory Storage DXRAM

Global meta-data management

Asynchronous Logging

26.September 2014

Asynchronous Logging

SSD Utilization

• Characteristics of SSDs:
• SSDs write at least one page (4KB), pages are clustered to be accessed in

parallel

• SSDs cannot overwrite a single flash page, but delete a block (64 to 128

pages) and write on another

• It is faster to write sequentially than randomly on SSD
• Mixing write and read accesses slows the SSD down
• Life span: Limited number of program-erase cycles
• Consequences:
• Buffer write accesses
• Use a log to avoid deletions and to write sequentially
• Only read the log during recovery

26.September 2014

6/13

• Two-level log organization: One primary log and one secondary log

for every node requesting backups

• Idea: Store incoming backup requests as soon as possible on SSD to avoid

data loss and at the same time write as much as possible at once

• No need to store meta-data in RAM, because every entry is self describing

Secondary Log 1

Asynchronous Logging

Architecture

26.September 2014

7/13

Backup Requests

Buffer Write

Time-Out / Threshold

Primary Log Secondary Log 1 Secondary Log 1

Sort by NID

Asynchronous Logging

Architecture

26.September 2014

8/13

Backup Requests

Buffer Write

X Producer Network Threads 1 Consumer Writer Thread

RAM SSD

Primary Log Time-Out / Threshold

Write buffer:

• The write buffer stores chunks from potentially

every node: Is filled frequently

• Bundles backup requests (4KB)
• Decouples network threads (sync possible)
• Parallel access to write buffer

Writer thread:

• Flushes write buffer to primary log after time-out
• r (e.g. 0.5s) if threshold is reached (e.g. 16MB)
• Two bucket approach

Problem:

• To recover all data from one node the whole

primary log must be processed

Asynchronous Logging

Architecture

26.September 2014

9/13

Backup Requests

Buffer Write

RAM SSD

Time-Out / Threshold

Primary Log Secondary Log 1 Secondary Log 2 Secondary Log X ... Sec.Log Buffer 1 Sec.Log Buffer 2 ... Sec.Log Buffer X

Asynchronous Logging

Optimizations

• The write buffer is sorted by NID before writing to SSD
• If there is more than 4KB for one node, the data is written directly to the

corresponding secondary log

• Method: Combination of hashing and monitoring
• Clearing the primary log:
• Flush all secondary log buffers
• Set read pointer to write pointer

26.September 2014

10/13

Fast Recovery

26.September 2014

Fast Recovery

• Super-peer overlay:
• Fast and distributed failure detection (hierarchical heart beat protocol)
• Coordinated and purposeful peer recovery (super-peer knows all

corresponding backup locations)

• Recovery modes:

1. Every contacted peer recovers chunks locally (fastest, no data transfer) 2. All chunks are recovered and sent to one peer (1:1) 3. All chunks are recovered and sent to several peers (faster, but less locality, used by RAMCloud) 4. 1 and 2 combined: Recover locally and rebuild failed peer gradually

26.September 2014

11/13

Reorganization

26.September 2014

Reorganization

• Write buffers and primary log are cleared periodically
• Secondary logs are contiguously filled
• To free space of deleted or outdated entries the secondary logs have to be

reorganized

• Every peer reorganizes his logs independently
• Demands:
• Space-efficiency
• As little disruptive as possible
• Incremental operation to guarantee fast recovery
• Idea (inspired by LSF):
• Divide log into segments with fixed size
• Reorganize one segment after another
• Distinguish segments by access frequency (hot and cold zones)
• Decide which segment to reorganize by cost benefit ratio

26.September 2014

12/13

Conclusion

• Current status:
• DXRAM memory management tested on cluster with more than 5 billion objects
• Small object processing faster than RAMCloud
• Multithread buffer implemented and examined under worst-case scenario
• Logs fully functional with less complex reorganization scheme
• Node failure detection and initialization of recovery process tested
• Outlook:
• Implementation of LSF-like reorganization scheme with adapted cost-benefit

formula

• Replica placement (Copysets)
• Evaluation of complete recovery process

26.September 2014

13/13

Backup Slides

26.September 2014

The In-Memory Storage DXRAM

26.September 2014

14/13

In-memory data management

• Paging-like translation to local addresses

instead of hast table

• Space-efficient and fast
• Minimized internal fragmentation
• Small overhead: Only 7 bytes for chunks

smaller than 256 bytes
